為什麼要移植？（Why Cloning?）
- 因為我所使用的硬體設備都是又老又舊又慢，所選用的套件都是一件一件只安裝或編譯我自己所需要的，例如 LaTeX、gcc、mplayer、xv……，還有一大堆自己寫的程式，所以拿到剛到手的機器之後，不適合從頭開始安裝一個完整的 Linux 系統。
- 拿到一個空的機器，我只想要趕快能夠依之前的工作方式，繼續在上面做事情，不想要再從頭來過，做一大堆有的沒有的設定。
- Linux 系統的移植，我已經做過好幾次，每次都可以讓剛到手的舊機器迅速就範。就順便藉這次機器把它記錄下來，以供有需要的人參考。
本次手術檯上的機器
1. 使用中的 Toshiba Libretto U100（機器 A）
處理器：Intle Pentium M @ 1.10GHz
記憶體：1G 硬碟：60G
顯示器：7.2" WXGA 1280x768 (5:3, 206dpi)
作業系統：Debian Etch/Kernel 2.6.27.59
到手時間：2005-11-16（全新）
服役時間：2005-11-16 至今
2. 剛到手的 HP 2133 Mini-Note PC（機器 B）
處理器：VIA C7-M @ 1.6GHz
BIOS：v02.61 (C) Copyright 1985-2006, American Megatrends, Inc.
記憶體：2G 硬碟：120G
顯示器：8.9" WXGA 1280x768 (5:3, 167dpi)
作業系統：Windows XP
到手時間：2011-12-18（三手貨，內含一陽春的 XP/SP2）
服役時間：2011-12-24 至今（Debian Etch/Kernel 2.6.27.59）
3. 所需工具
- 開機工具：可以用來在新機器上開機的任何 Live 作業系統。我所用的是安裝在 50MB USB 隨身碟的 DSL-4.4.10 (Damn Small Linux)，它也有光碟版本，也可以選擇由 USB 光碟開機。這個系統必須含有 sshd 以及 rsync，讓我可以由舊機器把系統傳輸到新的機器。
- 連線工具：跳接的 RJ-45 網路線。因為傳輸的資料量龐大，不適合使用無線網路。另一方面也是因為，live 開機光碟上的系統很少能支援筆電上的無線網路卡。
移植手術過程
- 機器 B：以 DSL 或其他 live 光碟開機。在 HP2133 上，以 [F9] 鍵選擇由 USB 開機。開機順利，可是看不到機器裡面的硬碟，無法 mount，當然也無法安裝。於是關機，用 [F10] 鍵進 BIOS 設定，發現 BIOS 裡有 SATA 硬碟的選擇項 [Native] 跟 [Compatible]，設為 [Compatible] 之後，重新開機，DSL 就可以看到硬碟，也可以 mount。
- 機器 B：sshd 跟 password。在 DSL 上面，我先用 "sudo bash" 開啟一個具有 root 權限的工作視窗。再來是以
機器B: # /etc/init.d/ssh start
開啟 sshd 伺服程式，再用
機器B: # passwd
設定一個新的 root 密碼，以利接下來於遠端抄入檔案。
- 機器B：fdisk 跟 mkfs。機器到手時，XP 上有 C 槽跟 D 槽。在 DSL 上，C 槽是 /dev/hda1，D 槽是 /dev/hda2，我決定不需要 D 槽裡的東西（必要的時候也可以把它們先抄到 C 槽），所以用
機器B: # fdisk /dev/hda
進去後，用 'd' (delete) 指令把第二個 partition，也就是 D 槽移除。接下來是新增一個 4GB 的 swap partition（Id=82），其他空間則全部留給第三個 partition（Id=83），作為 Linux 的 boot 跟 root partition。再來就是要 initialize 這兩個 partitions：
機器B: # mkswap /dev/hda2
機器B: # mkfs.ext3 /dev/hda3
因為這是個 60G 的巨大 partition，最好用 jounaling，免得一出問題，開機時就要作老半天的 fsck。
- 機器 A & B：建立連線。接下來跳接網路線就派上用場了。現在要透過有線網路，把 U100 上的整個 Linux 系統「照抄」到 HP2133 的 /dev/hda3。在 U100 上，做
機器A: # ifconfig eth0 192.168.25.1 up
然後在 HP2133 上，則
機器B: # ifconfig eth0 192.168.25.2 up
機器B: # ping 192.168.25.1
就通了。
- 機器 B：mount 硬碟。通了之後，就必須在新機器 HP2133 上，把想要移植作業系統的標的 partition 先 mount 起來，在 DSL 上，它是 /dev/hda3。可以用
機器B: # fdisk -l /dev/hda
再檢視一次 partition table 的配置情形，以確定無誤。其中 hda1 是 XP 的 C 槽，hda2 是 swap partition，hda3 則是想要移植 Linux 作業系統的 partition。
Disk /dev/hda: 120.0 GB, 120034123776 bytes
255 heads, 63 sectors/track, 14593 cylinders
Units = cylinders of 16065 * 512 = 8225280 bytes
Device Boot Start End Blocks Id System
/dev/hda1 1 6375 51206054+ 7 HPFS/NTFS
Partition 1 does not end on cylinder boundary.
/dev/hda2 6375 6861 3904918+ 82 Linux swap / Solaris
/dev/hda3 * 6862 14593 62107290 83 Linux
接下來必須先把這個 partition mount 起來：
機器B: # mkdir /hda3
機器B: # mount -t ext3 /dev/hda3 /hda3
- 機器 B：建立空資料夾。在 HP2133 上，要在根目錄上面建立一些空的資料夾：
機器B: # mkdir /hda3/tmp
機器B: # chmod 1777 /hda3/tmp
機器B: # mkdir /hda3/mnt
機器B: # mkdir /hda3/proc
機器B: # mkdir /hda3/sys
- 機器 A & B：系統複製。接下來就是用 "rsync -avzuxH" 這個指令把系統由舊機器一個資料夾一個資料夾地抄到新機器來。在U100 上面，
機器A: # rsync -avzuxH /boot/ 192.169.25.2:/hda3/boot/
機器A: # rsync -avzuxH /dev/ 192.169.25.2:/hda3/dev/
機器A: # rsync -avzuxH /etc/ 192.169.25.2:/hda3/etc/
機器A: # rsync -avzuxH /sbin/ 192.169.25.2:/hda3/sbin/
機器A: # rsync -avzuxH /lib/ 192.169.25.2:/hda3/lib/
機器A: # rsync -avzuxH /bin/ 192.169.25.2:/hda3/bin/
機器A: # rsync -avzuxH /usr/ 192.169.25.2:/hda3/usr/
機器A: # rsync -avzuxH /root/ 192.169.25.2:/hda3/root/
機器A: # rsync -avzuxH /home/ 192.169.25.2:/hda3/home/
機器A: # rsync -avzuxH /var/ 192.169.25.2:/hda3/var/
在 這裡不能忘記真正的 target 是 mount 在 /hda3 之下，我自己也常常忘記。rsync 的這些參數可以確保所有的特殊檔案類型都會一模一樣地保留下來，包括 hard links、symbolic links、special files、device nodes，以及所有 permissions。再來就是要我那巨大的 /local/ 也抄過去：
機器A: # rsync -avzuxH /local/ 192.169.25.2:/hda3/local/
因為我把所有 Debian 以外的東西或個人的程式，全部都塞在這裡，要抄很久，所以放在最後。就這樣，整夜在半睡半醒的狀態中，一共透過網路線抄了將近 20GB。但是如果只是要 copy 系統本身的話，我估計大概不到 7GB，這很快就可以完成。
- 機器 B：修改檔案。抄完之後，先幫新的機器取個新的名字吧，因為有些檔案的設定需要用到 hostname。由於看到許多的使用者，不管三七二十一，也不管它的 performance 如何，就算是它的 CPU 效能不夠高，也可以因為它的金屬質感而原諒它，繼續深愛它，這種真情在 3C 市場還真是少見，所以我就把它叫做 "ferrum"（而 "ferrum" 就是拉丁文 "iron" 的意思）。
在機器 B 上必須修改的檔案包括：
/etc/hostname（換成新的機器名字）
/etc/hosts（"127.0.0.1 localhost" 那行我必須要加入新的機器名字 ）
/etc/fstab（在新的機器上有不同的 root 跟 swap partitions 必須修改）
/etc/lilo.conf（修改 root 跟 boot partitions）
/etc/modules（有少部分需要的 modules 必須聲明）
/etc/X11/xorg.conf（在這裡起碼必須修改顯示卡的 driver）
$HOME/.gtkrc-2.0（因為兩邊螢幕解析度不一樣，所以必須修改字體大小）
其他檔案我不需要修改，這是因為大多數設定都已將之盡量一般化，那就是盡量避免使用「常數」（這跟寫程式的原則是一樣的），所以許多設定檔是可以在我家不同的機器上面分享、套用。很有可能，讀者要修改更多的檔案。
修改完檔案系統之後，還需要修改的，就是 MBR。我習慣用 LILO，因此要執行
機器B: # lilo
（TODO: 這裡有一些 complications，包括 chroot、/proc/partitions、lilo -P fix 等。）
- 機器 B：umount 硬碟。接著在新機器上 umount 硬碟，然後關機，禱告一番，重新開機。通常移植手術就此完成，可以進入新系統修編一些因機器而異的細節。
- 機器B：移除不需要的套件。新機器開機之後，我就移除一些特別只為舊機器 Toshiba Libretto U100 所安裝的 Debian 套件：
機器B: $ sudo aptitude purge fnfxd # 這是只給 U100 使用的功能鍵 daemon
機器B: $ sudo aptitude purge 915resolution # VBIOS 顯示卡解析度矯正
至此移植手術順利完成。
以下為機器硬體跟 Linux 相容性的問題。
HP2133 Machine Dependent Issues
然而對於 HP2133 而言，我碰到了一個大問題。開機過程 panic，它找不到我的 /dev/hda3，螢幕上出現：
(......)
Using API Shortcut mode
input: AT Tanslated Set 2 keyboard as /clas/input/input0
VFS: Cannot open root device "303" or unknown-block(3,3)
Please append a correct "root=" boot option; here are the available partitions
Kernel panic - not syncing: VFS: Unable to mount root fs on unknown-block(3,3)
這是 kernel 2.6.27.59 的開機狀況。因為我機器上有許多的 kernel 版本，試過了 2.6.32.46、2.6.23.17，以及 Debian Lenny 安裝光碟上的 kernel 2.6.26-2-486，也得到同樣的結果。不知所措。最後決定選擇一個我覺得還有一些 bugs 的老 kernel，2.6.16.62。雖然這是一個 longterm 維護的 kernel，我對它的信任感還是不夠充分。但是居然順利開機。
- 這是與 HP2133 上的顯示卡有關的問題。開機之後，發現 X11 起不來。因為 Debian Echt 上面的 video driver，/usr/lib/xorg/modules/drivers/via_drv.so 不能用。我只好改用 vesa_drv.so。解析度可以達到最高的 native resolution 1280x768。只不過 xorg 裡 SubSection "Display" 內的 Modes 不可以包含 "1600x1200"，要不然，它雖然以 1280x768 的解析度開啟視窗介面，但是在幾何上發生錯誤，所以我的背景圖片位置不對。
- 功能鍵上面的兩個螢幕亮度鍵可用。功能鍵上的三個喇叭控制鍵不能用。所以我聲音很小，不能調整。可以說是聲音就不能用。
- 因為是 vesa driver，所以我沒有 Xv 以及 Direct Rendering。因此 mplayer 也等於是不堪用。
- 機器內建的 Broadcom 無線網卡它不認得。我插了 PCi Mini2 的 USB 無線網卡，還算堪用。
- 雖然 BIOS 顯示記憶體有 2G，但是在 Etch/2.6.16.62 下，不論是 top(1)、free(1)，還是 /proc/meminfo，都顯示只有 1G 的記憶體。猜測可能是我以前 compiled 的 kernel 因為都在非常老舊的電腦上面跑，所以還是 CONFIG_NOHIGHMEM=y。很可能必須改為 CONFIG_HIGHMEM4G=y。
- 結論：因為我用的是老舊的 kernel 2.6.16.62，以及老舊的 Debian Etch（/etc/debian_version: 4.0），整個機器可以說是還處於不堪用的狀態。（2011-12-21 ）
HP2133 開機問題的解決
日以繼夜被機器玩了幾天之後，於 2011-12-24 06:00，我慣用的 kernel 2.6.27.59 終於 boot 上來了。
開機時 kernel panic、不能 mount root 檔案系統的問題，我已經碰過了許多次。在某些舊機器上，至今始終無法得到解決。這種問題的原因很多也很複雜，而且跟快速發展中的每一個 kernel 版本息息相關。雖然 2.6.16.62 可以動，我對其 performance 以及可靠度相當不滿意，就連檔案系統裡資料的安全性，都令我非常憂心，而且因為 kernel 老舊，許多 drivers 不是沒有，就是問題很多。所以幾天來，我試圖解決的第一個問題，就是要讓較新且較穩定的 2.6.27.59 開上來，而不是在 2.6.16.62 上嘗試去解決各種問題。
為了解決這個開機問題，看遍了網路上幾乎所有的討論。不能 mount root filesystem 的原因何其多，這包括很值得一讀的 [1] 跟 [2] 裡面所提到的諸多情形。我也跟著試過了幾乎所有的可能性，這甚至於包括在 Lilo 的 boot command 加上幾個亂七八糟的字元，作為 kernel parameters，都徒勞無功。最後意外地發現，我以前 compiled 過的 2.6.23.17 居然突然可以開機，並沒未發生上述的
VFS: Cannot open root device "303" or unknown-block(3,3)
只不過這次是因為當時 EXT3_FS 並沒有 compiled 進 kernel，所以開機進去之後與 /etc/fstab 不符，而發生錯誤，kernel 就把 root filesystem remount 為 read-only，X 都起不來，因為連 /tmp/ 也不能寫。然而，由此可見光是缺乏 EXT3_FS 並不見得一定會造成開機時 Cannot open root fs，因為 ext2 子系統也可以讀取 ext3 檔案系統，只不過缺少了 journaling，所以才被 kernel remount 為 ro 以防不測。這是因為 /etc/fstab 裡面 root device 的 mount 選項 "errors=remount-ro"。我想，要是把這個選項去掉的話，系統還是可以運作，只是少了 journaling 的保障。
雖然 2.6.23.17 可以動，可是我還是不想在這個版本下工夫，也不想把它們的 config 檔拿來一行一行地比對，去猜到底是哪個環節出了問題，就決定把 config-2.6.23.17 拿來作為重新 compile 2.6.27.59 的基底。
# cd /usr/src/linux-2.6.27.59/
# make mrproper
# cp -p /boot/config-2.6.23.17 .config
# make oldconfig
在這個步驟必須要回答很多問題，我就盡量用預設值，除了預設為 N 但可設為 M 的，我就設為 M，讓它們 compile 成 kernel modules。接下來再以 menuconfig 手動設定幾個已知必要、但很可能不會影響大局的值，像是把 CONFIG_LOG_BUF_SHIFT 由 14 改為 16，這樣的話，我才可以用 dmesg 看到完整的 messages。此外，像是把 CONFIG_EXT3_FS 由 M 改為 Y，因為我現在的 root device 用的是 ext3 檔案系統。
# make menuconfig
# make bzImage && make modules && make modules_install
# install-bzImage 2.6.27.59
# lilo
其中 install-bzImage 是我自己寫的小小 shell-script，它是用來把 .config 檔、System.map 以及 bzImage 拷貝到 /boot/。其實就是
# cp -p .config /boot/config-2.6.27.59
# cp -p System.map /boot/System.map-2.6.27.59
# cp -p arch/i386/boot/bzImage /boot/vmlinuz-2.6.27.59
我並沒有用 initrd。
略過 compile 時的一些小問題不談，這個重新編譯的 kernel 2.6.27.59 就這樣開起來了。以下附上現在順利開機運作的 config-2.6.27.59：
#
# Automatically generated make config: don't edit
# Linux kernel version: 2.6.27.59
# Sat Dec 24 07:31:28 2011
#
# CONFIG_64BIT is not set
CONFIG_X86_32=y
# CONFIG_X86_64 is not set
CONFIG_X86=y
CONFIG_ARCH_DEFCONFIG="arch/x86/configs/i386_defconfig"
# CONFIG_GENERIC_LOCKBREAK is not set
CONFIG_GENERIC_TIME=y
CONFIG_GENERIC_CMOS_UPDATE=y
CONFIG_CLOCKSOURCE_WATCHDOG=y
CONFIG_GENERIC_CLOCKEVENTS=y
CONFIG_GENERIC_CLOCKEVENTS_BROADCAST=y
CONFIG_LOCKDEP_SUPPORT=y
CONFIG_STACKTRACE_SUPPORT=y
CONFIG_HAVE_LATENCYTOP_SUPPORT=y
CONFIG_FAST_CMPXCHG_LOCAL=y
CONFIG_MMU=y
CONFIG_ZONE_DMA=y
CONFIG_GENERIC_ISA_DMA=y
CONFIG_GENERIC_IOMAP=y
CONFIG_GENERIC_BUG=y
CONFIG_GENERIC_HWEIGHT=y
# CONFIG_GENERIC_GPIO is not set
CONFIG_ARCH_MAY_HAVE_PC_FDC=y
# CONFIG_RWSEM_GENERIC_SPINLOCK is not set
CONFIG_RWSEM_XCHGADD_ALGORITHM=y
# CONFIG_ARCH_HAS_ILOG2_U32 is not set
# CONFIG_ARCH_HAS_ILOG2_U64 is not set
CONFIG_ARCH_HAS_CPU_IDLE_WAIT=y
CONFIG_GENERIC_CALIBRATE_DELAY=y
# CONFIG_GENERIC_TIME_VSYSCALL is not set
CONFIG_ARCH_HAS_CPU_RELAX=y
CONFIG_ARCH_HAS_DEFAULT_IDLE=y
CONFIG_ARCH_HAS_CACHE_LINE_SIZE=y
# CONFIG_HAVE_SETUP_PER_CPU_AREA is not set
# CONFIG_HAVE_CPUMASK_OF_CPU_MAP is not set
CONFIG_ARCH_HIBERNATION_POSSIBLE=y
CONFIG_ARCH_SUSPEND_POSSIBLE=y
# CONFIG_ZONE_DMA32 is not set
CONFIG_ARCH_POPULATES_NODE_MAP=y
# CONFIG_AUDIT_ARCH is not set
CONFIG_ARCH_SUPPORTS_AOUT=y
CONFIG_ARCH_SUPPORTS_OPTIMIZED_INLINING=y
CONFIG_GENERIC_HARDIRQS=y
CONFIG_GENERIC_IRQ_PROBE=y
CONFIG_X86_BIOS_REBOOT=y
CONFIG_KTIME_SCALAR=y
CONFIG_DEFCONFIG_LIST="/lib/modules/$UNAME_RELEASE/.config"
#
# General setup
#
CONFIG_EXPERIMENTAL=y
CONFIG_BROKEN_ON_SMP=y
CONFIG_LOCK_KERNEL=y
CONFIG_INIT_ENV_ARG_LIMIT=32
CONFIG_LOCALVERSION=""
CONFIG_LOCALVERSION_AUTO=y
CONFIG_SWAP=y
CONFIG_SYSVIPC=y
CONFIG_SYSVIPC_SYSCTL=y
# CONFIG_POSIX_MQUEUE is not set
# CONFIG_BSD_PROCESS_ACCT is not set
# CONFIG_TASKSTATS is not set
# CONFIG_AUDIT is not set
# CONFIG_IKCONFIG is not set
CONFIG_LOG_BUF_SHIFT=16
# CONFIG_CGROUPS is not set
CONFIG_HAVE_UNSTABLE_SCHED_CLOCK=y
# CONFIG_GROUP_SCHED is not set
CONFIG_SYSFS_DEPRECATED=y
CONFIG_SYSFS_DEPRECATED_V2=y
# CONFIG_RELAY is not set
CONFIG_NAMESPACES=y
# CONFIG_UTS_NS is not set
# CONFIG_IPC_NS is not set
# CONFIG_USER_NS is not set
# CONFIG_PID_NS is not set
CONFIG_BLK_DEV_INITRD=y
CONFIG_INITRAMFS_SOURCE=""
# CONFIG_CC_OPTIMIZE_FOR_SIZE is not set
CONFIG_SYSCTL=y
# CONFIG_EMBEDDED is not set
CONFIG_UID16=y
CONFIG_SYSCTL_SYSCALL=y
CONFIG_KALLSYMS=y
# CONFIG_KALLSYMS_EXTRA_PASS is not set
CONFIG_HOTPLUG=y
CONFIG_PRINTK=y
CONFIG_BUG=y
CONFIG_ELF_CORE=y
CONFIG_PCSPKR_PLATFORM=y
CONFIG_COMPAT_BRK=y
CONFIG_BASE_FULL=y
CONFIG_FUTEX=y
CONFIG_ANON_INODES=y
CONFIG_EPOLL=y
CONFIG_SIGNALFD=y
CONFIG_TIMERFD=y
CONFIG_EVENTFD=y
CONFIG_SHMEM=y
CONFIG_VM_EVENT_COUNTERS=y
CONFIG_SLAB=y
# CONFIG_SLUB is not set
# CONFIG_SLOB is not set
# CONFIG_PROFILING is not set
# CONFIG_MARKERS is not set
CONFIG_HAVE_OPROFILE=y
# CONFIG_KPROBES is not set
CONFIG_HAVE_EFFICIENT_UNALIGNED_ACCESS=y
CONFIG_HAVE_IOREMAP_PROT=y
CONFIG_HAVE_KPROBES=y
CONFIG_HAVE_KRETPROBES=y
# CONFIG_HAVE_ARCH_TRACEHOOK is not set
# CONFIG_HAVE_DMA_ATTRS is not set
# CONFIG_USE_GENERIC_SMP_HELPERS is not set
# CONFIG_HAVE_CLK is not set
CONFIG_PROC_PAGE_MONITOR=y
CONFIG_HAVE_GENERIC_DMA_COHERENT=y
CONFIG_SLABINFO=y
CONFIG_RT_MUTEXES=y
# CONFIG_TINY_SHMEM is not set
CONFIG_BASE_SMALL=0
CONFIG_MODULES=y
# CONFIG_MODULE_FORCE_LOAD is not set
CONFIG_MODULE_UNLOAD=y
# CONFIG_MODULE_FORCE_UNLOAD is not set
CONFIG_MODVERSIONS=y
# CONFIG_MODULE_SRCVERSION_ALL is not set
CONFIG_KMOD=y
CONFIG_BLOCK=y
# CONFIG_LBD is not set
# CONFIG_BLK_DEV_IO_TRACE is not set
# CONFIG_LSF is not set
# CONFIG_BLK_DEV_BSG is not set
# CONFIG_BLK_DEV_INTEGRITY is not set
#
# IO Schedulers
#
CONFIG_IOSCHED_NOOP=y
CONFIG_IOSCHED_AS=m
CONFIG_IOSCHED_DEADLINE=m
CONFIG_IOSCHED_CFQ=m
# CONFIG_DEFAULT_AS is not set
# CONFIG_DEFAULT_DEADLINE is not set
# CONFIG_DEFAULT_CFQ is not set
CONFIG_DEFAULT_NOOP=y
CONFIG_DEFAULT_IOSCHED="noop"
CONFIG_CLASSIC_RCU=y
#
# Processor type and features
#
# CONFIG_TICK_ONESHOT is not set
# CONFIG_NO_HZ is not set
# CONFIG_HIGH_RES_TIMERS is not set
CONFIG_GENERIC_CLOCKEVENTS_BUILD=y
# CONFIG_SMP is not set
CONFIG_X86_FIND_SMP_CONFIG=y
CONFIG_X86_MPPARSE=y
CONFIG_X86_PC=y
# CONFIG_X86_ELAN is not set
# CONFIG_X86_VOYAGER is not set
# CONFIG_X86_GENERICARCH is not set
# CONFIG_X86_VSMP is not set
# CONFIG_X86_RDC321X is not set
CONFIG_SCHED_NO_NO_OMIT_FRAME_POINTER=y
# CONFIG_PARAVIRT_GUEST is not set
# CONFIG_MEMTEST is not set
# CONFIG_M386 is not set
# CONFIG_M486 is not set
# CONFIG_M586 is not set
# CONFIG_M586TSC is not set
CONFIG_M586MMX=y
# CONFIG_M686 is not set
# CONFIG_MPENTIUMII is not set
# CONFIG_MPENTIUMIII is not set
# CONFIG_MPENTIUMM is not set
# CONFIG_MPENTIUM4 is not set
# CONFIG_MK6 is not set
# CONFIG_MK7 is not set
# CONFIG_MK8 is not set
# CONFIG_MCRUSOE is not set
# CONFIG_MEFFICEON is not set
# CONFIG_MWINCHIPC6 is not set
# CONFIG_MWINCHIP2 is not set
# CONFIG_MWINCHIP3D is not set
# CONFIG_MGEODEGX1 is not set
# CONFIG_MGEODE_LX is not set
# CONFIG_MCYRIXIII is not set
# CONFIG_MVIAC3_2 is not set
# CONFIG_MVIAC7 is not set
# CONFIG_MPSC is not set
# CONFIG_MCORE2 is not set
# CONFIG_GENERIC_CPU is not set
CONFIG_X86_GENERIC=y
CONFIG_X86_CPU=y
CONFIG_X86_CMPXCHG=y
CONFIG_X86_L1_CACHE_SHIFT=7
CONFIG_X86_XADD=y
CONFIG_X86_PPRO_FENCE=y
CONFIG_X86_F00F_BUG=y
CONFIG_X86_WP_WORKS_OK=y
CONFIG_X86_INVLPG=y
CONFIG_X86_BSWAP=y
CONFIG_X86_POPAD_OK=y
CONFIG_X86_ALIGNMENT_16=y
CONFIG_X86_INTEL_USERCOPY=y
CONFIG_X86_TSC=y
CONFIG_X86_MINIMUM_CPU_FAMILY=4
# CONFIG_HPET_TIMER is not set
CONFIG_DMI=y
# CONFIG_IOMMU_HELPER is not set
# CONFIG_PREEMPT_NONE is not set
# CONFIG_PREEMPT_VOLUNTARY is not set
CONFIG_PREEMPT=y
# CONFIG_PREEMPT_RCU is not set
CONFIG_X86_UP_APIC=y
CONFIG_X86_UP_IOAPIC=y
CONFIG_X86_LOCAL_APIC=y
CONFIG_X86_IO_APIC=y
CONFIG_X86_MCE=y
# CONFIG_X86_MCE_NONFATAL is not set
# CONFIG_X86_MCE_P4THERMAL is not set
CONFIG_VM86=y
CONFIG_TOSHIBA=m
CONFIG_I8K=m
CONFIG_X86_REBOOTFIXUPS=y
CONFIG_MICROCODE=m
CONFIG_MICROCODE_OLD_INTERFACE=y
CONFIG_X86_MSR=m
CONFIG_X86_CPUID=m
# CONFIG_NOHIGHMEM is not set
CONFIG_HIGHMEM4G=y
# CONFIG_HIGHMEM64G is not set
CONFIG_PAGE_OFFSET=0xC0000000
CONFIG_HIGHMEM=y
CONFIG_ARCH_FLATMEM_ENABLE=y
CONFIG_ARCH_SPARSEMEM_ENABLE=y
CONFIG_ARCH_SELECT_MEMORY_MODEL=y
CONFIG_SELECT_MEMORY_MODEL=y
CONFIG_FLATMEM_MANUAL=y
# CONFIG_DISCONTIGMEM_MANUAL is not set
# CONFIG_SPARSEMEM_MANUAL is not set
CONFIG_FLATMEM=y
CONFIG_FLAT_NODE_MEM_MAP=y
CONFIG_SPARSEMEM_STATIC=y
# CONFIG_SPARSEMEM_VMEMMAP_ENABLE is not set
CONFIG_PAGEFLAGS_EXTENDED=y
CONFIG_SPLIT_PTLOCK_CPUS=4
# CONFIG_RESOURCES_64BIT is not set
CONFIG_ZONE_DMA_FLAG=1
CONFIG_BOUNCE=y
CONFIG_VIRT_TO_BUS=y
CONFIG_DEFAULT_MMAP_MIN_ADDR=4096
# CONFIG_HIGHPTE is not set
CONFIG_X86_RESERVE_LOW_64K=y
CONFIG_MATH_EMULATION=y
CONFIG_MTRR=y
# CONFIG_MTRR_SANITIZER is not set
# CONFIG_X86_PAT is not set
# CONFIG_EFI is not set
CONFIG_SECCOMP=y
# CONFIG_HZ_100 is not set
# CONFIG_HZ_250 is not set
# CONFIG_HZ_300 is not set
CONFIG_HZ_1000=y
CONFIG_HZ=1000
# CONFIG_SCHED_HRTICK is not set
# CONFIG_KEXEC is not set
# CONFIG_CRASH_DUMP is not set
CONFIG_PHYSICAL_START=0x100000
# CONFIG_RELOCATABLE is not set
CONFIG_PHYSICAL_ALIGN=0x100000
CONFIG_COMPAT_VDSO=y
CONFIG_ARCH_ENABLE_MEMORY_HOTPLUG=y
#
# Power management options
#
CONFIG_PM=y
# CONFIG_PM_DEBUG is not set
CONFIG_PM_SLEEP=y
CONFIG_SUSPEND=y
CONFIG_SUSPEND_FREEZER=y
# CONFIG_HIBERNATION is not set
CONFIG_ACPI=y
CONFIG_ACPI_SLEEP=y
CONFIG_ACPI_PROCFS=y
CONFIG_ACPI_PROCFS_POWER=y
CONFIG_ACPI_SYSFS_POWER=y
CONFIG_ACPI_PROC_EVENT=y
CONFIG_ACPI_AC=m
CONFIG_ACPI_BATTERY=m
CONFIG_ACPI_BUTTON=m
CONFIG_ACPI_VIDEO=m
CONFIG_ACPI_FAN=m
CONFIG_ACPI_DOCK=m
# CONFIG_ACPI_BAY is not set
CONFIG_ACPI_PROCESSOR=m
CONFIG_ACPI_THERMAL=m
# CONFIG_ACPI_WMI is not set
CONFIG_ACPI_ASUS=m
CONFIG_ACPI_TOSHIBA=m
# CONFIG_ACPI_CUSTOM_DSDT is not set
CONFIG_ACPI_BLACKLIST_YEAR=0
# CONFIG_ACPI_DEBUG is not set
CONFIG_ACPI_EC=y
CONFIG_ACPI_PCI_SLOT=m
CONFIG_ACPI_POWER=y
CONFIG_ACPI_SYSTEM=y
CONFIG_X86_PM_TIMER=y
# CONFIG_ACPI_CONTAINER is not set
CONFIG_ACPI_SBS=m
CONFIG_X86_APM_BOOT=y
CONFIG_APM=m
# CONFIG_APM_IGNORE_USER_SUSPEND is not set
# CONFIG_APM_DO_ENABLE is not set
# CONFIG_APM_CPU_IDLE is not set
CONFIG_APM_DISPLAY_BLANK=y
# CONFIG_APM_ALLOW_INTS is not set
# CONFIG_APM_REAL_MODE_POWER_OFF is not set
#
# CPU Frequency scaling
#
CONFIG_CPU_FREQ=y
CONFIG_CPU_FREQ_TABLE=m
# CONFIG_CPU_FREQ_DEBUG is not set
CONFIG_CPU_FREQ_STAT=m
CONFIG_CPU_FREQ_STAT_DETAILS=y
# CONFIG_CPU_FREQ_DEFAULT_GOV_PERFORMANCE is not set
# CONFIG_CPU_FREQ_DEFAULT_GOV_POWERSAVE is not set
CONFIG_CPU_FREQ_DEFAULT_GOV_USERSPACE=y
# CONFIG_CPU_FREQ_DEFAULT_GOV_ONDEMAND is not set
# CONFIG_CPU_FREQ_DEFAULT_GOV_CONSERVATIVE is not set
CONFIG_CPU_FREQ_GOV_PERFORMANCE=m
CONFIG_CPU_FREQ_GOV_POWERSAVE=m
CONFIG_CPU_FREQ_GOV_USERSPACE=y
CONFIG_CPU_FREQ_GOV_ONDEMAND=m
CONFIG_CPU_FREQ_GOV_CONSERVATIVE=m
#
# CPUFreq processor drivers
#
CONFIG_X86_ACPI_CPUFREQ=m
CONFIG_X86_POWERNOW_K6=m
CONFIG_X86_POWERNOW_K7=m
CONFIG_X86_POWERNOW_K7_ACPI=y
CONFIG_X86_POWERNOW_K8=m
CONFIG_X86_POWERNOW_K8_ACPI=y
CONFIG_X86_GX_SUSPMOD=m
CONFIG_X86_SPEEDSTEP_CENTRINO=m
CONFIG_X86_SPEEDSTEP_CENTRINO_TABLE=y
CONFIG_X86_SPEEDSTEP_ICH=m
CONFIG_X86_SPEEDSTEP_SMI=m
CONFIG_X86_P4_CLOCKMOD=m
CONFIG_X86_CPUFREQ_NFORCE2=m
CONFIG_X86_LONGRUN=m
CONFIG_X86_LONGHAUL=m
CONFIG_X86_E_POWERSAVER=m
#
# shared options
#
CONFIG_X86_ACPI_CPUFREQ_PROC_INTF=y
CONFIG_X86_SPEEDSTEP_LIB=m
CONFIG_X86_SPEEDSTEP_RELAXED_CAP_CHECK=y
CONFIG_CPU_IDLE=y
CONFIG_CPU_IDLE_GOV_LADDER=y
#
# Bus options (PCI etc.)
#
CONFIG_PCI=y
# CONFIG_PCI_GOBIOS is not set
# CONFIG_PCI_GOMMCONFIG is not set
# CONFIG_PCI_GODIRECT is not set
# CONFIG_PCI_GOOLPC is not set
CONFIG_PCI_GOANY=y
CONFIG_PCI_BIOS=y
CONFIG_PCI_DIRECT=y
CONFIG_PCI_MMCONFIG=y
CONFIG_PCI_OLPC=y
CONFIG_PCI_DOMAINS=y
CONFIG_PCIEPORTBUS=y
CONFIG_PCIEAER=y
# CONFIG_PCIEASPM is not set
CONFIG_ARCH_SUPPORTS_MSI=y
# CONFIG_PCI_MSI is not set
CONFIG_PCI_LEGACY=y
CONFIG_HT_IRQ=y
CONFIG_ISA_DMA_API=y
CONFIG_ISA=y
CONFIG_EISA=y
# CONFIG_EISA_VLB_PRIMING is not set
CONFIG_EISA_PCI_EISA=y
CONFIG_EISA_VIRTUAL_ROOT=y
CONFIG_EISA_NAMES=y
CONFIG_MCA=y
CONFIG_MCA_LEGACY=y
CONFIG_MCA_PROC_FS=y
CONFIG_SCx200=m
CONFIG_SCx200HR_TIMER=m
CONFIG_OLPC=y
CONFIG_K8_NB=y
CONFIG_PCCARD=m
# CONFIG_PCMCIA_DEBUG is not set
CONFIG_PCMCIA=m
CONFIG_PCMCIA_LOAD_CIS=y
CONFIG_PCMCIA_IOCTL=y
CONFIG_CARDBUS=y
#
# PC-card bridges
#
CONFIG_YENTA=m
CONFIG_YENTA_O2=y
CONFIG_YENTA_RICOH=y
CONFIG_YENTA_TI=y
CONFIG_YENTA_ENE_TUNE=y
CONFIG_YENTA_TOSHIBA=y
CONFIG_PD6729=m
CONFIG_I82092=m
CONFIG_I82365=m
CONFIG_TCIC=m
CONFIG_PCMCIA_PROBE=y
CONFIG_PCCARD_NONSTATIC=m
# CONFIG_HOTPLUG_PCI is not set
#
# Executable file formats / Emulations
#
CONFIG_BINFMT_ELF=y
CONFIG_BINFMT_AOUT=m
CONFIG_BINFMT_MISC=m
CONFIG_NET=y
#
# Networking options
#
CONFIG_PACKET=m
# CONFIG_PACKET_MMAP is not set
CONFIG_UNIX=y
CONFIG_XFRM=y
CONFIG_XFRM_USER=y
# CONFIG_XFRM_SUB_POLICY is not set
# CONFIG_XFRM_MIGRATE is not set
# CONFIG_XFRM_STATISTICS is not set
CONFIG_XFRM_IPCOMP=y
CONFIG_NET_KEY=y
# CONFIG_NET_KEY_MIGRATE is not set
CONFIG_INET=y
# CONFIG_IP_MULTICAST is not set
CONFIG_IP_ADVANCED_ROUTER=y
CONFIG_ASK_IP_FIB_HASH=y
# CONFIG_IP_FIB_TRIE is not set
CONFIG_IP_FIB_HASH=y
# CONFIG_IP_MULTIPLE_TABLES is not set
CONFIG_IP_ROUTE_MULTIPATH=y
CONFIG_IP_ROUTE_VERBOSE=y
CONFIG_IP_PNP=y
CONFIG_IP_PNP_DHCP=y
CONFIG_IP_PNP_BOOTP=y
CONFIG_IP_PNP_RARP=y
CONFIG_NET_IPIP=m
CONFIG_NET_IPGRE=m
# CONFIG_ARPD is not set
CONFIG_SYN_COOKIES=y
CONFIG_INET_AH=y
CONFIG_INET_ESP=y
CONFIG_INET_IPCOMP=y
CONFIG_INET_XFRM_TUNNEL=y
CONFIG_INET_TUNNEL=y
CONFIG_INET_XFRM_MODE_TRANSPORT=y
CONFIG_INET_XFRM_MODE_TUNNEL=y
CONFIG_INET_XFRM_MODE_BEET=y
CONFIG_INET_LRO=m
CONFIG_INET_DIAG=y
CONFIG_INET_TCP_DIAG=y
# CONFIG_TCP_CONG_ADVANCED is not set
CONFIG_TCP_CONG_CUBIC=y
CONFIG_DEFAULT_TCP_CONG="cubic"
# CONFIG_TCP_MD5SIG is not set
# CONFIG_IP_VS is not set
# CONFIG_IPV6 is not set
# CONFIG_NETWORK_SECMARK is not set
CONFIG_NETFILTER=y
# CONFIG_NETFILTER_DEBUG is not set
CONFIG_NETFILTER_ADVANCED=y
CONFIG_BRIDGE_NETFILTER=y
#
# Core Netfilter Configuration
#
CONFIG_NETFILTER_NETLINK=m
CONFIG_NETFILTER_NETLINK_QUEUE=m
CONFIG_NETFILTER_NETLINK_LOG=m
CONFIG_NF_CONNTRACK=m
CONFIG_NF_CT_ACCT=y
CONFIG_NF_CONNTRACK_MARK=y
# CONFIG_NF_CONNTRACK_EVENTS is not set
# CONFIG_NF_CT_PROTO_DCCP is not set
CONFIG_NF_CT_PROTO_GRE=m
# CONFIG_NF_CT_PROTO_SCTP is not set
# CONFIG_NF_CT_PROTO_UDPLITE is not set
# CONFIG_NF_CONNTRACK_AMANDA is not set
CONFIG_NF_CONNTRACK_FTP=m
# CONFIG_NF_CONNTRACK_H323 is not set
CONFIG_NF_CONNTRACK_IRC=m
# CONFIG_NF_CONNTRACK_NETBIOS_NS is not set
CONFIG_NF_CONNTRACK_PPTP=m
# CONFIG_NF_CONNTRACK_SANE is not set
# CONFIG_NF_CONNTRACK_SIP is not set
CONFIG_NF_CONNTRACK_TFTP=m
# CONFIG_NF_CT_NETLINK is not set
CONFIG_NETFILTER_XTABLES=m
CONFIG_NETFILTER_XT_TARGET_CLASSIFY=m
CONFIG_NETFILTER_XT_TARGET_CONNMARK=m
CONFIG_NETFILTER_XT_TARGET_DSCP=m
CONFIG_NETFILTER_XT_TARGET_MARK=m
CONFIG_NETFILTER_XT_TARGET_NFQUEUE=m
# CONFIG_NETFILTER_XT_TARGET_NFLOG is not set
CONFIG_NETFILTER_XT_TARGET_NOTRACK=m
CONFIG_NETFILTER_XT_TARGET_RATEEST=m
CONFIG_NETFILTER_XT_TARGET_TRACE=m
CONFIG_NETFILTER_XT_TARGET_TCPMSS=m
# CONFIG_NETFILTER_XT_TARGET_TCPOPTSTRIP is not set
CONFIG_NETFILTER_XT_MATCH_COMMENT=m
CONFIG_NETFILTER_XT_MATCH_CONNBYTES=m
CONFIG_NETFILTER_XT_MATCH_CONNLIMIT=m
CONFIG_NETFILTER_XT_MATCH_CONNMARK=m
CONFIG_NETFILTER_XT_MATCH_CONNTRACK=m
CONFIG_NETFILTER_XT_MATCH_DCCP=m
CONFIG_NETFILTER_XT_MATCH_DSCP=m
CONFIG_NETFILTER_XT_MATCH_ESP=m
CONFIG_NETFILTER_XT_MATCH_HELPER=m
CONFIG_NETFILTER_XT_MATCH_IPRANGE=m
CONFIG_NETFILTER_XT_MATCH_LENGTH=m
CONFIG_NETFILTER_XT_MATCH_LIMIT=m
CONFIG_NETFILTER_XT_MATCH_MAC=m
CONFIG_NETFILTER_XT_MATCH_MARK=m
CONFIG_NETFILTER_XT_MATCH_OWNER=m
CONFIG_NETFILTER_XT_MATCH_POLICY=m
CONFIG_NETFILTER_XT_MATCH_MULTIPORT=m
CONFIG_NETFILTER_XT_MATCH_PHYSDEV=m
CONFIG_NETFILTER_XT_MATCH_PKTTYPE=m
CONFIG_NETFILTER_XT_MATCH_QUOTA=m
CONFIG_NETFILTER_XT_MATCH_RATEEST=m
CONFIG_NETFILTER_XT_MATCH_REALM=m
CONFIG_NETFILTER_XT_MATCH_SCTP=m
CONFIG_NETFILTER_XT_MATCH_STATE=m
CONFIG_NETFILTER_XT_MATCH_STATISTIC=m
CONFIG_NETFILTER_XT_MATCH_STRING=m
CONFIG_NETFILTER_XT_MATCH_TCPMSS=m
CONFIG_NETFILTER_XT_MATCH_TIME=m
CONFIG_NETFILTER_XT_MATCH_U32=m
# CONFIG_NETFILTER_XT_MATCH_HASHLIMIT is not set
#
# IP: Netfilter Configuration
#
CONFIG_NF_CONNTRACK_IPV4=m
CONFIG_NF_CONNTRACK_PROC_COMPAT=y
CONFIG_IP_NF_QUEUE=m
CONFIG_IP_NF_IPTABLES=m
CONFIG_IP_NF_MATCH_RECENT=m
CONFIG_IP_NF_MATCH_ECN=m
CONFIG_IP_NF_MATCH_AH=m
CONFIG_IP_NF_MATCH_TTL=m
CONFIG_IP_NF_MATCH_ADDRTYPE=m
CONFIG_IP_NF_FILTER=m
CONFIG_IP_NF_TARGET_REJECT=m
CONFIG_IP_NF_TARGET_LOG=m
CONFIG_IP_NF_TARGET_ULOG=m
CONFIG_NF_NAT=m
CONFIG_NF_NAT_NEEDED=y
CONFIG_IP_NF_TARGET_MASQUERADE=m
CONFIG_IP_NF_TARGET_REDIRECT=m
CONFIG_IP_NF_TARGET_NETMAP=m
# CONFIG_NF_NAT_SNMP_BASIC is not set
CONFIG_NF_NAT_PROTO_GRE=m
CONFIG_NF_NAT_FTP=m
CONFIG_NF_NAT_IRC=m
CONFIG_NF_NAT_TFTP=m
# CONFIG_NF_NAT_AMANDA is not set
CONFIG_NF_NAT_PPTP=m
# CONFIG_NF_NAT_H323 is not set
# CONFIG_NF_NAT_SIP is not set
CONFIG_IP_NF_MANGLE=m
CONFIG_IP_NF_TARGET_ECN=m
CONFIG_IP_NF_TARGET_TTL=m
# CONFIG_IP_NF_TARGET_CLUSTERIP is not set
CONFIG_IP_NF_RAW=m
CONFIG_IP_NF_ARPTABLES=m
CONFIG_IP_NF_ARPFILTER=m
CONFIG_IP_NF_ARP_MANGLE=m
#
# DECnet: Netfilter Configuration
#
# CONFIG_DECNET_NF_GRABULATOR is not set
#
# Bridge: Netfilter Configuration
#
CONFIG_BRIDGE_NF_EBTABLES=m
CONFIG_BRIDGE_EBT_BROUTE=m
CONFIG_BRIDGE_EBT_T_FILTER=m
CONFIG_BRIDGE_EBT_T_NAT=m
CONFIG_BRIDGE_EBT_802_3=m
CONFIG_BRIDGE_EBT_AMONG=m
CONFIG_BRIDGE_EBT_ARP=m
CONFIG_BRIDGE_EBT_IP=m
CONFIG_BRIDGE_EBT_LIMIT=m
CONFIG_BRIDGE_EBT_MARK=m
CONFIG_BRIDGE_EBT_PKTTYPE=m
CONFIG_BRIDGE_EBT_STP=m
CONFIG_BRIDGE_EBT_VLAN=m
CONFIG_BRIDGE_EBT_ARPREPLY=m
CONFIG_BRIDGE_EBT_DNAT=m
CONFIG_BRIDGE_EBT_MARK_T=m
CONFIG_BRIDGE_EBT_REDIRECT=m
CONFIG_BRIDGE_EBT_SNAT=m
CONFIG_BRIDGE_EBT_LOG=m
CONFIG_BRIDGE_EBT_ULOG=m
CONFIG_BRIDGE_EBT_NFLOG=m
# CONFIG_IP_DCCP is not set
# CONFIG_IP_SCTP is not set
# CONFIG_TIPC is not set
# CONFIG_ATM is not set
CONFIG_STP=m
CONFIG_BRIDGE=m
CONFIG_VLAN_8021Q=m
# CONFIG_VLAN_8021Q_GVRP is not set
CONFIG_DECNET=m
# CONFIG_DECNET_ROUTER is not set
CONFIG_LLC=m
CONFIG_LLC2=m
CONFIG_IPX=m
# CONFIG_IPX_INTERN is not set
# CONFIG_ATALK is not set
# CONFIG_X25 is not set
# CONFIG_LAPB is not set
# CONFIG_ECONET is not set
# CONFIG_WAN_ROUTER is not set
CONFIG_NET_SCHED=y
#
# Queueing/Scheduling
#
CONFIG_NET_SCH_CBQ=m
CONFIG_NET_SCH_HTB=m
CONFIG_NET_SCH_HFSC=m
CONFIG_NET_SCH_PRIO=m
CONFIG_NET_SCH_RED=m
CONFIG_NET_SCH_SFQ=m
CONFIG_NET_SCH_TEQL=m
CONFIG_NET_SCH_TBF=m
CONFIG_NET_SCH_GRED=m
CONFIG_NET_SCH_DSMARK=m
CONFIG_NET_SCH_NETEM=m
CONFIG_NET_SCH_INGRESS=m
#
# Classification
#
CONFIG_NET_CLS=y
CONFIG_NET_CLS_BASIC=m
CONFIG_NET_CLS_TCINDEX=m
CONFIG_NET_CLS_ROUTE4=m
CONFIG_NET_CLS_ROUTE=y
CONFIG_NET_CLS_FW=m
CONFIG_NET_CLS_U32=m
# CONFIG_CLS_U32_PERF is not set
CONFIG_CLS_U32_MARK=y
CONFIG_NET_CLS_RSVP=m
CONFIG_NET_CLS_RSVP6=m
CONFIG_NET_CLS_FLOW=m
CONFIG_NET_EMATCH=y
CONFIG_NET_EMATCH_STACK=32
CONFIG_NET_EMATCH_CMP=m
CONFIG_NET_EMATCH_NBYTE=m
CONFIG_NET_EMATCH_U32=m
CONFIG_NET_EMATCH_META=m
CONFIG_NET_EMATCH_TEXT=m
CONFIG_NET_CLS_ACT=y
CONFIG_NET_ACT_POLICE=y
# CONFIG_NET_ACT_GACT is not set
# CONFIG_NET_ACT_MIRRED is not set
# CONFIG_NET_ACT_IPT is not set
CONFIG_NET_ACT_NAT=m
# CONFIG_NET_ACT_PEDIT is not set
# CONFIG_NET_ACT_SIMP is not set
# CONFIG_NET_CLS_IND is not set
CONFIG_NET_SCH_FIFO=y
#
# Network testing
#
# CONFIG_NET_PKTGEN is not set
# CONFIG_HAMRADIO is not set
CONFIG_CAN=m
CONFIG_CAN_RAW=m
CONFIG_CAN_BCM=m
#
# CAN Device Drivers
#
CONFIG_CAN_VCAN=m
# CONFIG_CAN_DEBUG_DEVICES is not set
CONFIG_IRDA=m
#
# IrDA protocols
#
CONFIG_IRLAN=m
CONFIG_IRNET=m
CONFIG_IRCOMM=m
# CONFIG_IRDA_ULTRA is not set
#
# IrDA options
#
# CONFIG_IRDA_CACHE_LAST_LSAP is not set
# CONFIG_IRDA_FAST_RR is not set
# CONFIG_IRDA_DEBUG is not set
#
# Infrared-port device drivers
#
#
# SIR device drivers
#
CONFIG_IRTTY_SIR=m
#
# Dongle support
#
# CONFIG_DONGLE is not set
CONFIG_KINGSUN_DONGLE=m
# CONFIG_KSDAZZLE_DONGLE is not set
# CONFIG_KS959_DONGLE is not set
#
# FIR device drivers
#
CONFIG_USB_IRDA=m
# CONFIG_SIGMATEL_FIR is not set
CONFIG_NSC_FIR=m
CONFIG_WINBOND_FIR=m
CONFIG_TOSHIBA_FIR=m
# CONFIG_SMC_IRCC_FIR is not set
# CONFIG_ALI_FIR is not set
# CONFIG_VLSI_FIR is not set
CONFIG_VIA_FIR=m
CONFIG_MCS_FIR=m
CONFIG_BT=m
CONFIG_BT_L2CAP=m
CONFIG_BT_SCO=m
CONFIG_BT_RFCOMM=m
CONFIG_BT_RFCOMM_TTY=y
CONFIG_BT_BNEP=m
CONFIG_BT_BNEP_MC_FILTER=y
CONFIG_BT_BNEP_PROTO_FILTER=y
CONFIG_BT_HIDP=m
#
# Bluetooth device drivers
#
CONFIG_BT_HCIBTUSB=m
CONFIG_BT_HCIBTSDIO=m
CONFIG_BT_HCIUART=m
CONFIG_BT_HCIUART_H4=y
CONFIG_BT_HCIUART_BCSP=y
# CONFIG_BT_HCIUART_LL is not set
CONFIG_BT_HCIBCM203X=m
CONFIG_BT_HCIBPA10X=m
CONFIG_BT_HCIBFUSB=m
CONFIG_BT_HCIDTL1=m
CONFIG_BT_HCIBT3C=m
CONFIG_BT_HCIBLUECARD=m
CONFIG_BT_HCIBTUART=m
CONFIG_BT_HCIVHCI=m
CONFIG_AF_RXRPC=m
# CONFIG_AF_RXRPC_DEBUG is not set
# CONFIG_RXKAD is not set
#
# Wireless
#
CONFIG_CFG80211=m
CONFIG_NL80211=y
CONFIG_WIRELESS_EXT=y
CONFIG_WIRELESS_EXT_SYSFS=y
CONFIG_MAC80211=m
#
# Rate control algorithm selection
#
CONFIG_MAC80211_RC_PID=y
CONFIG_MAC80211_RC_DEFAULT_PID=y
CONFIG_MAC80211_RC_DEFAULT="pid"
# CONFIG_MAC80211_MESH is not set
CONFIG_MAC80211_LEDS=y
# CONFIG_MAC80211_DEBUG_MENU is not set
CONFIG_IEEE80211=m
# CONFIG_IEEE80211_DEBUG is not set
CONFIG_IEEE80211_CRYPT_WEP=m
CONFIG_IEEE80211_CRYPT_CCMP=m
CONFIG_IEEE80211_CRYPT_TKIP=m
CONFIG_RFKILL=m
CONFIG_RFKILL_INPUT=m
CONFIG_RFKILL_LEDS=y
# CONFIG_NET_9P is not set
#
# Device Drivers
#
#
# Generic Driver Options
#
CONFIG_UEVENT_HELPER_PATH="/sbin/hotplug"
CONFIG_STANDALONE=y
CONFIG_PREVENT_FIRMWARE_BUILD=y
CONFIG_FW_LOADER=y
CONFIG_FIRMWARE_IN_KERNEL=y
CONFIG_EXTRA_FIRMWARE=""
# CONFIG_SYS_HYPERVISOR is not set
CONFIG_CONNECTOR=m
CONFIG_MTD=m
# CONFIG_MTD_DEBUG is not set
CONFIG_MTD_CONCAT=m
CONFIG_MTD_PARTITIONS=y
CONFIG_MTD_REDBOOT_PARTS=m
CONFIG_MTD_REDBOOT_DIRECTORY_BLOCK=-1
CONFIG_MTD_REDBOOT_PARTS_UNALLOCATED=y
# CONFIG_MTD_REDBOOT_PARTS_READONLY is not set
CONFIG_MTD_AR7_PARTS=m
#
# User Modules And Translation Layers
#
CONFIG_MTD_CHAR=m
CONFIG_MTD_BLKDEVS=m
CONFIG_MTD_BLOCK=m
CONFIG_MTD_BLOCK_RO=m
CONFIG_FTL=m
CONFIG_NFTL=m
# CONFIG_NFTL_RW is not set
CONFIG_INFTL=m
CONFIG_RFD_FTL=m
CONFIG_SSFDC=m
CONFIG_MTD_OOPS=m
#
# RAM/ROM/Flash chip drivers
#
# CONFIG_MTD_CFI is not set
CONFIG_MTD_JEDECPROBE=m
CONFIG_MTD_GEN_PROBE=m
# CONFIG_MTD_CFI_ADV_OPTIONS is not set
CONFIG_MTD_MAP_BANK_WIDTH_1=y
CONFIG_MTD_MAP_BANK_WIDTH_2=y
CONFIG_MTD_MAP_BANK_WIDTH_4=y
# CONFIG_MTD_MAP_BANK_WIDTH_8 is not set
# CONFIG_MTD_MAP_BANK_WIDTH_16 is not set
# CONFIG_MTD_MAP_BANK_WIDTH_32 is not set
CONFIG_MTD_CFI_I1=y
CONFIG_MTD_CFI_I2=y
# CONFIG_MTD_CFI_I4 is not set
# CONFIG_MTD_CFI_I8 is not set
# CONFIG_MTD_CFI_INTELEXT is not set
CONFIG_MTD_CFI_AMDSTD=m
# CONFIG_MTD_CFI_STAA is not set
CONFIG_MTD_CFI_UTIL=m
CONFIG_MTD_RAM=m
# CONFIG_MTD_ROM is not set
CONFIG_MTD_ABSENT=m
#
# Mapping drivers for chip access
#
# CONFIG_MTD_COMPLEX_MAPPINGS is not set
CONFIG_MTD_PHYSMAP=m
CONFIG_MTD_PHYSMAP_START=0x8000000
CONFIG_MTD_PHYSMAP_LEN=0x0
CONFIG_MTD_PHYSMAP_BANKWIDTH=2
# CONFIG_MTD_TS5500 is not set
# CONFIG_MTD_AMD76XROM is not set
# CONFIG_MTD_ICHXROM is not set
# CONFIG_MTD_ESB2ROM is not set
# CONFIG_MTD_CK804XROM is not set
# CONFIG_MTD_SCB2_FLASH is not set
# CONFIG_MTD_NETtel is not set
# CONFIG_MTD_L440GX is not set
CONFIG_MTD_INTEL_VR_NOR=m
# CONFIG_MTD_PLATRAM is not set
#
# Self-contained MTD device drivers
#
CONFIG_MTD_PMC551=m
# CONFIG_MTD_PMC551_BUGFIX is not set
# CONFIG_MTD_PMC551_DEBUG is not set
CONFIG_MTD_SLRAM=m
CONFIG_MTD_PHRAM=m
CONFIG_MTD_MTDRAM=m
CONFIG_MTDRAM_TOTAL_SIZE=4096
CONFIG_MTDRAM_ERASE_SIZE=128
# CONFIG_MTD_BLOCK2MTD is not set
#
# Disk-On-Chip Device Drivers
#
CONFIG_MTD_DOC2000=m
CONFIG_MTD_DOC2001=m
CONFIG_MTD_DOC2001PLUS=m
CONFIG_MTD_DOCPROBE=m
CONFIG_MTD_DOCECC=m
# CONFIG_MTD_DOCPROBE_ADVANCED is not set
CONFIG_MTD_DOCPROBE_ADDRESS=0
CONFIG_MTD_NAND=m
# CONFIG_MTD_NAND_VERIFY_WRITE is not set
# CONFIG_MTD_NAND_ECC_SMC is not set
# CONFIG_MTD_NAND_MUSEUM_IDS is not set
CONFIG_MTD_NAND_IDS=m
# CONFIG_MTD_NAND_DISKONCHIP is not set
# CONFIG_MTD_NAND_CAFE is not set
# CONFIG_MTD_NAND_CS553X is not set
CONFIG_MTD_NAND_NANDSIM=m
# CONFIG_MTD_NAND_PLATFORM is not set
CONFIG_MTD_ALAUDA=m
CONFIG_MTD_ONENAND=m
# CONFIG_MTD_ONENAND_VERIFY_WRITE is not set
# CONFIG_MTD_ONENAND_OTP is not set
# CONFIG_MTD_ONENAND_2X_PROGRAM is not set
CONFIG_MTD_ONENAND_SIM=m
#
# UBI - Unsorted block images
#
# CONFIG_MTD_UBI is not set
CONFIG_PARPORT=m
CONFIG_PARPORT_PC=m
CONFIG_PARPORT_SERIAL=m
# CONFIG_PARPORT_PC_FIFO is not set
# CONFIG_PARPORT_PC_SUPERIO is not set
CONFIG_PARPORT_PC_PCMCIA=m
# CONFIG_PARPORT_GSC is not set
CONFIG_PARPORT_AX88796=m
CONFIG_PARPORT_1284=y
CONFIG_PARPORT_NOT_PC=y
CONFIG_PNP=y
CONFIG_PNP_DEBUG=y
#
# Protocols
#
CONFIG_ISAPNP=y
CONFIG_PNPBIOS=y
CONFIG_PNPBIOS_PROC_FS=y
CONFIG_PNPACPI=y
CONFIG_BLK_DEV=y
CONFIG_BLK_DEV_FD=y
# CONFIG_BLK_DEV_XD is not set
CONFIG_PARIDE=m
#
# Parallel IDE high-level drivers
#
CONFIG_PARIDE_PD=m
CONFIG_PARIDE_PCD=m
CONFIG_PARIDE_PF=m
CONFIG_PARIDE_PT=m
CONFIG_PARIDE_PG=m
#
# Parallel IDE protocol modules
#
CONFIG_PARIDE_ATEN=m
# CONFIG_PARIDE_BPCK is not set
# CONFIG_PARIDE_BPCK6 is not set
CONFIG_PARIDE_COMM=m
CONFIG_PARIDE_DSTR=m
CONFIG_PARIDE_FIT2=m
CONFIG_PARIDE_FIT3=m
CONFIG_PARIDE_EPAT=m
# CONFIG_PARIDE_EPATC8 is not set
CONFIG_PARIDE_EPIA=m
CONFIG_PARIDE_FRIQ=m
CONFIG_PARIDE_FRPW=m
CONFIG_PARIDE_KBIC=m
CONFIG_PARIDE_KTTI=m
CONFIG_PARIDE_ON20=m
CONFIG_PARIDE_ON26=m
CONFIG_BLK_CPQ_DA=m
CONFIG_BLK_CPQ_CISS_DA=m
CONFIG_CISS_SCSI_TAPE=y
CONFIG_BLK_DEV_DAC960=m
# CONFIG_BLK_DEV_UMEM is not set
# CONFIG_BLK_DEV_COW_COMMON is not set
CONFIG_BLK_DEV_LOOP=m
CONFIG_BLK_DEV_CRYPTOLOOP=m
CONFIG_BLK_DEV_NBD=m
CONFIG_BLK_DEV_SX8=m
# CONFIG_BLK_DEV_UB is not set
CONFIG_BLK_DEV_RAM=y
CONFIG_BLK_DEV_RAM_COUNT=16
CONFIG_BLK_DEV_RAM_SIZE=8192
# CONFIG_BLK_DEV_XIP is not set
CONFIG_CDROM_PKTCDVD=m
CONFIG_CDROM_PKTCDVD_BUFFERS=8
# CONFIG_CDROM_PKTCDVD_WCACHE is not set
CONFIG_ATA_OVER_ETH=m
CONFIG_VIRTIO_BLK=m
# CONFIG_BLK_DEV_HD is not set
CONFIG_MISC_DEVICES=y
# CONFIG_IBM_ASM is not set
CONFIG_PHANTOM=m
CONFIG_EEPROM_93CX6=m
CONFIG_SGI_IOC4=m
CONFIG_TIFM_CORE=m
CONFIG_TIFM_7XX1=m
# CONFIG_ACER_WMI is not set
CONFIG_ASUS_LAPTOP=m
CONFIG_FUJITSU_LAPTOP=m
# CONFIG_FUJITSU_LAPTOP_DEBUG is not set
# CONFIG_TC1100_WMI is not set
CONFIG_MSI_LAPTOP=m
CONFIG_COMPAL_LAPTOP=m
CONFIG_SONY_LAPTOP=m
# CONFIG_SONYPI_COMPAT is not set
CONFIG_THINKPAD_ACPI=m
# CONFIG_THINKPAD_ACPI_DEBUG is not set
CONFIG_THINKPAD_ACPI_VIDEO=y
CONFIG_THINKPAD_ACPI_HOTKEY_POLL=y
CONFIG_INTEL_MENLOW=m
CONFIG_EEEPC_LAPTOP=m
CONFIG_ENCLOSURE_SERVICES=m
CONFIG_HP_ILO=m
CONFIG_HAVE_IDE=y
CONFIG_IDE=y
CONFIG_BLK_DEV_IDE=y
#
# Please see Documentation/ide/ide.txt for help/info on IDE drives
#
CONFIG_IDE_TIMINGS=y
CONFIG_IDE_ATAPI=y
# CONFIG_BLK_DEV_IDE_SATA is not set
CONFIG_BLK_DEV_IDEDISK=y
# CONFIG_IDEDISK_MULTI_MODE is not set
CONFIG_BLK_DEV_IDECS=m
CONFIG_BLK_DEV_DELKIN=m
CONFIG_BLK_DEV_IDECD=y
CONFIG_BLK_DEV_IDECD_VERBOSE_ERRORS=y
# CONFIG_BLK_DEV_IDETAPE is not set
CONFIG_BLK_DEV_IDEFLOPPY=y
CONFIG_BLK_DEV_IDESCSI=y
# CONFIG_BLK_DEV_IDEACPI is not set
CONFIG_IDE_TASK_IOCTL=y
CONFIG_IDE_PROC_FS=y
#
# IDE chipset support/bugfixes
#
CONFIG_IDE_GENERIC=y
CONFIG_BLK_DEV_PLATFORM=m
CONFIG_BLK_DEV_CMD640=y
# CONFIG_BLK_DEV_CMD640_ENHANCED is not set
CONFIG_BLK_DEV_IDEPNP=y
CONFIG_BLK_DEV_IDEDMA_SFF=y
#
# PCI IDE chipsets support
#
CONFIG_BLK_DEV_IDEPCI=y
CONFIG_IDEPCI_PCIBUS_ORDER=y
# CONFIG_BLK_DEV_OFFBOARD is not set
CONFIG_BLK_DEV_GENERIC=y
# CONFIG_BLK_DEV_OPTI621 is not set
CONFIG_BLK_DEV_RZ1000=y
CONFIG_BLK_DEV_IDEDMA_PCI=y
CONFIG_BLK_DEV_AEC62XX=y
CONFIG_BLK_DEV_ALI15X3=y
CONFIG_BLK_DEV_AMD74XX=y
CONFIG_BLK_DEV_ATIIXP=y
CONFIG_BLK_DEV_CMD64X=y
CONFIG_BLK_DEV_TRIFLEX=y
# CONFIG_BLK_DEV_CS5520 is not set
CONFIG_BLK_DEV_CS5530=y
CONFIG_BLK_DEV_CS5535=y
CONFIG_BLK_DEV_HPT366=y
CONFIG_BLK_DEV_JMICRON=m
CONFIG_BLK_DEV_SC1200=y
CONFIG_BLK_DEV_PIIX=y
CONFIG_BLK_DEV_IT8213=m
CONFIG_BLK_DEV_IT821X=y
CONFIG_BLK_DEV_NS87415=y
CONFIG_BLK_DEV_PDC202XX_OLD=y
CONFIG_BLK_DEV_PDC202XX_NEW=y
CONFIG_BLK_DEV_SVWKS=y
CONFIG_BLK_DEV_SIIMAGE=y
CONFIG_BLK_DEV_SIS5513=y
CONFIG_BLK_DEV_SLC90E66=y
CONFIG_BLK_DEV_TRM290=y
CONFIG_BLK_DEV_VIA82CXXX=y
CONFIG_BLK_DEV_TC86C001=m
#
# Other IDE chipsets support
#
#
# Note: most of these also require special kernel boot parameters
#
CONFIG_BLK_DEV_4DRIVES=m
CONFIG_BLK_DEV_ALI14XX=m
CONFIG_BLK_DEV_DTC2278=m
CONFIG_BLK_DEV_HT6560B=m
CONFIG_BLK_DEV_QD65XX=m
CONFIG_BLK_DEV_UMC8672=m
CONFIG_BLK_DEV_IDEDMA=y
#
# SCSI device support
#
# CONFIG_RAID_ATTRS is not set
CONFIG_SCSI=y
CONFIG_SCSI_DMA=y
# CONFIG_SCSI_TGT is not set
CONFIG_SCSI_NETLINK=y
CONFIG_SCSI_PROC_FS=y
#
# SCSI support type (disk, tape, CD-ROM)
#
CONFIG_BLK_DEV_SD=y
CONFIG_CHR_DEV_ST=m
CONFIG_CHR_DEV_OSST=m
CONFIG_BLK_DEV_SR=y
CONFIG_BLK_DEV_SR_VENDOR=y
CONFIG_CHR_DEV_SG=m
CONFIG_CHR_DEV_SCH=m
# CONFIG_SCSI_ENCLOSURE is not set
#
# Some SCSI devices (e.g. CD jukebox) support multiple LUNs
#
CONFIG_SCSI_MULTI_LUN=y
# CONFIG_SCSI_CONSTANTS is not set
# CONFIG_SCSI_LOGGING is not set
# CONFIG_SCSI_SCAN_ASYNC is not set
CONFIG_SCSI_WAIT_SCAN=m
#
# SCSI Transports
#
CONFIG_SCSI_SPI_ATTRS=y
CONFIG_SCSI_FC_ATTRS=y
CONFIG_SCSI_ISCSI_ATTRS=y
CONFIG_SCSI_SAS_ATTRS=m
CONFIG_SCSI_SAS_LIBSAS=m
# CONFIG_SCSI_SAS_ATA is not set
CONFIG_SCSI_SAS_HOST_SMP=y
CONFIG_SCSI_SAS_LIBSAS_DEBUG=y
CONFIG_SCSI_SRP_ATTRS=m
CONFIG_SCSI_LOWLEVEL=y
CONFIG_ISCSI_TCP=m
CONFIG_BLK_DEV_3W_XXXX_RAID=m
CONFIG_SCSI_3W_9XXX=m
CONFIG_SCSI_7000FASST=m
CONFIG_SCSI_ACARD=m
CONFIG_SCSI_AHA152X=m
CONFIG_SCSI_AHA1542=m
CONFIG_SCSI_AHA1740=m
CONFIG_SCSI_AACRAID=m
CONFIG_SCSI_AIC7XXX=m
CONFIG_AIC7XXX_CMDS_PER_DEVICE=32
CONFIG_AIC7XXX_RESET_DELAY_MS=15000
# CONFIG_AIC7XXX_DEBUG_ENABLE is not set
CONFIG_AIC7XXX_DEBUG_MASK=0
# CONFIG_AIC7XXX_REG_PRETTY_PRINT is not set
CONFIG_SCSI_AIC7XXX_OLD=m
CONFIG_SCSI_AIC79XX=m
CONFIG_AIC79XX_CMDS_PER_DEVICE=32
CONFIG_AIC79XX_RESET_DELAY_MS=15000
# CONFIG_AIC79XX_DEBUG_ENABLE is not set
CONFIG_AIC79XX_DEBUG_MASK=0
# CONFIG_AIC79XX_REG_PRETTY_PRINT is not set
# CONFIG_SCSI_AIC94XX is not set
CONFIG_SCSI_DPT_I2O=m
CONFIG_SCSI_ADVANSYS=m
CONFIG_SCSI_IN2000=m
# CONFIG_SCSI_ARCMSR is not set
# CONFIG_MEGARAID_NEWGEN is not set
CONFIG_MEGARAID_LEGACY=m
CONFIG_MEGARAID_SAS=m
CONFIG_SCSI_HPTIOP=m
CONFIG_SCSI_BUSLOGIC=m
# CONFIG_SCSI_FLASHPOINT is not set
CONFIG_SCSI_DMX3191D=m
CONFIG_SCSI_DTC3280=m
CONFIG_SCSI_EATA=m
# CONFIG_SCSI_EATA_TAGGED_QUEUE is not set
# CONFIG_SCSI_EATA_LINKED_COMMANDS is not set
CONFIG_SCSI_EATA_MAX_TAGS=16
CONFIG_SCSI_FUTURE_DOMAIN=m
CONFIG_SCSI_FD_MCS=m
CONFIG_SCSI_GDTH=m
CONFIG_SCSI_GENERIC_NCR5380=m
CONFIG_SCSI_GENERIC_NCR5380_MMIO=m
# CONFIG_SCSI_GENERIC_NCR53C400 is not set
CONFIG_SCSI_IBMMCA=m
CONFIG_IBMMCA_SCSI_ORDER_STANDARD=y
# CONFIG_IBMMCA_SCSI_DEV_RESET is not set
CONFIG_SCSI_IPS=m
CONFIG_SCSI_INITIO=m
CONFIG_SCSI_INIA100=m
CONFIG_SCSI_PPA=m
CONFIG_SCSI_IMM=m
# CONFIG_SCSI_IZIP_EPP16 is not set
# CONFIG_SCSI_IZIP_SLOW_CTR is not set
CONFIG_SCSI_MVSAS=m
CONFIG_SCSI_NCR53C406A=m
CONFIG_SCSI_NCR_D700=m
# CONFIG_SCSI_STEX is not set
CONFIG_SCSI_SYM53C8XX_2=m
CONFIG_SCSI_SYM53C8XX_DMA_ADDRESSING_MODE=1
CONFIG_SCSI_SYM53C8XX_DEFAULT_TAGS=16
CONFIG_SCSI_SYM53C8XX_MAX_TAGS=64
CONFIG_SCSI_SYM53C8XX_MMIO=y
CONFIG_SCSI_IPR=m
# CONFIG_SCSI_IPR_TRACE is not set
# CONFIG_SCSI_IPR_DUMP is not set
CONFIG_SCSI_NCR_Q720=m
CONFIG_SCSI_NCR53C8XX_DEFAULT_TAGS=8
CONFIG_SCSI_NCR53C8XX_MAX_TAGS=32
CONFIG_SCSI_NCR53C8XX_SYNC=20
CONFIG_SCSI_PAS16=m
CONFIG_SCSI_QLOGIC_FAS=m
CONFIG_SCSI_QLOGIC_1280=m
CONFIG_SCSI_QLA_FC=m
# CONFIG_SCSI_QLA_ISCSI is not set
CONFIG_SCSI_LPFC=m
CONFIG_SCSI_SIM710=m
CONFIG_SCSI_SYM53C416=m
# CONFIG_SCSI_DC395x is not set
CONFIG_SCSI_DC390T=m
CONFIG_SCSI_T128=m
CONFIG_SCSI_U14_34F=m
# CONFIG_SCSI_U14_34F_TAGGED_QUEUE is not set
# CONFIG_SCSI_U14_34F_LINKED_COMMANDS is not set
CONFIG_SCSI_U14_34F_MAX_TAGS=8
CONFIG_SCSI_ULTRASTOR=m
CONFIG_SCSI_NSP32=m
CONFIG_SCSI_DEBUG=m
# CONFIG_SCSI_SRP is not set
# CONFIG_SCSI_LOWLEVEL_PCMCIA is not set
CONFIG_SCSI_DH=m
CONFIG_SCSI_DH_RDAC=m
CONFIG_SCSI_DH_HP_SW=m
CONFIG_SCSI_DH_EMC=m
CONFIG_SCSI_DH_ALUA=m
CONFIG_ATA=m
# CONFIG_ATA_NONSTANDARD is not set
CONFIG_ATA_ACPI=y
CONFIG_SATA_PMP=y
CONFIG_SATA_AHCI=m
CONFIG_SATA_SIL24=m
CONFIG_ATA_SFF=y
CONFIG_SATA_SVW=m
CONFIG_ATA_PIIX=m
CONFIG_SATA_MV=m
CONFIG_SATA_NV=m
CONFIG_PDC_ADMA=m
CONFIG_SATA_QSTOR=m
CONFIG_SATA_PROMISE=m
CONFIG_SATA_SX4=m
CONFIG_SATA_SIL=m
CONFIG_SATA_SIS=m
CONFIG_SATA_ULI=m
CONFIG_SATA_VIA=m
CONFIG_SATA_VITESSE=m
CONFIG_SATA_INIC162X=m
CONFIG_PATA_ACPI=m
CONFIG_PATA_ALI=m
CONFIG_PATA_AMD=m
CONFIG_PATA_ARTOP=m
CONFIG_PATA_ATIIXP=m
CONFIG_PATA_CMD640_PCI=m
CONFIG_PATA_CMD64X=m
CONFIG_PATA_CS5520=m
CONFIG_PATA_CS5530=m
CONFIG_PATA_CS5535=m
# CONFIG_PATA_CS5536 is not set
# CONFIG_PATA_CYPRESS is not set
CONFIG_PATA_EFAR=m
CONFIG_ATA_GENERIC=m
CONFIG_PATA_HPT366=m
CONFIG_PATA_HPT37X=m
# CONFIG_PATA_HPT3X2N is not set
CONFIG_PATA_HPT3X3=m
# CONFIG_PATA_HPT3X3_DMA is not set
# CONFIG_PATA_ISAPNP is not set
CONFIG_PATA_IT821X=m
CONFIG_PATA_IT8213=m
CONFIG_PATA_JMICRON=m
# CONFIG_PATA_LEGACY is not set
CONFIG_PATA_TRIFLEX=m
CONFIG_PATA_MARVELL=m
CONFIG_PATA_MPIIX=m
CONFIG_PATA_OLDPIIX=m
CONFIG_PATA_NETCELL=m
# CONFIG_PATA_NINJA32 is not set
# CONFIG_PATA_NS87410 is not set
# CONFIG_PATA_NS87415 is not set
# CONFIG_PATA_OPTI is not set
# CONFIG_PATA_OPTIDMA is not set
CONFIG_PATA_PCMCIA=m
# CONFIG_PATA_PDC_OLD is not set
CONFIG_PATA_QDI=m
# CONFIG_PATA_RADISYS is not set
# CONFIG_PATA_RZ1000 is not set
# CONFIG_PATA_SC1200 is not set
CONFIG_PATA_SERVERWORKS=m
CONFIG_PATA_PDC2027X=m
CONFIG_PATA_SIL680=m
CONFIG_PATA_SIS=m
CONFIG_PATA_VIA=m
CONFIG_PATA_WINBOND=m
CONFIG_PATA_WINBOND_VLB=m
CONFIG_PATA_SCH=m
# CONFIG_MD is not set
# CONFIG_FUSION is not set
#
# IEEE 1394 (FireWire) support
#
#
# Enable only one of the two stacks, unless you know what you are doing
#
# CONFIG_FIREWIRE is not set
CONFIG_IEEE1394=m
CONFIG_IEEE1394_OHCI1394=m
CONFIG_IEEE1394_PCILYNX=m
CONFIG_IEEE1394_SBP2=m
# CONFIG_IEEE1394_SBP2_PHYS_DMA is not set
# CONFIG_IEEE1394_ETH1394_ROM_ENTRY is not set
# CONFIG_IEEE1394_ETH1394 is not set
CONFIG_IEEE1394_RAWIO=m
CONFIG_IEEE1394_VIDEO1394=m
CONFIG_IEEE1394_DV1394=m
# CONFIG_IEEE1394_VERBOSEDEBUG is not set
# CONFIG_I2O is not set
# CONFIG_MACINTOSH_DRIVERS is not set
CONFIG_NETDEVICES=y
# CONFIG_IFB is not set
CONFIG_DUMMY=m
CONFIG_BONDING=m
CONFIG_MACVLAN=m
CONFIG_EQUALIZER=m
CONFIG_TUN=m
CONFIG_VETH=m
CONFIG_NET_SB1000=m
CONFIG_ARCNET=m
CONFIG_ARCNET_1201=m
CONFIG_ARCNET_1051=m
CONFIG_ARCNET_RAW=m
CONFIG_ARCNET_CAP=m
CONFIG_ARCNET_COM90xx=m
CONFIG_ARCNET_COM90xxIO=m
CONFIG_ARCNET_RIM_I=m
CONFIG_ARCNET_COM20020=m
CONFIG_ARCNET_COM20020_ISA=m
CONFIG_ARCNET_COM20020_PCI=m
CONFIG_PHYLIB=m
#
# MII PHY device drivers
#
CONFIG_MARVELL_PHY=m
CONFIG_DAVICOM_PHY=m
CONFIG_QSEMI_PHY=m
CONFIG_LXT_PHY=m
CONFIG_CICADA_PHY=m
CONFIG_VITESSE_PHY=m
CONFIG_SMSC_PHY=m
CONFIG_BROADCOM_PHY=m
CONFIG_ICPLUS_PHY=m
CONFIG_REALTEK_PHY=m
CONFIG_MDIO_BITBANG=m
CONFIG_NET_ETHERNET=y
CONFIG_MII=y
CONFIG_HAPPYMEAL=m
CONFIG_SUNGEM=m
CONFIG_CASSINI=m
CONFIG_NET_VENDOR_3COM=y
CONFIG_EL1=m
CONFIG_EL2=m
CONFIG_ELPLUS=m
# CONFIG_EL16 is not set
CONFIG_EL3=m
CONFIG_3C515=m
CONFIG_ELMC=m
CONFIG_ELMC_II=m
CONFIG_VORTEX=m
CONFIG_TYPHOON=m
CONFIG_LANCE=m
CONFIG_NET_VENDOR_SMC=y
CONFIG_WD80x3=m
CONFIG_ULTRAMCA=m
CONFIG_ULTRA=m
CONFIG_ULTRA32=m
CONFIG_SMC9194=m
CONFIG_NET_VENDOR_RACAL=y
CONFIG_NI5010=m
CONFIG_NI52=m
CONFIG_NI65=m
CONFIG_NET_TULIP=y
# CONFIG_DE2104X is not set
CONFIG_TULIP=m
# CONFIG_TULIP_MWI is not set
# CONFIG_TULIP_MMIO is not set
# CONFIG_TULIP_NAPI is not set
CONFIG_DE4X5=m
CONFIG_WINBOND_840=m
CONFIG_DM9102=m
CONFIG_ULI526X=m
CONFIG_PCMCIA_XIRCOM=m
# CONFIG_AT1700 is not set
CONFIG_DEPCA=m
CONFIG_HP100=m
CONFIG_NET_ISA=y
CONFIG_E2100=m
CONFIG_EWRK3=m
CONFIG_EEXPRESS=m
CONFIG_EEXPRESS_PRO=m
CONFIG_HPLAN_PLUS=m
CONFIG_HPLAN=m
CONFIG_LP486E=m
CONFIG_ETH16I=m
CONFIG_NE2000=m
# CONFIG_ZNET is not set
# CONFIG_SEEQ8005 is not set
CONFIG_NE2_MCA=m
CONFIG_IBMLANA=m
# CONFIG_IBM_NEW_EMAC_ZMII is not set
# CONFIG_IBM_NEW_EMAC_RGMII is not set
# CONFIG_IBM_NEW_EMAC_TAH is not set
# CONFIG_IBM_NEW_EMAC_EMAC4 is not set
CONFIG_NET_PCI=y
CONFIG_PCNET32=m
CONFIG_AMD8111_ETH=m
CONFIG_ADAPTEC_STARFIRE=m
# CONFIG_AC3200 is not set
CONFIG_APRICOT=m
CONFIG_B44=m
CONFIG_B44_PCI_AUTOSELECT=y
CONFIG_B44_PCICORE_AUTOSELECT=y
CONFIG_B44_PCI=y
CONFIG_FORCEDETH=m
# CONFIG_FORCEDETH_NAPI is not set
CONFIG_CS89x0=m
CONFIG_EEPRO100=m
CONFIG_E100=m
# CONFIG_LNE390 is not set
CONFIG_FEALNX=m
CONFIG_NATSEMI=m
CONFIG_NE2K_PCI=m
# CONFIG_NE3210 is not set
# CONFIG_ES3210 is not set
CONFIG_8139CP=m
CONFIG_8139TOO=m
# CONFIG_8139TOO_PIO is not set
CONFIG_8139TOO_TUNE_TWISTER=y
CONFIG_8139TOO_8129=y
# CONFIG_8139_OLD_RX_RESET is not set
# CONFIG_R6040 is not set
CONFIG_SIS900=m
CONFIG_EPIC100=m
CONFIG_SUNDANCE=m
CONFIG_SUNDANCE_MMIO=y
CONFIG_TLAN=m
CONFIG_VIA_RHINE=m
CONFIG_VIA_RHINE_MMIO=y
# CONFIG_SC92031 is not set
CONFIG_NET_POCKET=y
CONFIG_ATP=m
CONFIG_DE600=m
CONFIG_DE620=m
CONFIG_NETDEV_1000=y
CONFIG_ACENIC=m
# CONFIG_ACENIC_OMIT_TIGON_I is not set
CONFIG_DL2K=m
CONFIG_E1000=m
# CONFIG_E1000_DISABLE_PACKET_SPLIT is not set
# CONFIG_E1000E is not set
CONFIG_IP1000=m
CONFIG_IGB=m
# CONFIG_IGB_LRO is not set
CONFIG_NS83820=m
CONFIG_HAMACHI=m
CONFIG_YELLOWFIN=m
CONFIG_R8169=m
CONFIG_R8169_VLAN=y
CONFIG_SIS190=m
CONFIG_SKGE=m
CONFIG_SKY2=m
CONFIG_VIA_VELOCITY=m
CONFIG_TIGON3=m
CONFIG_BNX2=m
CONFIG_QLA3XXX=m
CONFIG_ATL1=m
# CONFIG_ATL1E is not set
CONFIG_NETDEV_10000=y
# CONFIG_CHELSIO_T1 is not set
CONFIG_CHELSIO_T3=m
CONFIG_IXGBE=m
# CONFIG_IXGB is not set
# CONFIG_S2IO is not set
CONFIG_MYRI10GE=m
CONFIG_NETXEN_NIC=m
CONFIG_NIU=m
# CONFIG_MLX4_CORE is not set
CONFIG_TEHUTI=m
CONFIG_BNX2X=m
CONFIG_SFC=m
# CONFIG_TR is not set
#
# Wireless LAN
#
# CONFIG_WLAN_PRE80211 is not set
CONFIG_WLAN_80211=y
CONFIG_PCMCIA_RAYCS=m
CONFIG_IPW2100=m
CONFIG_IPW2100_MONITOR=y
CONFIG_IPW2100_DEBUG=y
CONFIG_IPW2200=m
CONFIG_IPW2200_MONITOR=y
CONFIG_IPW2200_RADIOTAP=y
CONFIG_IPW2200_PROMISCUOUS=y
CONFIG_IPW2200_QOS=y
# CONFIG_IPW2200_DEBUG is not set
CONFIG_LIBERTAS=m
CONFIG_LIBERTAS_USB=m
CONFIG_LIBERTAS_CS=m
CONFIG_LIBERTAS_SDIO=m
# CONFIG_LIBERTAS_DEBUG is not set
CONFIG_AIRO=m
CONFIG_HERMES=m
CONFIG_PLX_HERMES=m
CONFIG_TMD_HERMES=m
CONFIG_NORTEL_HERMES=m
CONFIG_PCI_HERMES=m
CONFIG_PCMCIA_HERMES=m
CONFIG_PCMCIA_SPECTRUM=m
CONFIG_ATMEL=m
CONFIG_PCI_ATMEL=m
CONFIG_PCMCIA_ATMEL=m
CONFIG_AIRO_CS=m
CONFIG_PCMCIA_WL3501=m
CONFIG_PRISM54=m
CONFIG_USB_ZD1201=m
CONFIG_USB_NET_RNDIS_WLAN=m
CONFIG_RTL8180=m
CONFIG_RTL8187=m
CONFIG_ADM8211=m
CONFIG_MAC80211_HWSIM=m
CONFIG_P54_COMMON=m
CONFIG_P54_USB=m
CONFIG_P54_PCI=m
CONFIG_ATH5K=m
# CONFIG_ATH5K_DEBUG is not set
CONFIG_ATH9K=m
CONFIG_IWLWIFI=m
CONFIG_IWLCORE=m
# CONFIG_IWLWIFI_LEDS is not set
# CONFIG_IWLWIFI_RFKILL is not set
# CONFIG_IWLWIFI_DEBUG is not set
CONFIG_IWLAGN=m
# CONFIG_IWLAGN_SPECTRUM_MEASUREMENT is not set
# CONFIG_IWLAGN_LEDS is not set
# CONFIG_IWL4965 is not set
# CONFIG_IWL5000 is not set
CONFIG_IWL3945=m
# CONFIG_IWL3945_RFKILL is not set
# CONFIG_IWL3945_SPECTRUM_MEASUREMENT is not set
# CONFIG_IWL3945_LEDS is not set
# CONFIG_IWL3945_DEBUG is not set
CONFIG_HOSTAP=m
# CONFIG_HOSTAP_FIRMWARE is not set
CONFIG_HOSTAP_PLX=m
CONFIG_HOSTAP_PCI=m
CONFIG_HOSTAP_CS=m
CONFIG_B43=m
CONFIG_B43_PCI_AUTOSELECT=y
CONFIG_B43_PCICORE_AUTOSELECT=y
# CONFIG_B43_PCMCIA is not set
CONFIG_B43_LEDS=y
CONFIG_B43_RFKILL=y
# CONFIG_B43_DEBUG is not set
CONFIG_B43LEGACY=m
CONFIG_B43LEGACY_PCI_AUTOSELECT=y
CONFIG_B43LEGACY_PCICORE_AUTOSELECT=y
CONFIG_B43LEGACY_LEDS=y
CONFIG_B43LEGACY_RFKILL=y
CONFIG_B43LEGACY_DEBUG=y
CONFIG_B43LEGACY_DMA=y
CONFIG_B43LEGACY_PIO=y
CONFIG_B43LEGACY_DMA_AND_PIO_MODE=y
# CONFIG_B43LEGACY_DMA_MODE is not set
# CONFIG_B43LEGACY_PIO_MODE is not set
CONFIG_ZD1211RW=m
# CONFIG_ZD1211RW_DEBUG is not set
CONFIG_RT2X00=m
CONFIG_RT2X00_LIB=m
CONFIG_RT2X00_LIB_PCI=m
CONFIG_RT2X00_LIB_USB=m
CONFIG_RT2X00_LIB_FIRMWARE=y
CONFIG_RT2400PCI=m
# CONFIG_RT2400PCI_RFKILL is not set
# CONFIG_RT2400PCI_LEDS is not set
CONFIG_RT2500PCI=m
# CONFIG_RT2500PCI_RFKILL is not set
# CONFIG_RT2500PCI_LEDS is not set
CONFIG_RT61PCI=m
# CONFIG_RT61PCI_RFKILL is not set
# CONFIG_RT61PCI_LEDS is not set
CONFIG_RT2500USB=m
# CONFIG_RT2500USB_LEDS is not set
CONFIG_RT73USB=m
# CONFIG_RT73USB_LEDS is not set
# CONFIG_RT2X00_DEBUG is not set
#
# USB Network Adapters
#
CONFIG_USB_CATC=m
CONFIG_USB_KAWETH=m
CONFIG_USB_PEGASUS=m
CONFIG_USB_RTL8150=m
CONFIG_USB_USBNET=m
CONFIG_USB_NET_AX8817X=m
CONFIG_USB_NET_CDCETHER=m
CONFIG_USB_NET_DM9601=m
CONFIG_USB_NET_GL620A=m
CONFIG_USB_NET_NET1080=m
CONFIG_USB_NET_PLUSB=m
CONFIG_USB_NET_MCS7830=m
CONFIG_USB_NET_RNDIS_HOST=m
CONFIG_USB_NET_CDC_SUBSET=m
CONFIG_USB_ALI_M5632=y
CONFIG_USB_AN2720=y
CONFIG_USB_BELKIN=y
CONFIG_USB_ARMLINUX=y
# CONFIG_USB_EPSON2888 is not set
# CONFIG_USB_KC2190 is not set
CONFIG_USB_NET_ZAURUS=m
CONFIG_USB_HSO=m
CONFIG_NET_PCMCIA=y
CONFIG_PCMCIA_3C589=m
CONFIG_PCMCIA_3C574=m
CONFIG_PCMCIA_FMVJ18X=m
CONFIG_PCMCIA_PCNET=m
CONFIG_PCMCIA_NMCLAN=m
CONFIG_PCMCIA_SMC91C92=m
CONFIG_PCMCIA_XIRC2PS=m
CONFIG_PCMCIA_AXNET=m
CONFIG_ARCNET_COM20020_CS=m
# CONFIG_WAN is not set
# CONFIG_FDDI is not set
# CONFIG_HIPPI is not set
# CONFIG_PLIP is not set
CONFIG_PPP=m
# CONFIG_PPP_MULTILINK is not set
# CONFIG_PPP_FILTER is not set
CONFIG_PPP_ASYNC=m
CONFIG_PPP_SYNC_TTY=m
CONFIG_PPP_DEFLATE=m
CONFIG_PPP_BSDCOMP=m
# CONFIG_PPP_MPPE is not set
CONFIG_PPPOE=m
CONFIG_PPPOL2TP=m
CONFIG_SLIP=m
CONFIG_SLIP_COMPRESSED=y
CONFIG_SLHC=m
CONFIG_SLIP_SMART=y
CONFIG_SLIP_MODE_SLIP6=y
CONFIG_NET_FC=y
# CONFIG_NETCONSOLE is not set
# CONFIG_NETPOLL is not set
# CONFIG_NET_POLL_CONTROLLER is not set
CONFIG_VIRTIO_NET=m
# CONFIG_ISDN is not set
# CONFIG_PHONE is not set
#
# Input device support
#
CONFIG_INPUT=y
CONFIG_INPUT_FF_MEMLESS=m
CONFIG_INPUT_POLLDEV=m
#
# Userland interfaces
#
CONFIG_INPUT_MOUSEDEV=y
CONFIG_INPUT_MOUSEDEV_PSAUX=y
CONFIG_INPUT_MOUSEDEV_SCREEN_X=1024
CONFIG_INPUT_MOUSEDEV_SCREEN_Y=768
CONFIG_INPUT_JOYDEV=m
CONFIG_INPUT_EVDEV=m
# CONFIG_INPUT_EVBUG is not set
#
# Input Device Drivers
#
CONFIG_INPUT_KEYBOARD=y
CONFIG_KEYBOARD_ATKBD=y
CONFIG_KEYBOARD_SUNKBD=m
CONFIG_KEYBOARD_LKKBD=m
CONFIG_KEYBOARD_XTKBD=m
CONFIG_KEYBOARD_NEWTON=m
CONFIG_KEYBOARD_STOWAWAY=m
CONFIG_INPUT_MOUSE=y
CONFIG_MOUSE_PS2=y
CONFIG_MOUSE_PS2_ALPS=y
CONFIG_MOUSE_PS2_LOGIPS2PP=y
CONFIG_MOUSE_PS2_SYNAPTICS=y
CONFIG_MOUSE_PS2_LIFEBOOK=y
CONFIG_MOUSE_PS2_TRACKPOINT=y
CONFIG_MOUSE_PS2_TOUCHKIT=y
CONFIG_MOUSE_SERIAL=m
CONFIG_MOUSE_APPLETOUCH=m
CONFIG_MOUSE_BCM5974=m
# CONFIG_MOUSE_INPORT is not set
# CONFIG_MOUSE_LOGIBM is not set
# CONFIG_MOUSE_PC110PAD is not set
CONFIG_MOUSE_VSXXXAA=m
CONFIG_INPUT_JOYSTICK=y
# CONFIG_JOYSTICK_ANALOG is not set
# CONFIG_JOYSTICK_A3D is not set
# CONFIG_JOYSTICK_ADI is not set
# CONFIG_JOYSTICK_COBRA is not set
# CONFIG_JOYSTICK_GF2K is not set
# CONFIG_JOYSTICK_GRIP is not set
# CONFIG_JOYSTICK_GRIP_MP is not set
# CONFIG_JOYSTICK_GUILLEMOT is not set
# CONFIG_JOYSTICK_INTERACT is not set
# CONFIG_JOYSTICK_SIDEWINDER is not set
# CONFIG_JOYSTICK_TMDC is not set
# CONFIG_JOYSTICK_IFORCE is not set
# CONFIG_JOYSTICK_WARRIOR is not set
# CONFIG_JOYSTICK_MAGELLAN is not set
# CONFIG_JOYSTICK_SPACEORB is not set
# CONFIG_JOYSTICK_SPACEBALL is not set
# CONFIG_JOYSTICK_STINGER is not set
# CONFIG_JOYSTICK_TWIDJOY is not set
CONFIG_JOYSTICK_ZHENHUA=m
# CONFIG_JOYSTICK_DB9 is not set
# CONFIG_JOYSTICK_GAMECON is not set
# CONFIG_JOYSTICK_TURBOGRAFX is not set
# CONFIG_JOYSTICK_JOYDUMP is not set
CONFIG_JOYSTICK_XPAD=m
# CONFIG_JOYSTICK_XPAD_FF is not set
CONFIG_JOYSTICK_XPAD_LEDS=y
CONFIG_INPUT_TABLET=y
CONFIG_TABLET_USB_ACECAD=m
CONFIG_TABLET_USB_AIPTEK=m
CONFIG_TABLET_USB_GTCO=m
CONFIG_TABLET_USB_KBTAB=m
CONFIG_TABLET_USB_WACOM=m
CONFIG_INPUT_TOUCHSCREEN=y
CONFIG_TOUCHSCREEN_FUJITSU=m
# CONFIG_TOUCHSCREEN_GUNZE is not set
# CONFIG_TOUCHSCREEN_ELO is not set
# CONFIG_TOUCHSCREEN_MTOUCH is not set
CONFIG_TOUCHSCREEN_INEXIO=m
# CONFIG_TOUCHSCREEN_MK712 is not set
CONFIG_TOUCHSCREEN_HTCPEN=m
CONFIG_TOUCHSCREEN_PENMOUNT=m
CONFIG_TOUCHSCREEN_TOUCHRIGHT=m
CONFIG_TOUCHSCREEN_TOUCHWIN=m
CONFIG_TOUCHSCREEN_UCB1400=m
CONFIG_TOUCHSCREEN_WM97XX=m
CONFIG_TOUCHSCREEN_WM9705=y
CONFIG_TOUCHSCREEN_WM9712=y
CONFIG_TOUCHSCREEN_WM9713=y
CONFIG_TOUCHSCREEN_USB_COMPOSITE=m
CONFIG_TOUCHSCREEN_USB_EGALAX=y
CONFIG_TOUCHSCREEN_USB_PANJIT=y
CONFIG_TOUCHSCREEN_USB_3M=y
CONFIG_TOUCHSCREEN_USB_ITM=y
CONFIG_TOUCHSCREEN_USB_ETURBO=y
CONFIG_TOUCHSCREEN_USB_GUNZE=y
CONFIG_TOUCHSCREEN_USB_DMC_TSC10=y
CONFIG_TOUCHSCREEN_USB_IRTOUCH=y
CONFIG_TOUCHSCREEN_USB_IDEALTEK=y
CONFIG_TOUCHSCREEN_USB_GENERAL_TOUCH=y
CONFIG_TOUCHSCREEN_USB_GOTOP=y
CONFIG_TOUCHSCREEN_TOUCHIT213=m
CONFIG_INPUT_MISC=y
CONFIG_INPUT_PCSPKR=m
CONFIG_INPUT_APANEL=m
CONFIG_INPUT_WISTRON_BTNS=m
CONFIG_INPUT_ATLAS_BTNS=m
CONFIG_INPUT_ATI_REMOTE=m
CONFIG_INPUT_ATI_REMOTE2=m
CONFIG_INPUT_KEYSPAN_REMOTE=m
CONFIG_INPUT_POWERMATE=m
CONFIG_INPUT_YEALINK=m
CONFIG_INPUT_UINPUT=m
#
# Hardware I/O ports
#
CONFIG_SERIO=y
CONFIG_SERIO_I8042=y
CONFIG_SERIO_SERPORT=m
CONFIG_SERIO_CT82C710=m
CONFIG_SERIO_PARKBD=m
CONFIG_SERIO_PCIPS2=m
CONFIG_SERIO_LIBPS2=y
CONFIG_SERIO_RAW=m
CONFIG_GAMEPORT=m
CONFIG_GAMEPORT_NS558=m
CONFIG_GAMEPORT_L4=m
CONFIG_GAMEPORT_EMU10K1=m
CONFIG_GAMEPORT_FM801=m
#
# Character devices
#
CONFIG_VT=y
CONFIG_CONSOLE_TRANSLATIONS=y
CONFIG_VT_CONSOLE=y
CONFIG_HW_CONSOLE=y
# CONFIG_VT_HW_CONSOLE_BINDING is not set
CONFIG_DEVKMEM=y
CONFIG_SERIAL_NONSTANDARD=y
CONFIG_COMPUTONE=m
CONFIG_ROCKETPORT=m
CONFIG_CYCLADES=m
# CONFIG_CYZ_INTR is not set
CONFIG_DIGIEPCA=m
CONFIG_ESPSERIAL=m
CONFIG_MOXA_INTELLIO=m
CONFIG_MOXA_SMARTIO=m
# CONFIG_ISI is not set
CONFIG_SYNCLINK=m
CONFIG_SYNCLINKMP=m
CONFIG_SYNCLINK_GT=m
CONFIG_N_HDLC=m
CONFIG_RISCOM8=m
CONFIG_SPECIALIX=m
CONFIG_STALDRV=y
CONFIG_STALLION=m
CONFIG_ISTALLION=m
CONFIG_NOZOMI=m
#
# Serial drivers
#
CONFIG_SERIAL_8250=y
CONFIG_SERIAL_8250_CONSOLE=y
CONFIG_FIX_EARLYCON_MEM=y
CONFIG_SERIAL_8250_PCI=y
CONFIG_SERIAL_8250_PNP=y
CONFIG_SERIAL_8250_CS=m
CONFIG_SERIAL_8250_NR_UARTS=4
CONFIG_SERIAL_8250_RUNTIME_UARTS=4
# CONFIG_SERIAL_8250_EXTENDED is not set
CONFIG_SERIAL_8250_MCA=m
#
# Non-8250 serial port support
#
CONFIG_SERIAL_CORE=y
CONFIG_SERIAL_CORE_CONSOLE=y
CONFIG_SERIAL_JSM=m
CONFIG_UNIX98_PTYS=y
CONFIG_LEGACY_PTYS=y
CONFIG_LEGACY_PTY_COUNT=256
CONFIG_PRINTER=m
CONFIG_LP_CONSOLE=y
CONFIG_PPDEV=m
CONFIG_HVC_DRIVER=y
CONFIG_VIRTIO_CONSOLE=m
CONFIG_IPMI_HANDLER=m
# CONFIG_IPMI_PANIC_EVENT is not set
CONFIG_IPMI_DEVICE_INTERFACE=m
CONFIG_IPMI_SI=m
CONFIG_IPMI_WATCHDOG=m
CONFIG_IPMI_POWEROFF=m
CONFIG_HW_RANDOM=m
CONFIG_HW_RANDOM_INTEL=m
CONFIG_HW_RANDOM_AMD=m
CONFIG_HW_RANDOM_GEODE=m
CONFIG_HW_RANDOM_VIA=m
CONFIG_HW_RANDOM_VIRTIO=m
CONFIG_NVRAM=m
CONFIG_DTLK=m
CONFIG_R3964=m
CONFIG_APPLICOM=m
# CONFIG_SONYPI is not set
#
# PCMCIA character devices
#
CONFIG_SYNCLINK_CS=m
CONFIG_CARDMAN_4000=m
CONFIG_CARDMAN_4040=m
CONFIG_IPWIRELESS=m
CONFIG_MWAVE=m
CONFIG_SCx200_GPIO=m
CONFIG_PC8736x_GPIO=m
CONFIG_NSC_GPIO=m
CONFIG_CS5535_GPIO=m
CONFIG_RAW_DRIVER=m
CONFIG_MAX_RAW_DEVS=256
# CONFIG_HPET is not set
CONFIG_HANGCHECK_TIMER=m
# CONFIG_TCG_TPM is not set
CONFIG_TELCLOCK=m
CONFIG_DEVPORT=y
CONFIG_I2C=m
CONFIG_I2C_BOARDINFO=y
CONFIG_I2C_CHARDEV=m
CONFIG_I2C_HELPER_AUTO=y
CONFIG_I2C_ALGOBIT=m
CONFIG_I2C_ALGOPCF=m
CONFIG_I2C_ALGOPCA=m
#
# I2C Hardware Bus support
#
#
# PC SMBus host controller drivers
#
CONFIG_I2C_ALI1535=m
CONFIG_I2C_ALI1563=m
CONFIG_I2C_ALI15X3=m
CONFIG_I2C_AMD756=m
CONFIG_I2C_AMD756_S4882=m
CONFIG_I2C_AMD8111=m
CONFIG_I2C_I801=m
CONFIG_I2C_ISCH=m
CONFIG_I2C_PIIX4=m
CONFIG_I2C_NFORCE2=m
CONFIG_I2C_NFORCE2_S4985=m
CONFIG_I2C_SIS5595=m
CONFIG_I2C_SIS630=m
CONFIG_I2C_SIS96X=m
CONFIG_I2C_VIA=m
CONFIG_I2C_VIAPRO=m
#
# I2C system bus drivers (mostly embedded / system-on-chip)
#
CONFIG_I2C_OCORES=m
CONFIG_I2C_SIMTEC=m
#
# External I2C/SMBus adapter drivers
#
CONFIG_I2C_PARPORT=m
CONFIG_I2C_PARPORT_LIGHT=m
CONFIG_I2C_TAOS_EVM=m
CONFIG_I2C_TINY_USB=m
#
# Graphics adapter I2C/DDC channel drivers
#
CONFIG_I2C_VOODOO3=m
#
# Other I2C/SMBus bus drivers
#
CONFIG_I2C_ELEKTOR=m
CONFIG_I2C_PCA_ISA=m
CONFIG_I2C_PCA_PLATFORM=m
CONFIG_I2C_STUB=m
CONFIG_SCx200_I2C=m
CONFIG_SCx200_I2C_SCL=12
CONFIG_SCx200_I2C_SDA=13
CONFIG_SCx200_ACB=m
#
# Miscellaneous I2C Chip support
#
CONFIG_DS1682=m
CONFIG_AT24=m
CONFIG_SENSORS_EEPROM=m
CONFIG_SENSORS_PCF8574=m
CONFIG_PCF8575=m
CONFIG_SENSORS_PCA9539=m
CONFIG_SENSORS_PCF8591=m
CONFIG_SENSORS_MAX6875=m
CONFIG_SENSORS_TSL2550=m
# CONFIG_I2C_DEBUG_CORE is not set
# CONFIG_I2C_DEBUG_ALGO is not set
# CONFIG_I2C_DEBUG_BUS is not set
# CONFIG_I2C_DEBUG_CHIP is not set
# CONFIG_SPI is not set
CONFIG_ARCH_WANT_OPTIONAL_GPIOLIB=y
# CONFIG_GPIOLIB is not set
CONFIG_W1=m
CONFIG_W1_CON=y
#
# 1-wire Bus Masters
#
CONFIG_W1_MASTER_MATROX=m
CONFIG_W1_MASTER_DS2490=m
CONFIG_W1_MASTER_DS2482=m
#
# 1-wire Slaves
#
CONFIG_W1_SLAVE_THERM=m
CONFIG_W1_SLAVE_SMEM=m
CONFIG_W1_SLAVE_DS2433=m
# CONFIG_W1_SLAVE_DS2433_CRC is not set
CONFIG_W1_SLAVE_DS2760=m
CONFIG_POWER_SUPPLY=y
# CONFIG_POWER_SUPPLY_DEBUG is not set
CONFIG_PDA_POWER=m
CONFIG_BATTERY_DS2760=m
CONFIG_BATTERY_OLPC=m
CONFIG_HWMON=m
CONFIG_HWMON_VID=m
CONFIG_SENSORS_ABITUGURU=m
CONFIG_SENSORS_ABITUGURU3=m
CONFIG_SENSORS_AD7414=m
CONFIG_SENSORS_AD7418=m
CONFIG_SENSORS_ADM1021=m
CONFIG_SENSORS_ADM1025=m
CONFIG_SENSORS_ADM1026=m
CONFIG_SENSORS_ADM1029=m
CONFIG_SENSORS_ADM1031=m
CONFIG_SENSORS_ADM9240=m
CONFIG_SENSORS_ADT7470=m
CONFIG_SENSORS_ADT7473=m
CONFIG_SENSORS_K8TEMP=m
CONFIG_SENSORS_ASB100=m
CONFIG_SENSORS_ATXP1=m
CONFIG_SENSORS_DS1621=m
CONFIG_SENSORS_I5K_AMB=m
CONFIG_SENSORS_F71805F=m
CONFIG_SENSORS_F71882FG=m
CONFIG_SENSORS_F75375S=m
CONFIG_SENSORS_FSCHER=m
CONFIG_SENSORS_FSCPOS=m
CONFIG_SENSORS_FSCHMD=m
CONFIG_SENSORS_GL518SM=m
CONFIG_SENSORS_GL520SM=m
CONFIG_SENSORS_CORETEMP=m
CONFIG_SENSORS_IBMAEM=m
CONFIG_SENSORS_IBMPEX=m
CONFIG_SENSORS_IT87=m
CONFIG_SENSORS_LM63=m
CONFIG_SENSORS_LM75=m
CONFIG_SENSORS_LM77=m
CONFIG_SENSORS_LM78=m
CONFIG_SENSORS_LM80=m
CONFIG_SENSORS_LM83=m
CONFIG_SENSORS_LM85=m
CONFIG_SENSORS_LM87=m
CONFIG_SENSORS_LM90=m
CONFIG_SENSORS_LM92=m
CONFIG_SENSORS_LM93=m
CONFIG_SENSORS_MAX1619=m
CONFIG_SENSORS_MAX6650=m
CONFIG_SENSORS_PC87360=m
CONFIG_SENSORS_PC87427=m
CONFIG_SENSORS_SIS5595=m
CONFIG_SENSORS_DME1737=m
CONFIG_SENSORS_SMSC47M1=m
CONFIG_SENSORS_SMSC47M192=m
CONFIG_SENSORS_SMSC47B397=m
CONFIG_SENSORS_ADS7828=m
CONFIG_SENSORS_THMC50=m
CONFIG_SENSORS_VIA686A=m
CONFIG_SENSORS_VT1211=m
CONFIG_SENSORS_VT8231=m
CONFIG_SENSORS_W83781D=m
CONFIG_SENSORS_W83791D=m
CONFIG_SENSORS_W83792D=m
CONFIG_SENSORS_W83793=m
CONFIG_SENSORS_W83L785TS=m
CONFIG_SENSORS_W83L786NG=m
CONFIG_SENSORS_W83627HF=m
CONFIG_SENSORS_W83627EHF=m
CONFIG_SENSORS_HDAPS=m
CONFIG_SENSORS_APPLESMC=m
# CONFIG_HWMON_DEBUG_CHIP is not set
CONFIG_THERMAL=m
# CONFIG_THERMAL_HWMON is not set
# CONFIG_WATCHDOG is not set
#
# Sonics Silicon Backplane
#
CONFIG_SSB_POSSIBLE=y
CONFIG_SSB=m
CONFIG_SSB_SPROM=y
CONFIG_SSB_PCIHOST_POSSIBLE=y
CONFIG_SSB_PCIHOST=y
CONFIG_SSB_B43_PCI_BRIDGE=y
CONFIG_SSB_PCMCIAHOST_POSSIBLE=y
# CONFIG_SSB_PCMCIAHOST is not set
# CONFIG_SSB_DEBUG is not set
CONFIG_SSB_DRIVER_PCICORE_POSSIBLE=y
CONFIG_SSB_DRIVER_PCICORE=y
#
# Multifunction device drivers
#
# CONFIG_MFD_CORE is not set
CONFIG_MFD_SM501=m
CONFIG_HTC_PASIC3=m
# CONFIG_MFD_TMIO is not set
#
# Multimedia devices
#
#
# Multimedia core support
#
CONFIG_VIDEO_DEV=m
CONFIG_VIDEO_V4L2_COMMON=m
CONFIG_VIDEO_ALLOW_V4L1=y
CONFIG_VIDEO_V4L1_COMPAT=y
CONFIG_DVB_CORE=m
CONFIG_VIDEO_MEDIA=m
#
# Multimedia drivers
#
CONFIG_VIDEO_SAA7146=m
CONFIG_VIDEO_SAA7146_VV=m
# CONFIG_MEDIA_ATTACH is not set
CONFIG_MEDIA_TUNER=m
# CONFIG_MEDIA_TUNER_CUSTOMIZE is not set
CONFIG_MEDIA_TUNER_SIMPLE=m
CONFIG_MEDIA_TUNER_TDA8290=m
CONFIG_MEDIA_TUNER_TDA18271=m
CONFIG_MEDIA_TUNER_TDA9887=m
CONFIG_MEDIA_TUNER_TEA5761=m
CONFIG_MEDIA_TUNER_TEA5767=m
CONFIG_MEDIA_TUNER_MT20XX=m
CONFIG_MEDIA_TUNER_XC2028=m
CONFIG_MEDIA_TUNER_XC5000=m
CONFIG_MEDIA_TUNER_MXL5007T=m
CONFIG_VIDEO_V4L2=m
CONFIG_VIDEO_V4L1=m
CONFIG_VIDEOBUF_GEN=m
CONFIG_VIDEOBUF_DMA_SG=m
CONFIG_VIDEOBUF_VMALLOC=m
CONFIG_VIDEOBUF_DMA_CONTIG=m
CONFIG_VIDEOBUF_DVB=m
CONFIG_VIDEO_BTCX=m
CONFIG_VIDEO_IR=m
CONFIG_VIDEO_TVEEPROM=m
CONFIG_VIDEO_TUNER=m
CONFIG_VIDEO_CAPTURE_DRIVERS=y
# CONFIG_VIDEO_ADV_DEBUG is not set
CONFIG_VIDEO_HELPER_CHIPS_AUTO=y
CONFIG_VIDEO_IR_I2C=m
CONFIG_VIDEO_TVAUDIO=m
CONFIG_VIDEO_TDA7432=m
CONFIG_VIDEO_TDA9840=m
CONFIG_VIDEO_TDA9875=m
CONFIG_VIDEO_TEA6415C=m
CONFIG_VIDEO_TEA6420=m
CONFIG_VIDEO_MSP3400=m
CONFIG_VIDEO_CS5345=m
CONFIG_VIDEO_CS53L32A=m
CONFIG_VIDEO_M52790=m
CONFIG_VIDEO_WM8775=m
CONFIG_VIDEO_WM8739=m
CONFIG_VIDEO_VP27SMPX=m
CONFIG_VIDEO_BT819=m
CONFIG_VIDEO_BT856=m
CONFIG_VIDEO_KS0127=m
CONFIG_VIDEO_OV7670=m
CONFIG_VIDEO_SAA7110=m
CONFIG_VIDEO_SAA7111=m
CONFIG_VIDEO_SAA7114=m
CONFIG_VIDEO_SAA711X=m
CONFIG_VIDEO_SAA717X=m
CONFIG_VIDEO_TVP5150=m
CONFIG_VIDEO_VPX3220=m
CONFIG_VIDEO_CX25840=m
CONFIG_VIDEO_CX2341X=m
CONFIG_VIDEO_SAA7127=m
CONFIG_VIDEO_SAA7185=m
CONFIG_VIDEO_ADV7170=m
CONFIG_VIDEO_ADV7175=m
CONFIG_VIDEO_UPD64031A=m
CONFIG_VIDEO_UPD64083=m
CONFIG_VIDEO_VIVI=m
CONFIG_VIDEO_BT848=m
CONFIG_VIDEO_BT848_DVB=y
CONFIG_VIDEO_SAA6588=m
CONFIG_VIDEO_PMS=m
CONFIG_VIDEO_BWQCAM=m
CONFIG_VIDEO_CQCAM=m
CONFIG_VIDEO_W9966=m
CONFIG_VIDEO_CPIA=m
CONFIG_VIDEO_CPIA_PP=m
CONFIG_VIDEO_CPIA_USB=m
CONFIG_VIDEO_CPIA2=m
CONFIG_VIDEO_SAA5246A=m
CONFIG_VIDEO_SAA5249=m
CONFIG_TUNER_3036=m
# CONFIG_VIDEO_STRADIS is not set
CONFIG_VIDEO_ZORAN=m
CONFIG_VIDEO_ZORAN_DC30=m
CONFIG_VIDEO_ZORAN_ZR36060=m
CONFIG_VIDEO_ZORAN_BUZ=m
CONFIG_VIDEO_ZORAN_DC10=m
CONFIG_VIDEO_ZORAN_LML33=m
CONFIG_VIDEO_ZORAN_LML33R10=m
CONFIG_VIDEO_ZORAN_AVS6EYES=m
CONFIG_VIDEO_MEYE=m
CONFIG_VIDEO_SAA7134=m
CONFIG_VIDEO_SAA7134_ALSA=m
CONFIG_VIDEO_SAA7134_DVB=m
CONFIG_VIDEO_MXB=m
CONFIG_VIDEO_DPC=m
CONFIG_VIDEO_HEXIUM_ORION=m
CONFIG_VIDEO_HEXIUM_GEMINI=m
CONFIG_VIDEO_CX88=m
CONFIG_VIDEO_CX88_ALSA=m
CONFIG_VIDEO_CX88_BLACKBIRD=m
CONFIG_VIDEO_CX88_DVB=m
CONFIG_VIDEO_CX88_VP3054=m
CONFIG_VIDEO_CX23885=m
CONFIG_VIDEO_AU0828=m
CONFIG_VIDEO_IVTV=m
CONFIG_VIDEO_FB_IVTV=m
CONFIG_VIDEO_CX18=m
CONFIG_VIDEO_CAFE_CCIC=m
CONFIG_V4L_USB_DRIVERS=y
CONFIG_USB_VIDEO_CLASS=m
CONFIG_USB_VIDEO_CLASS_INPUT_EVDEV=y
CONFIG_USB_GSPCA=m
CONFIG_VIDEO_PVRUSB2=m
CONFIG_VIDEO_PVRUSB2_SYSFS=y
CONFIG_VIDEO_PVRUSB2_DVB=y
# CONFIG_VIDEO_PVRUSB2_DEBUGIFC is not set
CONFIG_VIDEO_EM28XX=m
CONFIG_VIDEO_EM28XX_ALSA=m
CONFIG_VIDEO_EM28XX_DVB=m
CONFIG_VIDEO_USBVISION=m
CONFIG_VIDEO_USBVIDEO=m
# CONFIG_USB_VICAM is not set
CONFIG_USB_IBMCAM=m
CONFIG_USB_KONICAWC=m
CONFIG_USB_QUICKCAM_MESSENGER=m
CONFIG_USB_ET61X251=m
CONFIG_VIDEO_OVCAMCHIP=m
CONFIG_USB_W9968CF=m
CONFIG_USB_OV511=m
CONFIG_USB_SE401=m
CONFIG_USB_SN9C102=m
CONFIG_USB_STV680=m
CONFIG_USB_ZC0301=m
CONFIG_USB_PWC=m
# CONFIG_USB_PWC_DEBUG is not set
CONFIG_USB_ZR364XX=m
CONFIG_USB_STKWEBCAM=m
CONFIG_USB_S2255=m
CONFIG_SOC_CAMERA=m
CONFIG_SOC_CAMERA_MT9M001=m
CONFIG_SOC_CAMERA_MT9V022=m
CONFIG_SOC_CAMERA_PLATFORM=m
CONFIG_VIDEO_SH_MOBILE_CEU=m
CONFIG_RADIO_ADAPTERS=y
CONFIG_RADIO_CADET=m
CONFIG_RADIO_RTRACK=m
CONFIG_RADIO_RTRACK2=m
CONFIG_RADIO_AZTECH=m
CONFIG_RADIO_GEMTEK=m
CONFIG_RADIO_GEMTEK_PCI=m
CONFIG_RADIO_MAXIRADIO=m
CONFIG_RADIO_MAESTRO=m
CONFIG_RADIO_SF16FMI=m
CONFIG_RADIO_SF16FMR2=m
CONFIG_RADIO_TERRATEC=m
CONFIG_RADIO_TRUST=m
CONFIG_RADIO_TYPHOON=m
CONFIG_RADIO_TYPHOON_PROC_FS=y
CONFIG_RADIO_ZOLTRIX=m
CONFIG_USB_DSBR=m
CONFIG_USB_SI470X=m
CONFIG_DVB_CAPTURE_DRIVERS=y
#
# Supported SAA7146 based PCI Adapters
#
CONFIG_TTPCI_EEPROM=m
CONFIG_DVB_AV7110=m
CONFIG_DVB_AV7110_OSD=y
CONFIG_DVB_BUDGET_CORE=m
CONFIG_DVB_BUDGET=m
CONFIG_DVB_BUDGET_CI=m
CONFIG_DVB_BUDGET_AV=m
CONFIG_DVB_BUDGET_PATCH=m
#
# Supported USB Adapters
#
CONFIG_DVB_USB=m
CONFIG_DVB_USB_DEBUG=y
CONFIG_DVB_USB_A800=m
CONFIG_DVB_USB_DIBUSB_MB=m
CONFIG_DVB_USB_DIBUSB_MB_FAULTY=y
CONFIG_DVB_USB_DIBUSB_MC=m
CONFIG_DVB_USB_DIB0700=m
CONFIG_DVB_USB_UMT_010=m
CONFIG_DVB_USB_CXUSB=m
CONFIG_DVB_USB_M920X=m
CONFIG_DVB_USB_GL861=m
CONFIG_DVB_USB_AU6610=m
CONFIG_DVB_USB_DIGITV=m
CONFIG_DVB_USB_VP7045=m
CONFIG_DVB_USB_VP702X=m
CONFIG_DVB_USB_GP8PSK=m
CONFIG_DVB_USB_NOVA_T_USB2=m
CONFIG_DVB_USB_TTUSB2=m
CONFIG_DVB_USB_DTT200U=m
CONFIG_DVB_USB_OPERA1=m
CONFIG_DVB_USB_AF9005=m
CONFIG_DVB_USB_AF9005_REMOTE=m
CONFIG_DVB_USB_DW2102=m
CONFIG_DVB_USB_ANYSEE=m
CONFIG_DVB_TTUSB_BUDGET=m
CONFIG_DVB_TTUSB_DEC=m
CONFIG_DVB_CINERGYT2=m
CONFIG_DVB_CINERGYT2_TUNING=y
CONFIG_DVB_CINERGYT2_STREAM_URB_COUNT=32
CONFIG_DVB_CINERGYT2_STREAM_BUF_SIZE=512
CONFIG_DVB_CINERGYT2_QUERY_INTERVAL=250
# CONFIG_DVB_CINERGYT2_ENABLE_RC_INPUT_DEVICE is not set
CONFIG_DVB_SIANO_SMS1XXX=m
CONFIG_DVB_SIANO_SMS1XXX_SMS_IDS=y
#
# Supported FlexCopII (B2C2) Adapters
#
CONFIG_DVB_B2C2_FLEXCOP=m
CONFIG_DVB_B2C2_FLEXCOP_PCI=m
CONFIG_DVB_B2C2_FLEXCOP_USB=m
# CONFIG_DVB_B2C2_FLEXCOP_DEBUG is not set
#
# Supported BT878 Adapters
#
CONFIG_DVB_BT8XX=m
#
# Supported Pluto2 Adapters
#
CONFIG_DVB_PLUTO2=m
#
# Supported DVB Frontends
#
#
# Customise DVB Frontends
#
CONFIG_DVB_FE_CUSTOMISE=y
#
# DVB-S (satellite) frontends
#
CONFIG_DVB_CX24110=m
CONFIG_DVB_CX24123=m
CONFIG_DVB_MT312=m
CONFIG_DVB_S5H1420=m
CONFIG_DVB_STV0299=m
CONFIG_DVB_TDA8083=m
CONFIG_DVB_TDA10086=m
CONFIG_DVB_VES1X93=m
CONFIG_DVB_TUNER_ITD1000=m
CONFIG_DVB_TDA826X=m
CONFIG_DVB_TUA6100=m
#
# DVB-T (terrestrial) frontends
#
CONFIG_DVB_SP8870=m
CONFIG_DVB_SP887X=m
CONFIG_DVB_CX22700=m
CONFIG_DVB_CX22702=m
CONFIG_DVB_DRX397XD=m
CONFIG_DVB_L64781=m
CONFIG_DVB_TDA1004X=m
CONFIG_DVB_NXT6000=m
CONFIG_DVB_MT352=m
CONFIG_DVB_ZL10353=m
CONFIG_DVB_DIB3000MB=m
CONFIG_DVB_DIB3000MC=m
CONFIG_DVB_DIB7000M=m
CONFIG_DVB_DIB7000P=m
CONFIG_DVB_TDA10048=m
#
# DVB-C (cable) frontends
#
CONFIG_DVB_VES1820=m
CONFIG_DVB_TDA10021=m
CONFIG_DVB_TDA10023=m
CONFIG_DVB_STV0297=m
#
# ATSC (North American/Korean Terrestrial/Cable DTV) frontends
#
CONFIG_DVB_NXT200X=m
CONFIG_DVB_OR51211=m
CONFIG_DVB_OR51132=m
CONFIG_DVB_BCM3510=m
CONFIG_DVB_LGDT330X=m
CONFIG_DVB_S5H1409=m
CONFIG_DVB_AU8522=m
CONFIG_DVB_S5H1411=m
#
# Digital terrestrial only tuners/PLL
#
CONFIG_DVB_PLL=m
CONFIG_DVB_TUNER_DIB0070=m
#
# SEC control devices for DVB-S
#
CONFIG_DVB_LNBP21=m
CONFIG_DVB_ISL6405=m
CONFIG_DVB_ISL6421=m
CONFIG_DAB=y
CONFIG_USB_DABUSB=m
#
# Graphics support
#
CONFIG_AGP=m
CONFIG_AGP_ALI=m
CONFIG_AGP_ATI=m
CONFIG_AGP_AMD=m
CONFIG_AGP_AMD64=m
CONFIG_AGP_INTEL=m
CONFIG_AGP_NVIDIA=m
CONFIG_AGP_SIS=m
CONFIG_AGP_SWORKS=m
CONFIG_AGP_VIA=m
CONFIG_AGP_EFFICEON=m
CONFIG_DRM=m
CONFIG_DRM_TDFX=m
CONFIG_DRM_R128=m
CONFIG_DRM_RADEON=m
CONFIG_DRM_I810=m
CONFIG_DRM_I830=m
CONFIG_DRM_I915=m
CONFIG_DRM_MGA=m
CONFIG_DRM_SIS=m
CONFIG_DRM_VIA=m
CONFIG_DRM_SAVAGE=m
CONFIG_VGASTATE=m
CONFIG_VIDEO_OUTPUT_CONTROL=m
CONFIG_FB=y
CONFIG_FIRMWARE_EDID=y
CONFIG_FB_DDC=m
CONFIG_FB_CFB_FILLRECT=y
CONFIG_FB_CFB_COPYAREA=y
CONFIG_FB_CFB_IMAGEBLIT=y
# CONFIG_FB_CFB_REV_PIXELS_IN_BYTE is not set
CONFIG_FB_SYS_FILLRECT=m
CONFIG_FB_SYS_COPYAREA=m
CONFIG_FB_SYS_IMAGEBLIT=m
# CONFIG_FB_FOREIGN_ENDIAN is not set
CONFIG_FB_SYS_FOPS=m
CONFIG_FB_DEFERRED_IO=y
CONFIG_FB_HECUBA=m
CONFIG_FB_SVGALIB=m
# CONFIG_FB_MACMODES is not set
CONFIG_FB_BACKLIGHT=y
CONFIG_FB_MODE_HELPERS=y
CONFIG_FB_TILEBLITTING=y
#
# Frame buffer hardware drivers
#
CONFIG_FB_CIRRUS=m
CONFIG_FB_PM2=m
# CONFIG_FB_PM2_FIFO_DISCONNECT is not set
CONFIG_FB_CYBER2000=m
CONFIG_FB_ARC=m
# CONFIG_FB_ASILIANT is not set
# CONFIG_FB_IMSTT is not set
CONFIG_FB_VGA16=m
CONFIG_FB_UVESA=m
CONFIG_FB_VESA=y
# CONFIG_FB_EFI is not set
CONFIG_FB_N411=m
CONFIG_FB_HGA=m
# CONFIG_FB_HGA_ACCEL is not set
CONFIG_FB_S1D13XXX=m
CONFIG_FB_NVIDIA=m
CONFIG_FB_NVIDIA_I2C=y
# CONFIG_FB_NVIDIA_DEBUG is not set
CONFIG_FB_NVIDIA_BACKLIGHT=y
CONFIG_FB_RIVA=m
CONFIG_FB_RIVA_I2C=y
# CONFIG_FB_RIVA_DEBUG is not set
CONFIG_FB_RIVA_BACKLIGHT=y
CONFIG_FB_I810=m
# CONFIG_FB_I810_GTF is not set
CONFIG_FB_LE80578=m
CONFIG_FB_CARILLO_RANCH=m
CONFIG_FB_INTEL=m
# CONFIG_FB_INTEL_DEBUG is not set
CONFIG_FB_INTEL_I2C=y
CONFIG_FB_MATROX=m
CONFIG_FB_MATROX_MILLENIUM=y
CONFIG_FB_MATROX_MYSTIQUE=y
CONFIG_FB_MATROX_G=y
CONFIG_FB_MATROX_I2C=m
CONFIG_FB_MATROX_MAVEN=m
CONFIG_FB_MATROX_MULTIHEAD=y
CONFIG_FB_RADEON=m
CONFIG_FB_RADEON_I2C=y
CONFIG_FB_RADEON_BACKLIGHT=y
# CONFIG_FB_RADEON_DEBUG is not set
CONFIG_FB_ATY128=m
CONFIG_FB_ATY128_BACKLIGHT=y
CONFIG_FB_ATY=m
CONFIG_FB_ATY_CT=y
CONFIG_FB_ATY_GENERIC_LCD=y
CONFIG_FB_ATY_GX=y
CONFIG_FB_ATY_BACKLIGHT=y
CONFIG_FB_S3=m
CONFIG_FB_SAVAGE=m
CONFIG_FB_SAVAGE_I2C=y
CONFIG_FB_SAVAGE_ACCEL=y
CONFIG_FB_SIS=m
CONFIG_FB_SIS_300=y
CONFIG_FB_SIS_315=y
CONFIG_FB_NEOMAGIC=m
CONFIG_FB_KYRO=m
CONFIG_FB_3DFX=m
# CONFIG_FB_3DFX_ACCEL is not set
CONFIG_FB_VOODOO1=m
CONFIG_FB_VT8623=m
CONFIG_FB_CYBLA=m
CONFIG_FB_TRIDENT=m
CONFIG_FB_TRIDENT_ACCEL=y
CONFIG_FB_ARK=m
CONFIG_FB_PM3=m
CONFIG_FB_CARMINE=m
CONFIG_FB_CARMINE_DRAM_EVAL=y
# CONFIG_CARMINE_DRAM_CUSTOM is not set
# CONFIG_FB_GEODE is not set
CONFIG_FB_SM501=m
# CONFIG_FB_VIRTUAL is not set
CONFIG_BACKLIGHT_LCD_SUPPORT=y
CONFIG_LCD_CLASS_DEVICE=m
# CONFIG_LCD_ILI9320 is not set
CONFIG_LCD_PLATFORM=m
CONFIG_BACKLIGHT_CLASS_DEVICE=y
CONFIG_BACKLIGHT_CORGI=m
CONFIG_BACKLIGHT_PROGEAR=m
CONFIG_BACKLIGHT_CARILLO_RANCH=m
CONFIG_BACKLIGHT_MBP_NVIDIA=m
#
# Display device support
#
CONFIG_DISPLAY_SUPPORT=m
#
# Display hardware drivers
#
#
# Console display driver support
#
CONFIG_VGA_CONSOLE=y
CONFIG_VGACON_SOFT_SCROLLBACK=y
CONFIG_VGACON_SOFT_SCROLLBACK_SIZE=64
CONFIG_VIDEO_SELECT=y
# CONFIG_MDA_CONSOLE is not set
CONFIG_DUMMY_CONSOLE=y
CONFIG_FRAMEBUFFER_CONSOLE=y
CONFIG_FRAMEBUFFER_CONSOLE_DETECT_PRIMARY=y
CONFIG_FRAMEBUFFER_CONSOLE_ROTATION=y
CONFIG_FONTS=y
CONFIG_FONT_8x8=y
CONFIG_FONT_8x16=y
# CONFIG_FONT_6x11 is not set
# CONFIG_FONT_7x14 is not set
CONFIG_FONT_PEARL_8x8=y
CONFIG_FONT_ACORN_8x8=y
CONFIG_FONT_MINI_4x6=y
# CONFIG_FONT_SUN8x16 is not set
# CONFIG_FONT_SUN12x22 is not set
# CONFIG_FONT_10x18 is not set
CONFIG_LOGO=y
CONFIG_LOGO_LINUX_MONO=y
CONFIG_LOGO_LINUX_VGA16=y
CONFIG_LOGO_LINUX_CLUT224=y
CONFIG_SOUND=m
CONFIG_SND=m
CONFIG_SND_TIMER=m
CONFIG_SND_PCM=m
CONFIG_SND_HWDEP=m
CONFIG_SND_RAWMIDI=m
CONFIG_SND_SEQUENCER=m
CONFIG_SND_SEQ_DUMMY=m
CONFIG_SND_OSSEMUL=y
CONFIG_SND_MIXER_OSS=m
CONFIG_SND_PCM_OSS=m
CONFIG_SND_PCM_OSS_PLUGINS=y
CONFIG_SND_SEQUENCER_OSS=y
# CONFIG_SND_DYNAMIC_MINORS is not set
CONFIG_SND_SUPPORT_OLD_API=y
CONFIG_SND_VERBOSE_PROCFS=y
CONFIG_SND_VERBOSE_PRINTK=y
# CONFIG_SND_DEBUG is not set
CONFIG_SND_VMASTER=y
CONFIG_SND_MPU401_UART=m
CONFIG_SND_OPL3_LIB=m
CONFIG_SND_OPL4_LIB=m
CONFIG_SND_VX_LIB=m
CONFIG_SND_AC97_CODEC=m
CONFIG_SND_DRIVERS=y
CONFIG_SND_DUMMY=m
CONFIG_SND_VIRMIDI=m
CONFIG_SND_MTPAV=m
CONFIG_SND_MTS64=m
CONFIG_SND_SERIAL_U16550=m
CONFIG_SND_MPU401=m
CONFIG_SND_PORTMAN2X4=m
# CONFIG_SND_AC97_POWER_SAVE is not set
CONFIG_SND_AD1848_LIB=m
CONFIG_SND_CS4231_LIB=m
CONFIG_SND_SB_COMMON=m
CONFIG_SND_SB8_DSP=m
CONFIG_SND_SB16_DSP=m
CONFIG_SND_ISA=y
CONFIG_SND_ADLIB=m
CONFIG_SND_AD1816A=m
CONFIG_SND_AD1848=m
CONFIG_SND_ALS100=m
CONFIG_SND_AZT2320=m
CONFIG_SND_CMI8330=m
CONFIG_SND_CS4231=m
CONFIG_SND_CS4232=m
CONFIG_SND_CS4236=m
CONFIG_SND_DT019X=m
CONFIG_SND_ES968=m
CONFIG_SND_ES1688=m
CONFIG_SND_ES18XX=m
CONFIG_SND_SC6000=m
CONFIG_SND_GUSCLASSIC=m
CONFIG_SND_GUSEXTREME=m
CONFIG_SND_GUSMAX=m
CONFIG_SND_INTERWAVE=m
CONFIG_SND_INTERWAVE_STB=m
CONFIG_SND_OPL3SA2=m
CONFIG_SND_OPTI92X_AD1848=m
CONFIG_SND_OPTI92X_CS4231=m
CONFIG_SND_OPTI93X=m
CONFIG_SND_MIRO=m
CONFIG_SND_SB8=m
CONFIG_SND_SB16=m
CONFIG_SND_SBAWE=m
CONFIG_SND_SB16_CSP=y
CONFIG_SND_SGALAXY=m
CONFIG_SND_SSCAPE=m
CONFIG_SND_WAVEFRONT=m
CONFIG_SND_WAVEFRONT_FIRMWARE_IN_KERNEL=y
CONFIG_SND_PCI=y
CONFIG_SND_AD1889=m
CONFIG_SND_ALS300=m
CONFIG_SND_ALS4000=m
CONFIG_SND_ALI5451=m
CONFIG_SND_ATIIXP=m
CONFIG_SND_ATIIXP_MODEM=m
CONFIG_SND_AU8810=m
CONFIG_SND_AU8820=m
CONFIG_SND_AU8830=m
CONFIG_SND_AW2=m
CONFIG_SND_AZT3328=m
CONFIG_SND_BT87X=m
CONFIG_SND_BT87X_OVERCLOCK=y
CONFIG_SND_CA0106=m
CONFIG_SND_CMIPCI=m
CONFIG_SND_OXYGEN_LIB=m
CONFIG_SND_OXYGEN=m
CONFIG_SND_CS4281=m
CONFIG_SND_CS46XX=m
CONFIG_SND_CS46XX_NEW_DSP=y
CONFIG_SND_CS5530=m
CONFIG_SND_CS5535AUDIO=m
CONFIG_SND_DARLA20=m
CONFIG_SND_GINA20=m
CONFIG_SND_LAYLA20=m
CONFIG_SND_DARLA24=m
CONFIG_SND_GINA24=m
CONFIG_SND_LAYLA24=m
CONFIG_SND_MONA=m
CONFIG_SND_MIA=m
CONFIG_SND_ECHO3G=m
CONFIG_SND_INDIGO=m
CONFIG_SND_INDIGOIO=m
CONFIG_SND_INDIGODJ=m
CONFIG_SND_EMU10K1=m
CONFIG_SND_EMU10K1X=m
CONFIG_SND_ENS1370=m
CONFIG_SND_ENS1371=m
CONFIG_SND_ES1938=m
CONFIG_SND_ES1968=m
CONFIG_SND_FM801=m
CONFIG_SND_FM801_TEA575X_BOOL=y
CONFIG_SND_FM801_TEA575X=m
CONFIG_SND_HDA_INTEL=m
# CONFIG_SND_HDA_HWDEP is not set
CONFIG_SND_HDA_CODEC_REALTEK=y
CONFIG_SND_HDA_CODEC_ANALOG=y
CONFIG_SND_HDA_CODEC_SIGMATEL=y
CONFIG_SND_HDA_CODEC_VIA=y
CONFIG_SND_HDA_CODEC_ATIHDMI=y
CONFIG_SND_HDA_CODEC_CONEXANT=y
CONFIG_SND_HDA_CODEC_CMEDIA=y
CONFIG_SND_HDA_CODEC_SI3054=y
CONFIG_SND_HDA_GENERIC=y
# CONFIG_SND_HDA_POWER_SAVE is not set
CONFIG_SND_HDSP=m
CONFIG_SND_HDSPM=m
CONFIG_SND_HIFIER=m
CONFIG_SND_ICE1712=m
CONFIG_SND_ICE1724=m
CONFIG_SND_INTEL8X0=m
CONFIG_SND_INTEL8X0M=m
CONFIG_SND_KORG1212=m
CONFIG_SND_MAESTRO3=m
CONFIG_SND_MIXART=m
CONFIG_SND_NM256=m
CONFIG_SND_PCXHR=m
CONFIG_SND_RIPTIDE=m
CONFIG_SND_RME32=m
CONFIG_SND_RME96=m
CONFIG_SND_RME9652=m
CONFIG_SND_SIS7019=m
CONFIG_SND_SONICVIBES=m
CONFIG_SND_TRIDENT=m
CONFIG_SND_VIA82XX=m
CONFIG_SND_VIA82XX_MODEM=m
CONFIG_SND_VIRTUOSO=m
CONFIG_SND_VX222=m
CONFIG_SND_YMFPCI=m
CONFIG_SND_USB=y
CONFIG_SND_USB_AUDIO=m
CONFIG_SND_USB_USX2Y=m
CONFIG_SND_USB_CAIAQ=m
CONFIG_SND_USB_CAIAQ_INPUT=y
CONFIG_SND_PCMCIA=y
CONFIG_SND_VXPOCKET=m
CONFIG_SND_PDAUDIOCF=m
CONFIG_SND_SOC=m
# CONFIG_SOUND_PRIME is not set
CONFIG_AC97_BUS=m
CONFIG_HID_SUPPORT=y
CONFIG_HID=m
CONFIG_HID_DEBUG=y
# CONFIG_HIDRAW is not set
#
# USB Input Devices
#
CONFIG_USB_HID=m
# CONFIG_USB_HIDINPUT_POWERBOOK is not set
# CONFIG_HID_FF is not set
CONFIG_USB_HIDDEV=y
#
# USB HID Boot Protocol drivers
#
# CONFIG_USB_KBD is not set
# CONFIG_USB_MOUSE is not set
CONFIG_USB_SUPPORT=y
CONFIG_USB_ARCH_HAS_HCD=y
CONFIG_USB_ARCH_HAS_OHCI=y
CONFIG_USB_ARCH_HAS_EHCI=y
CONFIG_USB=y
# CONFIG_USB_DEBUG is not set
# CONFIG_USB_ANNOUNCE_NEW_DEVICES is not set
#
# Miscellaneous USB options
#
CONFIG_USB_DEVICEFS=y
CONFIG_USB_DEVICE_CLASS=y
# CONFIG_USB_DYNAMIC_MINORS is not set
CONFIG_USB_SUSPEND=y
# CONFIG_USB_OTG is not set
CONFIG_USB_MON=y
#
# USB Host Controller Drivers
#
CONFIG_USB_C67X00_HCD=m
CONFIG_USB_EHCI_HCD=m
# CONFIG_USB_EHCI_ROOT_HUB_TT is not set
# CONFIG_USB_EHCI_TT_NEWSCHED is not set
CONFIG_USB_ISP116X_HCD=m
CONFIG_USB_ISP1760_HCD=m
CONFIG_USB_OHCI_HCD=m
# CONFIG_USB_OHCI_HCD_SSB is not set
# CONFIG_USB_OHCI_BIG_ENDIAN_DESC is not set
# CONFIG_USB_OHCI_BIG_ENDIAN_MMIO is not set
CONFIG_USB_OHCI_LITTLE_ENDIAN=y
CONFIG_USB_UHCI_HCD=m
CONFIG_USB_U132_HCD=m
CONFIG_USB_SL811_HCD=m
CONFIG_USB_SL811_CS=m
CONFIG_USB_R8A66597_HCD=m
# CONFIG_USB_GADGET_MUSB_HDRC is not set
#
# USB Device Class drivers
#
CONFIG_USB_ACM=m
CONFIG_USB_PRINTER=m
CONFIG_USB_WDM=m
#
# NOTE: USB_STORAGE enables SCSI, and 'SCSI disk support'
#
#
# may also be needed; see USB_STORAGE Help for more information
#
CONFIG_USB_STORAGE=m
# CONFIG_USB_STORAGE_DEBUG is not set
CONFIG_USB_STORAGE_DATAFAB=y
CONFIG_USB_STORAGE_FREECOM=y
CONFIG_USB_STORAGE_ISD200=y
CONFIG_USB_STORAGE_DPCM=y
CONFIG_USB_STORAGE_USBAT=y
CONFIG_USB_STORAGE_SDDR09=y
CONFIG_USB_STORAGE_SDDR55=y
CONFIG_USB_STORAGE_JUMPSHOT=y
CONFIG_USB_STORAGE_ALAUDA=y
CONFIG_USB_STORAGE_ONETOUCH=y
CONFIG_USB_STORAGE_KARMA=y
CONFIG_USB_STORAGE_CYPRESS_ATACB=y
# CONFIG_USB_LIBUSUAL is not set
#
# USB Imaging devices
#
CONFIG_USB_MDC800=m
CONFIG_USB_MICROTEK=m
#
# USB port drivers
#
CONFIG_USB_USS720=m
CONFIG_USB_SERIAL=m
CONFIG_USB_EZUSB=y
CONFIG_USB_SERIAL_GENERIC=y
CONFIG_USB_SERIAL_AIRCABLE=m
CONFIG_USB_SERIAL_ARK3116=m
CONFIG_USB_SERIAL_BELKIN=m
CONFIG_USB_SERIAL_CH341=m
CONFIG_USB_SERIAL_WHITEHEAT=m
CONFIG_USB_SERIAL_DIGI_ACCELEPORT=m
CONFIG_USB_SERIAL_CP2101=m
CONFIG_USB_SERIAL_CYPRESS_M8=m
CONFIG_USB_SERIAL_EMPEG=m
CONFIG_USB_SERIAL_FTDI_SIO=m
CONFIG_USB_SERIAL_FUNSOFT=m
CONFIG_USB_SERIAL_VISOR=m
CONFIG_USB_SERIAL_IPAQ=m
CONFIG_USB_SERIAL_IR=m
CONFIG_USB_SERIAL_EDGEPORT=m
CONFIG_USB_SERIAL_EDGEPORT_TI=m
CONFIG_USB_SERIAL_GARMIN=m
CONFIG_USB_SERIAL_IPW=m
CONFIG_USB_SERIAL_IUU=m
CONFIG_USB_SERIAL_KEYSPAN_PDA=m
CONFIG_USB_SERIAL_KEYSPAN=m
CONFIG_USB_SERIAL_KEYSPAN_MPR=y
CONFIG_USB_SERIAL_KEYSPAN_USA28=y
CONFIG_USB_SERIAL_KEYSPAN_USA28X=y
CONFIG_USB_SERIAL_KEYSPAN_USA28XA=y
CONFIG_USB_SERIAL_KEYSPAN_USA28XB=y
CONFIG_USB_SERIAL_KEYSPAN_USA19=y
CONFIG_USB_SERIAL_KEYSPAN_USA18X=y
CONFIG_USB_SERIAL_KEYSPAN_USA19W=y
CONFIG_USB_SERIAL_KEYSPAN_USA19QW=y
CONFIG_USB_SERIAL_KEYSPAN_USA19QI=y
CONFIG_USB_SERIAL_KEYSPAN_USA49W=y
CONFIG_USB_SERIAL_KEYSPAN_USA49WLC=y
CONFIG_USB_SERIAL_KLSI=m
CONFIG_USB_SERIAL_KOBIL_SCT=m
CONFIG_USB_SERIAL_MCT_U232=m
CONFIG_USB_SERIAL_MOS7720=m
CONFIG_USB_SERIAL_MOS7840=m
CONFIG_USB_SERIAL_MOTOROLA=m
CONFIG_USB_SERIAL_NAVMAN=m
CONFIG_USB_SERIAL_PL2303=m
CONFIG_USB_SERIAL_OTI6858=m
CONFIG_USB_SERIAL_SPCP8X5=m
CONFIG_USB_SERIAL_HP4X=m
CONFIG_USB_SERIAL_SAFE=m
# CONFIG_USB_SERIAL_SAFE_PADDED is not set
CONFIG_USB_SERIAL_SIERRAWIRELESS=m
CONFIG_USB_SERIAL_TI=m
CONFIG_USB_SERIAL_CYBERJACK=m
CONFIG_USB_SERIAL_XIRCOM=m
CONFIG_USB_SERIAL_OPTION=m
CONFIG_USB_SERIAL_OMNINET=m
# CONFIG_USB_SERIAL_DEBUG is not set
#
# USB Miscellaneous drivers
#
CONFIG_USB_EMI62=m
CONFIG_USB_EMI26=m
CONFIG_USB_ADUTUX=m
CONFIG_USB_RIO500=m
CONFIG_USB_LEGOTOWER=m
CONFIG_USB_LCD=m
CONFIG_USB_BERRY_CHARGE=m
CONFIG_USB_LED=m
CONFIG_USB_CYPRESS_CY7C63=m
CONFIG_USB_CYTHERM=m
CONFIG_USB_PHIDGET=m
CONFIG_USB_PHIDGETKIT=m
CONFIG_USB_PHIDGETMOTORCONTROL=m
CONFIG_USB_PHIDGETSERVO=m
CONFIG_USB_IDMOUSE=m
CONFIG_USB_FTDI_ELAN=m
CONFIG_USB_APPLEDISPLAY=m
CONFIG_USB_SISUSBVGA=m
CONFIG_USB_SISUSBVGA_CON=y
CONFIG_USB_LD=m
CONFIG_USB_TRANCEVIBRATOR=m
CONFIG_USB_IOWARRIOR=m
# CONFIG_USB_TEST is not set
CONFIG_USB_ISIGHTFW=m
CONFIG_USB_GADGET=m
# CONFIG_USB_GADGET_DEBUG_FILES is not set
CONFIG_USB_GADGET_SELECTED=y
CONFIG_USB_GADGET_AMD5536UDC=y
CONFIG_USB_AMD5536UDC=m
# CONFIG_USB_GADGET_ATMEL_USBA is not set
# CONFIG_USB_GADGET_FSL_USB2 is not set
# CONFIG_USB_GADGET_NET2280 is not set
# CONFIG_USB_GADGET_PXA25X is not set
# CONFIG_USB_GADGET_M66592 is not set
# CONFIG_USB_GADGET_PXA27X is not set
# CONFIG_USB_GADGET_GOKU is not set
# CONFIG_USB_GADGET_LH7A40X is not set
# CONFIG_USB_GADGET_OMAP is not set
# CONFIG_USB_GADGET_S3C2410 is not set
# CONFIG_USB_GADGET_AT91 is not set
# CONFIG_USB_GADGET_DUMMY_HCD is not set
CONFIG_USB_GADGET_DUALSPEED=y
# CONFIG_USB_ZERO is not set
# CONFIG_USB_ETH is not set
# CONFIG_USB_GADGETFS is not set
# CONFIG_USB_FILE_STORAGE is not set
# CONFIG_USB_G_SERIAL is not set
# CONFIG_USB_MIDI_GADGET is not set
# CONFIG_USB_G_PRINTER is not set
# CONFIG_USB_CDC_COMPOSITE is not set
CONFIG_MMC=m
# CONFIG_MMC_DEBUG is not set
# CONFIG_MMC_UNSAFE_RESUME is not set
#
# MMC/SD Card Drivers
#
CONFIG_MMC_BLOCK=m
CONFIG_MMC_BLOCK_BOUNCE=y
CONFIG_SDIO_UART=m
CONFIG_MMC_TEST=m
#
# MMC/SD Host Controller Drivers
#
CONFIG_MMC_SDHCI=m
CONFIG_MMC_SDHCI_PCI=m
CONFIG_MMC_RICOH_MMC=m
CONFIG_MMC_WBSD=m
CONFIG_MMC_TIFM_SD=m
CONFIG_MMC_SDRICOH_CS=m
CONFIG_MEMSTICK=m
# CONFIG_MEMSTICK_DEBUG is not set
#
# MemoryStick drivers
#
# CONFIG_MEMSTICK_UNSAFE_RESUME is not set
CONFIG_MSPRO_BLOCK=m
#
# MemoryStick Host Controller Drivers
#
# CONFIG_MEMSTICK_TIFM_MS is not set
# CONFIG_MEMSTICK_JMICRON_38X is not set
CONFIG_NEW_LEDS=y
CONFIG_LEDS_CLASS=m
#
# LED drivers
#
CONFIG_LEDS_NET48XX=m
CONFIG_LEDS_WRAP=m
CONFIG_LEDS_PCA9532=m
CONFIG_LEDS_CLEVO_MAIL=m
CONFIG_LEDS_PCA955X=m
#
# LED Triggers
#
CONFIG_LEDS_TRIGGERS=y
CONFIG_LEDS_TRIGGER_TIMER=m
CONFIG_LEDS_TRIGGER_IDE_DISK=y
CONFIG_LEDS_TRIGGER_HEARTBEAT=m
CONFIG_LEDS_TRIGGER_DEFAULT_ON=m
# CONFIG_ACCESSIBILITY is not set
# CONFIG_INFINIBAND is not set
# CONFIG_EDAC is not set
CONFIG_RTC_LIB=m
CONFIG_RTC_CLASS=m
#
# RTC interfaces
#
CONFIG_RTC_INTF_SYSFS=y
CONFIG_RTC_INTF_PROC=y
CONFIG_RTC_INTF_DEV=y
CONFIG_RTC_INTF_DEV_UIE_EMUL=y
CONFIG_RTC_DRV_TEST=m
#
# I2C RTC drivers
#
CONFIG_RTC_DRV_DS1307=m
CONFIG_RTC_DRV_DS1374=m
CONFIG_RTC_DRV_DS1672=m
CONFIG_RTC_DRV_MAX6900=m
CONFIG_RTC_DRV_RS5C372=m
CONFIG_RTC_DRV_ISL1208=m
CONFIG_RTC_DRV_X1205=m
CONFIG_RTC_DRV_PCF8563=m
CONFIG_RTC_DRV_PCF8583=m
CONFIG_RTC_DRV_M41T80=m
# CONFIG_RTC_DRV_M41T80_WDT is not set
CONFIG_RTC_DRV_S35390A=m
CONFIG_RTC_DRV_FM3130=m
#
# SPI RTC drivers
#
#
# Platform RTC drivers
#
CONFIG_RTC_DRV_CMOS=m
CONFIG_RTC_DRV_DS1511=m
CONFIG_RTC_DRV_DS1553=m
CONFIG_RTC_DRV_DS1742=m
CONFIG_RTC_DRV_STK17TA8=m
CONFIG_RTC_DRV_M48T86=m
CONFIG_RTC_DRV_M48T59=m
CONFIG_RTC_DRV_V3020=m
#
# on-CPU RTC drivers
#
# CONFIG_DMADEVICES is not set
CONFIG_AUXDISPLAY=y
CONFIG_KS0108=m
CONFIG_KS0108_PORT=0x378
CONFIG_KS0108_DELAY=2
CONFIG_CFAG12864B=m
CONFIG_CFAG12864B_RATE=20
CONFIG_UIO=m
CONFIG_UIO_CIF=m
CONFIG_UIO_PDRV=m
CONFIG_UIO_PDRV_GENIRQ=m
CONFIG_UIO_SMX=m
#
# Firmware Drivers
#
# CONFIG_EDD is not set
CONFIG_FIRMWARE_MEMMAP=y
CONFIG_DELL_RBU=m
CONFIG_DCDBAS=m
CONFIG_DMIID=y
# CONFIG_ISCSI_IBFT_FIND is not set
#
# File systems
#
CONFIG_EXT2_FS=y
CONFIG_EXT2_FS_XATTR=y
CONFIG_EXT2_FS_POSIX_ACL=y
CONFIG_EXT2_FS_SECURITY=y
CONFIG_EXT2_FS_XIP=y
CONFIG_FS_XIP=y
CONFIG_EXT3_FS=y
CONFIG_EXT3_FS_XATTR=y
CONFIG_EXT3_FS_POSIX_ACL=y
CONFIG_EXT3_FS_SECURITY=y
CONFIG_EXT4DEV_FS=m
CONFIG_EXT4DEV_FS_XATTR=y
# CONFIG_EXT4DEV_FS_POSIX_ACL is not set
# CONFIG_EXT4DEV_FS_SECURITY is not set
CONFIG_JBD=y
CONFIG_JBD2=m
CONFIG_FS_MBCACHE=y
CONFIG_REISERFS_FS=m
# CONFIG_REISERFS_CHECK is not set
# CONFIG_REISERFS_PROC_INFO is not set
# CONFIG_REISERFS_FS_XATTR is not set
CONFIG_JFS_FS=m
# CONFIG_JFS_POSIX_ACL is not set
# CONFIG_JFS_SECURITY is not set
# CONFIG_JFS_DEBUG is not set
# CONFIG_JFS_STATISTICS is not set
CONFIG_FS_POSIX_ACL=y
CONFIG_XFS_FS=m
# CONFIG_XFS_QUOTA is not set
# CONFIG_XFS_POSIX_ACL is not set
# CONFIG_XFS_RT is not set
# CONFIG_XFS_DEBUG is not set
# CONFIG_OCFS2_FS is not set
CONFIG_DNOTIFY=y
CONFIG_INOTIFY=y
CONFIG_INOTIFY_USER=y
# CONFIG_QUOTA is not set
CONFIG_AUTOFS_FS=m
CONFIG_AUTOFS4_FS=m
CONFIG_FUSE_FS=y
#
# CD-ROM/DVD Filesystems
#
CONFIG_ISO9660_FS=m
CONFIG_JOLIET=y
# CONFIG_ZISOFS is not set
CONFIG_UDF_FS=m
CONFIG_UDF_NLS=y
#
# DOS/FAT/NT Filesystems
#
CONFIG_FAT_FS=y
CONFIG_MSDOS_FS=y
CONFIG_VFAT_FS=y
CONFIG_FAT_DEFAULT_CODEPAGE=437
CONFIG_FAT_DEFAULT_IOCHARSET="iso8859-1"
CONFIG_NTFS_FS=m
# CONFIG_NTFS_DEBUG is not set
CONFIG_NTFS_RW=y
#
# Pseudo filesystems
#
CONFIG_PROC_FS=y
# CONFIG_PROC_KCORE is not set
CONFIG_PROC_SYSCTL=y
CONFIG_SYSFS=y
CONFIG_TMPFS=y
# CONFIG_TMPFS_POSIX_ACL is not set
# CONFIG_HUGETLBFS is not set
# CONFIG_HUGETLB_PAGE is not set
# CONFIG_CONFIGFS_FS is not set
#
# Miscellaneous filesystems
#
# CONFIG_ADFS_FS is not set
# CONFIG_AFFS_FS is not set
# CONFIG_ECRYPT_FS is not set
# CONFIG_HFS_FS is not set
CONFIG_HFSPLUS_FS=m
# CONFIG_BEFS_FS is not set
# CONFIG_BFS_FS is not set
# CONFIG_EFS_FS is not set
CONFIG_JFFS2_FS=m
CONFIG_JFFS2_FS_DEBUG=0
CONFIG_JFFS2_FS_WRITEBUFFER=y
# CONFIG_JFFS2_FS_WBUF_VERIFY is not set
# CONFIG_JFFS2_SUMMARY is not set
# CONFIG_JFFS2_FS_XATTR is not set
# CONFIG_JFFS2_COMPRESSION_OPTIONS is not set
CONFIG_JFFS2_ZLIB=y
# CONFIG_JFFS2_LZO is not set
CONFIG_JFFS2_RTIME=y
# CONFIG_JFFS2_RUBIN is not set
CONFIG_CRAMFS=m
CONFIG_VXFS_FS=m
CONFIG_MINIX_FS=m
CONFIG_OMFS_FS=m
CONFIG_HPFS_FS=m
CONFIG_QNX4FS_FS=m
CONFIG_ROMFS_FS=m
CONFIG_SYSV_FS=m
CONFIG_UFS_FS=m
# CONFIG_UFS_FS_WRITE is not set
# CONFIG_UFS_DEBUG is not set
CONFIG_NETWORK_FILESYSTEMS=y
CONFIG_NFS_FS=m
CONFIG_NFS_V3=y
# CONFIG_NFS_V3_ACL is not set
# CONFIG_NFS_V4 is not set
CONFIG_NFSD=m
CONFIG_NFSD_V3=y
# CONFIG_NFSD_V3_ACL is not set
# CONFIG_NFSD_V4 is not set
CONFIG_LOCKD=m
CONFIG_LOCKD_V4=y
CONFIG_EXPORTFS=m
CONFIG_NFS_COMMON=y
CONFIG_SUNRPC=m
# CONFIG_RPCSEC_GSS_KRB5 is not set
# CONFIG_RPCSEC_GSS_SPKM3 is not set
CONFIG_SMB_FS=m
# CONFIG_SMB_NLS_DEFAULT is not set
CONFIG_CIFS=m
# CONFIG_CIFS_STATS is not set
# CONFIG_CIFS_WEAK_PW_HASH is not set
# CONFIG_CIFS_UPCALL is not set
# CONFIG_CIFS_XATTR is not set
# CONFIG_CIFS_DEBUG2 is not set
# CONFIG_CIFS_EXPERIMENTAL is not set
CONFIG_NCP_FS=m
# CONFIG_NCPFS_PACKET_SIGNING is not set
# CONFIG_NCPFS_IOCTL_LOCKING is not set
# CONFIG_NCPFS_STRONG is not set
# CONFIG_NCPFS_NFS_NS is not set
# CONFIG_NCPFS_OS2_NS is not set
# CONFIG_NCPFS_SMALLDOS is not set
# CONFIG_NCPFS_NLS is not set
# CONFIG_NCPFS_EXTRAS is not set
CONFIG_CODA_FS=m
# CONFIG_AFS_FS is not set
#
# Partition Types
#
CONFIG_PARTITION_ADVANCED=y
# CONFIG_ACORN_PARTITION is not set
# CONFIG_OSF_PARTITION is not set
# CONFIG_AMIGA_PARTITION is not set
# CONFIG_ATARI_PARTITION is not set
# CONFIG_MAC_PARTITION is not set
CONFIG_MSDOS_PARTITION=y
CONFIG_BSD_DISKLABEL=y
CONFIG_MINIX_SUBPARTITION=y
CONFIG_SOLARIS_X86_PARTITION=y
CONFIG_UNIXWARE_DISKLABEL=y
CONFIG_LDM_PARTITION=y
# CONFIG_LDM_DEBUG is not set
# CONFIG_SGI_PARTITION is not set
# CONFIG_ULTRIX_PARTITION is not set
CONFIG_SUN_PARTITION=y
# CONFIG_KARMA_PARTITION is not set
# CONFIG_EFI_PARTITION is not set
CONFIG_SYSV68_PARTITION=y
CONFIG_NLS=y
CONFIG_NLS_DEFAULT="iso8859-1"
CONFIG_NLS_CODEPAGE_437=m
CONFIG_NLS_CODEPAGE_737=m
CONFIG_NLS_CODEPAGE_775=m
CONFIG_NLS_CODEPAGE_850=m
CONFIG_NLS_CODEPAGE_852=m
CONFIG_NLS_CODEPAGE_855=m
CONFIG_NLS_CODEPAGE_857=m
CONFIG_NLS_CODEPAGE_860=m
CONFIG_NLS_CODEPAGE_861=m
CONFIG_NLS_CODEPAGE_862=m
CONFIG_NLS_CODEPAGE_863=m
CONFIG_NLS_CODEPAGE_864=m
CONFIG_NLS_CODEPAGE_865=m
CONFIG_NLS_CODEPAGE_866=m
CONFIG_NLS_CODEPAGE_869=m
CONFIG_NLS_CODEPAGE_936=m
CONFIG_NLS_CODEPAGE_950=m
CONFIG_NLS_CODEPAGE_932=m
CONFIG_NLS_CODEPAGE_949=m
CONFIG_NLS_CODEPAGE_874=m
CONFIG_NLS_ISO8859_8=m
CONFIG_NLS_CODEPAGE_1250=m
CONFIG_NLS_CODEPAGE_1251=m
# CONFIG_NLS_ASCII is not set
CONFIG_NLS_ISO8859_1=m
CONFIG_NLS_ISO8859_2=m
CONFIG_NLS_ISO8859_3=m
CONFIG_NLS_ISO8859_4=m
CONFIG_NLS_ISO8859_5=m
CONFIG_NLS_ISO8859_6=m
CONFIG_NLS_ISO8859_7=m
CONFIG_NLS_ISO8859_9=m
CONFIG_NLS_ISO8859_13=m
CONFIG_NLS_ISO8859_14=m
CONFIG_NLS_ISO8859_15=m
CONFIG_NLS_KOI8_R=m
CONFIG_NLS_KOI8_U=m
CONFIG_NLS_UTF8=m
# CONFIG_DLM is not set
#
# Kernel hacking
#
CONFIG_TRACE_IRQFLAGS_SUPPORT=y
# CONFIG_PRINTK_TIME is not set
CONFIG_ENABLE_WARN_DEPRECATED=y
CONFIG_ENABLE_MUST_CHECK=y
CONFIG_FRAME_WARN=1024
# CONFIG_MAGIC_SYSRQ is not set
CONFIG_UNUSED_SYMBOLS=y
# CONFIG_DEBUG_FS is not set
# CONFIG_HEADERS_CHECK is not set
# CONFIG_DEBUG_KERNEL is not set
CONFIG_DEBUG_BUGVERBOSE=y
CONFIG_DEBUG_MEMORY_INIT=y
# CONFIG_LATENCYTOP is not set
# CONFIG_SYSCTL_SYSCALL_CHECK is not set
CONFIG_HAVE_FTRACE=y
CONFIG_HAVE_DYNAMIC_FTRACE=y
# CONFIG_FTRACE is not set
# CONFIG_IRQSOFF_TRACER is not set
# CONFIG_PREEMPT_TRACER is not set
# CONFIG_SYSPROF_TRACER is not set
# CONFIG_SCHED_TRACER is not set
# CONFIG_CONTEXT_SWITCH_TRACER is not set
# CONFIG_PROVIDE_OHCI1394_DMA_INIT is not set
# CONFIG_SAMPLES is not set
CONFIG_HAVE_ARCH_KGDB=y
# CONFIG_STRICT_DEVMEM is not set
CONFIG_X86_VERBOSE_BOOTUP=y
CONFIG_EARLY_PRINTK=y
# CONFIG_4KSTACKS is not set
CONFIG_DOUBLEFAULT=y
CONFIG_IO_DELAY_TYPE_0X80=0
CONFIG_IO_DELAY_TYPE_0XED=1
CONFIG_IO_DELAY_TYPE_UDELAY=2
CONFIG_IO_DELAY_TYPE_NONE=3
CONFIG_IO_DELAY_0X80=y
# CONFIG_IO_DELAY_0XED is not set
# CONFIG_IO_DELAY_UDELAY is not set
# CONFIG_IO_DELAY_NONE is not set
CONFIG_DEFAULT_IO_DELAY_TYPE=0
# CONFIG_OPTIMIZE_INLINING is not set
#
# Security options
#
CONFIG_KEYS=y
CONFIG_KEYS_DEBUG_PROC_KEYS=y
# CONFIG_SECURITY is not set
# CONFIG_SECURITY_FILE_CAPABILITIES is not set
CONFIG_CRYPTO=y
#
# Crypto core or helper
#
CONFIG_CRYPTO_ALGAPI=y
CONFIG_CRYPTO_AEAD=y
CONFIG_CRYPTO_BLKCIPHER=y
CONFIG_CRYPTO_HASH=y
CONFIG_CRYPTO_MANAGER=y
CONFIG_CRYPTO_GF128MUL=m
CONFIG_CRYPTO_NULL=m
CONFIG_CRYPTO_CRYPTD=m
CONFIG_CRYPTO_AUTHENC=y
CONFIG_CRYPTO_TEST=m
#
# Authenticated Encryption with Associated Data
#
CONFIG_CRYPTO_CCM=m
CONFIG_CRYPTO_GCM=m
CONFIG_CRYPTO_SEQIV=m
#
# Block modes
#
CONFIG_CRYPTO_CBC=y
CONFIG_CRYPTO_CTR=m
CONFIG_CRYPTO_CTS=m
CONFIG_CRYPTO_ECB=m
CONFIG_CRYPTO_LRW=m
CONFIG_CRYPTO_PCBC=m
# CONFIG_CRYPTO_XTS is not set
#
# Hash modes
#
CONFIG_CRYPTO_HMAC=y
CONFIG_CRYPTO_XCBC=m
#
# Digest
#
CONFIG_CRYPTO_CRC32C=m
CONFIG_CRYPTO_MD4=m
CONFIG_CRYPTO_MD5=y
CONFIG_CRYPTO_MICHAEL_MIC=m
# CONFIG_CRYPTO_RMD128 is not set
# CONFIG_CRYPTO_RMD160 is not set
# CONFIG_CRYPTO_RMD256 is not set
# CONFIG_CRYPTO_RMD320 is not set
CONFIG_CRYPTO_SHA1=y
CONFIG_CRYPTO_SHA256=m
CONFIG_CRYPTO_SHA512=m
CONFIG_CRYPTO_TGR192=m
# CONFIG_CRYPTO_WP512 is not set
#
# Ciphers
#
CONFIG_CRYPTO_AES=m
# CONFIG_CRYPTO_AES_586 is not set
# CONFIG_CRYPTO_ANUBIS is not set
CONFIG_CRYPTO_ARC4=m
CONFIG_CRYPTO_BLOWFISH=m
CONFIG_CRYPTO_CAMELLIA=m
CONFIG_CRYPTO_CAST5=m
CONFIG_CRYPTO_CAST6=m
CONFIG_CRYPTO_DES=y
CONFIG_CRYPTO_FCRYPT=m
# CONFIG_CRYPTO_KHAZAD is not set
CONFIG_CRYPTO_SALSA20=m
# CONFIG_CRYPTO_SALSA20_586 is not set
CONFIG_CRYPTO_SEED=m
CONFIG_CRYPTO_SERPENT=m
CONFIG_CRYPTO_TEA=m
CONFIG_CRYPTO_TWOFISH=m
CONFIG_CRYPTO_TWOFISH_COMMON=m
CONFIG_CRYPTO_TWOFISH_586=m
#
# Compression
#
CONFIG_CRYPTO_DEFLATE=y
CONFIG_CRYPTO_LZO=m
CONFIG_CRYPTO_HW=y
# CONFIG_CRYPTO_DEV_PADLOCK is not set
CONFIG_CRYPTO_DEV_GEODE=m
CONFIG_CRYPTO_DEV_HIFN_795X=m
# CONFIG_CRYPTO_DEV_HIFN_795X_RNG is not set
CONFIG_HAVE_KVM=y
CONFIG_VIRTUALIZATION=y
# CONFIG_KVM is not set
CONFIG_LGUEST=m
CONFIG_VIRTIO=m
CONFIG_VIRTIO_RING=m
CONFIG_VIRTIO_PCI=m
CONFIG_VIRTIO_BALLOON=m
#
# Library routines
#
CONFIG_BITREVERSE=y
CONFIG_GENERIC_FIND_FIRST_BIT=y
CONFIG_GENERIC_FIND_NEXT_BIT=y
CONFIG_CRC_CCITT=m
CONFIG_CRC16=m
CONFIG_CRC_T10DIF=m
CONFIG_CRC_ITU_T=m
CONFIG_CRC32=y
CONFIG_CRC7=m
CONFIG_LIBCRC32C=m
CONFIG_ZLIB_INFLATE=y
CONFIG_ZLIB_DEFLATE=y
CONFIG_LZO_COMPRESS=m
CONFIG_LZO_DECOMPRESS=m
CONFIG_TEXTSEARCH=y
CONFIG_TEXTSEARCH_KMP=m
CONFIG_TEXTSEARCH_BM=m
CONFIG_TEXTSEARCH_FSM=m
CONFIG_PLIST=y
CONFIG_HAS_IOMEM=y
CONFIG_HAS_IOPORT=y
CONFIG_HAS_DMA=y
CONFIG_CHECK_SIGNATURE=y
以下是 2.6.27.59 不能開機與順利開機兩種版本 .config 檔的 diff output：
$ diff /boot/u100/config-2.6.27.59 /boot/config-2.6.27.59
4c4
< # Tue Sep 27 15:19:09 2011
---
> # Sat Dec 24 07:31:28 2011
29,30c29,30
< CONFIG_RWSEM_GENERIC_SPINLOCK=y
< # CONFIG_RWSEM_XCHGADD_ALGORITHM is not set
---
> # CONFIG_RWSEM_GENERIC_SPINLOCK is not set
> CONFIG_RWSEM_XCHGADD_ALGORITHM=y
79,80c79,80
< CONFIG_UTS_NS=y
< CONFIG_IPC_NS=y
---
> # CONFIG_UTS_NS is not set
> # CONFIG_IPC_NS is not set
97c97
< # CONFIG_COMPAT_BRK is not set
---
> CONFIG_COMPAT_BRK=y
175c175
< CONFIG_M386=y
---
> # CONFIG_M386 is not set
179c179
< # CONFIG_M586MMX is not set
---
> CONFIG_M586MMX=y
203c203
< # CONFIG_X86_CMPXCHG is not set
---
> CONFIG_X86_CMPXCHG=y
205c205,206
< # CONFIG_X86_PPRO_FENCE is not set
---
> CONFIG_X86_XADD=y
> CONFIG_X86_PPRO_FENCE=y
206a208,212
> CONFIG_X86_WP_WORKS_OK=y
> CONFIG_X86_INVLPG=y
> CONFIG_X86_BSWAP=y
> CONFIG_X86_POPAD_OK=y
> CONFIG_X86_ALIGNMENT_16=y
208c214,215
< CONFIG_X86_MINIMUM_CPU_FAMILY=3
---
> CONFIG_X86_TSC=y
> CONFIG_X86_MINIMUM_CPU_FAMILY=4
284,285c291
< CONFIG_HIBERNATION=y
< CONFIG_PM_STD_PARTITION=""
---
> # CONFIG_HIBERNATION is not set
312c318
< CONFIG_ACPI_CONTAINER=m
---
> # CONFIG_ACPI_CONTAINER is not set
319c325
< # CONFIG_APM_DISPLAY_BLANK is not set
---
> CONFIG_APM_DISPLAY_BLANK=y
453c459
< CONFIG_IP_MULTICAST=y
---
> # CONFIG_IP_MULTICAST is not set
467,468d472
< # CONFIG_NET_IPGRE_BROADCAST is not set
< # CONFIG_IP_MROUTE is not set
526c530
< # CONFIG_NETFILTER_XT_TARGET_RATEEST is not set
---
> CONFIG_NETFILTER_XT_TARGET_RATEEST=m
539c543
< # CONFIG_NETFILTER_XT_MATCH_IPRANGE is not set
---
> CONFIG_NETFILTER_XT_MATCH_IPRANGE=m
544c548
< # CONFIG_NETFILTER_XT_MATCH_OWNER is not set
---
> CONFIG_NETFILTER_XT_MATCH_OWNER=m
550c554
< # CONFIG_NETFILTER_XT_MATCH_RATEEST is not set
---
> CONFIG_NETFILTER_XT_MATCH_RATEEST=m
557c561
< # CONFIG_NETFILTER_XT_MATCH_TIME is not set
---
> CONFIG_NETFILTER_XT_MATCH_TIME=m
628c632
< # CONFIG_BRIDGE_EBT_NFLOG is not set
---
> CONFIG_BRIDGE_EBT_NFLOG=m
680c684
< # CONFIG_NET_CLS_FLOW is not set
---
> CONFIG_NET_CLS_FLOW=m
693c697
< # CONFIG_NET_ACT_NAT is not set
---
> CONFIG_NET_ACT_NAT=m
704c708,716
< # CONFIG_CAN is not set
---
> CONFIG_CAN=m
> CONFIG_CAN_RAW=m
> CONFIG_CAN_BCM=m
>
> #
> # CAN Device Drivers
> #
> CONFIG_CAN_VCAN=m
> # CONFIG_CAN_DEBUG_DEVICES is not set
765,768c777,778
< CONFIG_BT_HCIUSB=m
< CONFIG_BT_HCIUSB_SCO=y
< # CONFIG_BT_HCIBTUSB is not set
< # CONFIG_BT_HCIBTSDIO is not set
---
> CONFIG_BT_HCIBTUSB=m
> CONFIG_BT_HCIBTSDIO=m
828c838,950
< # CONFIG_MTD is not set
---
> CONFIG_MTD=m
> # CONFIG_MTD_DEBUG is not set
> CONFIG_MTD_CONCAT=m
> CONFIG_MTD_PARTITIONS=y
> CONFIG_MTD_REDBOOT_PARTS=m
> CONFIG_MTD_REDBOOT_DIRECTORY_BLOCK=-1
> CONFIG_MTD_REDBOOT_PARTS_UNALLOCATED=y
> # CONFIG_MTD_REDBOOT_PARTS_READONLY is not set
> CONFIG_MTD_AR7_PARTS=m
>
> #
> # User Modules And Translation Layers
> #
> CONFIG_MTD_CHAR=m
> CONFIG_MTD_BLKDEVS=m
> CONFIG_MTD_BLOCK=m
> CONFIG_MTD_BLOCK_RO=m
> CONFIG_FTL=m
> CONFIG_NFTL=m
> # CONFIG_NFTL_RW is not set
> CONFIG_INFTL=m
> CONFIG_RFD_FTL=m
> CONFIG_SSFDC=m
> CONFIG_MTD_OOPS=m
>
> #
> # RAM/ROM/Flash chip drivers
> #
> # CONFIG_MTD_CFI is not set
> CONFIG_MTD_JEDECPROBE=m
> CONFIG_MTD_GEN_PROBE=m
> # CONFIG_MTD_CFI_ADV_OPTIONS is not set
> CONFIG_MTD_MAP_BANK_WIDTH_1=y
> CONFIG_MTD_MAP_BANK_WIDTH_2=y
> CONFIG_MTD_MAP_BANK_WIDTH_4=y
> # CONFIG_MTD_MAP_BANK_WIDTH_8 is not set
> # CONFIG_MTD_MAP_BANK_WIDTH_16 is not set
> # CONFIG_MTD_MAP_BANK_WIDTH_32 is not set
> CONFIG_MTD_CFI_I1=y
> CONFIG_MTD_CFI_I2=y
> # CONFIG_MTD_CFI_I4 is not set
> # CONFIG_MTD_CFI_I8 is not set
> # CONFIG_MTD_CFI_INTELEXT is not set
> CONFIG_MTD_CFI_AMDSTD=m
> # CONFIG_MTD_CFI_STAA is not set
> CONFIG_MTD_CFI_UTIL=m
> CONFIG_MTD_RAM=m
> # CONFIG_MTD_ROM is not set
> CONFIG_MTD_ABSENT=m
>
> #
> # Mapping drivers for chip access
> #
> # CONFIG_MTD_COMPLEX_MAPPINGS is not set
> CONFIG_MTD_PHYSMAP=m
> CONFIG_MTD_PHYSMAP_START=0x8000000
> CONFIG_MTD_PHYSMAP_LEN=0x0
> CONFIG_MTD_PHYSMAP_BANKWIDTH=2
> # CONFIG_MTD_TS5500 is not set
> # CONFIG_MTD_AMD76XROM is not set
> # CONFIG_MTD_ICHXROM is not set
> # CONFIG_MTD_ESB2ROM is not set
> # CONFIG_MTD_CK804XROM is not set
> # CONFIG_MTD_SCB2_FLASH is not set
> # CONFIG_MTD_NETtel is not set
> # CONFIG_MTD_L440GX is not set
> CONFIG_MTD_INTEL_VR_NOR=m
> # CONFIG_MTD_PLATRAM is not set
>
> #
> # Self-contained MTD device drivers
> #
> CONFIG_MTD_PMC551=m
> # CONFIG_MTD_PMC551_BUGFIX is not set
> # CONFIG_MTD_PMC551_DEBUG is not set
> CONFIG_MTD_SLRAM=m
> CONFIG_MTD_PHRAM=m
> CONFIG_MTD_MTDRAM=m
> CONFIG_MTDRAM_TOTAL_SIZE=4096
> CONFIG_MTDRAM_ERASE_SIZE=128
> # CONFIG_MTD_BLOCK2MTD is not set
>
> #
> # Disk-On-Chip Device Drivers
> #
> CONFIG_MTD_DOC2000=m
> CONFIG_MTD_DOC2001=m
> CONFIG_MTD_DOC2001PLUS=m
> CONFIG_MTD_DOCPROBE=m
> CONFIG_MTD_DOCECC=m
> # CONFIG_MTD_DOCPROBE_ADVANCED is not set
> CONFIG_MTD_DOCPROBE_ADDRESS=0
> CONFIG_MTD_NAND=m
> # CONFIG_MTD_NAND_VERIFY_WRITE is not set
> # CONFIG_MTD_NAND_ECC_SMC is not set
> # CONFIG_MTD_NAND_MUSEUM_IDS is not set
> CONFIG_MTD_NAND_IDS=m
> # CONFIG_MTD_NAND_DISKONCHIP is not set
> # CONFIG_MTD_NAND_CAFE is not set
> # CONFIG_MTD_NAND_CS553X is not set
> CONFIG_MTD_NAND_NANDSIM=m
> # CONFIG_MTD_NAND_PLATFORM is not set
> CONFIG_MTD_ALAUDA=m
> CONFIG_MTD_ONENAND=m
> # CONFIG_MTD_ONENAND_VERIFY_WRITE is not set
> # CONFIG_MTD_ONENAND_OTP is not set
> # CONFIG_MTD_ONENAND_2X_PROGRAM is not set
> CONFIG_MTD_ONENAND_SIM=m
>
> #
> # UBI - Unsorted block images
> #
> # CONFIG_MTD_UBI is not set
900a1023
> CONFIG_VIRTIO_BLK=m
924,925c1047,1048
< # CONFIG_ENCLOSURE_SERVICES is not set
< # CONFIG_HP_ILO is not set
---
> CONFIG_ENCLOSURE_SERVICES=m
> CONFIG_HP_ILO=m
937c1060
< CONFIG_IDEDISK_MULTI_MODE=y
---
> # CONFIG_IDEDISK_MULTI_MODE is not set
944,946c1067,1069
< # CONFIG_BLK_DEV_IDESCSI is not set
< CONFIG_BLK_DEV_IDEACPI=y
< # CONFIG_IDE_TASK_IOCTL is not set
---
> CONFIG_BLK_DEV_IDESCSI=y
> # CONFIG_BLK_DEV_IDEACPI is not set
> CONFIG_IDE_TASK_IOCTL=y
952,953c1075,1076
< # CONFIG_IDE_GENERIC is not set
< # CONFIG_BLK_DEV_PLATFORM is not set
---
> CONFIG_IDE_GENERIC=y
> CONFIG_BLK_DEV_PLATFORM=m
963c1086
< # CONFIG_IDEPCI_PCIBUS_ORDER is not set
---
> CONFIG_IDEPCI_PCIBUS_ORDER=y
1002,1007c1125,1130
< # CONFIG_BLK_DEV_4DRIVES is not set
< # CONFIG_BLK_DEV_ALI14XX is not set
< # CONFIG_BLK_DEV_DTC2278 is not set
< # CONFIG_BLK_DEV_HT6560B is not set
< # CONFIG_BLK_DEV_QD65XX is not set
< # CONFIG_BLK_DEV_UMC8672 is not set
---
> CONFIG_BLK_DEV_4DRIVES=m
> CONFIG_BLK_DEV_ALI14XX=m
> CONFIG_BLK_DEV_DTC2278=m
> CONFIG_BLK_DEV_HT6560B=m
> CONFIG_BLK_DEV_QD65XX=m
> CONFIG_BLK_DEV_UMC8672=m
1029a1153
> # CONFIG_SCSI_ENCLOSURE is not set
1046,1047c1170,1175
< # CONFIG_SCSI_SAS_LIBSAS is not set
< # CONFIG_SCSI_SRP_ATTRS is not set
---
> CONFIG_SCSI_SAS_ATTRS=m
> CONFIG_SCSI_SAS_LIBSAS=m
> # CONFIG_SCSI_SAS_ATA is not set
> CONFIG_SCSI_SAS_HOST_SMP=y
> CONFIG_SCSI_SAS_LIBSAS_DEBUG=y
> CONFIG_SCSI_SRP_ATTRS=m
1104c1232
< # CONFIG_SCSI_MVSAS is not set
---
> CONFIG_SCSI_MVSAS=m
1139,1145c1267,1272
< CONFIG_SCSI_LOWLEVEL_PCMCIA=y
< # CONFIG_PCMCIA_AHA152X is not set
< # CONFIG_PCMCIA_FDOMAIN is not set
< # CONFIG_PCMCIA_NINJA_SCSI is not set
< # CONFIG_PCMCIA_QLOGIC is not set
< # CONFIG_PCMCIA_SYM53C500 is not set
< # CONFIG_SCSI_DH is not set
---
> # CONFIG_SCSI_LOWLEVEL_PCMCIA is not set
> CONFIG_SCSI_DH=m
> CONFIG_SCSI_DH_RDAC=m
> CONFIG_SCSI_DH_HP_SW=m
> CONFIG_SCSI_DH_EMC=m
> CONFIG_SCSI_DH_ALUA=m
1155c1282
< # CONFIG_SATA_MV is not set
---
> CONFIG_SATA_MV=m
1167,1168c1294,1295
< # CONFIG_PATA_ACPI is not set
< # CONFIG_PATA_ALI is not set
---
> CONFIG_PATA_ACPI=m
> CONFIG_PATA_ALI=m
1172c1299
< # CONFIG_PATA_CMD640_PCI is not set
---
> CONFIG_PATA_CMD640_PCI=m
1175,1176c1302,1303
< # CONFIG_PATA_CS5530 is not set
< # CONFIG_PATA_CS5535 is not set
---
> CONFIG_PATA_CS5530=m
> CONFIG_PATA_CS5535=m
1182c1309
< # CONFIG_PATA_HPT37X is not set
---
> CONFIG_PATA_HPT37X=m
1188c1315
< # CONFIG_PATA_IT8213 is not set
---
> CONFIG_PATA_IT8213=m
1205c1332
< CONFIG_PATA_RZ1000=m
---
> # CONFIG_PATA_RZ1000 is not set
1213c1340
< # CONFIG_PATA_WINBOND_VLB is not set
---
> CONFIG_PATA_WINBOND_VLB=m
1273,1274c1400,1401
< # CONFIG_REALTEK_PHY is not set
< # CONFIG_MDIO_BITBANG is not set
---
> CONFIG_REALTEK_PHY=m
> CONFIG_MDIO_BITBANG=m
1355c1482
< # CONFIG_8139CP is not set
---
> CONFIG_8139CP=m
1381,1382c1508,1510
< # CONFIG_IP1000 is not set
< # CONFIG_IGB is not set
---
> CONFIG_IP1000=m
> CONFIG_IGB=m
> # CONFIG_IGB_LRO is not set
1400c1528
< # CONFIG_IXGBE is not set
---
> CONFIG_IXGBE=m
1405c1533
< # CONFIG_NIU is not set
---
> CONFIG_NIU=m
1407,1409c1535,1537
< # CONFIG_TEHUTI is not set
< # CONFIG_BNX2X is not set
< # CONFIG_SFC is not set
---
> CONFIG_TEHUTI=m
> CONFIG_BNX2X=m
> CONFIG_SFC=m
1420c1548
< # CONFIG_IPW2100_DEBUG is not set
---
> CONFIG_IPW2100_DEBUG=y
1451c1579
< # CONFIG_MAC80211_HWSIM is not set
---
> CONFIG_MAC80211_HWSIM=m
1456c1584
< CONFIG_ATH5K_DEBUG=y
---
> # CONFIG_ATH5K_DEBUG is not set
1460c1588
< CONFIG_IWLWIFI_LEDS=y
---
> # CONFIG_IWLWIFI_LEDS is not set
1464,1467c1592,1595
< CONFIG_IWLAGN_SPECTRUM_MEASUREMENT=y
< CONFIG_IWLAGN_LEDS=y
< CONFIG_IWL4965=y
< CONFIG_IWL5000=y
---
> # CONFIG_IWLAGN_SPECTRUM_MEASUREMENT is not set
> # CONFIG_IWLAGN_LEDS is not set
> # CONFIG_IWL4965 is not set
> # CONFIG_IWL5000 is not set
1474,1475c1602
< CONFIG_HOSTAP_FIRMWARE=y
< CONFIG_HOSTAP_FIRMWARE_NVRAM=y
---
> # CONFIG_HOSTAP_FIRMWARE is not set
1479,1480c1606,1623
< # CONFIG_B43 is not set
< # CONFIG_B43LEGACY is not set
---
> CONFIG_B43=m
> CONFIG_B43_PCI_AUTOSELECT=y
> CONFIG_B43_PCICORE_AUTOSELECT=y
> # CONFIG_B43_PCMCIA is not set
> CONFIG_B43_LEDS=y
> CONFIG_B43_RFKILL=y
> # CONFIG_B43_DEBUG is not set
> CONFIG_B43LEGACY=m
> CONFIG_B43LEGACY_PCI_AUTOSELECT=y
> CONFIG_B43LEGACY_PCICORE_AUTOSELECT=y
> CONFIG_B43LEGACY_LEDS=y
> CONFIG_B43LEGACY_RFKILL=y
> CONFIG_B43LEGACY_DEBUG=y
> CONFIG_B43LEGACY_DMA=y
> CONFIG_B43LEGACY_PIO=y
> CONFIG_B43LEGACY_DMA_AND_PIO_MODE=y
> # CONFIG_B43LEGACY_DMA_MODE is not set
> # CONFIG_B43LEGACY_PIO_MODE is not set
1482c1625
< CONFIG_ZD1211RW_DEBUG=y
---
> # CONFIG_ZD1211RW_DEBUG is not set
1488,1489d1630
< CONFIG_RT2X00_LIB_RFKILL=y
< CONFIG_RT2X00_LIB_LEDS=y
1491,1492c1632,1633
< CONFIG_RT2400PCI_RFKILL=y
< CONFIG_RT2400PCI_LEDS=y
---
> # CONFIG_RT2400PCI_RFKILL is not set
> # CONFIG_RT2400PCI_LEDS is not set
1494,1495c1635,1636
< CONFIG_RT2500PCI_RFKILL=y
< CONFIG_RT2500PCI_LEDS=y
---
> # CONFIG_RT2500PCI_RFKILL is not set
> # CONFIG_RT2500PCI_LEDS is not set
1497,1498c1638,1639
< CONFIG_RT61PCI_RFKILL=y
< CONFIG_RT61PCI_LEDS=y
---
> # CONFIG_RT61PCI_RFKILL is not set
> # CONFIG_RT61PCI_LEDS is not set
1500c1641
< CONFIG_RT2500USB_LEDS=y
---
> # CONFIG_RT2500USB_LEDS is not set
1502,1503c1643,1644
< CONFIG_RT73USB_LEDS=y
< CONFIG_RT2X00_DEBUG=y
---
> # CONFIG_RT73USB_LEDS is not set
> # CONFIG_RT2X00_DEBUG is not set
1529c1670
< # CONFIG_USB_HSO is not set
---
> CONFIG_USB_HSO=m
1562a1704
> CONFIG_VIRTIO_NET=m
1570c1712
< # CONFIG_INPUT_FF_MEMLESS is not set
---
> CONFIG_INPUT_FF_MEMLESS=m
1595c1737
< CONFIG_MOUSE_PS2=m
---
> CONFIG_MOUSE_PS2=y
1601c1743
< # CONFIG_MOUSE_PS2_TOUCHKIT is not set
---
> CONFIG_MOUSE_PS2_TOUCHKIT=y
1604c1746
< # CONFIG_MOUSE_BCM5974 is not set
---
> CONFIG_MOUSE_BCM5974=m
1608c1750
< # CONFIG_MOUSE_VSXXXAA is not set
---
> CONFIG_MOUSE_VSXXXAA=m
1628c1770
< # CONFIG_JOYSTICK_ZHENHUA is not set
---
> CONFIG_JOYSTICK_ZHENHUA=m
1647c1789
< # CONFIG_TOUCHSCREEN_INEXIO is not set
---
> CONFIG_TOUCHSCREEN_INEXIO=m
1649c1791
< # CONFIG_TOUCHSCREEN_HTCPEN is not set
---
> CONFIG_TOUCHSCREEN_HTCPEN=m
1654c1796,1799
< # CONFIG_TOUCHSCREEN_WM97XX is not set
---
> CONFIG_TOUCHSCREEN_WM97XX=m
> CONFIG_TOUCHSCREEN_WM9705=y
> CONFIG_TOUCHSCREEN_WM9712=y
> CONFIG_TOUCHSCREEN_WM9713=y
1667c1812
< # CONFIG_TOUCHSCREEN_TOUCHIT213 is not set
---
> CONFIG_TOUCHSCREEN_TOUCHIT213=m
1670c1815
< # CONFIG_INPUT_APANEL is not set
---
> CONFIG_INPUT_APANEL=m
1725c1870
< # CONFIG_NOZOMI is not set
---
> CONFIG_NOZOMI=m
1738,1747c1883
< CONFIG_SERIAL_8250_EXTENDED=y
< CONFIG_SERIAL_8250_MANY_PORTS=y
< CONFIG_SERIAL_8250_FOURPORT=m
< CONFIG_SERIAL_8250_ACCENT=m
< CONFIG_SERIAL_8250_BOCA=m
< CONFIG_SERIAL_8250_EXAR_ST16C554=m
< CONFIG_SERIAL_8250_HUB6=m
< CONFIG_SERIAL_8250_SHARE_IRQ=y
< # CONFIG_SERIAL_8250_DETECT_IRQ is not set
< CONFIG_SERIAL_8250_RSA=y
---
> # CONFIG_SERIAL_8250_EXTENDED is not set
1761a1898,1899
> CONFIG_HVC_DRIVER=y
> CONFIG_VIRTIO_CONSOLE=m
1772a1911
> CONFIG_HW_RANDOM_VIRTIO=m
1798c1937
< CONFIG_I2C=y
---
> CONFIG_I2C=m
1820c1959
< # CONFIG_I2C_ISCH is not set
---
> CONFIG_I2C_ISCH=m
1823c1962
< # CONFIG_I2C_NFORCE2_S4985 is not set
---
> CONFIG_I2C_NFORCE2_S4985=m
1854c1993
< # CONFIG_I2C_PCA_PLATFORM is not set
---
> CONFIG_I2C_PCA_PLATFORM=m
1865c2004
< # CONFIG_AT24 is not set
---
> CONFIG_AT24=m
1868c2007
< # CONFIG_PCF8575 is not set
---
> CONFIG_PCF8575=m
1982c2121
< # CONFIG_SSB_B43_PCI_BRIDGE is not set
---
> CONFIG_SSB_B43_PCI_BRIDGE=y
1994c2133
< # CONFIG_HTC_PASIC3 is not set
---
> CONFIG_HTC_PASIC3=m
2132c2271
< CONFIG_USB_VICAM=m
---
> # CONFIG_USB_VICAM is not set
2221c2360,2361
< # CONFIG_DVB_SIANO_SMS1XXX is not set
---
> CONFIG_DVB_SIANO_SMS1XXX=m
> CONFIG_DVB_SIANO_SMS1XXX_SMS_IDS=y
2357a2498,2499
> CONFIG_FB_DEFERRED_IO=y
> CONFIG_FB_HECUBA=m
2375c2517
< # CONFIG_FB_UVESA is not set
---
> CONFIG_FB_UVESA=m
2378c2520
< # CONFIG_FB_N411 is not set
---
> CONFIG_FB_N411=m
2442c2584
< # CONFIG_LCD_PLATFORM is not set
---
> CONFIG_LCD_PLATFORM=m
2444c2586
< # CONFIG_BACKLIGHT_CORGI is not set
---
> CONFIG_BACKLIGHT_CORGI=m
2447c2589
< # CONFIG_BACKLIGHT_MBP_NVIDIA is not set
---
> CONFIG_BACKLIGHT_MBP_NVIDIA=m
2473,2474c2615,2616
< CONFIG_FONT_6x11=y
< CONFIG_FONT_7x14=y
---
> # CONFIG_FONT_6x11 is not set
> # CONFIG_FONT_7x14 is not set
2478,2480c2620,2622
< CONFIG_FONT_SUN8x16=y
< CONFIG_FONT_SUN12x22=y
< CONFIG_FONT_10x18=y
---
> # CONFIG_FONT_SUN8x16 is not set
> # CONFIG_FONT_SUN12x22 is not set
> # CONFIG_FONT_10x18 is not set
2537c2679
< # CONFIG_SND_SC6000 is not set
---
> CONFIG_SND_SC6000=m
2566c2708
< # CONFIG_SND_AW2 is not set
---
> CONFIG_SND_AW2=m
2572c2714,2715
< # CONFIG_SND_OXYGEN is not set
---
> CONFIG_SND_OXYGEN_LIB=m
> CONFIG_SND_OXYGEN=m
2613c2756
< # CONFIG_SND_HIFIER is not set
---
> CONFIG_SND_HIFIER=m
2627c2770
< # CONFIG_SND_SIS7019 is not set
---
> CONFIG_SND_SIS7019=m
2632c2775
< # CONFIG_SND_VIRTUOSO is not set
---
> CONFIG_SND_VIRTUOSO=m
2644,2647c2787
< CONFIG_SOUND_PRIME=m
< # CONFIG_SOUND_MSNDCLAS is not set
< # CONFIG_SOUND_MSNDPIN is not set
< # CONFIG_SOUND_OSS is not set
---
> # CONFIG_SOUND_PRIME is not set
2673c2813
< CONFIG_USB_ANNOUNCE_NEW_DEVICES=y
---
> # CONFIG_USB_ANNOUNCE_NEW_DEVICES is not set
2690c2830
< CONFIG_USB_EHCI_ROOT_HUB_TT=y
---
> # CONFIG_USB_EHCI_ROOT_HUB_TT is not set
2752c2892
< # CONFIG_USB_SERIAL_CH341 is not set
---
> CONFIG_USB_SERIAL_CH341=m
2767c2907
< # CONFIG_USB_SERIAL_IUU is not set
---
> CONFIG_USB_SERIAL_IUU=m
2787c2927
< # CONFIG_USB_SERIAL_MOTOROLA is not set
---
> CONFIG_USB_SERIAL_MOTOROLA=m
2791c2931
< # CONFIG_USB_SERIAL_SPCP8X5 is not set
---
> CONFIG_USB_SERIAL_SPCP8X5=m
2866c3006
< # CONFIG_MMC_TEST is not set
---
> CONFIG_MMC_TEST=m
2877c3017,3030
< # CONFIG_MEMSTICK is not set
---
> CONFIG_MEMSTICK=m
> # CONFIG_MEMSTICK_DEBUG is not set
>
> #
> # MemoryStick drivers
> #
> # CONFIG_MEMSTICK_UNSAFE_RESUME is not set
> CONFIG_MSPRO_BLOCK=m
>
> #
> # MemoryStick Host Controller Drivers
> #
> # CONFIG_MEMSTICK_TIFM_MS is not set
> # CONFIG_MEMSTICK_JMICRON_38X is not set
2886,2888c3039,3041
< # CONFIG_LEDS_PCA9532 is not set
< # CONFIG_LEDS_CLEVO_MAIL is not set
< # CONFIG_LEDS_PCA955X is not set
---
> CONFIG_LEDS_PCA9532=m
> CONFIG_LEDS_CLEVO_MAIL=m
> CONFIG_LEDS_PCA955X=m
2897c3050
< # CONFIG_LEDS_TRIGGER_DEFAULT_ON is not set
---
> CONFIG_LEDS_TRIGGER_DEFAULT_ON=m
2917c3070
< # CONFIG_RTC_DRV_DS1374 is not set
---
> CONFIG_RTC_DRV_DS1374=m
2927,2928c3080,3081
< # CONFIG_RTC_DRV_S35390A is not set
< # CONFIG_RTC_DRV_FM3130 is not set
---
> CONFIG_RTC_DRV_S35390A=m
> CONFIG_RTC_DRV_FM3130=m
2938c3091
< # CONFIG_RTC_DRV_DS1511 is not set
---
> CONFIG_RTC_DRV_DS1511=m
2950,2951c3103,3113
< # CONFIG_AUXDISPLAY is not set
< # CONFIG_UIO is not set
---
> CONFIG_AUXDISPLAY=y
> CONFIG_KS0108=m
> CONFIG_KS0108_PORT=0x378
> CONFIG_KS0108_DELAY=2
> CONFIG_CFAG12864B=m
> CONFIG_CFAG12864B_RATE=20
> CONFIG_UIO=m
> CONFIG_UIO_CIF=m
> CONFIG_UIO_PDRV=m
> CONFIG_UIO_PDRV_GENIRQ=m
> CONFIG_UIO_SMX=m
2967c3129,3131
< # CONFIG_EXT2_FS_XATTR is not set
---
> CONFIG_EXT2_FS_XATTR=y
> CONFIG_EXT2_FS_POSIX_ACL=y
> CONFIG_EXT2_FS_SECURITY=y
2971,2972c3135,3141
< # CONFIG_EXT3_FS_XATTR is not set
< # CONFIG_EXT4DEV_FS is not set
---
> CONFIG_EXT3_FS_XATTR=y
> CONFIG_EXT3_FS_POSIX_ACL=y
> CONFIG_EXT3_FS_SECURITY=y
> CONFIG_EXT4DEV_FS=m
> CONFIG_EXT4DEV_FS_XATTR=y
> # CONFIG_EXT4DEV_FS_POSIX_ACL is not set
> # CONFIG_EXT4DEV_FS_SECURITY is not set
2973a3143,3144
> CONFIG_JBD2=m
> CONFIG_FS_MBCACHE=y
2983c3154
< # CONFIG_FS_POSIX_ACL is not set
---
> CONFIG_FS_POSIX_ACL=y
3023c3194
< CONFIG_PROC_KCORE=y
---
> # CONFIG_PROC_KCORE is not set
3042a3214,3224
> CONFIG_JFFS2_FS=m
> CONFIG_JFFS2_FS_DEBUG=0
> CONFIG_JFFS2_FS_WRITEBUFFER=y
> # CONFIG_JFFS2_FS_WBUF_VERIFY is not set
> # CONFIG_JFFS2_SUMMARY is not set
> # CONFIG_JFFS2_FS_XATTR is not set
> # CONFIG_JFFS2_COMPRESSION_OPTIONS is not set
> CONFIG_JFFS2_ZLIB=y
> # CONFIG_JFFS2_LZO is not set
> CONFIG_JFFS2_RTIME=y
> # CONFIG_JFFS2_RUBIN is not set
3099c3281
< CONFIG_MAC_PARTITION=y
---
> # CONFIG_MAC_PARTITION is not set
3110c3292
< CONFIG_KARMA_PARTITION=y
---
> # CONFIG_KARMA_PARTITION is not set
3164c3346
< # CONFIG_UNUSED_SYMBOLS is not set
---
> CONFIG_UNUSED_SYMBOLS=y
3183c3365
< CONFIG_STRICT_DEVMEM=y
---
> # CONFIG_STRICT_DEVMEM is not set
3225,3227c3407,3409
< # CONFIG_CRYPTO_CCM is not set
< # CONFIG_CRYPTO_GCM is not set
< # CONFIG_CRYPTO_SEQIV is not set
---
> CONFIG_CRYPTO_CCM=m
> CONFIG_CRYPTO_GCM=m
> CONFIG_CRYPTO_SEQIV=m
3233,3234c3415,3416
< # CONFIG_CRYPTO_CTR is not set
< # CONFIG_CRYPTO_CTS is not set
---
> CONFIG_CRYPTO_CTR=m
> CONFIG_CRYPTO_CTS=m
3277c3459
< # CONFIG_CRYPTO_SALSA20 is not set
---
> CONFIG_CRYPTO_SALSA20=m
3279c3461
< # CONFIG_CRYPTO_SEED is not set
---
> CONFIG_CRYPTO_SEED=m
3290c3472
< # CONFIG_CRYPTO_LZO is not set
---
> CONFIG_CRYPTO_LZO=m
3294c3476,3477
< # CONFIG_CRYPTO_DEV_HIFN_795X is not set
---
> CONFIG_CRYPTO_DEV_HIFN_795X=m
> # CONFIG_CRYPTO_DEV_HIFN_795X_RNG is not set
3296c3479,3485
< # CONFIG_VIRTUALIZATION is not set
---
> CONFIG_VIRTUALIZATION=y
> # CONFIG_KVM is not set
> CONFIG_LGUEST=m
> CONFIG_VIRTIO=m
> CONFIG_VIRTIO_RING=m
> CONFIG_VIRTIO_PCI=m
> CONFIG_VIRTIO_BALLOON=m
3306c3495
< # CONFIG_CRC_T10DIF is not set
---
> CONFIG_CRC_T10DIF=m
3312a3502,3503
> CONFIG_LZO_COMPRESS=m
> CONFIG_LZO_DECOMPRESS=m
後於 2011-12-29 下載 2.6.32.51，使用其預設的 config，compiled 後，嘗試開機，還是得到 VFS: Cannot open root device "303" or unknown-block(3,3) 的結果。所以現在服役的 2.6.27.59，之所以可以在這個機器上開機的真正原因，還是不明。
其他 HP2133 與系統相關問題（2.6.27.59）
- 音效（Sound）。在 Etch/2.6.27.59 之下，ALSA 驅動的音效卡問題，可以先執行
$ sudo alsaconf
$ alsamixer
只看到 [Master]、[PCM]、[Mic]、[Capture] 以及 [Beep] 五個調整桿，而且麥克風輸入孔無效。再來就直接編輯
$ sudo vim /etc/modprobe.d/sound
改為
alias snd-card-0 snd-hda-intel
options snd-hda-intel model=laptop
編輯完之後，執行
$ sudo /etc/init.d/alsa reload
$ alsamixer -V all
這個時候會看到 [Master] [PCM] [Mic] [Mic Boos] [Mic Boos] [Capture] [Capture] [Beep] 共 8 個控制桿，這時也可見 [Fn]-[F10] 跟 [Fn]-[F11] 所調整的是 [PCM] 控制桿的電平。調整好各個控制桿的強度之後，就可以測試麥克風，臨時找不到麥克風的話，也可以把耳機當作麥克風插入麥克風插孔，把耳機貼在喇叭上，應該可以聽到回授聲，分別對兩個耳塞吹氣或講話，立刻可以分辨麥克風輸入是左右聲道分開的，也就是立體的。
HP2133 這個機器特點之一，就是喇叭聲音比一般筆記型電腦大很多。我拿了一些測試檔案來播放，效果相當突出，很是享受。大概是因為我用過的所有筆記型電腦，喇叭聲音都很小。所以聲音問題就此完美解決。在 Debian Etch/Kernel 2.6.27.59 上，唯一要知道的關鍵是，要加上 model=laptop。
補充於 2011-12-29。被 alsamixer 騙了。如果窗子太窄的話，alsamixer 並沒有一頁就顯示出所有的控制桿，鍵盤右鍵一直按，會看到更多的控制桿。以 [Tab] 鍵可以切換 [Playback]、[Capture] 跟 [All] 三種顯示模式。這三種顯示模式也可以在指令行以 -V 指定。在 [All] 的情形下，所有的控制桿，由左至右為 [Master] [PCM] [Mic] [Mic Boos] [Mic Boos] [Capture] [Capture] [Beep] [Dock] [Dock Mic] [Dock Mic] [Dock Mic] [Input So] [Input So] [Internal] [Internal] [Internal]，共 17 個。
- 記憶體（Storage）。重新編譯 kernel 2.6.27.59 時，以 make menuconfig 調整為
CONFIG_NOHIGHMEM=n
CONFIG_HIGHMEM4G=y
果然讓裝在機器裡的另外一個 giga bytes 重見天日。可以用 top(1) 或 free(1) 查看。
- 螢幕亮度調整（LCD Backlight Control）。功能鍵 [Fn]-[F3]、[Fn]-[F4] 可用。軟體控制則可透過 ACPI subsystem 所建立的 /proc/acpi/video/VGA/LCD/ 以及 /sys/class/backlight/acpi_video0/ 實現，所以我的 script "lcd" 也可以用了。
- 無線網卡（Wireless）。內建無線網卡原本還是無法使用。雖然這個 kernel 有 b43.ko 以及 broadcom.ko 兩個 modules，但是都起不了作用。只好插上一個 USB 的無線網卡 "pci mini2"。我由 Broadcom 下載了原始碼 [3]，解開後順利在 2.6.27.59 上 compile 通過（跟編譯 kernel 時一樣，是 gcc-3.4/make-3.81），得到 wl.ko 這個 modules。在
# make install
# depmod -ae（因為 Makefile 沒有做這件事情，所以必須自己做。）
# modprobe wl
# iwconfig
之後，即見已新增一 wireless interface。以 dmesg 查看，則見：
eth0: Broadcom BCM4315 802.11 Hybrid Wireless Controller 5.100.82.112
往左扳一下右下方的硬體開關，讓 LED 燈由橘色轉藍色，即可使用。
- 有線網路（Ethernet）。內建的有線網路卡 BCM5788，無論是 2.6.16.62 還是 2.6.27.59，都含有可用的驅動模組。只要 "modprobe tg3" 就可以使用，也可以把它加入加入 /etc/modules。
- 網路攝影機（Webcam）。kernel 2.6.27.59 上有 uvcvideo.ko 這個 module，開機時，內建的攝影機會被偵測到，並自動載入 uvcvideo 這個 module。用
mplayer -tv device=/dev/video0 tv://
這個指令，即可播放影像、擷取照片。因為我現在還在 Debian Etch 之下，沒有 Xv，只用 vesa 來驅動顯示卡，必須先用 "-vo x11" 這個選項來呼叫 mplayer，也就是：
mplayer -vo x11 -tv device=/dev/video0 tv://
以上使用完整語法的目的在於提示，要是有插入額外的攝影機，那麼可能要從 device=/dev/video1 開始。
- CPU 速度調整（CPU Frequency Scaling）。在 kernel 2.6.16.26 上，用的是 acpi-cpufreq.ko，可是在 2.6.27.59 上，如果用 "modprobe acpi-cpufreq"，會發生 "Device or resource busy"。經過一番摸索，原來是必須使用 e_powersaver.ko：
$ sudo modprobe e_powersaver
dmesg 會顯示以下訊息：eps: Detected VIA Model D C7-M
eps: Current voltage = 988mV
eps: Current multiplier = 8
eps: Highest voltage = 988mV
eps: Highest multiplier = 8
eps: Lowest voltage = 796mV
eps: Lowest multiplier = 4
再驗證一下 CPU Scaling 的選項：
$ cat /sys/devices/system/cpu/cpu0/cpufreq/scaling_available_frequencies
797984 997480 1196976 1396472 1595968
$ cpu
cpu v0.6a Nan-shan Chen C20051210/20080628
usage: cpu [-l] <797|997|1196|1396|1595>
VIA C7-M Processor 1600MHz runs at 1595.968 MHz
以上的 "cpu" 是我自己的 shell-script。
dmeg (2011-12-29)
$ dmesg # Debian Etch / kernel 2.6.27.59
Linux version 2.6.27.59 (root@ferrum) (gcc version 3.4.6 (Debian 3.4.6-5)) #3 PREEMPT Sat Dec 24 07:56:30 TWT 2011
BIOS-provided physical RAM map:
BIOS-e820: 0000000000000000 - 000000000009fc00 (usable)
BIOS-e820: 000000000009fc00 - 00000000000a0000 (reserved)
BIOS-e820: 00000000000e0000 - 0000000000100000 (reserved)
BIOS-e820: 0000000000100000 - 000000006feb0000 (usable)
BIOS-e820: 000000006feb0000 - 000000006febe000 (ACPI data)
BIOS-e820: 000000006febe000 - 000000006fef0000 (ACPI NVS)
BIOS-e820: 000000006fef0000 - 000000006ff00000 (reserved)
BIOS-e820: 00000000fec00000 - 00000000fec01000 (reserved)
BIOS-e820: 00000000fecc0000 - 00000000fecc1000 (reserved)
BIOS-e820: 00000000fee00000 - 00000000fee01000 (reserved)
BIOS-e820: 00000000fff00000 - 0000000100000000 (reserved)
DMI present.
last_pfn = 0x6feb0 max_arch_pfn = 0x100000
kernel direct mapping tables up to 38000000 @ 7000-c000
ACPI: RSDP 000F9EF0, 0024 (r2 HP )
ACPI: XSDT 6FEB0100, 0064 (r1 HPQOEM SLIC-MPC 20081111 MSFT 97)
ACPI: FACP 6FEB0290, 00F4 (r4 HP FACP1726 20081111 MSFT 97)
ACPI: DSDT 6FEB0600, 909C (r2 68VGU 68VGUF06 F06 INTL 20061109)
ACPI: FACS 6FEBE000, 0040
ACPI: APIC 6FEB0390, 0060 (r2 HP APIC1726 20081111 MSFT 97)
ACPI: MCFG 6FEB03F0, 003C (r1 HP OEMMCFG 20081111 MSFT 97)
ACPI: SLIC 6FEB0430, 0176 (r1 HPQOEM SLIC-MPC 20081111 MSFT 97)
ACPI: WDRT 6FEB05B0, 0047 (r1 HP VT-8237S 20081111 MSFT 97)
ACPI: OEMB 6FEBE040, 00F0 (r1 HP OEMB1726 20081111 MSFT 97)
ACPI: HPET 6FEB96A0, 0038 (r1 HP VT-8237S 20081111 MSFT 97)
ACPI: SSDT 6FEBE130, 03A0 (r1 HP P001PM 1 INTL 20051117)
ACPI: DMI detected: Hewlett-Packard
894MB HIGHMEM available.
896MB LOWMEM available.
mapped low ram: 0 - 38000000
low ram: 00000000 - 38000000
bootmap 00008000 - 0000f000
(6 early reservations) ==> bootmem [0000000000 - 0038000000]
#0 [0000000000 - 0000001000] BIOS data page ==> [0000000000 - 0000001000]
#1 [0000100000 - 000051c064] TEXT DATA BSS ==> [0000100000 - 000051c064]
#2 [000051d000 - 0000520000] INIT_PG_TABLE ==> [000051d000 - 0000520000]
#3 [000009fc00 - 0000100000] BIOS reserved ==> [000009fc00 - 0000100000]
#4 [0000007000 - 0000008000] PGTABLE ==> [0000007000 - 0000008000]
#5 [0000008000 - 000000f000] BOOTMAP ==> [0000008000 - 000000f000]
found SMP MP-table at [c00ff780] 000ff780
Zone PFN ranges:
DMA 0x00000000 -> 0x00001000
Normal 0x00001000 -> 0x00038000
HighMem 0x00038000 -> 0x0006feb0
Movable zone start PFN for each node
early_node_map[2] active PFN ranges
0: 0x00000000 -> 0x0000009f
0: 0x00000100 -> 0x0006feb0
On node 0 totalpages: 458319
free_area_init_node: node 0, pgdat c047de80, node_mem_map c1000000
DMA zone: 3967 pages, LIFO batch:0
Normal zone: 223520 pages, LIFO batch:31
HighMem zone: 227250 pages, LIFO batch:31
ACPI: PM-Timer IO Port: 0x808
ACPI: Local APIC address 0xfee00000
ACPI: LAPIC (acpi_id[0x01] lapic_id[0x00] enabled)
ACPI: IOAPIC (id[0x01] address[0xfec00000] gsi_base[0])
IOAPIC[0]: apic_id 1, version 3, address 0xfec00000, GSI 0-23
ACPI: IOAPIC (id[0x02] address[0xfecc0000] gsi_base[24])
IOAPIC[1]: apic_id 2, version 3, address 0xfecc0000, GSI 24-47
ACPI: INT_SRC_OVR (bus 0 bus_irq 0 global_irq 2 dfl dfl)
ACPI: INT_SRC_OVR (bus 0 bus_irq 9 global_irq 9 low level)
ACPI: IRQ0 used by override.
ACPI: IRQ2 used by override.
ACPI: IRQ9 used by override.
Enabling APIC mode: Flat. Using 2 I/O APICs
Using ACPI (MADT) for SMP configuration information
mapped APIC to ffffb000 (fee00000)
mapped IOAPIC to ffffa000 (fec00000)
mapped IOAPIC to ffff9000 (fecc0000)
Allocating PCI resources starting at 70000000 (gap: 6ff00000:8ed00000)
Built 1 zonelists in Zone order, mobility grouping on. Total pages: 454737
Kernel command line: auto BOOT_IMAGE=Linux262759 ro root=303 probe_mask=0x3f
Enabling fast FPU save and restore... done.
Enabling unmasked SIMD FPU exception support... done.
Initializing CPU#0
PID hash table entries: 4096 (order: 12, 16384 bytes)
Extended CMOS year: 2000
TSC: PIT calibration confirmed by PMTIMER.
TSC: using PIT calibration value
Detected 1595.949 MHz processor.
Console: colour dummy device 80x25
console [tty0] enabled
Dentry cache hash table entries: 131072 (order: 7, 524288 bytes)
Inode-cache hash table entries: 65536 (order: 6, 262144 bytes)
Memory: 1812996k/1833664k available (2609k kernel code, 19392k reserved, 996k data, 356k init, 916160k highmem)
virtual kernel memory layout:
fixmap : 0xfffab000 - 0xfffff000 ( 336 kB)
pkmap : 0xff800000 - 0xffc00000 (4096 kB)
vmalloc : 0xf8800000 - 0xff7fe000 ( 111 MB)
lowmem : 0xc0000000 - 0xf8000000 ( 896 MB)
.init : 0xc0488000 - 0xc04e1000 ( 356 kB)
.data : 0xc038c42b - 0xc04855bc ( 996 kB)
.text : 0xc0100000 - 0xc038c42b (2609 kB)
Checking if this processor honours the WP bit even in supervisor mode...Ok.
CPA: page pool initialized 1 of 1 pages preallocated
Calibrating delay loop (skipped), value calculated using timer frequency.. 3191.89 BogoMIPS (lpj=1595949)
Mount-cache hash table entries: 512
CPU: L1 I Cache: 64K (64 bytes/line), D cache 64K (64 bytes/line)
CPU: L2 Cache: 128K (64 bytes/line)
CPU: Centaur VIA C7-M Processor 1600MHz stepping 00
Checking 'hlt' instruction... OK.
Freeing SMP alternatives: 0k freed
ACPI: Core revision 20080609
ENABLING IO-APIC IRQs
..TIMER: vector=0x31 apic1=0 pin1=2 apic2=-1 pin2=-1
net_namespace: 588 bytes
NET: Registered protocol family 16
EISA bus registered
ACPI: bus type pci registered
PCI: MCFG configuration 0: base e0000000 segment 0 buses 0 - 255
PCI: Not using MMCONFIG.
PCI: PCI BIOS revision 3.00 entry at 0xf0031, last bus=7
PCI: Using configuration type 1 for base access
ACPI: EC: Look up EC in DSDT
ACPI: Interpreter enabled
ACPI: (supports S0 S3 S5)
ACPI: Using IOAPIC for interrupt routing
PCI: MCFG configuration 0: base e0000000 segment 0 buses 0 - 255
PCI: MCFG area at e0000000 reserved in ACPI motherboard resources
PCI: Using MMCONFIG for extended config space
ACPI: EC: non-query interrupt received, switching to interrupt mode
ACPI: EC: GPE = 0x11, I/O: command/status = 0x66, data = 0x62
ACPI: EC: driver started in interrupt mode
ACPI: PCI Root Bridge [PCI0] (0000:00)
PCI: 0000:00:00.0 reg 10 32bit mmio: [f0000000, f7ffffff]
pci 0000:00:02.0: PME# supported from D0 D3hot D3cold
pci 0000:00:02.0: PME# disabled
pci 0000:00:03.0: PME# supported from D0 D3hot D3cold
pci 0000:00:03.0: PME# disabled
PCI: 0000:00:0f.0 reg 20 io port: [fc00, fc0f]
PCI: 0000:00:0f.0 reg 24 io port: [f800, f8ff]
PCI: 0000:00:10.0 reg 20 io port: [c800, c81f]
pci 0000:00:10.0: supports D1
pci 0000:00:10.0: supports D2
pci 0000:00:10.0: PME# supported from D0 D1 D2 D3hot D3cold
pci 0000:00:10.0: PME# disabled
PCI: 0000:00:10.2 reg 20 io port: [c880, c89f]
pci 0000:00:10.2: supports D1
pci 0000:00:10.2: supports D2
pci 0000:00:10.2: PME# supported from D0 D1 D2 D3hot D3cold
pci 0000:00:10.2: PME# disabled
PCI: 0000:00:10.3 reg 20 io port: [cc00, cc1f]
pci 0000:00:10.3: supports D1
pci 0000:00:10.3: supports D2
pci 0000:00:10.3: PME# supported from D0 D1 D2 D3hot D3cold
pci 0000:00:10.3: PME# disabled
PCI: 0000:00:10.4 reg 10 32bit mmio: [fbeffc00, fbeffcff]
pci 0000:00:10.4: supports D1
pci 0000:00:10.4: supports D2
pci 0000:00:10.4: PME# supported from D0 D1 D2 D3hot D3cold
pci 0000:00:10.4: PME# disabled
PCI: 0000:01:00.0 reg 10 32bit mmio: [c0000000, cfffffff]
PCI: 0000:01:00.0 reg 14 32bit mmio: [fc000000, fcffffff]
PCI: 0000:01:00.0 reg 30 32bit mmio: [fbff0000, fbffffff]
pci 0000:01:00.0: supports D1
pci 0000:01:00.0: supports D2
PCI: bridge 0000:00:01.0 32bit mmio: [fbf00000, fcffffff]
PCI: bridge 0000:00:01.0 32bit mmio pref: [c0000000, cfffffff]
PCI: 0000:02:00.0 reg 10 64bit mmio: [fdffc000, fdffffff]
pci 0000:02:00.0: supports D1
pci 0000:02:00.0: supports D2
PCI: bridge 0000:00:02.0 io port: [d000, dfff]
PCI: bridge 0000:00:02.0 32bit mmio: [fd000000, fdffffff]
PCI: bridge 0000:00:02.0 64bit mmio pref: [de000000, dfffffff]
PCI: bridge 0000:00:03.0 io port: [e000, efff]
PCI: bridge 0000:00:03.0 32bit mmio: [fe000000, fe9fffff]
PCI: bridge 0000:00:03.0 64bit mmio pref: [f8000000, faffffff]
PCI: 0000:07:03.0 reg 10 32bit mmio: [feaf0000, feafffff]
pci 0000:07:03.0: PME# supported from D3hot D3cold
pci 0000:07:03.0: PME# disabled
pci 0000:00:13.1: transparent bridge
PCI: bridge 0000:00:13.1 32bit mmio: [fea00000, feafffff]
bus 00 -> node 0
ACPI: PCI Interrupt Routing Table [\_SB_.PCI0._PRT]
ACPI: PCI Interrupt Routing Table [\_SB_.PCI0.P0P1._PRT]
ACPI: PCI Interrupt Routing Table [\_SB_.PCI0.NBPG._PRT]
ACPI: PCI Interrupt Routing Table [\_SB_.PCI0.P0P9._PRT]
ACPI: PCI Interrupt Routing Table [\_SB_.PCI0.P0PA._PRT]
ACPI: PCI Interrupt Routing Table [\_SB_.PCI0.NBP0._PRT]
ACPI: PCI Root Bridge [PCI1] (0000:80)
PCI: 0000:80:01.0 reg 10 64bit mmio: [febfc000, febfffff]
pci 0000:80:01.0: PME# supported from D0 D3hot D3cold
pci 0000:80:01.0: PME# disabled
bus 80 -> node 0
ACPI: PCI Interrupt Routing Table [\_SB_.PCI1._PRT]
ACPI: PCI Interrupt Link [LNKA] (IRQs 3 4 5 6 7 10 *11 12 14 15)
ACPI: PCI Interrupt Link [LNKB] (IRQs 3 4 5 6 *7 10 11 12 14 15)
ACPI: PCI Interrupt Link [LNKC] (IRQs 3 4 *5 6 7 10 11 12 14 15)
ACPI: PCI Interrupt Link [LNKD] (IRQs *3 4 5 6 7 10 11 12 14 15)
ACPI: PCI Interrupt Link [LNKE] (IRQs 3 4 5 6 7 10 11 12 14 15) *0, disabled.
ACPI: PCI Interrupt Link [LNKF] (IRQs 3 4 5 6 7 10 11 12 14 15) *0, disabled.
ACPI: PCI Interrupt Link [LNKG] (IRQs 3 4 5 6 7 10 11 12 14 15) *0, disabled.
ACPI: PCI Interrupt Link [LNKH] (IRQs 3 4 5 6 7 *10 11 12 14 15)
ACPI: Power Resource [APMF] (off)
Linux Plug and Play Support v0.97 (c) Adam Belay
pnp: PnP ACPI init
ACPI: bus type pnp registered
pnp 00:00: parse allocated resources
pnp 00:00: add io 0xcf8-0xcff flags 0x1
pnp 00:00: Plug and Play ACPI device, IDs PNP0a03 (active)
pnp 00:01: parse allocated resources
pnp 00:01: add dma 4 flags 0x4
pnp 00:01: add io 0x0-0xf flags 0x1
pnp 00:01: add io 0x81-0x83 flags 0x1
pnp 00:01: add io 0x87-0x87 flags 0x1
pnp 00:01: add io 0x89-0x8b flags 0x1
pnp 00:01: add io 0x8f-0x8f flags 0x1
pnp 00:01: add io 0xc0-0xdf flags 0x1
pnp 00:01: Plug and Play ACPI device, IDs PNP0200 (active)
pnp 00:02: parse allocated resources
pnp 00:02: add io 0x60-0x60 flags 0x1
pnp 00:02: add io 0x64-0x64 flags 0x1
pnp 00:02: add irq 1 flags 0x1
pnp 00:02: Plug and Play ACPI device, IDs PNP0303 PNP030b (active)
pnp 00:03: parse allocated resources
pnp 00:03: add io 0x61-0x61 flags 0x1
pnp 00:03: Plug and Play ACPI device, IDs PNP0800 (active)
pnp 00:04: parse allocated resources
pnp 00:04: add io 0xf0-0xff flags 0x1
pnp 00:04: add irq 13 flags 0x1
pnp 00:04: Plug and Play ACPI device, IDs PNP0c04 (active)
pnp 00:05: parse allocated resources
pnp 00:05: add io 0x10-0x1f flags 0x1
pnp 00:05: add io 0x22-0x3f flags 0x1
pnp 00:05: add io 0x44-0x5f flags 0x1
pnp 00:05: add io 0x63-0x63 flags 0x1
pnp 00:05: add io 0x65-0x65 flags 0x1
pnp 00:05: add io 0x67-0x6f flags 0x1
pnp 00:05: add io 0x72-0x7f flags 0x1
pnp 00:05: add io 0x80-0x80 flags 0x1
pnp 00:05: add io 0x84-0x86 flags 0x1
pnp 00:05: add io 0x88-0x88 flags 0x1
pnp 00:05: add io 0x8c-0x8e flags 0x1
pnp 00:05: add io 0x90-0x9f flags 0x1
pnp 00:05: add io 0xa2-0xbf flags 0x1
pnp 00:05: add io 0xe0-0xef flags 0x1
pnp 00:05: add io 0x3e0-0x3e7 flags 0x1
pnp 00:05: add io 0x4d0-0x4d1 flags 0x1
pnp 00:05: add io 0x500-0x501 flags 0x1
pnp 00:05: add io 0x800-0x87f flags 0x1
pnp 00:05: add io 0x400-0x41f flags 0x1
pnp 00:05: add io 0x0-0xffffffff flags 0x10000001
pnp 00:05: add mem 0xfecc0000-0xfecc0fff flags 0x0
pnp 00:05: add mem 0xfed02000-0xfed02fff flags 0x0
pnp 00:05: PNP0c02: calling quirk_system_pci_resources+0x0/0x1b0
pnp 00:05: Plug and Play ACPI device, IDs PNP0c02 (active)
pnp 00:06: parse allocated resources
pnp 00:06: add mem 0xfed00000-0xfed003ff flags 0x0
pnp 00:06: add irq 0 flags 0x10000000
pnp 00:06: add irq 8 flags 0x1
pnp 00:06: Plug and Play ACPI device, IDs PNP0103 (active)
pnp 00:07: parse allocated resources
pnp 00:07: add io 0x70-0x71 flags 0x1
pnp 00:07: Plug and Play ACPI device, IDs PNP0b00 (active)
pnp 00:08: parse allocated resources
pnp 00:08: add mem 0xfec00000-0xfec00fff flags 0x0
pnp 00:08: add mem 0xfee00000-0xfee00fff flags 0x0
pnp 00:08: PNP0c02: calling quirk_system_pci_resources+0x0/0x1b0
pnp 00:08: Plug and Play ACPI device, IDs PNP0c02 (active)
pnp 00:09: parse allocated resources
pnp 00:09: add irq 12 flags 0x1
pnp 00:09: Plug and Play ACPI device, IDs SYN013d SYN0100 SYN0002 PNP0f12 (active)
pnp 00:0a: parse allocated resources
pnp 00:0a: add mem 0xe0000000-0xefffffff flags 0x0
pnp 00:0a: PNP0c02: calling quirk_system_pci_resources+0x0/0x1b0
pnp 00:0a: Plug and Play ACPI device, IDs PNP0c02 (active)
pnp 00:0b: parse allocated resources
pnp 00:0b: add irq 22 flags 0x1
pnp 00:0b: Plug and Play ACPI device, IDs HPQ0004 (active)
pnp 00:0c: parse allocated resources
pnp 00:0c: add mem 0x0-0x9ffff flags 0x1
pnp 00:0c: add mem 0xc0000-0xcffff flags 0x0
pnp 00:0c: add mem 0xe0000-0xfffff flags 0x0
pnp 00:0c: add mem 0x100000-0x6fefffff flags 0x1
pnp 00:0c: add mem 0xfec00000-0xffffffff flags 0x0
pnp 00:0c: PNP0c01: calling quirk_system_pci_resources+0x0/0x1b0
pnp 00:0c: Plug and Play ACPI device, IDs PNP0c01 (active)
pnp 00:0d: parse allocated resources
pnp 00:0d: Plug and Play ACPI device, IDs PNP0a08 PNP0a03 (active)
pnp: PnP ACPI: found 14 devices
ACPI: ACPI bus type pnp unregistered
PnPBIOS: Disabled by ACPI PNP
SCSI subsystem initialized
usbcore: registered new interface driver usbfs
usbcore: registered new interface driver hub
usbcore: registered new device driver usb
PCI: Using ACPI for IRQ routing
ACPI: RTC can wake from S4
pnp: the driver 'system' has been registered
system 00:05: ioport range 0x3e0-0x3e7 has been reserved
system 00:05: ioport range 0x4d0-0x4d1 has been reserved
system 00:05: ioport range 0x500-0x501 has been reserved
system 00:05: ioport range 0x800-0x87f has been reserved
system 00:05: ioport range 0x400-0x41f has been reserved
system 00:05: iomem range 0xfecc0000-0xfecc0fff could not be reserved
system 00:05: iomem range 0xfed02000-0xfed02fff has been reserved
system 00:05: driver attached
system 00:08: iomem range 0xfec00000-0xfec00fff could not be reserved
system 00:08: iomem range 0xfee00000-0xfee00fff could not be reserved
system 00:08: driver attached
system 00:0a: iomem range 0xe0000000-0xefffffff has been reserved
system 00:0a: driver attached
system 00:0c: iomem range 0x0-0x9ffff could not be reserved
system 00:0c: iomem range 0xc0000-0xcffff could not be reserved
system 00:0c: iomem range 0xe0000-0xfffff could not be reserved
system 00:0c: iomem range 0x100000-0x6fefffff could not be reserved
system 00:0c: iomem range 0xfec00000-0xffffffff could not be reserved
system 00:0c: driver attached
pci 0000:00:01.0: PCI bridge, secondary bus 0000:01
pci 0000:00:01.0: IO window: disabled
pci 0000:00:01.0: MEM window: 0xfbf00000-0xfcffffff
pci 0000:00:01.0: PREFETCH window: 0x000000c0000000-0x000000cfffffff
pci 0000:00:02.0: PCI bridge, secondary bus 0000:02
pci 0000:00:02.0: IO window: 0xd000-0xdfff
pci 0000:00:02.0: MEM window: 0xfd000000-0xfdffffff
pci 0000:00:02.0: PREFETCH window: 0x000000de000000-0x000000dfffffff
pci 0000:00:03.0: PCI bridge, secondary bus 0000:05
pci 0000:00:03.0: IO window: 0xe000-0xefff
pci 0000:00:03.0: MEM window: 0xfe000000-0xfe9fffff
pci 0000:00:03.0: PREFETCH window: 0x000000f8000000-0x000000faffffff
pci 0000:00:13.1: PCI bridge, secondary bus 0000:07
pci 0000:00:13.1: IO window: disabled
pci 0000:00:13.1: MEM window: 0xfea00000-0xfeafffff
pci 0000:00:13.1: PREFETCH window: disabled
pci 0000:00:01.0: setting latency timer to 64
pci 0000:00:02.0: PCI INT A -> GSI 27 (level, low) -> IRQ 27
pci 0000:00:02.0: setting latency timer to 64
pci 0000:00:03.0: PCI INT A -> GSI 31 (level, low) -> IRQ 31
pci 0000:00:03.0: setting latency timer to 64
pci 0000:00:13.1: setting latency timer to 64
bus: 00 index 0 io port: [0, ffff]
bus: 00 index 1 mmio: [0, ffffffff]
bus: 01 index 0 mmio: [0, 0]
bus: 01 index 1 mmio: [fbf00000, fcffffff]
bus: 01 index 2 mmio: [c0000000, cfffffff]
bus: 01 index 3 mmio: [0, 0]
bus: 02 index 0 io port: [d000, dfff]
bus: 02 index 1 mmio: [fd000000, fdffffff]
bus: 02 index 2 mmio: [de000000, dfffffff]
bus: 02 index 3 mmio: [0, 0]
bus: 05 index 0 io port: [e000, efff]
bus: 05 index 1 mmio: [fe000000, fe9fffff]
bus: 05 index 2 mmio: [f8000000, faffffff]
bus: 05 index 3 mmio: [0, 0]
bus: 07 index 0 mmio: [0, 0]
bus: 07 index 1 mmio: [fea00000, feafffff]
bus: 07 index 2 mmio: [0, 0]
bus: 07 index 3 io port: [0, ffff]
bus: 07 index 4 mmio: [0, ffffffff]
bus: 80 index 0 io port: [0, ffff]
bus: 80 index 1 mmio: [0, ffffffff]
NET: Registered protocol family 2
IP route cache hash table entries: 32768 (order: 5, 131072 bytes)
TCP established hash table entries: 131072 (order: 8, 1048576 bytes)
TCP bind hash table entries: 65536 (order: 6, 262144 bytes)
TCP: Hash tables configured (established 131072 bind 65536)
TCP reno registered
NET: Registered protocol family 1
highmem bounce pool size: 64 pages
fuse init (API version 7.9)
msgmni has been set to 1753
io scheduler noop registered (default)
PCI: VIA PCI bridge detected.Disabling DAC.
pci 0000:01:00.0: Boot video device
pcieport-driver 0000:00:02.0: setting latency timer to 64
pcieport-driver 0000:00:02.0: found MSI capability
pci_express 0000:00:02.0:pcie00: allocate port service
pci_express 0000:00:02.0:pcie01: allocate port service
pci_express 0000:00:02.0:pcie02: allocate port service
pci_express 0000:00:02.0:pcie03: allocate port service
pcieport-driver 0000:00:03.0: setting latency timer to 64
pcieport-driver 0000:00:03.0: found MSI capability
pci_express 0000:00:03.0:pcie00: allocate port service
pci_express 0000:00:03.0:pcie01: allocate port service
pci_express 0000:00:03.0:pcie02: allocate port service
pci_express 0000:00:03.0:pcie03: allocate port service
aer 0000:00:02.0:pcie01: AER service couldn't init device: no _OSC support
aer 0000:00:03.0:pcie01: AER service couldn't init device: no _OSC support
vesafb: framebuffer at 0xc0000000, mapped to 0xf8880000, using 1920k, total 32768k
vesafb: mode is 1280x768x8, linelength=1280, pages=33
vesafb: protected mode interface info at c000:8345
vesafb: pmi: set display start = c00c8393, set palette = c00c8428
vesafb: scrolling: redraw
vesafb: Pseudocolor: size=8:8:8:8, shift=0:0:0:0
Console: switching to colour frame buffer device 160x48
fb0: VESA VGA frame buffer device
isapnp: Scanning for PnP cards...
isapnp: No Plug & Play device found
Serial: 8250/16550 driver4 ports, IRQ sharing disabled
pnp: the driver 'serial' has been registered
Floppy drive(s): fd0 is 1.44M
floppy0: no floppy controllers found
brd: module loaded
Uniform Multi-Platform E-IDE driver
ide_generic: please use "probe_mask=0x3f" module parameter for probing all legacy ISA IDE ports
Probing IDE interface ide0...
hda: ST9120817AS, ATA DISK drive
Probing IDE interface ide1...
ide0 at 0x1f0-0x1f7,0x3f6 on irq 14
ide1 at 0x170-0x177,0x376 on irq 15
pnp: the driver 'ide' has been registered
hda: max request size: 512KiB
hda: 234441648 sectors (120034 MB) w/8192KiB Cache, CHS=16383/255/63
hda: cache flushes supported
hda: hda1 hda2 hda3 hda4
ide-floppy driver 1.00
Loading iSCSI transport class v2.0-870.
Driver 'sd' needs updating - please use bus_type methods
Driver 'sr' needs updating - please use bus_type methods
usbmon: debugfs is not available
pnp: the driver 'i8042 kbd' has been registered
i8042 kbd 00:02: driver attached
pnp: the driver 'i8042 aux' has been registered
i8042 aux 00:09: driver attached
PNP: PS/2 Controller [PNP0303:PS2K,PNP0f12:PS2M] at 0x60,0x64 irq 1,12
i8042.c: Detected active multiplexing controller, rev 1.1.
serio: i8042 KBD port at 0x60,0x64 irq 1
serio: i8042 AUX0 port at 0x60,0x64 irq 12
serio: i8042 AUX1 port at 0x60,0x64 irq 12
serio: i8042 AUX2 port at 0x60,0x64 irq 12
serio: i8042 AUX3 port at 0x60,0x64 irq 12
mice: PS/2 mouse device common for all mice
EISA: Probing bus 0 at eisa.0
cpuidle: using governor ladder
TCP cubic registered
Initializing XFRM netlink socket
NET: Registered protocol family 15
Using IPI Shortcut mode
Synaptics Touchpad, model: 1, fw: 6.5, id: 0x1c0b1, caps: 0xa04711/0xa00000
input: SynPS/2 Synaptics TouchPad as /class/input/input0
input: AT Translated Set 2 keyboard as /class/input/input1
kjournald starting. Commit interval 5 seconds
EXT3-fs: mounted filesystem with ordered data mode.
VFS: Mounted root (ext3 filesystem) readonly.
Freeing unused kernel memory: 356k freed
Linux agpgart interface v0.103
agpgart: Detected VIA P4M900 chipset
agpgart-via 0000:00:00.0: AGP aperture is 128M @ 0xf0000000
No dock devices found.
ieee80211_crypt: registered algorithm 'NULL'
libata version 3.00 loaded.
wl: module license 'unspecified' taints kernel.
sata_via 0000:00:0f.0: version 2.3
sata_via 0000:00:0f.0: power state changed by ACPI to D0
sata_via 0000:00:0f.0: invalid PCI BAR 1 (sz 0x3f6, val 0x1)
wl 0000:02:00.0: PCI INT A -> GSI 24 (level, low) -> IRQ 24
wl 0000:02:00.0: setting latency timer to 64
input: Power Button (FF) as /class/input/input2
ACPI: Power Button (FF) [PWRF]
ieee80211_crypt: registered algorithm 'TKIP'
eth0: Broadcom BCM4315 802.11 Hybrid Wireless Controller 5.100.82.112
ehci_hcd 0000:00:10.4: PCI INT C -> GSI 21 (level, low) -> IRQ 21
ehci_hcd 0000:00:10.4: EHCI Host Controller
ehci_hcd 0000:00:10.4: new USB bus registered, assigned bus number 1
ehci_hcd 0000:00:10.4: debug port 1
ehci_hcd 0000:00:10.4: irq 21, io mem 0xfbeffc00
input: Lid Switch as /class/input/input3
ehci_hcd 0000:00:10.4: USB 2.0 started, EHCI 1.00, driver 10 Dec 2004
usb usb1: configuration #1 chosen from 1 choice
hub 1-0:1.0: USB hub found
ACPI: CPU0 (power states: C1[C1] C2[C2] C3[C3])
processor ACPI0007:00: registered as cooling_device0
hub 1-0:1.0: 8 ports detected
ACPI: Lid Switch [LID]
input: Sleep Button (CM) as /class/input/input4
ACPI: Processor [P001] (supports 16 throttling states)
ACPI: Sleep Button (CM) [SLPB]
pata_acpi 0000:00:0f.0: power state changed by ACPI to D0
pata_acpi 0000:00:0f.0: BAR 0: can't reserve I/O region [0x1f0-0x1f7]
pata_acpi 0000:00:0f.0: failed to request/iomap BARs for port 0 (errno=-16)
pata_acpi 0000:00:0f.0: BAR 2: can't reserve I/O region [0x170-0x177]
pata_acpi 0000:00:0f.0: failed to request/iomap BARs for port 1 (errno=-16)
pata_acpi 0000:00:0f.0: no available native port
ACPI: I/O resource vt596_smbus [0x400-0x407] conflicts with ACPI region SMA1 [0x400-0x40f]
ACPI: Device needs an ACPI driver
thermal LNXTHERM:01: registered as thermal_zone0
ACPI: Thermal Zone [THRM] (78 C)
USB Universal Host Controller Interface driver v3.0
uhci_hcd 0000:00:10.0: PCI INT A -> GSI 20 (level, low) -> IRQ 20
usb 1-8: new high speed USB device using ehci_hcd and address 2
uhci_hcd 0000:00:10.0: UHCI Host Controller
input: Power Button (CM) as /class/input/input5
uhci_hcd 0000:00:10.0: new USB bus registered, assigned bus number 2
ACPI: Power Button (CM) [PWRB]
uhci_hcd 0000:00:10.0: irq 20, io base 0x0000c800
usb 1-8: configuration #1 chosen from 1 choice
usb usb2: configuration #1 chosen from 1 choice
hub 2-0:1.0: USB hub found
hub 2-0:1.0: 2 ports detected
uhci_hcd 0000:00:10.2: PCI INT C -> GSI 21 (level, low) -> IRQ 21
uhci_hcd 0000:00:10.2: UHCI Host Controller
uhci_hcd 0000:00:10.2: new USB bus registered, assigned bus number 3
uhci_hcd 0000:00:10.2: irq 21, io base 0x0000c880
usb usb3: configuration #1 chosen from 1 choice
hub 3-0:1.0: USB hub found
hub 3-0:1.0: 2 ports detected
uhci_hcd 0000:00:10.3: PCI INT D -> GSI 23 (level, low) -> IRQ 23
uhci_hcd 0000:00:10.3: UHCI Host Controller
uhci_hcd 0000:00:10.3: new USB bus registered, assigned bus number 4
uhci_hcd 0000:00:10.3: irq 23, io base 0x0000cc00
usb usb4: configuration #1 chosen from 1 choice
ACPI: Battery Slot [BAT1] (battery present)
hub 4-0:1.0: USB hub found
hub 4-0:1.0: 2 ports detected
acpi device:0a: registered as cooling_device1
input: Video Bus as /class/input/input6
ACPI: Video Device [VGA] (multi-head: yes rom: no post: no)
input: PC Speaker as /class/input/input7
ACPI: AC Adapter [AC0] (on-line)
HDA Intel 0000:80:01.0: power state changed by ACPI to D0
HDA Intel 0000:80:01.0: PCI INT A -> GSI 17 (level, low) -> IRQ 17
HDA Intel 0000:80:01.0: setting latency timer to 64
HDA Intel 0000:80:01.0: PCI: Disallowing DAC for device
tg3.c:v3.94 (August 14, 2008)
tg3 0000:07:03.0: PCI INT A -> GSI 16 (level, low) -> IRQ 16
eth0: Tigon3 [partno(BCM95788) rev 3003 PHY(5705)] (PCI:33MHz:32-bit) 10/100/1000Base-T Ethernet 00:24:81:59:74:99
eth0: RXcsums[1] LinkChgREG[0] MIirq[0] ASF[0] WireSpeed[0] TSOcap[1]
eth0: dma_rwctrl[763f0000] dma_mask[32-bit]
Linux video capture interface: v2.00
uvcvideo: Found UVC 1.00 device CNF7070 (04f2:b107)
uvcvideo: UVC non compliance - GET_DEF(PROBE) not supported. Enabling workaround.
input: CNF7070 as /class/input/input8
usbcore: registered new interface driver uvcvideo
USB Video Class driver (v0.1.0)
Marking TSC unstable due to TSC halts in idle
Adding 3904908k swap on /dev/hda2. Priority:-1 extents:1 across:3904908k
EXT3 FS on hda3, internal journal
[drm] Initialized drm 1.1.0 20060810
via-rhine.c:v1.10-LK1.4.3 2007-03-06 Written by Donald Becker
eps: Detected VIA Model D C7-M
eps: Current voltage = 988mV
eps: Current multiplier = 8
eps: Highest voltage = 988mV
eps: Highest multiplier = 8
eps: Lowest voltage = 796mV
eps: Lowest multiplier = 4
kjournald starting. Commit interval 5 seconds
EXT3 FS on hda4, internal journal
EXT3-fs: mounted filesystem with ordered data mode.
Clocksource tsc unstable (delta = -71159833 ns)
NET: Registered protocol family 17
Intel ISA PCIC probe: not found.
ttyS0: LSR safety check engaged!
ttyS0: LSR safety check engaged!
warning: `ntpd' uses 32-bit capabilities (legacy support in use)
$ lspci # Debian Etch / kernel 2.6.16.62
00:00.0 Host bridge: VIA Technologies, Inc. P4M900 Host Bridge
00:00.1 Host bridge: VIA Technologies, Inc. P4M900 Host Bridge
00:00.2 Host bridge: VIA Technologies, Inc. P4M900 Host Bridge
00:00.3 Host bridge: VIA Technologies, Inc. P4M900 Host Bridge
00:00.4 Host bridge: VIA Technologies, Inc. P4M900 Host Bridge
00:00.5 PIC: VIA Technologies, Inc. P4M900 I/O APIC Interrupt Controller
00:00.6 Host bridge: VIA Technologies, Inc. Unknown device 6364
00:00.7 Host bridge: VIA Technologies, Inc. P4M900 Host Bridge
00:01.0 PCI bridge: VIA Technologies, Inc. VT8237 PCI Bridge
00:02.0 PCI bridge: VIA Technologies, Inc. P4M900 PCI to PCI Bridge Controller (rev 80)
00:03.0 PCI bridge: VIA Technologies, Inc. P4M900 PCI to PCI Bridge Controller (rev 80)
00:0f.0 IDE interface: VIA Technologies, Inc. Unknown device 5372
00:10.0 USB Controller: VIA Technologies, Inc. VT82xxxxx UHCI USB 1.1 Controller (rev b0)
00:10.2 USB Controller: VIA Technologies, Inc. VT82xxxxx UHCI USB 1.1 Controller (rev b0)
00:10.3 USB Controller: VIA Technologies, Inc. VT82xxxxx UHCI USB 1.1 Controller (rev b0)
00:10.4 USB Controller: VIA Technologies, Inc. USB 2.0 (rev 90)
00:11.0 ISA bridge: VIA Technologies, Inc. Unknown device 3372
00:11.7 Host bridge: VIA Technologies, Inc. VT8251 Ultra VLINK Controller
00:13.0 Host bridge: VIA Technologies, Inc. VT8237A Host Bridge
00:13.1 PCI bridge: VIA Technologies, Inc. VT8237A PCI to PCI Bridge
01:00.0 VGA compatible controller: VIA Technologies, Inc. Unknown device 3371 (rev 01)
02:00.0 Network controller: Broadcom Corporation BCM4310 USB Controller (rev 01)
07:03.0 Ethernet controller: Broadcom Corporation NetXtreme BCM5788 Gigabit Ethernet (rev 03)
80:01.0 Audio device: VIA Technologies, Inc. VIA High Definition Audio Controller (rev 10)
$ lsmod # Debian Etch / kernel 2.6.16.62
Module Size Used by
rt73 205696 1
firmware_class 10752 1 rt73
thermal 13320 0
fan 4740 0
button 6800 0
ac 4996 0
battery 9604 0
rsrc_nonstatic 12800 0
pcmcia_core 40848 1 rsrc_nonstatic
af_packet 18184 2
snd_hwdep 9860 0
acpi_cpufreq 6280 1
processor 25536 2 thermal,acpi_cpufreq
freq_table 4612 1 acpi_cpufreq
via_rhine 23684 0
via 45664 0
drm 67988 1 via
via_agp 9728 0
agpgart 33628 2 drm,via_agp
sata_via 8708 0
libata 59024 1 sata_via
joydev 9664 0
tsdev 7616 0
rtc 13748 0
bcm5700 145580 0
tg3 98820 0
psmouse 36872 0
serio_raw 7300 0
snd_hda_intel 17936 0
snd_hda_codec 118912 1 snd_hda_intel
snd_pcm_oss 50208 0
snd_mixer_oss 17408 1 snd_pcm_oss
snd_pcm 85128 3 snd_hda_intel,snd_hda_codec,snd_pcm_oss
snd_timer 24964 1 snd_pcm
uhci_hcd 31632 0
pcspkr 3588 0
snd 52196 7 snd_hwdep,snd_hda_intel,snd_hda_codec,snd_pcm_oss,snd_mixer_oss,snd_pcm,snd_timer
soundcore 10336 1 snd
snd_page_alloc 10888 2 snd_hda_intel,snd_pcm
ehci_hcd 30088 0
ieee80211_crypt 6528 0
evdev 9728 1
$ cat /etc/modules # Debian Etch / kernel 2.6.16.62
sata_via
via-agp
via
via-rhine
freq_table
acpi-cpufreq
# pciehp # for Expresscard 54/34 slot
# 2.6.16.62/2.6.27.59 CONFIG_PCIEPORTBUS=y
uvcvideo
# NetXtreme BCM5788 Gigabit Ethernet (rev 03)
tg3
# -inbuilt WLAN (BCM4312 802.11a/b/g):
# b43
snd-hwdep
$ lspci # Debian Etch / kernel 2.6.27.59
00:00.0 Host bridge: VIA Technologies, Inc. P4M900 Host Bridge
00:00.1 Host bridge: VIA Technologies, Inc. P4M900 Host Bridge
00:00.2 Host bridge: VIA Technologies, Inc. P4M900 Host Bridge
00:00.3 Host bridge: VIA Technologies, Inc. P4M900 Host Bridge
00:00.4 Host bridge: VIA Technologies, Inc. P4M900 Host Bridge
00:00.5 PIC: VIA Technologies, Inc. P4M900 I/O APIC Interrupt Controller
00:00.6 Host bridge: VIA Technologies, Inc. Unknown device 6364
00:00.7 Host bridge: VIA Technologies, Inc. P4M900 Host Bridge
00:01.0 PCI bridge: VIA Technologies, Inc. VT8237 PCI Bridge
00:02.0 PCI bridge: VIA Technologies, Inc. P4M900 PCI to PCI Bridge Controller (rev 80)
00:03.0 PCI bridge: VIA Technologies, Inc. P4M900 PCI to PCI Bridge Controller (rev 80)
00:0f.0 IDE interface: VIA Technologies, Inc. Unknown device 5372
00:10.0 USB Controller: VIA Technologies, Inc. VT82xxxxx UHCI USB 1.1 Controller (rev b0)
00:10.2 USB Controller: VIA Technologies, Inc. VT82xxxxx UHCI USB 1.1 Controller (rev b0)
00:10.3 USB Controller: VIA Technologies, Inc. VT82xxxxx UHCI USB 1.1 Controller (rev b0)
00:10.4 USB Controller: VIA Technologies, Inc. USB 2.0 (rev 90)
00:11.0 ISA bridge: VIA Technologies, Inc. Unknown device 3372
00:11.7 Host bridge: VIA Technologies, Inc. VT8251 Ultra VLINK Controller
00:13.0 Host bridge: VIA Technologies, Inc. VT8237A Host Bridge
00:13.1 PCI bridge: VIA Technologies, Inc. VT8237A PCI to PCI Bridge
01:00.0 VGA compatible controller: VIA Technologies, Inc. Unknown device 3371 (rev 01)
02:00.0 Network controller: Broadcom Corporation BCM4310 USB Controller (rev 01)
07:03.0 Ethernet controller: Broadcom Corporation NetXtreme BCM5788 Gigabit Ethernet (rev 03)
80:01.0 Audio device: VIA Technologies, Inc. VIA High Definition Audio Controller (rev 10)
$ lsmod # Debian Etch / kernel 2.6.27.59
Module Size Used by
snd_hda_intel 367512 1
snd_pcm_oss 41824 0
snd_mixer_oss 15496 1 snd_pcm_oss
snd_pcm 76332 2 snd_hda_intel,snd_pcm_oss
snd_timer 22548 1 snd_pcm
snd 54668 7 snd_hda_intel,snd_pcm_oss,snd_mixer_oss,snd_pcm,snd_timer
soundcore 7396 1 snd
snd_page_alloc 8340 2 snd_hda_intel,snd_pcm
fan 4748 0
rsrc_nonstatic 11540 0
pcmcia_core 37456 1 rsrc_nonstatic
af_packet 13320 0
e_powersaver 4364 0
freq_table 4492 1 e_powersaver
via_rhine 21664 0
via 40652 0
drm 77824 1 via
uvcvideo 56624 0
compat_ioctl32 1416 1 uvcvideo
videodev 36776 1 uvcvideo
v4l1_compat 13584 2 uvcvideo,videodev
serio_raw 5644 0
tg3 121616 0
libphy 19216 1 tg3
pcspkr 2568 0
video 18076 0
output 3080 1 video
battery 10768 0
ata_generic 5136 0
i2c_viapro 7972 0
ac 4364 0
i2c_core 23960 1 i2c_viapro
pata_acpi 4232 0
uhci_hcd 23196 0
ieee80211_crypt_tkip 9224 0
thermal 16444 0
sata_via 7820 0
button 6424 0
processor 33368 2 thermal
thermal_sys 10408 4 fan,video,thermal,processor
ehci_hcd 35876 0
wl 2438284 0
ieee80211_crypt 5640 2 ieee80211_crypt_tkip,wl
libata 173976 3 ata_generic,pata_acpi,sata_via
dock 8984 1 libata
via_agp 8200 1
agpgart 34244 2 drm,via_agp
joydev 10212 0
evdev 10532 1
$ cat /etc/modules # Debian Etch / kernel 2.6.27.59
sata_via
# http://kmuto.jp/debian/hcl/HP/Mini+(HP2133)/ "Debian HCL - HP / Mini (HP2133)"
# VIA Technologies, Inc. CN896/VN896/P4M900 Host Bridge
via-agp
via
via-rhine
# http://kmuto.jp/debian/hcl/HP/Mini+(HP2133)/ "Debian HCL - HP / Mini (HP2133)"
# VIA Technologies, Inc. VT8237S PCI to ISA Bridge
# See also i2cdetect(8)
i2c-dev
i2c-viapro
eeprom
# TODO: modprobe i2c-viapro
# ACPI: I/O resource vt596_smbus [0x400-0x407] conflicts with ACPI region SMA1 [0x400-0x40f]
# ACPI: Device needs an ACPI driver
# for HP2133/2.6.16.62
#acpi-cpufreq
# for HP2133/2.6.27.59
# (NB! Do not append the # comment behind)
freq_table
e_powersaver
# for the device /dev/dsp
snd-pcm-oss
# for Expresscard 54/34 slot
# 2.6.16.62/2.6.27.59 CONFIG_PCIEPORTBUS=y
# pciehp
# video works on HP2133/etch/2.6.27.59
uvcvideo
# NetXtreme BCM5788 Gigabit Ethernet
# http://kmuto.jp/debian/hcl/HP/Mini+(HP2133)/ "Debian HCL - HP / Mini (HP2133)"
# dmesg: Tigon3 partno(BCM95788) rev 3003 PHY(5705) Ethernet
# lspci: NetXtreme BCM5788 Gigabit Ethernet (rev 03)
tg3
# Wireless Broadcom BCM4315 802.11 Hybrid Wireless Controller 5.100.82.112
# -inbuilt WLAN (BCM4312 802.11a/b/g):
# b43 (on 2.6.27.59) did not work
#
# 1324698439 while wl.ko compiled under HP2133/etch/2.6.27.59 in
# /local/hp2133/wireless/hybrid-portsrc_x86_32-v5_100_82_112/
# This driver compiled under 2.6.27.59/gcc-3.4
wl
# ssb (according to # http://kmuto.jp/debian/hcl/HP/Mini+(HP2133)/)
$ sudo hwinfo --framebuffer # Debian Etch / kernel 2.6.27.59
02: None 00.0: 11001 VESA Framebuffer
[Created at bios.440]
Unique ID: rdCR.qFD6ZagmcN1
Hardware Class: framebuffer
Model: "VIA N3364
"
Vendor: "VIA N3364
"
Device: "VIA N3364
"
SubVendor: "VIA N3364
"
SubDevice:
Revision: "VIA N3364
"
Memory Size: 32 MB
Memory Range: 0xc0000000-0xc1ffffff (rw)
Mode 0x0301: 640x480 (+640), 8 bits
Mode 0x0311: 640x480 (+1280), 16 bits
Mode 0x0312: 640x480 (+2560), 32 bits
Mode 0x0371: 720x480 (+736), 8 bits
Mode 0x0373: 720x480 (+1440), 16 bits
Mode 0x0375: 720x480 (+2880), 32 bits
Mode 0x03b9: 720x540 (+736), 8 bits
Mode 0x03ba: 720x540 (+1440), 16 bits
Mode 0x03bb: 720x540 (+2880), 32 bits
Mode 0x037c: 720x576 (+736), 8 bits
Mode 0x037e: 720x576 (+1440), 16 bits
Mode 0x037f: 720x576 (+2880), 32 bits
Mode 0x042e: 800x480 (+800), 8 bits
Mode 0x042f: 800x480 (+1600), 16 bits
Mode 0x0430: 800x480 (+3200), 32 bits
Mode 0x0303: 800x600 (+800), 8 bits
Mode 0x0314: 800x600 (+1600), 16 bits
Mode 0x0315: 800x600 (+3200), 32 bits
Mode 0x0422: 852x480 (+864), 8 bits
Mode 0x0423: 852x480 (+1728), 16 bits
Mode 0x0424: 852x480 (+3424), 32 bits
Mode 0x0400: 1024x600 (+1024), 8 bits
Mode 0x0401: 1024x600 (+2048), 16 bits
Mode 0x0403: 1024x600 (+4096), 32 bits
Mode 0x0305: 1024x768 (+1024), 8 bits
Mode 0x0317: 1024x768 (+2048), 16 bits
Mode 0x0318: 1024x768 (+4096), 32 bits
Mode 0x0325: 1280x720 (+1280), 8 bits
Mode 0x0326: 1280x720 (+2560), 16 bits
Mode 0x0327: 1280x720 (+5120), 32 bits
Mode 0x0379: 1280x768 (+1280), 8 bits
Mode 0x037a: 1280x768 (+2560), 16 bits
Mode 0x037b: 1280x768 (+5120), 32 bits
Mode 0x03b6: 1280x800 (+1280), 8 bits
Mode 0x03b7: 1280x800 (+2560), 16 bits
Mode 0x03b8: 1280x800 (+5120), 32 bits
Mode 0x033f: 1280x960 (+1280), 8 bits
Mode 0x034f: 1280x960 (+2560), 16 bits
Mode 0x036a: 1280x960 (+5120), 32 bits
Mode 0x0307: 1280x1024 (+1280), 8 bits
Mode 0x031a: 1280x1024 (+2560), 16 bits
Mode 0x031b: 1280x1024 (+5120), 32 bits
Mode 0x0383: 1366x768 (+1376), 8 bits
Mode 0x0384: 1366x768 (+2752), 16 bits
Mode 0x0385: 1366x768 (+5472), 32 bits
Mode 0x033b: 1400x1050 (+1408), 8 bits
Mode 0x033c: 1400x1050 (+2816), 16 bits
Mode 0x033e: 1400x1050 (+5600), 32 bits
Mode 0x0411: 1440x900 (+1440), 8 bits
Mode 0x0412: 1440x900 (+2880), 16 bits
Mode 0x0413: 1440x900 (+5760), 32 bits
Mode 0x0320: 1600x1200 (+1600), 8 bits
Mode 0x0322: 1600x1200 (+3200), 16 bits
Mode 0x0324: 1600x1200 (+6400), 32 bits
Mode 0x032b: 1680x1050 (+1696), 8 bits
Mode 0x032c: 1680x1050 (+3360), 16 bits
Mode 0x032d: 1680x1050 (+6720), 32 bits
Mode 0x0366: 1920x1080 (+1920), 8 bits
Mode 0x0367: 1920x1080 (+3840), 16 bits
Mode 0x0368: 1920x1080 (+7680), 32 bits
Mode 0x0346: 1920x1200 (+1920), 8 bits
Mode 0x0348: 1920x1200 (+3840), 16 bits
Mode 0x0349: 1920x1200 (+7680), 32 bits
Config Status: cfg=new, avail=yes, need=no, active=unknown
$ sudo dmidecode # Debian Etch / kernel 2.6.27.59
# dmidecode 2.8
SMBIOS 2.5 present.
19 structures occupying 991 bytes.
Table at 0x000FC590.
Handle 0x0000, DMI type 0, 24 bytes
BIOS Information
Vendor: Hewlett-Packard
Version: 68VGU Ver. F.06
Release Date: 11/11/2008
Address: 0xF0000
Runtime Size: 64 kB
ROM Size: 1024 kB
Characteristics:
PCI is supported
PNP is supported
APM is supported
BIOS is upgradeable
BIOS shadowing is allowed
Boot from CD is supported
Selectable boot is supported
BIOS ROM is socketed
EDD is supported
3.5"/720 KB floppy services are supported (int 13h)
Print screen service is supported (int 5h)
8042 keyboard services are supported (int 9h)
Serial services are supported (int 14h)
Printer services are supported (int 17h)
ACPI is supported
USB legacy is supported
LS-120 boot is supported
Smart battery is supported
BIOS boot specification is supported
Function key-initiated network boot is supported
Targeted content distribution is supported
BIOS Revision: 8.14
Handle 0x0001, DMI type 1, 27 bytes
System Information
Manufacturer: Hewlett-Packard
Product Name:
Version: F.06
Serial Number:
UUID: C5E78657-EC91-11F0-A799-CCDDF9E80D7A
Wake-up Type: Power Switch
SKU Number:
Family: 103C_5336AN
Handle 0x0002, DMI type 2, 15 bytes
Base Board Information
Manufacturer: Hewlett-Packard
Product Name: 3030
Version: KBC Version 07.17
Serial Number:
Asset Tag:
Features:
Board is a hosting board
Board is replaceable
Location In Chassis:
Chassis Handle: 0x0003
Type: Motherboard
Contained Object Handles: 0
Handle 0x0003, DMI type 3, 21 bytes
Chassis Information
Manufacturer: Hewlett-Packard
Type: Notebook
Lock: Not Present
Version:
Serial Number:
Asset Tag:
Boot-up State: Safe
Power Supply State: Safe
Thermal State: Safe
Security Status: External Interface Enabled
OEM Information: 0x00000000
Heigth: Unspecified
Number Of Power Cords: 1
Contained Elements: 0
Handle 0x0004, DMI type 4, 40 bytes
Processor Information
Socket Designation: CPU 1
Type: Central Processor
Family:
Manufacturer: VIA
ID: D0 06 00 00 FF BB C9 A7
Version: VIA C7-M Processor 1600MHz
Voltage: 1.0 V
External Clock: 200 MHz
Max Speed: 1600 MHz
Current Speed: 1600 MHz
Status: Populated, Enabled
Upgrade: Socket 478
L1 Cache Handle: 0x0005
L2 Cache Handle: 0x0006
L3 Cache Handle: Not Provided
Serial Number: To Be Filled By O.E.M.
Asset Tag: To Be Filled By O.E.M.
Part Number: To Be Filled By O.E.M.
Handle 0x0005, DMI type 7, 19 bytes
Cache Information
Socket Designation: L1-Cache
Configuration: Enabled, Not Socketed, Level 1
Operational Mode: Write Back
Location: Internal
Installed Size: 128 KB
Maximum Size: 128 KB
Supported SRAM Types:
Other
Installed SRAM Type: Other
Speed: Unknown
Error Correction Type: Parity
System Type: Data
Associativity: 4-way Set-associative
Handle 0x0006, DMI type 7, 19 bytes
Cache Information
Socket Designation: L2-Cache
Configuration: Enabled, Not Socketed, Level 2
Operational Mode: Write Back
Location: Internal
Installed Size: 128 KB
Maximum Size: 128 KB
Supported SRAM Types:
Other
Installed SRAM Type: Other
Speed: Unknown
Error Correction Type: Single-bit ECC
System Type: Unified
Associativity: Other
Handle 0x0007, DMI type 9, 13 bytes
System Slot Information
Designation: AGP
Type: 32-bit AGP 4x
Current Usage: In Use
Length: Short
ID: 0
Characteristics:
3.3 V is provided
Opening is shared
PME signal is supported
Handle 0x0008, DMI type 9, 13 bytes
System Slot Information
Designation: PCI1
Type: 32-bit PCI
Current Usage: Available
Length: Short
ID: 1
Characteristics:
3.3 V is provided
Opening is shared
PME signal is supported
Handle 0x0009, DMI type 10, 6 bytes
On Board Device Information
Type: Video
Status: Enabled
Description: To Be Filled By O.E.M.
Handle 0x000A, DMI type 11, 5 bytes
OEM Strings
String 1: www.hp.com
String 2: LOC#ZZZ
String 3: ABS 70/71 79 7A 7B 7C
Handle 0x000B, DMI type 13, 22 bytes
BIOS Language Information
Installable Languages: 1
en|US|iso8859-1
Currently Installed Language: en|US|iso8859-1
Handle 0x000C, DMI type 15, 35 bytes
System Event Log
Area Length: 4 bytes
Header Start Offset: 0x0000
Header Length: 2 bytes
Data Start Offset: 0x0002
Access Method: Indexed I/O, one 16-bit index port, one 8-bit data port
Access Address: Index 0x046A, Data 0x046C
Status: Invalid, Not Full
Change Token: 0x00000000
Header Format: No Header
Supported Log Type Descriptors: 6
Descriptor 1: End of log
Data Format 1: OEM-specific
Descriptor 2: End of log
Data Format 2: OEM-specific
Descriptor 3: End of log
Data Format 3: OEM-specific
Descriptor 4: End of log
Data Format 4: OEM-specific
Descriptor 5: End of log
Data Format 5: OEM-specific
Descriptor 6: End of log
Data Format 6: OEM-specific
Handle 0x000D, DMI type 16, 15 bytes
Physical Memory Array
Location: System Board Or Motherboard
Use: System Memory
Error Correction Type: None
Maximum Capacity: 4 GB
Error Information Handle: Not Provided
Number Of Devices: 1
Handle 0x000E, DMI type 19, 15 bytes
Memory Array Mapped Address
Starting Address: 0x00000000000
Ending Address: 0x0007FFFFFFF
Range Size: 2 GB
Physical Array Handle: 0x000D
Partition Width: 0
Handle 0x000F, DMI type 17, 27 bytes
Memory Device
Array Handle: 0x000D
Error Information Handle: Not Provided
Total Width: 64 bits
Data Width: 64 bits
Size: 2048 MB
Form Factor: DIMM
Set: None
Locator: DIMM0
Bank Locator: BANK0
Type: DDR2
Type Detail: Synchronous
Speed: Unknown
Manufacturer: Manufacturer00
Serial Number: SerNum00
Asset Tag: AssetTagNum0
Part Number: ModulePartNumber00
Handle 0x0010, DMI type 20, 19 bytes
Memory Device Mapped Address
Starting Address: 0x00000000000
Ending Address: 0x0007FFFFFFF
Range Size: 2 GB
Physical Device Handle: 0x000F
Memory Array Mapped Address Handle: 0x000E
Partition Row Position: 1
Interleaved Data Depth: 1
Handle 0x0011, DMI type 32, 20 bytes
System Boot Information
Status: No errors detected
Handle 0x0012, DMI type 127, 4 bytes
End Of Table
$ sudo hwinfo # Debian Etch / kernel 2.6.27.59
============ start debug info ============
libhd version 13.11 (ia32)
using /var/lib/hardware
kernel version is 2.6
----- /proc/cmdline -----
auto BOOT_IMAGE=Linux262759 ro root=303
----- /proc/cmdline end -----
debug = 0xff7ffff7
probe = 0x0000138fc4aa17fff9fffe (+memory +pci +isapnp +net +floppy +misc +misc.serial +misc.par +misc.floppy +serial +cpu +bios +monitor +mouse +scsi +usb -usb.mods +modem +modem.usb +parallel +parallel.lp +parallel.zip +isa +isa.isdn +isdn +kbd +prom +sbus +int +braille +braille.alva +braille.fhp +braille.ht -ignx11 +sys -bios.vbe -isapnp.old -isapnp.new -isapnp.mod +braille.baum -manual +fb +pppoe -scan +pcmcia -fork -parallel.imm +s390 -cpuemu -sysfs -s390disks +udev +block +block.cdrom +block.part +edd +edd.mod -bios.ddc -bios.fb -bios.mode +input +block.mods +bios.vesa -cpuemu.debug -scsi.noserial +wlan -bios.crc -hal -bios.vram -bios.acpi -bios.ddc.ports=1 -bios.ddc.ports=2 -bios.ddc.ports=3 -bios.ddc.ports=4 -modules.pata -max -lxrc)
shm: attached segment 7634954 at 0xb74c1000
>> hal.1: read hal data
hal: connected to: :1.11
hal: libhal_ctx_init: (null): (null)
>> floppy.1: get nvram
>> floppy.2: klog info
>> bios.1: cmdline
>> bios.1.1: apm
>> bios.2: ram
/dev/mem[0x400, 256]: mmap(, 4096,,,, 0x0) ok
/dev/mem[0xc0000, 262144]: mmap(, 262144,,,, 0xc0000) ok
bios: 1 disks
bios: 639k low mem
/dev/mem[0x9fc00, 1]: mmap(, 4096,,,, 0x9f000) ok
/dev/mem[0x9fc00, 1024]: mmap(, 4096,,,, 0x9f000) ok
bios: EBDA 0x00400 bytes at 0x9fc00
>> bios.2: rom
----- SMBIOS Entry Point 0xfad30 - 0xfad4e -----
fad30 5f 53 4d 5f c1 1f 02 05 bb 00 00 00 00 00 00 00 "_SM_............"
fad40 5f 44 4d 49 5f 0f df 03 90 c5 0f 00 13 00 00 "_DMI_.........."
----- SMBIOS Entry Point end -----
/dev/mem[0xfc590, 991]: mmap(, 4096,,,, 0xfc000) ok
----- SMBIOS Structure Table 0xfc590 - 0xfc96e -----
fc590 00 18 00 00 01 02 00 f0 03 0f 80 9e 0b 3d 01 00 ".............=.."
fc5a0 00 00 93 07 08 0e ff ff 48 65 77 6c 65 74 74 2d "........Hewlett-"
fc5b0 50 61 63 6b 61 72 64 00 36 38 56 47 55 20 56 65 "Packard.68VGU Ve"
fc5c0 72 2e 20 46 2e 30 36 00 31 31 2f 31 31 2f 32 30 "r. F.06.11/11/20"
fc5d0 30 38 00 00 01 1b 01 00 01 02 03 04 c5 e7 86 57 "08.............W"
fc5e0 ec 91 11 f0 a7 99 cc dd f9 e8 0d 7a 06 05 06 48 "...........z...H"
fc5f0 65 77 6c 65 74 74 2d 50 61 63 6b 61 72 64 00 20 "ewlett-Packard. "
fc600 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 " "
fc610 20 20 20 00 46 2e 30 36 00 20 20 20 20 20 20 20 " .F.06. "
fc620 20 20 20 00 20 20 20 20 20 20 20 20 20 20 00 31 " . .1"
fc630 30 33 43 5f 35 33 33 36 41 4e 00 00 02 0f 02 00 "03C_5336AN......"
fc640 01 02 03 04 05 09 06 03 00 0a 00 48 65 77 6c 65 "...........Hewle"
fc650 74 74 2d 50 61 63 6b 61 72 64 00 33 30 33 30 00 "tt-Packard.3030."
fc660 4b 42 43 20 56 65 72 73 69 6f 6e 20 30 37 2e 31 "KBC Version 07.1"
fc670 37 00 20 20 20 20 20 20 20 20 20 20 00 20 20 20 "7. . "
fc680 20 20 20 20 20 20 20 00 20 20 20 20 20 20 20 20 " . "
fc690 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 " "
fc6a0 20 20 20 20 20 20 20 20 00 00 03 15 03 00 01 0a " ........"
fc6b0 02 03 04 03 03 03 05 00 00 00 00 00 01 00 00 48 "...............H"
fc6c0 65 77 6c 65 74 74 2d 50 61 63 6b 61 72 64 00 20 "ewlett-Packard. "
fc6d0 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 " "
fc6e0 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 00 " ."
fc6f0 20 20 20 20 20 20 20 20 20 20 00 20 20 20 20 20 " . "
fc700 20 20 20 20 20 00 00 04 28 04 00 01 03 d2 02 d0 " ...(......."
fc710 06 00 00 ff bb c9 a7 03 8a c8 00 40 06 40 06 41 "...........@.@.A"
fc720 0f 05 00 06 00 ff ff 04 05 06 01 01 01 00 00 43 "...............C"
fc730 50 55 20 31 00 56 49 41 20 20 20 20 20 20 20 20 "PU 1.VIA "
fc740 20 20 20 20 20 20 00 56 49 41 20 43 37 2d 4d 20 " .VIA C7-M "
fc750 50 72 6f 63 65 73 73 6f 72 20 31 36 30 30 4d 48 "Processor 1600MH"
fc760 7a 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 "z "
fc770 20 20 20 20 20 20 20 20 20 20 20 00 54 6f 20 42 " .To B"
fc780 65 20 46 69 6c 6c 65 64 20 42 79 20 4f 2e 45 2e "e Filled By O.E."
fc790 4d 2e 00 54 6f 20 42 65 20 46 69 6c 6c 65 64 20 "M..To Be Filled "
fc7a0 42 79 20 4f 2e 45 2e 4d 2e 00 54 6f 20 42 65 20 "By O.E.M..To Be "
fc7b0 46 69 6c 6c 65 64 20 42 79 20 4f 2e 45 2e 4d 2e "Filled By O.E.M."
fc7c0 00 00 07 13 05 00 01 80 01 80 00 80 00 01 00 01 "................"
fc7d0 00 00 04 04 05 4c 31 2d 43 61 63 68 65 00 00 07 ".....L1-Cache..."
fc7e0 13 06 00 01 81 01 80 00 80 00 01 00 01 00 00 05 "................"
fc7f0 05 01 4c 32 2d 43 61 63 68 65 00 00 09 0d 07 00 "..L2-Cache......"
fc800 01 11 05 04 03 00 00 0c 01 41 47 50 00 00 09 0d ".........AGP...."
fc810 08 00 01 06 05 03 03 01 00 0c 01 50 43 49 31 00 "...........PCI1."
fc820 00 0a 06 09 00 83 01 20 20 54 6f 20 42 65 20 46 "....... To Be F"
fc830 69 6c 6c 65 64 20 42 79 20 4f 2e 45 2e 4d 2e 00 "illed By O.E.M.."
fc840 00 0b 05 0a 00 03 77 77 77 2e 68 70 2e 63 6f 6d "......www.hp.com"
fc850 00 4c 4f 43 23 5a 5a 5a 00 41 42 53 20 37 30 2f ".LOC#ZZZ.ABS 70/"
fc860 37 31 20 37 39 20 37 41 20 37 42 20 37 43 00 00 "71 79 7A 7B 7C.."
fc870 0d 16 0b 00 01 ff 00 00 00 00 00 00 00 00 00 00 "................"
fc880 00 00 00 00 00 01 65 6e 7c 55 53 7c 69 73 6f 38 "......en|US|iso8"
fc890 38 35 39 2d 31 00 00 0f 23 0c 00 04 00 00 00 02 "859-1...#......."
fc8a0 00 02 00 00 00 00 00 6a 04 6c 04 00 06 02 ff ff ".......j.l......"
fc8b0 ff ff ff ff ff ff ff ff ff ff 00 00 10 0f 0d 00 "................"
fc8c0 03 03 03 00 00 40 00 fe ff 01 00 00 00 13 0f 0e ".....@.........."
fc8d0 00 00 00 00 00 ff ff 1f 00 0d 00 01 00 00 11 1b "................"
fc8e0 0f 00 0d 00 fe ff 40 00 40 00 00 08 09 00 01 02 "......@.@......."
fc8f0 13 80 00 00 00 03 04 05 06 44 49 4d 4d 30 00 42 ".........DIMM0.B"
fc900 41 4e 4b 30 00 4d 61 6e 75 66 61 63 74 75 72 65 "ANK0.Manufacture"
fc910 72 30 30 00 53 65 72 4e 75 6d 30 30 00 41 73 73 "r00.SerNum00.Ass"
fc920 65 74 54 61 67 4e 75 6d 30 00 4d 6f 64 75 6c 65 "etTagNum0.Module"
fc930 50 61 72 74 4e 75 6d 62 65 72 30 30 00 00 14 13 "PartNumber00...."
fc940 10 00 00 00 00 00 ff ff 1f 00 0f 00 0e 00 01 00 "................"
fc950 01 00 00 20 14 11 00 00 00 00 00 00 00 00 00 00 "... ............"
fc960 00 00 00 00 00 00 00 00 00 7f 04 12 00 00 00 "..............."
----- SMBIOS Structure Table end -----
type 0x00 [0x0000]: 00 18 00 00 01 02 00 f0 03 0f 80 9e 0b 3d 01 00 00 00 93 07 08 0e ff ff
str1: "Hewlett-Packard"
str2: "68VGU Ver. F.06"
str3: "11/11/2008"
type 0x01 [0x0001]: 01 1b 01 00 01 02 03 04 c5 e7 86 57 ec 91 11 f0 a7 99 cc dd f9 e8 0d 7a 06 05 06
str1: "Hewlett-Packard"
str3: "F.06"
str6: "103C_5336AN"
type 0x02 [0x0002]: 02 0f 02 00 01 02 03 04 05 09 06 03 00 0a 00
str1: "Hewlett-Packard"
str2: "3030"
str3: "KBC Version 07.17"
type 0x03 [0x0003]: 03 15 03 00 01 0a 02 03 04 03 03 03 05 00 00 00 00 00 01 00 00
str1: "Hewlett-Packard"
type 0x04 [0x0004]: 04 28 04 00 01 03 d2 02 d0 06 00 00 ff bb c9 a7 03 8a c8 00 40 06 40 06 41 0f 05 00 06 00 ff ff 04 05 06 01 01 01 00 00
str1: "CPU 1"
str2: "VIA"
str3: "VIA C7-M Processor 1600MHz"
str4: "To Be Filled By O.E.M."
str5: "To Be Filled By O.E.M."
str6: "To Be Filled By O.E.M."
type 0x07 [0x0005]: 07 13 05 00 01 80 01 80 00 80 00 01 00 01 00 00 04 04 05
str1: "L1-Cache"
type 0x07 [0x0006]: 07 13 06 00 01 81 01 80 00 80 00 01 00 01 00 00 05 05 01
str1: "L2-Cache"
type 0x09 [0x0007]: 09 0d 07 00 01 11 05 04 03 00 00 0c 01
str1: "AGP"
type 0x09 [0x0008]: 09 0d 08 00 01 06 05 03 03 01 00 0c 01
str1: "PCI1"
type 0x0a [0x0009]: 0a 06 09 00 83 01
str1: "To Be Filled By O.E.M."
type 0x0b [0x000a]: 0b 05 0a 00 03
str1: "www.hp.com"
str2: "LOC#ZZZ"
str3: "ABS 70/71 79 7A 7B 7C"
type 0x0d [0x000b]: 0d 16 0b 00 01 ff 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 01
str1: "en|US|iso8859-1"
type 0x0f [0x000c]: 0f 23 0c 00 04 00 00 00 02 00 02 00 00 00 00 00 6a 04 6c 04 00 06 02 ff ff ff ff ff ff ff ff ff ff ff ff
type 0x10 [0x000d]: 10 0f 0d 00 03 03 03 00 00 40 00 fe ff 01 00
type 0x13 [0x000e]: 13 0f 0e 00 00 00 00 00 ff ff 1f 00 0d 00 01
type 0x11 [0x000f]: 11 1b 0f 00 0d 00 fe ff 40 00 40 00 00 08 09 00 01 02 13 80 00 00 00 03 04 05 06
str1: "DIMM0"
str2: "BANK0"
str3: "Manufacturer00"
str4: "SerNum00"
str5: "AssetTagNum0"
str6: "ModulePartNumber00"
type 0x14 [0x0010]: 14 13 10 00 00 00 00 00 ff ff 1f 00 0f 00 0e 00 01 00 01
type 0x20 [0x0011]: 20 14 11 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
type 0x7f [0x0012]: 7f 04 12 00
smbios: stopped at end tag
>> bios.3: smp
smp: valid MP FP at 0xff780 (size 0x10, rev 4), MP config at 0xfd110
/dev/mem[0xfd110, 65536]: mmap(, 69632,,,, 0xfd000) ok
base MP config table (35 entries):
type 0, len 20
00 00 14 03 d0 06 00 00 ff bb c9 a7 00 00 00 00 00 00 00 00 "...................."
type 1, len 8
01 00 50 43 49 20 20 20 "..PCI "
type 1, len 8
01 01 50 43 49 20 20 20 "..PCI "
type 1, len 8
01 02 50 43 49 20 20 20 "..PCI "
type 1, len 8
01 03 50 43 49 20 20 20 "..PCI "
type 1, len 8
01 04 50 43 49 20 20 20 "..PCI "
type 1, len 8
01 05 50 43 49 20 20 20 "..PCI "
type 1, len 8
01 06 50 43 49 20 20 20 "..PCI "
type 1, len 8
01 80 50 43 49 20 20 20 "..PCI "
type 1, len 8
01 81 49 53 41 20 20 20 "..ISA "
type 2, len 8
02 01 03 01 00 00 c0 fe "........"
type 2, len 8
02 02 03 01 00 00 cc fe "........"
type 3, len 8
03 03 00 00 81 00 01 00 "........"
type 3, len 8
03 00 00 00 81 01 01 01 "........"
type 3, len 8
03 00 00 00 81 00 01 02 "........"
type 3, len 8
03 00 00 00 81 04 01 04 "........"
type 3, len 8
03 00 00 00 81 06 01 06 "........"
type 3, len 8
03 00 05 00 81 08 01 08 "........"
type 3, len 8
03 00 00 00 81 09 01 09 "........"
type 3, len 8
03 00 00 00 81 0a 01 0a "........"
type 3, len 8
03 00 00 00 81 0c 01 0c "........"
type 3, len 8
03 00 00 00 81 0d 01 0d "........"
type 3, len 8
03 00 00 00 81 0e 01 0e "........"
type 3, len 8
03 00 00 00 81 0f 01 0f "........"
type 3, len 8
03 00 0f 00 00 40 01 14 ".....@.."
type 3, len 8
03 00 0f 00 00 42 01 15 ".....B.."
type 3, len 8
03 00 0f 00 00 43 01 17 ".....C.."
type 3, len 8
03 00 0f 00 80 04 01 11 "........"
type 3, len 8
03 00 0f 00 01 00 01 10 "........"
type 3, len 8
03 00 0f 00 07 0c 01 10 "........"
type 3, len 8
03 00 0f 00 00 08 02 03 "........"
type 3, len 8
03 00 0f 00 02 00 02 00 "........"
type 3, len 8
03 00 0f 00 00 0c 02 07 "........"
type 4, len 8
04 03 00 00 00 00 ff 00 "........"
type 4, len 8
04 01 00 00 00 00 ff 01 "........"
extended MP config table:
type 128, len 20
80 14 00 00 00 00 00 00 00 00 00 00 0f 00 00 00 00 00 00 00 "...................."
type 128, len 20
80 14 00 01 00 00 0a 00 00 00 00 00 00 00 02 00 00 00 00 00 "...................."
type 128, len 20
80 14 00 01 00 00 00 00 00 00 00 00 00 00 ff ff 00 00 00 00 "...................."
type 128, len 20
80 14 00 02 00 00 00 f0 00 00 00 00 00 00 00 08 00 00 00 00 "...................."
type 128, len 20
80 14 00 02 0f 00 00 00 00 00 00 00 00 00 00 ff 00 00 00 00 "...................."
type 128, len 20
80 14 c0 00 00 00 00 00 00 00 00 00 ff ff 00 00 00 00 00 00 "...................."
type 128, len 20
80 14 c0 01 00 00 0a 00 00 00 00 00 00 00 02 00 00 00 00 00 "...................."
type 128, len 20
80 14 c0 01 00 00 00 00 00 00 00 00 00 ff 00 00 00 00 00 00 "...................."
type 128, len 20
80 14 c0 02 00 00 00 00 00 00 00 00 52 00 4a 00 00 00 00 00 "............R.J....."
type 128, len 20
80 14 00 01 00 00 0a 00 00 00 00 00 00 00 02 00 00 00 00 00 "...................."
type 128, len 20
80 14 00 01 00 00 52 00 00 00 00 00 4d 00 00 00 00 00 00 00 "......R.....M......."
type 128, len 20
80 14 00 02 00 00 00 f0 00 00 00 00 00 00 00 08 00 00 00 00 "...................."
type 128, len 20
80 14 00 02 00 00 40 40 00 00 00 00 00 00 40 00 00 00 00 00 "......@@......@....."
type 128, len 20
80 14 52 01 00 00 0a 00 00 00 00 00 00 00 02 00 00 00 00 00 "..R................."
type 128, len 20
80 14 52 02 00 00 00 00 00 00 00 00 ff ff 0f 00 00 00 00 00 "..R................."
type 128, len 20
80 14 0f 00 46 47 00 00 00 00 00 00 40 00 00 00 00 00 00 00 "....FG......@......."
type 128, len 20
80 14 0f 02 64 03 06 11 00 00 00 00 42 00 00 00 00 00 00 00 "....d.......B......."
type 128, len 20
80 14 01 01 00 00 0a 00 00 00 00 00 00 00 02 00 00 00 00 00 "...................."
type 128, len 20
80 14 01 01 0f 00 00 00 00 00 00 00 00 00 00 ff 00 00 00 00 "...................."
type 128, len 20
80 14 01 02 00 00 00 00 00 00 00 00 00 00 52 00 00 00 00 00 "..............R....."
type 128, len 20
80 14 00 00 00 00 00 00 00 00 00 00 00 01 00 00 00 00 00 00 "...................."
type 128, len 20
80 14 00 01 00 00 00 00 00 00 00 00 64 03 06 11 00 00 00 00 "............d......."
type 128, len 20
80 14 00 02 00 00 00 f0 00 00 00 00 00 00 00 08 00 00 00 00 "...................."
type 128, len 20
80 14 00 02 34 00 00 00 00 00 00 00 00 00 ff 0f 00 00 00 00 "....4..............."
type 128, len 20
80 14 00 01 64 03 06 11 00 00 00 00 26 00 00 00 00 00 00 00 "....d.......&......."
type 128, len 20
80 14 00 02 00 00 00 f0 00 00 00 00 00 00 00 08 00 00 00 00 "...................."
type 128, len 20
80 14 00 00 00 00 00 00 00 00 00 00 00 01 00 00 00 00 00 00 "...................."
type 128, len 20
80 14 00 01 00 00 0a 00 00 00 00 00 00 00 02 00 00 00 00 00 "...................."
type 128, len 20
80 14 00 02 00 00 00 f0 00 00 00 00 00 00 00 08 00 00 00 00 "...................."
type 128, len 20
80 14 00 02 40 40 00 00 00 00 00 00 40 00 01 00 00 00 00 00 "....@@......@......."
type 128, len 20
80 14 40 00 00 00 00 00 00 00 00 00 ff ff 00 00 00 00 00 00 "..@................."
type 128, len 20
80 14 40 01 00 00 0a 00 00 00 00 00 00 00 02 00 00 00 00 00 "..@................."
type 128, len 20
80 14 40 01 ff ff ff ff 00 00 00 00 ff ff ff ff 00 00 00 00 "..@................."
type 128, len 20
80 14 00 00 ff ff 00 00 00 00 00 00 ff ff 00 00 00 00 00 00 "...................."
type 128, len 20
80 14 00 00 00 00 00 00 00 00 00 00 00 01 00 00 00 00 00 00 "...................."
type 128, len 20
80 14 00 01 00 00 0a 00 00 00 00 00 00 00 02 00 00 00 00 00 "...................."
type 128, len 20
80 14 00 01 f0 ff ff ff 00 00 00 00 ff ff ff ff 00 00 00 00 "...................."
type 128, len 20
80 14 00 02 00 00 00 f0 00 00 00 00 00 00 00 08 00 00 00 00 "...................."
type 128, len 20
80 14 00 02 ff ff ff ff 00 00 00 00 ff ff 00 0f 00 00 00 00 "...................."
type 128, len 20
80 14 c0 00 00 00 00 00 00 00 00 00 ff ff 00 00 00 00 00 00 "...................."
type 128, len 20
80 14 c0 01 00 00 0a 00 00 00 00 00 00 00 02 00 00 00 00 00 "...................."
type 128, len 20
80 14 c0 01 00 00 00 00 00 00 00 00 00 40 00 00 00 00 00 00 ".............@......"
type 128, len 20
80 14 c0 02 00 00 00 00 00 00 00 00 52 00 8a 00 00 00 00 00 "............R......."
type 128, len 20
80 14 00 00 00 00 00 00 00 00 00 00 00 01 00 00 00 00 00 00 "...................."
type 128, len 20
80 14 00 01 00 00 0a 00 00 00 00 00 00 00 02 00 00 00 00 00 "...................."
type 128, len 20
80 14 00 01 00 00 52 00 00 00 00 00 8d 00 00 00 00 00 00 00 "......R............."
type 128, len 20
80 14 00 02 00 00 00 f0 00 00 00 00 00 00 00 08 00 00 00 00 "...................."
type 128, len 20
80 14 00 02 00 00 40 40 00 00 00 00 00 00 40 00 00 00 00 00 "......@@......@....."
type 128, len 20
80 14 52 01 00 00 0a 00 00 00 00 00 00 00 02 00 00 00 00 00 "..R................."
type 128, len 20
80 14 52 01 ff ff ff ff 00 00 00 00 00 00 f0 ff 00 00 00 00 "..R................."
type 128, len 20
80 14 52 02 ff ff ff ff 00 00 00 00 ff ff ff ff 00 00 00 00 "..R................."
type 128, len 20
80 14 ff 00 46 47 00 00 00 00 00 00 40 00 00 00 00 00 00 00 "....FG......@......."
type 128, len 20
80 14 ff 01 00 00 00 00 00 00 00 00 00 00 40 00 00 00 00 00 "..............@....."
type 128, len 20
80 14 ff 02 ff ff ff ff 00 00 00 00 02 00 00 ff 00 00 00 00 "...................."
type 129, len 8
81 08 81 01 00 00 00 00 "........"
type 130, len 8
82 08 00 00 00 00 00 00 "........"
type 130, len 8
82 08 c0 01 00 00 00 00 "........"
type 130, len 8
82 08 00 00 00 00 00 00 "........"
type 130, len 8
82 08 52 01 00 00 00 00 "..R....."
type 130, len 8
82 08 0f 01 00 00 00 00 "........"
type 130, len 8
82 08 01 01 00 00 00 00 "........"
type 130, len 8
82 08 00 00 00 00 00 00 "........"
type 130, len 8
82 08 00 00 00 00 00 00 "........"
type 130, len 8
82 08 00 00 00 00 00 00 "........"
type 130, len 8
82 08 40 01 00 00 00 00 "..@....."
type 130, len 8
82 08 00 00 00 00 00 00 "........"
type 130, len 8
82 08 c0 01 00 00 00 00 "........"
type 130, len 8
82 08 00 00 00 00 00 00 "........"
type 130, len 8
82 08 52 01 00 00 00 00 "..R....."
type 130, len 8
82 08 ff 01 00 00 00 00 "........"
type 130, len 8
82 08 00 00 01 00 00 00 "........"
type 130, len 8
82 08 c0 00 01 00 00 00 "........"
type 130, len 8
82 08 00 00 01 00 00 00 "........"
type 130, len 8
82 08 52 00 01 00 00 00 "..R....."
type 130, len 8
82 08 0f 01 01 00 00 00 "........"
type 130, len 8
82 08 01 00 01 00 00 00 "........"
type 130, len 8
82 08 00 01 01 00 00 00 "........"
type 130, len 8
82 08 00 01 01 00 00 00 "........"
type 130, len 8
82 08 00 00 01 00 00 00 "........"
type 130, len 8
82 08 40 00 01 00 00 00 "..@....."
type 130, len 8
82 08 00 00 01 00 00 00 "........"
type 130, len 8
82 08 c0 00 01 00 00 00 "........"
type 130, len 8
82 08 00 00 01 00 00 00 "........"
type 130, len 8
82 08 52 00 01 00 00 00 "..R....."
type 130, len 8
82 08 ff 01 01 00 00 00 "........"
----- BIOS data 0x00400 - 0x004ff -----
400 00 00 00 00 00 00 00 00 00 00 00 00 00 00 c0 9f "................"
410 26 00 20 7f 02 91 00 00 00 00 1e 00 1e 00 00 00 "&. ............."
420 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
430 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
440 00 00 00 00 00 00 00 00 00 2b a0 00 ff ff 00 00 ".........+......"
450 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
460 0e 0d 00 d4 03 29 30 d4 c7 00 90 00 27 91 0c 00 ".....)0.....'..."
470 00 00 00 00 00 01 08 00 14 14 14 14 01 01 01 01 "................"
480 1e 00 3e 00 2f 10 00 60 09 11 0b 81 58 01 00 02 "..>./..`....X..."
490 07 00 00 00 00 00 00 10 00 00 00 00 00 00 00 00 "................"
4a0 00 00 00 00 00 00 00 00 86 03 00 c0 00 00 00 00 "................"
4b0 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
4c0 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
4d0 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
4e0 04 c8 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
4f0 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
----- BIOS data end -----
----- EBDA 0x9fc00 - 0x9ffff -----
9fc00 01 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
9fc10 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
9fc20 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
9fc30 00 00 00 00 00 00 00 00 00 00 00 00 00 13 0f ff "................"
9fc40 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
9fc50 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
9fc60 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
9fc70 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
9fc80 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
9fc90 01 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
9fca0 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
9fcb0 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
9fcc0 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
9fcd0 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
9fce0 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
9fcf0 00 00 00 00 00 00 00 00 01 00 00 00 00 00 00 00 "................"
9fd00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
9fd10 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
9fd20 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
9fd30 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
9fd40 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
9fd50 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
9fd60 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
9fd70 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
9fd80 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
9fd90 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
9fda0 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
9fdb0 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
9fdc0 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
9fdd0 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
9fde0 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
9fdf0 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
9fe00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
9fe10 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
9fe20 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
9fe30 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
9fe40 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
9fe50 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
9fe60 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
9fe70 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
9fe80 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
9fe90 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
9fea0 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
9feb0 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
9fec0 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
9fed0 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
9fee0 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
9fef0 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
9ff00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
9ff10 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
9ff20 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
9ff30 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
9ff40 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
9ff50 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
9ff60 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
9ff70 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
9ff80 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
9ff90 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
9ffa0 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
9ffb0 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
9ffc0 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
9ffd0 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
9ffe0 80 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
9fff0 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
----- EBDA end -----
/dev/mem[0xff780, 16]: mmap(, 4096,,,, 0xff000) ok
----- MP FP 0xff780 - 0xff78f -----
ff780 5f 4d 50 5f 10 d1 0f 00 01 04 b0 00 00 00 00 00 "_MP_............"
----- MP FP end -----
/dev/mem[0xfd110, 1664]: mmap(, 4096,,,, 0xfd000) ok
----- MP config table 0xfd110 - 0xfd78f -----
fd110 50 43 4d 50 50 01 04 8c 54 45 4d 50 4c 41 54 45 "PCMPP...TEMPLATE"
fd120 45 54 45 4d 50 4c 41 54 45 20 20 20 00 00 00 00 "ETEMPLATE ...."
fd130 00 00 23 00 00 00 e0 fe 30 05 cd 00 00 00 14 03 "..#.....0......."
fd140 d0 06 00 00 ff bb c9 a7 00 00 00 00 00 00 00 00 "................"
fd150 01 00 50 43 49 20 20 20 01 01 50 43 49 20 20 20 "..PCI ..PCI "
fd160 01 02 50 43 49 20 20 20 01 03 50 43 49 20 20 20 "..PCI ..PCI "
fd170 01 04 50 43 49 20 20 20 01 05 50 43 49 20 20 20 "..PCI ..PCI "
fd180 01 06 50 43 49 20 20 20 01 80 50 43 49 20 20 20 "..PCI ..PCI "
fd190 01 81 49 53 41 20 20 20 02 01 03 01 00 00 c0 fe "..ISA ........"
fd1a0 02 02 03 01 00 00 cc fe 03 03 00 00 81 00 01 00 "................"
fd1b0 03 00 00 00 81 01 01 01 03 00 00 00 81 00 01 02 "................"
fd1c0 03 00 00 00 81 04 01 04 03 00 00 00 81 06 01 06 "................"
fd1d0 03 00 05 00 81 08 01 08 03 00 00 00 81 09 01 09 "................"
fd1e0 03 00 00 00 81 0a 01 0a 03 00 00 00 81 0c 01 0c "................"
fd1f0 03 00 00 00 81 0d 01 0d 03 00 00 00 81 0e 01 0e "................"
fd200 03 00 00 00 81 0f 01 0f 03 00 0f 00 00 40 01 14 ".............@.."
fd210 03 00 0f 00 00 42 01 15 03 00 0f 00 00 43 01 17 ".....B.......C.."
fd220 03 00 0f 00 80 04 01 11 03 00 0f 00 01 00 01 10 "................"
fd230 03 00 0f 00 07 0c 01 10 03 00 0f 00 00 08 02 03 "................"
fd240 03 00 0f 00 02 00 02 00 03 00 0f 00 00 0c 02 07 "................"
fd250 04 03 00 00 00 00 ff 00 04 01 00 00 00 00 ff 01 "................"
fd260 80 14 00 00 00 00 00 00 00 00 00 00 0f 00 00 00 "................"
fd270 00 00 00 00 80 14 00 01 00 00 0a 00 00 00 00 00 "................"
fd280 00 00 02 00 00 00 00 00 80 14 00 01 00 00 00 00 "................"
fd290 00 00 00 00 00 00 ff ff 00 00 00 00 80 14 00 02 "................"
fd2a0 00 00 00 f0 00 00 00 00 00 00 00 08 00 00 00 00 "................"
fd2b0 80 14 00 02 0f 00 00 00 00 00 00 00 00 00 00 ff "................"
fd2c0 00 00 00 00 80 14 c0 00 00 00 00 00 00 00 00 00 "................"
fd2d0 ff ff 00 00 00 00 00 00 80 14 c0 01 00 00 0a 00 "................"
fd2e0 00 00 00 00 00 00 02 00 00 00 00 00 80 14 c0 01 "................"
fd2f0 00 00 00 00 00 00 00 00 00 ff 00 00 00 00 00 00 "................"
fd300 80 14 c0 02 00 00 00 00 00 00 00 00 52 00 4a 00 "............R.J."
fd310 00 00 00 00 80 14 00 01 00 00 0a 00 00 00 00 00 "................"
fd320 00 00 02 00 00 00 00 00 80 14 00 01 00 00 52 00 "..............R."
fd330 00 00 00 00 4d 00 00 00 00 00 00 00 80 14 00 02 "....M..........."
fd340 00 00 00 f0 00 00 00 00 00 00 00 08 00 00 00 00 "................"
fd350 80 14 00 02 00 00 40 40 00 00 00 00 00 00 40 00 "......@@......@."
fd360 00 00 00 00 80 14 52 01 00 00 0a 00 00 00 00 00 "......R........."
fd370 00 00 02 00 00 00 00 00 80 14 52 02 00 00 00 00 "..........R....."
fd380 00 00 00 00 ff ff 0f 00 00 00 00 00 80 14 0f 00 "................"
fd390 46 47 00 00 00 00 00 00 40 00 00 00 00 00 00 00 "FG......@......."
fd3a0 80 14 0f 02 64 03 06 11 00 00 00 00 42 00 00 00 "....d.......B..."
fd3b0 00 00 00 00 80 14 01 01 00 00 0a 00 00 00 00 00 "................"
fd3c0 00 00 02 00 00 00 00 00 80 14 01 01 0f 00 00 00 "................"
fd3d0 00 00 00 00 00 00 00 ff 00 00 00 00 80 14 01 02 "................"
fd3e0 00 00 00 00 00 00 00 00 00 00 52 00 00 00 00 00 "..........R....."
fd3f0 80 14 00 00 00 00 00 00 00 00 00 00 00 01 00 00 "................"
fd400 00 00 00 00 80 14 00 01 00 00 00 00 00 00 00 00 "................"
fd410 64 03 06 11 00 00 00 00 80 14 00 02 00 00 00 f0 "d..............."
fd420 00 00 00 00 00 00 00 08 00 00 00 00 80 14 00 02 "................"
fd430 34 00 00 00 00 00 00 00 00 00 ff 0f 00 00 00 00 "4..............."
fd440 80 14 00 01 64 03 06 11 00 00 00 00 26 00 00 00 "....d.......&..."
fd450 00 00 00 00 80 14 00 02 00 00 00 f0 00 00 00 00 "................"
fd460 00 00 00 08 00 00 00 00 80 14 00 00 00 00 00 00 "................"
fd470 00 00 00 00 00 01 00 00 00 00 00 00 80 14 00 01 "................"
fd480 00 00 0a 00 00 00 00 00 00 00 02 00 00 00 00 00 "................"
fd490 80 14 00 02 00 00 00 f0 00 00 00 00 00 00 00 08 "................"
fd4a0 00 00 00 00 80 14 00 02 40 40 00 00 00 00 00 00 "........@@......"
fd4b0 40 00 01 00 00 00 00 00 80 14 40 00 00 00 00 00 "@.........@....."
fd4c0 00 00 00 00 ff ff 00 00 00 00 00 00 80 14 40 01 "..............@."
fd4d0 00 00 0a 00 00 00 00 00 00 00 02 00 00 00 00 00 "................"
fd4e0 80 14 40 01 ff ff ff ff 00 00 00 00 ff ff ff ff "..@............."
fd4f0 00 00 00 00 80 14 00 00 ff ff 00 00 00 00 00 00 "................"
fd500 ff ff 00 00 00 00 00 00 80 14 00 00 00 00 00 00 "................"
fd510 00 00 00 00 00 01 00 00 00 00 00 00 80 14 00 01 "................"
fd520 00 00 0a 00 00 00 00 00 00 00 02 00 00 00 00 00 "................"
fd530 80 14 00 01 f0 ff ff ff 00 00 00 00 ff ff ff ff "................"
fd540 00 00 00 00 80 14 00 02 00 00 00 f0 00 00 00 00 "................"
fd550 00 00 00 08 00 00 00 00 80 14 00 02 ff ff ff ff "................"
fd560 00 00 00 00 ff ff 00 0f 00 00 00 00 80 14 c0 00 "................"
fd570 00 00 00 00 00 00 00 00 ff ff 00 00 00 00 00 00 "................"
fd580 80 14 c0 01 00 00 0a 00 00 00 00 00 00 00 02 00 "................"
fd590 00 00 00 00 80 14 c0 01 00 00 00 00 00 00 00 00 "................"
fd5a0 00 40 00 00 00 00 00 00 80 14 c0 02 00 00 00 00 ".@.............."
fd5b0 00 00 00 00 52 00 8a 00 00 00 00 00 80 14 00 00 "....R..........."
fd5c0 00 00 00 00 00 00 00 00 00 01 00 00 00 00 00 00 "................"
fd5d0 80 14 00 01 00 00 0a 00 00 00 00 00 00 00 02 00 "................"
fd5e0 00 00 00 00 80 14 00 01 00 00 52 00 00 00 00 00 "..........R....."
fd5f0 8d 00 00 00 00 00 00 00 80 14 00 02 00 00 00 f0 "................"
fd600 00 00 00 00 00 00 00 08 00 00 00 00 80 14 00 02 "................"
fd610 00 00 40 40 00 00 00 00 00 00 40 00 00 00 00 00 "..@@......@....."
fd620 80 14 52 01 00 00 0a 00 00 00 00 00 00 00 02 00 "..R............."
fd630 00 00 00 00 80 14 52 01 ff ff ff ff 00 00 00 00 "......R........."
fd640 00 00 f0 ff 00 00 00 00 80 14 52 02 ff ff ff ff "..........R....."
fd650 00 00 00 00 ff ff ff ff 00 00 00 00 80 14 ff 00 "................"
fd660 46 47 00 00 00 00 00 00 40 00 00 00 00 00 00 00 "FG......@......."
fd670 80 14 ff 01 00 00 00 00 00 00 00 00 00 00 40 00 "..............@."
fd680 00 00 00 00 80 14 ff 02 ff ff ff ff 00 00 00 00 "................"
fd690 02 00 00 ff 00 00 00 00 81 08 81 01 00 00 00 00 "................"
fd6a0 82 08 00 00 00 00 00 00 82 08 c0 01 00 00 00 00 "................"
fd6b0 82 08 00 00 00 00 00 00 82 08 52 01 00 00 00 00 "..........R....."
fd6c0 82 08 0f 01 00 00 00 00 82 08 01 01 00 00 00 00 "................"
fd6d0 82 08 00 00 00 00 00 00 82 08 00 00 00 00 00 00 "................"
fd6e0 82 08 00 00 00 00 00 00 82 08 40 01 00 00 00 00 "..........@....."
fd6f0 82 08 00 00 00 00 00 00 82 08 c0 01 00 00 00 00 "................"
fd700 82 08 00 00 00 00 00 00 82 08 52 01 00 00 00 00 "..........R....."
fd710 82 08 ff 01 00 00 00 00 82 08 00 00 01 00 00 00 "................"
fd720 82 08 c0 00 01 00 00 00 82 08 00 00 01 00 00 00 "................"
fd730 82 08 52 00 01 00 00 00 82 08 0f 01 01 00 00 00 "..R............."
fd740 82 08 01 00 01 00 00 00 82 08 00 01 01 00 00 00 "................"
fd750 82 08 00 01 01 00 00 00 82 08 00 00 01 00 00 00 "................"
fd760 82 08 40 00 01 00 00 00 82 08 00 00 01 00 00 00 "..@............."
fd770 82 08 c0 00 01 00 00 00 82 08 00 00 01 00 00 00 "................"
fd780 82 08 52 00 01 00 00 00 82 08 ff 01 01 00 00 00 "..R............."
----- MP config table end -----
>> bios.4: vbe
/dev/mem[0xc0000, 3]: mmap(, 4096,,,, 0xc0000) ok
/dev/mem[0xc0000, 52224]: mmap(, 53248,,,, 0xc0000) ok
/dev/mem[0x0, 4096]: mmap(, 4096,,,, 0x0) ok
vbe: int 10h points to c000:68f9: fb fc 1e 06 66 60 e8 aa
>> bios.4.1: vbe info
vm86: using CPU emulation
>> bios.5: 32
bios32: valid SD header at 0xf0000 (size 0x10, rev 0), SD at 0xf0010
>> bios.6: acpi
>> sys.1: cpu
vmware check: 0
>> misc.9: kernel log
----- kernel log -----
<4>pata_acpi 0000:00:0f.0: BAR 2: can't reserve I/O region [0x170-0x177]
<4>pata_acpi 0000:00:0f.0: failed to request/iomap BARs for port 1 (errno=-16)
<3>pata_acpi 0000:00:0f.0: no available native port
<6>uhci_hcd 0000:00:10.2: PCI INT C -> GSI 21 (level, low) -> IRQ 21
<6>uhci_hcd 0000:00:10.2: UHCI Host Controller
<6>uhci_hcd 0000:00:10.2: new USB bus registered, assigned bus number 3
<6>uhci_hcd 0000:00:10.2: irq 21, io base 0x0000c880
<6>usb usb3: configuration #1 chosen from 1 choice
<6>hub 3-0:1.0: USB hub found
<6>hub 3-0:1.0: 2 ports detected
<6>uhci_hcd 0000:00:10.3: PCI INT D -> GSI 23 (level, low) -> IRQ 23
<6>uhci_hcd 0000:00:10.3: UHCI Host Controller
<6>uhci_hcd 0000:00:10.3: new USB bus registered, assigned bus number 4
<6>uhci_hcd 0000:00:10.3: irq 23, io base 0x0000cc00
<6>usb usb4: configuration #1 chosen from 1 choice
<6>hub 4-0:1.0: USB hub found
<6>hub 4-0:1.0: 2 ports detected
<6>ACPI: AC Adapter [AC0] (on-line)
<4>ACPI: I/O resource vt596_smbus [0x400-0x407] conflicts with ACPI region SMA1 [0x400-0x40f]
<6>ACPI: Device needs an ACPI driver
<6>ACPI: Battery Slot [BAT1] (battery present)
<6>acpi device:0a: registered as cooling_device1
<6>input: Video Bus as /class/input/input6
<6>ACPI: Video Device [VGA] (multi-head: yes rom: no post: no)
<6>input: PC Speaker as /class/input/input7
<6>HDA Intel 0000:80:01.0: power state changed by ACPI to D0
<6>HDA Intel 0000:80:01.0: PCI INT A -> GSI 17 (level, low) -> IRQ 17
<7>HDA Intel 0000:80:01.0: setting latency timer to 64
<6>HDA Intel 0000:80:01.0: PCI: Disallowing DAC for device
<6>tg3.c:v3.94 (August 14, 2008)
<6>tg3 0000:07:03.0: PCI INT A -> GSI 16 (level, low) -> IRQ 16
<6>eth0: Tigon3 [partno(BCM95788) rev 3003 PHY(5705)] (PCI:33MHz:32-bit) 10/100/1000Base-T Ethernet 00:24:81:59:74:99
<6>eth0: RXcsums[1] LinkChgREG[0] MIirq[0] ASF[0] WireSpeed[0] TSOcap[1]
<6>eth0: dma_rwctrl[763f0000] dma_mask[32-bit]
<6>Linux video capture interface: v2.00
<6>uvcvideo: Found UVC 1.00 device CNF7070 (04f2:b107)
<6>uvcvideo: UVC non compliance - GET_DEF(PROBE) not supported. Enabling workaround.
<6>input: CNF7070 as /class/input/input8
<6>usbcore: registered new interface driver uvcvideo
<6>USB Video Class driver (v0.1.0)
<4>Marking TSC unstable due to TSC halts in idle
<6>Adding 3904908k swap on /dev/hda2. Priority:-1 extents:1 across:3904908k
<6>EXT3 FS on hda3, internal journal
<6>[drm] Initialized drm 1.1.0 20060810
<6>via-rhine.c:v1.10-LK1.4.3 2007-03-06 Written by Donald Becker
<6>kjournald starting. Commit interval 5 seconds
<6>EXT3 FS on hda4, internal journal
<6>EXT3-fs: mounted filesystem with ordered data mode.
<3>FAT: Unrecognized mount option "nls=cp950" or missing value
<4>Clocksource tsc unstable (delta = -67969258 ns)
<6>NET: Registered protocol family 17
<6>Intel ISA PCIC probe: not found.
<4>ttyS0: LSR safety check engaged!
<4>ttyS0: LSR safety check engaged!
<6>warning: `ntpd' uses 32-bit capabilities (legacy support in use)
<4>evdev.c(EVIOCGBIT): Suspicious buffer size 511, limiting output to 64 bytes. See http://userweb.kernel.org/~dtor/eviocgbit-bug.html
<6>device eth13 entered promiscuous mode
<6>device eth13 left promiscuous mode
<4>hda-intel: Invalid position buffer, using LPIB read method instead.
<4>hda-intel: IRQ timing workaround is activated for card #0. Suggest a bigger bdl_pos_adj.
<6>usb 2-1: new low speed USB device using uhci_hcd and address 2
<6>usb 2-1: configuration #1 chosen from 1 choice
<6>usbcore: registered new interface driver hiddev
<6>input: USB OPTICAL MOUSE as /class/input/input9
<6>input: USB HID v1.11 Mouse [ USB OPTICAL MOUSE] on usb-0000:00:10.0-1
<6>usbcore: registered new interface driver usbhid
<6>usbhid: v2.6:USB HID core driver
<6>usb 2-1: USB disconnect, address 2
<4>evdev.c(EVIOCGBIT): Suspicious buffer size 511, limiting output to 64 bytes. See http://userweb.kernel.org/~dtor/eviocgbit-bug.html
<6>usb 2-1: new low speed USB device using uhci_hcd and address 3
<6>usb 2-1: configuration #1 chosen from 1 choice
<6>input: USB OPTICAL MOUSE as /class/input/input10
<6>input: USB HID v1.11 Mouse [ USB OPTICAL MOUSE] on usb-0000:00:10.0-1
<4>evdev.c(EVIOCGBIT): Suspicious buffer size 511, limiting output to 64 bytes. See http://userweb.kernel.org/~dtor/eviocgbit-bug.html
<4>evdev.c(EVIOCGBIT): Suspicious buffer size 511, limiting output to 64 bytes. See http://userweb.kernel.org/~dtor/eviocgbit-bug.html
<4>atkbd.c: Unknown key pressed (translated set 2, code 0x81 on isa0060/serio0).
<4>atkbd.c: Use 'setkeycodes e001 ' to make it known.
<4>psmouse.c: TouchPad at isa0060/serio4/input0 lost sync at byte 1
<4>psmouse.c: TouchPad at isa0060/serio4/input0 lost sync at byte 1
<4>psmouse.c: TouchPad at isa0060/serio4/input0 lost sync at byte 1
<4>psmouse.c: TouchPad at isa0060/serio4/input0 lost sync at byte 1
<4>psmouse.c: TouchPad at isa0060/serio4/input0 lost sync at byte 1
<5>psmouse.c: issuing reconnect request
<4>psmouse.c: TouchPad at isa0060/serio4/input0 lost sync at byte 4
<4>psmouse.c: TouchPad at isa0060/serio4/input0 lost sync at byte 1
<5>psmouse.c: TouchPad at isa0060/serio4/input0 - driver resynched.
<6>eps: Detected VIA Model D C7-M
<6>eps: Current voltage = 988mV
<6>eps: Current multiplier = 8
<6>eps: Highest voltage = 988mV
<6>eps: Highest multiplier = 8
<6>eps: Lowest voltage = 796mV
<6>eps: Lowest multiplier = 4
<4>atkbd.c: Unknown key pressed (translated set 2, code 0x81 on isa0060/serio0).
<4>atkbd.c: Use 'setkeycodes e001 ' to make it known.
<4>atkbd.c: Unknown key pressed (translated set 2, code 0x81 on isa0060/serio0).
<4>atkbd.c: Use 'setkeycodes e001 ' to make it known.
<4>atkbd.c: Unknown key pressed (translated set 2, code 0x81 on isa0060/serio0).
<4>atkbd.c: Use 'setkeycodes e001 ' to make it known.
<4>atkbd.c: Unknown key pressed (translated set 2, code 0x81 on isa0060/serio0).
<4>atkbd.c: Use 'setkeycodes e001 ' to make it known.
<4>atkbd.c: Unknown key pressed (translated set 2, code 0x81 on isa0060/serio0).
<4>atkbd.c: Use 'setkeycodes e001 ' to make it known.
<4>atkbd.c: Unknown key pressed (translated set 2, code 0x81 on isa0060/serio0).
<4>atkbd.c: Use 'setkeycodes e001 ' to make it known.
<4>atkbd.c: Unknown key pressed (translated set 2, code 0x81 on isa0060/serio0).
<4>atkbd.c: Use 'setkeycodes e001 ' to make it known.
<4>atkbd.c: Unknown key pressed (translated set 2, code 0x81 on isa0060/serio0).
<4>atkbd.c: Use 'setkeycodes e001 ' to make it known.
<4>atkbd.c: Unknown key pressed (translated set 2, code 0x81 on isa0060/serio0).
<4>atkbd.c: Use 'setkeycodes e001 ' to make it known.
<4>atkbd.c: Unknown key pressed (translated set 2, code 0x81 on isa0060/serio0).
<4>atkbd.c: Use 'setkeycodes e001 ' to make it known.
<4>atkbd.c: Unknown key pressed (translated set 2, code 0x81 on isa0060/serio0).
<4>atkbd.c: Use 'setkeycodes e001 ' to make it known.
<4>atkbd.c: Unknown key pressed (translated set 2, code 0x81 on isa0060/serio0).
<4>atkbd.c: Use 'setkeycodes e001 ' to make it known.
<4>atkbd.c: Unknown key pressed (translated set 2, code 0x81 on isa0060/serio0).
<4>atkbd.c: Use 'setkeycodes e001 ' to make it known.
<4>atkbd.c: Unknown key pressed (translated set 2, code 0x81 on isa0060/serio0).
<4>atkbd.c: Use 'setkeycodes e001 ' to make it known.
<4>atkbd.c: Unknown key pressed (translated set 2, code 0x81 on isa0060/serio0).
<4>atkbd.c: Use 'setkeycodes e001 ' to make it known.
<4>atkbd.c: Unknown key pressed (translated set 2, code 0x81 on isa0060/serio0).
<4>atkbd.c: Use 'setkeycodes e001 ' to make it known.
<4>atkbd.c: Unknown key pressed (translated set 2, code 0x81 on isa0060/serio0).
<4>atkbd.c: Use 'setkeycodes e001 ' to make it known.
<4>atkbd.c: Unknown key pressed (translated set 2, code 0x81 on isa0060/serio0).
<4>atkbd.c: Use 'setkeycodes e001 ' to make it known.
<4>atkbd.c: Unknown key pressed (translated set 2, code 0x81 on isa0060/serio0).
<4>atkbd.c: Use 'setkeycodes e001 ' to make it known.
<4>ttyS0: LSR safety check engaged!
<4>ttyS0: LSR safety check engaged!
<4>ttyS0: LSR safety check engaged!
----- kernel log end -----
>> misc.1: misc data
>> misc.1.1: open serial
>> misc.1.2: open parallel
----- exec: "/sbin/modprobe parport " -----
----- return code: ? -----
----- exec: "/sbin/modprobe parport_pc " -----
----- return code: ? -----
>> misc.2.1: io
>> misc.2.2: dma
>> misc.2.3: irq
----- /proc/ioports -----
0000-001f : dma1
0020-0021 : pic1
0022-0022 : ACPI PM2_CNT_BLK
0040-0043 : timer0
0050-0053 : timer1
0060-0060 : keyboard
0064-0064 : keyboard
0080-008f : dma page reg
00a0-00a1 : pic2
00c0-00df : dma2
00f0-00ff : fpu
0170-0177 : 0000:00:0f.0
0170-0177 : ide_generic
01f0-01f7 : 0000:00:0f.0
01f0-01f7 : ide_generic
0376-0376 : 0000:00:0f.0
0376-0376 : ide_generic
03c0-03df : vesafb
03e0-03e7 : pnp 00:05
03f6-03f6 : 0000:00:0f.0
03f6-03f6 : ide_generic
03f8-03ff : serial
0400-041f : pnp 00:05
0400-0407 : vt596_smbus
04d0-04d1 : pnp 00:05
0500-0501 : pnp 00:05
0800-087f : pnp 00:05
0800-0803 : ACPI PM1a_EVT_BLK
0804-0805 : ACPI PM1a_CNT_BLK
0808-080b : ACPI PM_TMR
0810-0815 : ACPI CPU throttle
0820-0823 : ACPI GPE0_BLK
0860-0867 : ACPI GPE1_BLK
0cf8-0cff : PCI conf1
c800-c81f : 0000:00:10.0
c800-c81f : uhci_hcd
c880-c89f : 0000:00:10.2
c880-c89f : uhci_hcd
cc00-cc1f : 0000:00:10.3
cc00-cc1f : uhci_hcd
d000-dfff : PCI Bus 0000:02
e000-efff : PCI Bus 0000:05
f800-f8ff : 0000:00:0f.0
fc00-fc0f : 0000:00:0f.0
----- /proc/ioports end -----
----- /proc/interrupts -----
0: 105229650 IO-APIC-edge timer
1: 91449 IO-APIC-edge i8042
9: 840925 IO-APIC-fasteoi acpi
12: 2620606 IO-APIC-edge i8042
14: 314374 IO-APIC-edge ide0
15: 0 IO-APIC-edge ide1
17: 666358 IO-APIC-fasteoi HDA Intel
20: 142495 IO-APIC-fasteoi uhci_hcd:usb2
21: 99 IO-APIC-fasteoi ehci_hcd:usb1, uhci_hcd:usb3
23: 0 IO-APIC-fasteoi uhci_hcd:usb4
24: 12862567 IO-APIC-fasteoi eth13
NMI: 0 Non-maskable interrupts
LOC: 14795 Local timer interrupts
TRM: 0 Thermal event interrupts
SPU: 0 Spurious interrupts
ERR: 0
MIS: 0
----- /proc/interrupts end -----
----- /proc/dma -----
4: cascade
----- /proc/dma end -----
>> misc.3: FPU
>> misc.3.1: DMA
>> misc.3.2: PIC
>> misc.3.3: timer
>> misc.3.4: RTC
>> cpu.1: cpuinfo
----- /proc/cpuinfo -----
processor : 0
vendor_id : CentaurHauls
cpu family : 6
model : 13
model name : VIA C7-M Processor 1600MHz
stepping : 0
cpu MHz : 1595.968
cache size : 128 KB
fdiv_bug : no
hlt_bug : no
f00f_bug : no
coma_bug : no
fpu : yes
fpu_exception : yes
cpuid level : 1
wp : yes
flags : fpu vme de pse tsc msr pae mce cx8 apic sep mtrr pge cmov pat clflush acpi mmx fxsr sse sse2 tm nx pni est tm2 xtpr rng rng_en ace ace_en ace2 ace2_en phe phe_en pmm pmm_en
bogomips : 3191.94
clflush size : 64
power management:
----- /proc/cpuinfo end -----
>> memory.1: main memory size
kcore mem: 0x0
klog mem 0: 0x0
klog mem 1: 0x0
klog mem: 0x0
bios mem: 0x0
meminfo: 0x6ebb7000
>> pci.1: sysfs drivers
----- sysfs driver list (id 0xb76b023fd68013aa) -----
vesafb: /devices/platform/vesafb.0
serial8250: /devices/platform/serial8250
i8042: /devices/platform/i8042
pcspkr: /devices/platform/pcspkr
pcspkr: module = pcspkr
parport_pc: module = parport_pc
pcieport-driver: /devices/pci0000:00/0000:00:02.0
pcieport-driver: /devices/pci0000:00/0000:00:03.0
agpgart-via: /devices/pci0000:00/0000:00:00.0
agpgart-via: module = via_agp
wl: /devices/pci0000:00/0000:00:02.0/0000:02:00.0
wl: module = wl
ehci_hcd: /devices/pci0000:00/0000:00:10.4
ehci_hcd: module = ehci_hcd
sata_via: module = sata_via
uhci_hcd: /devices/pci0000:00/0000:00:10.0
uhci_hcd: /devices/pci0000:00/0000:00:10.2
uhci_hcd: /devices/pci0000:00/0000:00:10.3
uhci_hcd: module = uhci_hcd
pata_acpi: module = pata_acpi
vt596_smbus: module = i2c_viapro
ata_generic: module = ata_generic
HDA Intel: /devices/pci0000:80/0000:80:01.0
HDA Intel: module = snd_hda_intel
tg3: /devices/pci0000:00/0000:00:13.1/0000:07:03.0
tg3: module = tg3
via-rhine: module = via_rhine
parport_pc: module = parport_pc
ec: /devices/LNXSYSTM:00/device:00/PNP0A03:00/device:21/PNP0C09:00
pci_root: /devices/LNXSYSTM:00/device:00/PNP0A03:00
pci_root: /devices/LNXSYSTM:00/device:00/PNP0A08:00
pci_link: /devices/LNXSYSTM:00/device:00/PNP0C0F:00
pci_link: /devices/LNXSYSTM:00/device:00/PNP0C0F:01
pci_link: /devices/LNXSYSTM:00/device:00/PNP0C0F:02
pci_link: /devices/LNXSYSTM:00/device:00/PNP0C0F:03
pci_link: /devices/LNXSYSTM:00/device:00/PNP0C0F:04
pci_link: /devices/LNXSYSTM:00/device:00/PNP0C0F:05
pci_link: /devices/LNXSYSTM:00/device:00/PNP0C0F:06
pci_link: /devices/LNXSYSTM:00/device:00/PNP0C0F:07
power: /devices/LNXSYSTM:00/device:00/PNP0A08:00/device:2f/LNXPOWER:00
processor: /devices/LNXSYSTM:00/ACPI0007:00
button: /devices/LNXSYSTM:00/LNXPWRBN:00
button: /devices/LNXSYSTM:00/device:00/PNP0A03:00/PNP0C0D:00
button: /devices/LNXSYSTM:00/device:00/PNP0C0E:00
button: /devices/LNXSYSTM:00/device:00/PNP0C0C:00
thermal: /devices/LNXSYSTM:00/LNXTHERM:00/LNXTHERM:01
ac: /devices/LNXSYSTM:00/device:00/PNP0A03:00/ACPI0003:00
battery: /devices/LNXSYSTM:00/device:00/PNP0A03:00/PNP0C0A:00
video: /devices/LNXSYSTM:00/device:00/PNP0A03:00/device:08/device:09
system: /devices/pnp0/00:05
system: /devices/pnp0/00:08
system: /devices/pnp0/00:0a
system: /devices/pnp0/00:0c
i8042 kbd: /devices/pnp0/00:02
i8042 aux: /devices/pnp0/00:09
usbfs: module = usbcore
hub: module = usbcore
hub: /devices/pci0000:00/0000:00:10.4/usb1/1-0:1.0
hub: /devices/pci0000:00/0000:00:10.0/usb2/2-0:1.0
hub: /devices/pci0000:00/0000:00:10.2/usb3/3-0:1.0
hub: /devices/pci0000:00/0000:00:10.3/usb4/4-0:1.0
usb: /devices/pci0000:00/0000:00:10.4/usb1
usb: /devices/pci0000:00/0000:00:10.0/usb2
usb: /devices/pci0000:00/0000:00:10.4/usb1/1-8
usb: /devices/pci0000:00/0000:00:10.2/usb3
usb: /devices/pci0000:00/0000:00:10.3/usb4
usb: /devices/pci0000:00/0000:00:10.0/usb2/2-1
uvcvideo: /devices/pci0000:00/0000:00:10.4/usb1/1-8/1-8:1.0
uvcvideo: /devices/pci0000:00/0000:00:10.4/usb1/1-8/1-8:1.1
uvcvideo: module = uvcvideo
hiddev: module = usbhid
usbhid: /devices/pci0000:00/0000:00:10.0/usb2/2-1/2-1:1.0
usbhid: module = usbhid
atkbd: module = atkbd
atkbd: /devices/platform/i8042/serio0
psmouse: module = psmouse
psmouse: /devices/platform/i8042/serio4
serio_raw: module = serio_raw
ide-disk: /devices/ide0/0.0
dummy: module = i2c_core
----- sysfs driver list end -----
>> pci.2: get sysfs pci data
pci device: name = 0000:80:01.0
path = /devices/pci0000:80/0000:80:01.0
modalias = "pci:v00001106d00003288sv0000103Csd00003030bc04sc03i00"
class = 0x40300
vendor = 0x1106
device = 0x3288
subvendor = 0x103c
subdevice = 0x3030
irq = 17
res[0] = 0xfebfc000 0xfebfffff 0x20204
config[64]
pci device: name = 0000:07:03.0
path = /devices/pci0000:00/0000:00:13.1/0000:07:03.0
modalias = "pci:v000014E4d0000169Csv0000103Csd00003030bc02sc00i00"
class = 0x20000
vendor = 0x14e4
device = 0x169c
subvendor = 0x103c
subdevice = 0x3030
irq = 16
res[0] = 0xfeaf0000 0xfeafffff 0x20200
config[64]
pci device: name = 0000:02:00.0
path = /devices/pci0000:00/0000:00:02.0/0000:02:00.0
modalias = "pci:v000014E4d00004315sv0000103Csd0000137Dbc02sc80i00"
class = 0x28000
vendor = 0x14e4
device = 0x4315
subvendor = 0x103c
subdevice = 0x137d
irq = 24
res[0] = 0xfdffc000 0xfdffffff 0x20204
config[64]
pci device: name = 0000:01:00.0
path = /devices/pci0000:00/0000:00:01.0/0000:01:00.0
modalias = "pci:v00001106d00003371sv0000103Csd00003030bc03sc00i00"
class = 0x30000
vendor = 0x1106
device = 0x3371
subvendor = 0x103c
subdevice = 0x3030
irq = 11
res[0] = 0xc0000000 0xcfffffff 0x21208
res[1] = 0xfc000000 0xfcffffff 0x20200
res[6] = 0xfbff0000 0xfbffffff 0x27202
config[64]
pci device: name = 0000:00:13.1
path = /devices/pci0000:00/0000:00:13.1
modalias = "pci:v00001106d0000337Asv00000000sd00000000bc06sc04i01"
class = 0x60401
vendor = 0x1106
device = 0x337a
subvendor = 0x0
subdevice = 0x0
irq = 0
config[64]
pci device: name = 0000:00:13.0
path = /devices/pci0000:00/0000:00:13.0
modalias = "pci:v00001106d0000337Bsv00000000sd00000000bc06sc00i00"
class = 0x60000
vendor = 0x1106
device = 0x337b
subvendor = 0x0
subdevice = 0x0
irq = 0
config[64]
pci device: name = 0000:00:11.7
path = /devices/pci0000:00/0000:00:11.7
modalias = "pci:v00001106d0000287Esv00001106sd0000337Ebc06sc00i00"
class = 0x60000
vendor = 0x1106
device = 0x287e
subvendor = 0x1106
subdevice = 0x337e
irq = 0
config[64]
pci device: name = 0000:00:11.0
path = /devices/pci0000:00/0000:00:11.0
modalias = "pci:v00001106d00003372sv0000103Csd00003030bc06sc01i00"
class = 0x60100
vendor = 0x1106
device = 0x3372
subvendor = 0x103c
subdevice = 0x3030
irq = 0
config[64]
pci device: name = 0000:00:10.4
path = /devices/pci0000:00/0000:00:10.4
modalias = "pci:v00001106d00003104sv0000103Csd00003030bc0Csc03i20"
class = 0xc0320
vendor = 0x1106
device = 0x3104
subvendor = 0x103c
subdevice = 0x3030
irq = 21
res[0] = 0xfbeffc00 0xfbeffcff 0x20200
config[64]
pci device: name = 0000:00:10.3
path = /devices/pci0000:00/0000:00:10.3
modalias = "pci:v00001106d00003038sv0000103Csd00003030bc0Csc03i00"
class = 0xc0300
vendor = 0x1106
device = 0x3038
subvendor = 0x103c
subdevice = 0x3030
irq = 23
res[4] = 0xcc00 0xcc1f 0x20101
config[64]
pci device: name = 0000:00:10.2
path = /devices/pci0000:00/0000:00:10.2
modalias = "pci:v00001106d00003038sv0000103Csd00003030bc0Csc03i00"
class = 0xc0300
vendor = 0x1106
device = 0x3038
subvendor = 0x103c
subdevice = 0x3030
irq = 21
res[4] = 0xc880 0xc89f 0x20101
config[64]
pci device: name = 0000:00:10.0
path = /devices/pci0000:00/0000:00:10.0
modalias = "pci:v00001106d00003038sv0000103Csd00003030bc0Csc03i00"
class = 0xc0300
vendor = 0x1106
device = 0x3038
subvendor = 0x103c
subdevice = 0x3030
irq = 20
res[4] = 0xc800 0xc81f 0x20101
config[64]
pci device: name = 0000:00:0f.0
path = /devices/pci0000:00/0000:00:0f.0
modalias = "pci:v00001106d00005372sv0000103Csd00003030bc01sc01i8a"
class = 0x1018a
vendor = 0x1106
device = 0x5372
subvendor = 0x103c
subdevice = 0x3030
irq = 0
res[0] = 0x1f0 0x1f7 0x110
res[1] = 0x3f6 0x3f6 0x110
res[2] = 0x170 0x177 0x110
res[3] = 0x376 0x376 0x110
res[4] = 0xfc00 0xfc0f 0x20101
res[5] = 0xf800 0xf8ff 0x20101
config[64]
pci device: name = 0000:00:03.0
path = /devices/pci0000:00/0000:00:03.0
modalias = "pci:v00001106d0000C364sv00000000sd00000000bc06sc04i00"
class = 0x60400
vendor = 0x1106
device = 0xc364
subvendor = 0x0
subdevice = 0x0
irq = 31
config[64]
pci device: name = 0000:00:02.0
path = /devices/pci0000:00/0000:00:02.0
modalias = "pci:v00001106d0000A364sv00000000sd00000000bc06sc04i00"
class = 0x60400
vendor = 0x1106
device = 0xa364
subvendor = 0x0
subdevice = 0x0
irq = 27
config[64]
pci device: name = 0000:00:01.0
path = /devices/pci0000:00/0000:00:01.0
modalias = "pci:v00001106d0000B198sv00000000sd00000000bc06sc04i00"
class = 0x60400
vendor = 0x1106
device = 0xb198
subvendor = 0x0
subdevice = 0x0
irq = 0
config[64]
pci device: name = 0000:00:00.7
path = /devices/pci0000:00/0000:00:00.7
modalias = "pci:v00001106d00007364sv00000000sd00000000bc06sc00i00"
class = 0x60000
vendor = 0x1106
device = 0x7364
subvendor = 0x0
subdevice = 0x0
irq = 0
config[64]
pci device: name = 0000:00:00.6
path = /devices/pci0000:00/0000:00:00.6
modalias = "pci:v00001106d00006364sv0000103Csd00003030bc06sc00i00"
class = 0x60000
vendor = 0x1106
device = 0x6364
subvendor = 0x103c
subdevice = 0x3030
irq = 0
config[64]
pci device: name = 0000:00:00.5
path = /devices/pci0000:00/0000:00:00.5
modalias = "pci:v00001106d00005364sv0000103Csd00003030bc08sc00i20"
class = 0x80020
vendor = 0x1106
device = 0x5364
subvendor = 0x103c
subdevice = 0x3030
irq = 0
config[64]
pci device: name = 0000:00:00.4
path = /devices/pci0000:00/0000:00:00.4
modalias = "pci:v00001106d00004364sv0000103Csd00003030bc06sc00i00"
class = 0x60000
vendor = 0x1106
device = 0x4364
subvendor = 0x103c
subdevice = 0x3030
irq = 0
config[64]
pci device: name = 0000:00:00.3
path = /devices/pci0000:00/0000:00:00.3
modalias = "pci:v00001106d00003364sv00000000sd00000000bc06sc00i00"
class = 0x60000
vendor = 0x1106
device = 0x3364
subvendor = 0x0
subdevice = 0x0
irq = 0
config[64]
pci device: name = 0000:00:00.2
path = /devices/pci0000:00/0000:00:00.2
modalias = "pci:v00001106d00002364sv0000103Csd00003030bc06sc00i00"
class = 0x60000
vendor = 0x1106
device = 0x2364
subvendor = 0x103c
subdevice = 0x3030
irq = 0
config[64]
pci device: name = 0000:00:00.1
path = /devices/pci0000:00/0000:00:00.1
modalias = "pci:v00001106d00001364sv0000103Csd00003030bc06sc00i00"
class = 0x60000
vendor = 0x1106
device = 0x1364
subvendor = 0x103c
subdevice = 0x3030
irq = 0
config[64]
pci device: name = 0000:00:00.0
path = /devices/pci0000:00/0000:00:00.0
modalias = "pci:v00001106d00000364sv0000103Csd00003030bc06sc00i00"
class = 0x60000
vendor = 0x1106
device = 0x364
subvendor = 0x103c
subdevice = 0x3030
irq = 0
res[0] = 0xf0000000 0xf7ffffff 0x21208
config[64]
---------- PCI raw data ----------
bus 80, slot 01, func 0, vend:dev:s_vend:s_dev:rev 1106:3288:103c:3030:10
class 04, sub_class 03 prog_if 00, hdr 0, flags , irq 17
addr0 febfc000, size 00004000
00: 06 11 88 32 06 00 10 00 10 00 03 04 08 00 00 00 "...2............"
10: 04 c0 bf fe 00 00 00 00 00 00 00 00 00 00 00 00 "................"
20: 00 00 00 00 00 00 00 00 00 00 00 00 3c 10 30 30 "............<.00" 30: 00 00 00 00 50 00 00 00 00 00 00 00 07 01 00 00 "....P..........." 40: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................" 50: 01 60 00 00 00 00 00 00 00 00 00 00 00 00 00 00 ".`.............." 60: 05 70 00 00 00 00 00 00 00 00 00 00 00 00 00 00 ".p.............." 70: 10 00 ".." bus 07, slot 03, func 0, vend:dev:s_vend:s_dev:rev 14e4:169c:103c:3030:03 class 02, sub_class 00 prog_if 00, hdr 0, flags , irq 16
addr0 feaf0000, size 00010000
00: e4 14 9c 16 06 01 b0 02 03 00 00 02 08 40 00 00 ".............@.."
10: 00 00 af fe 00 00 00 00 00 00 00 00 00 00 00 00 "................"
20: 00 00 00 00 00 00 00 00 07 00 00 00 3c 10 30 30 "............<.00" 30: 00 00 00 00 48 00 00 00 00 00 00 00 0b 01 40 00 "....H.........@." 40: 00 00 00 00 00 00 00 00 01 50 00 00 00 00 00 00 ".........P......" 50: 03 58 00 00 00 00 00 00 05 00 ".X........" bus 02, slot 00, func 0, vend:dev:s_vend:s_dev:rev 14e4:4315:103c:137d:01 class 02, sub_class 80 prog_if 00, hdr 0, flags , irq 24
addr0 fdffc000, size 00004000
00: e4 14 15 43 06 01 10 00 01 00 80 02 08 00 00 00 "...C............"
10: 04 c0 ff fd 00 00 00 00 00 00 00 00 00 00 00 00 "................"
20: 00 00 00 00 00 00 00 00 00 00 00 00 3c 10 7d 13 "............<.}." 30: 00 00 00 00 40 00 00 00 00 00 00 00 0a 01 00 00 "....@..........." 40: 01 58 00 00 00 00 00 00 00 00 00 00 00 00 00 00 ".X.............." 50: 00 00 00 00 00 00 00 00 09 e8 00 00 00 00 00 00 "................" 60: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................" 70: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................" 80: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................" 90: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................" a0: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................" b0: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................" c0: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................" d0: 10 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................" e0: 00 00 00 00 00 00 00 00 05 d0 ".........." bus 01, slot 00, func 0, vend:dev:s_vend:s_dev:rev 1106:3371:103c:3030:01 class 03, sub_class 00 prog_if 00, hdr 0, flags , irq 11
addr0 c0000000, size 10000000
addr1 fc000000, size 01000000
00: 06 11 71 33 07 00 30 02 01 00 00 03 00 40 00 00 "..q3..0......@.."
10: 08 00 00 c0 00 00 00 fc 00 00 00 00 00 00 00 00 "................"
20: 00 00 00 00 00 00 00 00 00 00 00 00 3c 10 30 30 "............<.00" 30: 00 00 ff fb 60 00 00 00 00 00 00 00 0b 01 02 00 "....`..........." 40: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................" 50: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................" 60: 01 70 00 00 00 00 00 00 00 00 00 00 00 00 00 00 ".p.............." 70: 02 00 ".." bus 00->07, slot 13, func 1, vend:dev:s_vend:s_dev:rev 1106:337a:0000:0000:00
class 06, sub_class 04 prog_if 01, hdr 1, flags <>, irq 0
00: 06 11 7a 33 06 01 10 20 00 01 04 06 00 00 01 00 "..z3... ........"
10: 00 00 00 00 00 00 00 00 00 07 07 00 f0 00 00 02 "................"
20: a0 fe a0 fe f1 ff 01 00 00 00 00 00 00 00 00 00 "................"
30: 00 00 00 00 60 00 00 00 00 00 00 00 00 00 03 00 "....`..........."
bus 00, slot 13, func 0, vend:dev:s_vend:s_dev:rev 1106:337b:0000:0000:00
class 06, sub_class 00 prog_if 00, hdr 0, flags <>, irq 0
00: 06 11 7b 33 06 01 10 20 00 00 00 06 00 00 80 00 "..{3... ........"
10: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
20: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
30: 00 00 00 00 60 00 00 00 00 00 00 00 00 00 00 00 "....`..........."
40: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
50: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
60: 08 00 ".."
bus 00, slot 11, func 7, vend:dev:s_vend:s_dev:rev 1106:287e:1106:337e:00
class 06, sub_class 00 prog_if 00, hdr 0, flags <>, irq 0
00: 06 11 7e 28 06 01 10 02 00 00 00 06 00 80 00 00 "..~(............"
10: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
20: 00 00 00 00 00 00 00 00 00 00 00 00 06 11 7e 33 "..............~3"
30: 00 00 00 00 58 00 00 00 00 00 00 00 00 00 00 00 "....X..........."
40: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
50: 00 00 00 00 00 00 00 00 08 00 ".........."
bus 00, slot 11, func 0, vend:dev:s_vend:s_dev:rev 1106:3372:103c:3030:00
class 06, sub_class 01 prog_if 00, hdr 0, flags , irq 0
00: 06 11 72 33 03 00 10 02 00 00 01 06 00 00 80 00 "..r3............"
10: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
20: 00 00 00 00 00 00 00 00 00 00 00 00 3c 10 30 30 "............<.00" 30: 00 00 00 00 c0 00 00 00 00 00 00 00 00 00 00 00 "................" 40: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................" 50: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................" 60: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................" 70: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................" 80: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................" 90: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................" a0: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................" b0: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................" c0: 01 00 ".." bus 00, slot 10, func 4, vend:dev:s_vend:s_dev:rev 1106:3104:103c:3030:90 class 0c, sub_class 03 prog_if 20, hdr 0, flags , irq 21
addr0 fbeffc00, size 00000100
00: 06 11 04 31 17 00 10 02 90 20 03 0c 08 40 80 00 "...1..... ...@.."
10: 00 fc ef fb 00 00 00 00 00 00 00 00 00 00 00 00 "................"
20: 00 00 00 00 00 00 00 00 00 00 00 00 3c 10 30 30 "............<.00" 30: 00 00 00 00 80 00 00 00 00 00 00 00 05 03 00 00 "................" 40: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................" 50: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................" 60: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................" 70: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................" 80: 01 88 00 00 00 00 00 00 0a 00 ".........." bus 00, slot 10, func 3, vend:dev:s_vend:s_dev:rev 1106:3038:103c:3030:b0 class 0c, sub_class 03 prog_if 00, hdr 0, flags , irq 23
addr4 0000cc00, size 00000020
00: 06 11 38 30 17 00 10 02 b0 00 03 0c 08 40 80 00 "..80.........@.."
10: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
20: 01 cc 00 00 00 00 00 00 00 00 00 00 3c 10 30 30 "............<.00" 30: 00 00 00 00 80 00 00 00 00 00 00 00 03 04 00 00 "................" 40: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................" 50: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................" 60: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................" 70: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................" 80: 01 00 ".." bus 00, slot 10, func 2, vend:dev:s_vend:s_dev:rev 1106:3038:103c:3030:b0 class 0c, sub_class 03 prog_if 00, hdr 0, flags , irq 21
addr4 0000c880, size 00000020
00: 06 11 38 30 17 00 10 02 b0 00 03 0c 08 40 80 00 "..80.........@.."
10: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
20: 81 c8 00 00 00 00 00 00 00 00 00 00 3c 10 30 30 "............<.00" 30: 00 00 00 00 80 00 00 00 00 00 00 00 05 03 00 00 "................" 40: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................" 50: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................" 60: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................" 70: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................" 80: 01 00 ".." bus 00, slot 10, func 0, vend:dev:s_vend:s_dev:rev 1106:3038:103c:3030:b0 class 0c, sub_class 03 prog_if 00, hdr 0, flags , irq 20
addr4 0000c800, size 00000020
00: 06 11 38 30 17 00 10 02 b0 00 03 0c 08 40 80 00 "..80.........@.."
10: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
20: 01 c8 00 00 00 00 00 00 00 00 00 00 3c 10 30 30 "............<.00" 30: 00 00 00 00 80 00 00 00 00 00 00 00 0b 01 00 00 "................" 40: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................" 50: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................" 60: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................" 70: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................" 80: 01 00 ".." bus 00, slot 0f, func 0, vend:dev:s_vend:s_dev:rev 1106:5372:103c:3030:00 class 01, sub_class 01 prog_if 8a, hdr 0, flags , irq 0
addr0 000001f0, size 00000008
addr1 000003f6, size 00000001
addr2 00000170, size 00000008
addr3 00000376, size 00000001
addr4 0000fc00, size 00000010
addr5 0000f800, size 00000100
00: 06 11 72 53 03 00 90 02 00 8a 01 01 00 20 00 00 "..rS......... .."
10: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
20: 01 fc 00 00 01 f8 00 00 00 00 00 00 3c 10 30 30 "............<.00" 30: 00 00 00 00 c0 00 00 00 00 00 00 00 ff 00 00 00 "................" 40: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................" 50: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................" 60: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................" 70: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................" 80: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................" 90: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................" a0: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................" b0: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................" c0: 01 00 ".." bus 00->05, slot 03, func 0, vend:dev:s_vend:s_dev:rev 1106:c364:0000:0000:80
class 06, sub_class 04 prog_if 00, hdr 1, flags <>, irq 31
00: 06 11 64 c3 07 01 10 00 80 00 04 06 08 00 81 00 "..d............."
10: 00 00 00 00 00 00 00 00 00 05 06 00 e0 e0 00 00 "................"
20: 00 fe 90 fe 01 f8 f1 fa 00 00 00 00 00 00 00 00 "................"
30: 00 00 00 00 40 00 00 00 00 00 00 00 0a 01 03 00 "....@..........."
bus 00->02, slot 02, func 0, vend:dev:s_vend:s_dev:rev 1106:a364:0000:0000:80
class 06, sub_class 04 prog_if 00, hdr 1, flags <>, irq 27
00: 06 11 64 a3 07 01 10 00 80 00 04 06 08 00 01 00 "..d............."
10: 00 00 00 00 00 00 00 00 00 02 04 00 d0 d0 00 00 "................"
20: 00 fd f0 fd 01 de f1 df 00 00 00 00 00 00 00 00 "................"
30: 00 00 00 00 40 00 00 00 00 00 00 00 0a 01 03 00 "....@..........."
bus 00->01, slot 01, func 0, vend:dev:s_vend:s_dev:rev 1106:b198:0000:0000:00
class 06, sub_class 04 prog_if 00, hdr 1, flags <>, irq 0
00: 06 11 98 b1 07 00 30 02 00 00 04 06 08 00 01 00 "......0........."
10: 00 00 00 00 00 00 00 00 00 01 01 00 f0 00 20 02 ".............. ."
20: f0 fb f0 fc 00 c0 f0 cf 00 00 00 00 00 00 00 00 "................"
30: 00 00 00 00 70 00 00 00 00 00 00 00 00 00 1b 00 "....p..........."
bus 00, slot 00, func 7, vend:dev:s_vend:s_dev:rev 1106:7364:0000:0000:00
class 06, sub_class 00 prog_if 00, hdr 0, flags <>, irq 0
00: 06 11 64 73 06 00 00 02 00 00 00 06 00 00 00 00 "..ds............"
10: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
20: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
30: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
bus 00, slot 00, func 6, vend:dev:s_vend:s_dev:rev 1106:6364:103c:3030:00
class 06, sub_class 00 prog_if 00, hdr 0, flags <>, irq 0
00: 06 11 64 63 06 00 00 00 00 00 00 06 00 00 80 00 "..dc............"
10: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
20: 00 00 00 00 00 00 00 00 00 00 00 00 3c 10 30 30 "............<.00" 30: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................" bus 00, slot 00, func 5, vend:dev:s_vend:s_dev:rev 1106:5364:103c:3030:00 class 08, sub_class 00 prog_if 20, hdr 0, flags <>, irq 0
00: 06 11 64 53 06 00 00 00 00 20 00 08 00 00 80 00 "..dS..... ......"
10: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
20: 00 00 00 00 00 00 00 00 00 00 00 00 3c 10 30 30 "............<.00" 30: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................" bus 00, slot 00, func 4, vend:dev:s_vend:s_dev:rev 1106:4364:103c:3030:00 class 06, sub_class 00 prog_if 00, hdr 0, flags <>, irq 0
00: 06 11 64 43 06 00 00 02 00 00 00 06 00 00 00 00 "..dC............"
10: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
20: 00 00 00 00 00 00 00 00 00 00 00 00 3c 10 30 30 "............<.00" 30: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................" bus 00, slot 00, func 3, vend:dev:s_vend:s_dev:rev 1106:3364:0000:0000:00 class 06, sub_class 00 prog_if 00, hdr 0, flags <>, irq 0
00: 06 11 64 33 06 00 00 02 00 00 00 06 00 00 00 00 "..d3............"
10: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
20: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
30: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
bus 00, slot 00, func 2, vend:dev:s_vend:s_dev:rev 1106:2364:103c:3030:00
class 06, sub_class 00 prog_if 00, hdr 0, flags <>, irq 0
00: 06 11 64 23 06 00 00 02 00 00 00 06 00 00 00 00 "..d#............"
10: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
20: 00 00 00 00 00 00 00 00 00 00 00 00 3c 10 30 30 "............<.00" 30: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................" bus 00, slot 00, func 1, vend:dev:s_vend:s_dev:rev 1106:1364:103c:3030:00 class 06, sub_class 00 prog_if 00, hdr 0, flags <>, irq 0
00: 06 11 64 13 06 00 00 02 00 00 00 06 00 00 00 00 "..d............."
10: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................"
20: 00 00 00 00 00 00 00 00 00 00 00 00 3c 10 30 30 "............<.00" 30: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................" bus 00, slot 00, func 0, vend:dev:s_vend:s_dev:rev 1106:0364:103c:3030:00 class 06, sub_class 00 prog_if 00, hdr 0, flags , irq 0
addr0 f0000000, size 08000000
00: 06 11 64 03 06 01 10 02 00 00 00 06 00 08 80 00 "..d............."
10: 08 00 00 f0 00 00 00 00 00 00 00 00 00 00 00 00 "................"
20: 00 00 00 00 00 00 00 00 00 00 00 00 3c 10 30 30 "............<.00" 30: 00 00 00 00 80 00 00 00 00 00 00 00 00 00 00 00 "................" 40: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................" 50: 01 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................" 60: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................" 70: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 "................" 80: 02 50 ".P" ---------- PCI raw data end ---------- >> pci.4: build list
>> pci.3: macio
sysfs: no such bus: macio
>> pci.3: vio
sysfs: no such bus: vio
>> monitor.1: ddc
>> monitor.2: bios
>> monitor.3: pci
>> monitor.4: internal db
>> monitor.5: prom
>> isapnp.1: pnp devices
pnp device: name = 00:0d
path = /devices/pnp0/00:0d
id = PNP 0a08
pnp device: name = 00:0c
path = /devices/pnp0/00:0c
id = PNP 0c01
pnp device: name = 00:0b
path = /devices/pnp0/00:0b
id = HPQ 0004
pnp device: name = 00:0a
path = /devices/pnp0/00:0a
id = PNP 0c02
pnp device: name = 00:09
path = /devices/pnp0/00:09
id = SYN 013d
pnp device: name = 00:08
path = /devices/pnp0/00:08
id = PNP 0c02
pnp device: name = 00:07
path = /devices/pnp0/00:07
id = PNP 0b00
pnp device: name = 00:06
path = /devices/pnp0/00:06
id = PNP 0103
pnp device: name = 00:05
path = /devices/pnp0/00:05
id = PNP 0c02
pnp device: name = 00:04
path = /devices/pnp0/00:04
id = PNP 0c04
pnp device: name = 00:03
path = /devices/pnp0/00:03
id = PNP 0800
pnp device: name = 00:02
path = /devices/pnp0/00:02
id = PNP 0303
pnp device: name = 00:01
path = /devices/pnp0/00:01
id = PNP 0200
pnp device: name = 00:00
path = /devices/pnp0/00:00
id = PNP 0a03
>> isa.1: isdn
---------- ISA ISDN raw data ----------
---------- ISA ISDN raw data end ----------
>> isa.1.1: isdn
>> pcmcia.1: sysfs drivers
>> pcmcia.2: pcmcia
sysfs: no such bus: pcmcia
>> pcmcia.3: pcmcia ctrl
sysfs: no such class: pcmcia_socket
>> serial.1: read info
----- /proc/tty/driver/serial -----
0: uart:16550A port:000003F8 irq:4 tx:0 rx:0 CTS|DSR|CD|RI
1: uart:unknown port:000002F8 irq:3
2: uart:unknown port:000003E8 irq:4
3: uart:unknown port:000002E8 irq:3
----- /proc/tty/driver/serial end -----
----- serial info -----
uart 16550A, line 0, port 0x3f8, irq 4, baud 0
----- serial info end -----
>> serial.2: build list
>> misc.5: misc data
----- misc resources -----
i/o:1 0x0000 - 0x001f (0x20) "dma1"
i/o:1 0x0020 - 0x0021 (0x02) "pic1"
i/o:0 0x0022 - 0x0022 (0x01) "ACPI PM2_CNT_BLK"
i/o:0 0x0040 - 0x0043 (0x04) "timer0"
i/o:0 0x0050 - 0x0053 (0x04) "timer1"
i/o:1 0x0060 - 0x0060 (0x01) "keyboard"
i/o:1 0x0064 - 0x0064 (0x01) "keyboard"
i/o:1 0x0080 - 0x008f (0x10) "dma page reg"
i/o:1 0x00a0 - 0x00a1 (0x02) "pic2"
i/o:1 0x00c0 - 0x00df (0x20) "dma2"
i/o:1 0x00f0 - 0x00ff (0x10) "fpu"
i/o:0 0x0170 - 0x0177 (0x08) "0000:00:0f.0"
i/o:0 0x0170 - 0x0177 (0x08) "ide_generic"
i/o:0 0x01f0 - 0x01f7 (0x08) "0000:00:0f.0"
i/o:0 0x01f0 - 0x01f7 (0x08) "ide_generic"
i/o:0 0x0376 - 0x0376 (0x01) "0000:00:0f.0"
i/o:0 0x0376 - 0x0376 (0x01) "ide_generic"
i/o:1 0x03c0 - 0x03df (0x20) "vesafb"
i/o:0 0x03e0 - 0x03e7 (0x08) "pnp 00:05"
i/o:0 0x03f6 - 0x03f6 (0x01) "0000:00:0f.0"
i/o:0 0x03f6 - 0x03f6 (0x01) "ide_generic"
i/o:1 0x03f8 - 0x03ff (0x08) "serial"
i/o:0 0x0400 - 0x041f (0x20) "pnp 00:05"
i/o:0 0x0400 - 0x0407 (0x08) "vt596_smbus"
i/o:0 0x04d0 - 0x04d1 (0x02) "pnp 00:05"
i/o:0 0x0500 - 0x0501 (0x02) "pnp 00:05"
i/o:0 0x0800 - 0x087f (0x80) "pnp 00:05"
i/o:0 0x0800 - 0x0803 (0x04) "ACPI PM1a_EVT_BLK"
i/o:0 0x0804 - 0x0805 (0x02) "ACPI PM1a_CNT_BLK"
i/o:0 0x0808 - 0x080b (0x04) "ACPI PM_TMR"
i/o:0 0x0810 - 0x0815 (0x06) "ACPI CPU throttle"
i/o:0 0x0820 - 0x0823 (0x04) "ACPI GPE0_BLK"
i/o:0 0x0860 - 0x0867 (0x08) "ACPI GPE1_BLK"
i/o:0 0x0cf8 - 0x0cff (0x08) "PCI conf1"
i/o:0 0xc800 - 0xc81f (0x20) "0000:00:10.0"
i/o:0 0xc800 - 0xc81f (0x20) "uhci_hcd"
i/o:0 0xc880 - 0xc89f (0x20) "0000:00:10.2"
i/o:0 0xc880 - 0xc89f (0x20) "uhci_hcd"
i/o:0 0xcc00 - 0xcc1f (0x20) "0000:00:10.3"
i/o:0 0xcc00 - 0xcc1f (0x20) "uhci_hcd"
i/o:0 0xd000 - 0xdfff (0x1000) "PCI Bus 0000:02"
i/o:0 0xe000 - 0xefff (0x1000) "PCI Bus 0000:05"
i/o:0 0xf800 - 0xf8ff (0x100) "0000:00:0f.0"
i/o:0 0xfc00 - 0xfc0f (0x10) "0000:00:0f.0"
irq:1 0 (105229650) "timer"
irq:0 1 ( 91449) "i8042"
irq:0 9 ( 840925) "acpi"
irq:0 12 ( 2620606) "i8042"
irq:1 14 ( 314374) "ide0"
irq:1 15 ( 0) "ide1"
irq:0 17 ( 666358) "HDA Intel"
irq:0 20 ( 142495) "uhci_hcd:usb2"
irq:0 21 ( 99) "ehci_hcd:usb1" "uhci_hcd:usb3"
irq:0 23 ( 0) "uhci_hcd:usb4"
irq:0 24 ( 12862567) "eth13"
dma:1 4 "cascade"
----- misc resources end -----
>> parallel.1: pp mod
----- exec: "/sbin/rmmod parport_pc" -----
----- return code: ? -----
----- exec: "/sbin/modprobe parport_pc" -----
----- return code: ? -----
----- exec: "/sbin/modprobe lp" -----
----- return code: ? -----
>> parallel.2.1: lp read info
>> parallel.2.2: lp read info
>> parallel.2.3: lp read info
----- parallel info -----
----- parallel info end -----
>> block.1: block modules
----- exec: "/sbin/modprobe ide_cd " -----
FATAL: Module ide_cd not found.
----- return code: ? -----
----- exec: "/sbin/modprobe sr_mod " -----
FATAL: Module sr_mod not found.
----- return code: ? -----
----- exec: "/sbin/modprobe sd_mod " -----
FATAL: Module sd_mod not found.
----- return code: ? -----
----- exec: "/sbin/modprobe st " -----
----- return code: ? -----
>> block.2: sysfs drivers
----- sysfs driver list (id 0x249c2ec55da9a69f) -----
vesafb: /devices/platform/vesafb.0
serial8250: /devices/platform/serial8250
i8042: /devices/platform/i8042
pcspkr: /devices/platform/pcspkr
pcspkr: module = pcspkr
parport_pc: module = parport_pc
pcieport-driver: /devices/pci0000:00/0000:00:02.0
pcieport-driver: /devices/pci0000:00/0000:00:03.0
agpgart-via: /devices/pci0000:00/0000:00:00.0
agpgart-via: module = via_agp
wl: /devices/pci0000:00/0000:00:02.0/0000:02:00.0
wl: module = wl
ehci_hcd: /devices/pci0000:00/0000:00:10.4
ehci_hcd: module = ehci_hcd
sata_via: module = sata_via
uhci_hcd: /devices/pci0000:00/0000:00:10.0
uhci_hcd: /devices/pci0000:00/0000:00:10.2
uhci_hcd: /devices/pci0000:00/0000:00:10.3
uhci_hcd: module = uhci_hcd
pata_acpi: module = pata_acpi
vt596_smbus: module = i2c_viapro
ata_generic: module = ata_generic
HDA Intel: /devices/pci0000:80/0000:80:01.0
HDA Intel: module = snd_hda_intel
tg3: /devices/pci0000:00/0000:00:13.1/0000:07:03.0
tg3: module = tg3
via-rhine: module = via_rhine
parport_pc: module = parport_pc
ec: /devices/LNXSYSTM:00/device:00/PNP0A03:00/device:21/PNP0C09:00
pci_root: /devices/LNXSYSTM:00/device:00/PNP0A03:00
pci_root: /devices/LNXSYSTM:00/device:00/PNP0A08:00
pci_link: /devices/LNXSYSTM:00/device:00/PNP0C0F:00
pci_link: /devices/LNXSYSTM:00/device:00/PNP0C0F:01
pci_link: /devices/LNXSYSTM:00/device:00/PNP0C0F:02
pci_link: /devices/LNXSYSTM:00/device:00/PNP0C0F:03
pci_link: /devices/LNXSYSTM:00/device:00/PNP0C0F:04
pci_link: /devices/LNXSYSTM:00/device:00/PNP0C0F:05
pci_link: /devices/LNXSYSTM:00/device:00/PNP0C0F:06
pci_link: /devices/LNXSYSTM:00/device:00/PNP0C0F:07
power: /devices/LNXSYSTM:00/device:00/PNP0A08:00/device:2f/LNXPOWER:00
processor: /devices/LNXSYSTM:00/ACPI0007:00
button: /devices/LNXSYSTM:00/LNXPWRBN:00
button: /devices/LNXSYSTM:00/device:00/PNP0A03:00/PNP0C0D:00
button: /devices/LNXSYSTM:00/device:00/PNP0C0E:00
button: /devices/LNXSYSTM:00/device:00/PNP0C0C:00
thermal: /devices/LNXSYSTM:00/LNXTHERM:00/LNXTHERM:01
ac: /devices/LNXSYSTM:00/device:00/PNP0A03:00/ACPI0003:00
battery: /devices/LNXSYSTM:00/device:00/PNP0A03:00/PNP0C0A:00
video: /devices/LNXSYSTM:00/device:00/PNP0A03:00/device:08/device:09
system: /devices/pnp0/00:05
system: /devices/pnp0/00:08
system: /devices/pnp0/00:0a
system: /devices/pnp0/00:0c
i8042 kbd: /devices/pnp0/00:02
i8042 aux: /devices/pnp0/00:09
usbfs: module = usbcore
hub: module = usbcore
hub: /devices/pci0000:00/0000:00:10.4/usb1/1-0:1.0
hub: /devices/pci0000:00/0000:00:10.0/usb2/2-0:1.0
hub: /devices/pci0000:00/0000:00:10.2/usb3/3-0:1.0
hub: /devices/pci0000:00/0000:00:10.3/usb4/4-0:1.0
usb: /devices/pci0000:00/0000:00:10.4/usb1
usb: /devices/pci0000:00/0000:00:10.0/usb2
usb: /devices/pci0000:00/0000:00:10.4/usb1/1-8
usb: /devices/pci0000:00/0000:00:10.2/usb3
usb: /devices/pci0000:00/0000:00:10.3/usb4
usb: /devices/pci0000:00/0000:00:10.0/usb2/2-1
uvcvideo: /devices/pci0000:00/0000:00:10.4/usb1/1-8/1-8:1.0
uvcvideo: /devices/pci0000:00/0000:00:10.4/usb1/1-8/1-8:1.1
uvcvideo: module = uvcvideo
hiddev: module = usbhid
usbhid: /devices/pci0000:00/0000:00:10.0/usb2/2-1/2-1:1.0
usbhid: module = usbhid
atkbd: module = atkbd
atkbd: /devices/platform/i8042/serio0
psmouse: module = psmouse
psmouse: /devices/platform/i8042/serio4
serio_raw: module = serio_raw
ide-disk: /devices/ide0/0.0
dummy: module = i2c_core
----- sysfs driver list end -----
>> block.3: cdrom
----- /proc/sys/dev/cdrom/info -----
drive name:
drive speed:
drive # of slots:
Can close tray:
Can open tray:
Can lock tray:
Can change speed:
Can select disk:
Can read multisession:
Can read MCN:
Reports media changed:
Can play audio:
Can write CD-R:
Can write CD-RW:
Can read DVD:
Can write DVD-R:
Can write DVD-RAM:
Can read MRW:
Can write MRW:
Can write RAM:
----- /proc/sys/dev/cdrom/info end -----
>> block.4: partition
----- /proc/partitions -----
3 0 117220824 hda
3 1 987966 hda1
3 2 3904918 hda2
3 3 62107290 hda3
3 4 50211157 hda4
----- /proc/partitions end -----
disks:
hda
partitions:
hda1
hda2
hda3
hda4
>> block.5: get sysfs block dev data
ide: bus_id = 0.0 path = /devices/ide0/0.0
block: name = hda, path = /block/hda
dev = 3:0
range = 64
block device: bus = ide, bus_id = 0.0 driver = ide-disk
path = /devices/ide0/0.0
block: name = ram15, path = /block/ram15
dev = 1:15
range = 1
block: name = ram14, path = /block/ram14
dev = 1:14
range = 1
block: name = ram13, path = /block/ram13
dev = 1:13
range = 1
block: name = ram12, path = /block/ram12
dev = 1:12
range = 1
block: name = ram11, path = /block/ram11
dev = 1:11
range = 1
block: name = ram10, path = /block/ram10
dev = 1:10
range = 1
block: name = ram9, path = /block/ram9
dev = 1:9
range = 1
block: name = ram8, path = /block/ram8
dev = 1:8
range = 1
block: name = ram7, path = /block/ram7
dev = 1:7
range = 1
block: name = ram6, path = /block/ram6
dev = 1:6
range = 1
block: name = ram5, path = /block/ram5
dev = 1:5
range = 1
block: name = ram4, path = /block/ram4
dev = 1:4
range = 1
block: name = ram3, path = /block/ram3
dev = 1:3
range = 1
block: name = ram2, path = /block/ram2
dev = 1:2
range = 1
block: name = ram1, path = /block/ram1
dev = 1:1
range = 1
block: name = ram0, path = /block/ram0
dev = 1:0
range = 1
>> scsi.1: scsi modules
----- exec: "/sbin/modprobe sg " -----
----- return code: ? -----
>> scsi.2: scsi tape
sysfs: no such class: scsi_tape
>> scsi.3: scsi generic
sysfs: no such class: scsi_generic
>> usb.1: sysfs drivers
----- sysfs driver list (id 0x104619e36d003657) -----
vesafb: /devices/platform/vesafb.0
serial8250: /devices/platform/serial8250
i8042: /devices/platform/i8042
pcspkr: /devices/platform/pcspkr
pcspkr: module = pcspkr
parport_pc: module = parport_pc
pcieport-driver: /devices/pci0000:00/0000:00:02.0
pcieport-driver: /devices/pci0000:00/0000:00:03.0
agpgart-via: /devices/pci0000:00/0000:00:00.0
agpgart-via: module = via_agp
wl: /devices/pci0000:00/0000:00:02.0/0000:02:00.0
wl: module = wl
ehci_hcd: /devices/pci0000:00/0000:00:10.4
ehci_hcd: module = ehci_hcd
sata_via: module = sata_via
uhci_hcd: /devices/pci0000:00/0000:00:10.0
uhci_hcd: /devices/pci0000:00/0000:00:10.2
uhci_hcd: /devices/pci0000:00/0000:00:10.3
uhci_hcd: module = uhci_hcd
pata_acpi: module = pata_acpi
vt596_smbus: module = i2c_viapro
ata_generic: module = ata_generic
HDA Intel: /devices/pci0000:80/0000:80:01.0
HDA Intel: module = snd_hda_intel
tg3: /devices/pci0000:00/0000:00:13.1/0000:07:03.0
tg3: module = tg3
via-rhine: module = via_rhine
parport_pc: module = parport_pc
ec: /devices/LNXSYSTM:00/device:00/PNP0A03:00/device:21/PNP0C09:00
pci_root: /devices/LNXSYSTM:00/device:00/PNP0A03:00
pci_root: /devices/LNXSYSTM:00/device:00/PNP0A08:00
pci_link: /devices/LNXSYSTM:00/device:00/PNP0C0F:00
pci_link: /devices/LNXSYSTM:00/device:00/PNP0C0F:01
pci_link: /devices/LNXSYSTM:00/device:00/PNP0C0F:02
pci_link: /devices/LNXSYSTM:00/device:00/PNP0C0F:03
pci_link: /devices/LNXSYSTM:00/device:00/PNP0C0F:04
pci_link: /devices/LNXSYSTM:00/device:00/PNP0C0F:05
pci_link: /devices/LNXSYSTM:00/device:00/PNP0C0F:06
pci_link: /devices/LNXSYSTM:00/device:00/PNP0C0F:07
power: /devices/LNXSYSTM:00/device:00/PNP0A08:00/device:2f/LNXPOWER:00
processor: /devices/LNXSYSTM:00/ACPI0007:00
button: /devices/LNXSYSTM:00/LNXPWRBN:00
button: /devices/LNXSYSTM:00/device:00/PNP0A03:00/PNP0C0D:00
button: /devices/LNXSYSTM:00/device:00/PNP0C0E:00
button: /devices/LNXSYSTM:00/device:00/PNP0C0C:00
thermal: /devices/LNXSYSTM:00/LNXTHERM:00/LNXTHERM:01
ac: /devices/LNXSYSTM:00/device:00/PNP0A03:00/ACPI0003:00
battery: /devices/LNXSYSTM:00/device:00/PNP0A03:00/PNP0C0A:00
video: /devices/LNXSYSTM:00/device:00/PNP0A03:00/device:08/device:09
system: /devices/pnp0/00:05
system: /devices/pnp0/00:08
system: /devices/pnp0/00:0a
system: /devices/pnp0/00:0c
i8042 kbd: /devices/pnp0/00:02
i8042 aux: /devices/pnp0/00:09
usbfs: module = usbcore
hub: module = usbcore
hub: /devices/pci0000:00/0000:00:10.4/usb1/1-0:1.0
hub: /devices/pci0000:00/0000:00:10.0/usb2/2-0:1.0
hub: /devices/pci0000:00/0000:00:10.2/usb3/3-0:1.0
hub: /devices/pci0000:00/0000:00:10.3/usb4/4-0:1.0
usb: /devices/pci0000:00/0000:00:10.4/usb1
usb: /devices/pci0000:00/0000:00:10.0/usb2
usb: /devices/pci0000:00/0000:00:10.4/usb1/1-8
usb: /devices/pci0000:00/0000:00:10.2/usb3
usb: /devices/pci0000:00/0000:00:10.3/usb4
usb: /devices/pci0000:00/0000:00:10.0/usb2/2-1
uvcvideo: /devices/pci0000:00/0000:00:10.4/usb1/1-8/1-8:1.0
uvcvideo: /devices/pci0000:00/0000:00:10.4/usb1/1-8/1-8:1.1
uvcvideo: module = uvcvideo
hiddev: module = usbhid
usbhid: /devices/pci0000:00/0000:00:10.0/usb2/2-1/2-1:1.0
usbhid: module = usbhid
atkbd: module = atkbd
atkbd: /devices/platform/i8042/serio0
psmouse: module = psmouse
psmouse: /devices/platform/i8042/serio4
serio_raw: module = serio_raw
ide-disk: /devices/ide0/0.0
dummy: module = i2c_core
----- sysfs driver list end -----
>> usb.2: usb
usb dev: /devices/pci0000:00/0000:00:10.0/usb2/2-1
usb dev: /devices/pci0000:00/0000:00:10.3/usb4
usb dev: /devices/pci0000:00/0000:00:10.2/usb3
usb dev: /devices/pci0000:00/0000:00:10.4/usb1/1-8
usb dev: /devices/pci0000:00/0000:00:10.0/usb2
usb dev: /devices/pci0000:00/0000:00:10.4/usb1
usb device: name = 2-1:1.0
path = /devices/pci0000:00/0000:00:10.0/usb2/2-1/2-1:1.0
modalias = "usb:v15D9p0A4Cd0100dc00dsc00dp00ic03isc01ip02"
bInterfaceNumber = 0
bInterfaceClass = 3
bInterfaceSubClass = 1
bInterfaceProtocol = 2
if: 2-1:1.0 @ /devices/pci0000:00/0000:00:10.0/usb2/2-1
bDeviceClass = 0
bDeviceSubClass = 0
bDeviceProtocol = 0
idVendor = 0x15d9
idProduct = 0x0a4c
product = "USB OPTICAL MOUSE"
bcdDevice = 0100
speed = "1.5"
usb device: name = 2-1
path = /devices/pci0000:00/0000:00:10.0/usb2/2-1
usb device: name = 4-0:1.0
path = /devices/pci0000:00/0000:00:10.3/usb4/4-0:1.0
modalias = "usb:v1D6Bp0001d0206dc09dsc00dp00ic09isc00ip00"
bInterfaceNumber = 0
bInterfaceClass = 9
bInterfaceSubClass = 0
bInterfaceProtocol = 0
if: 4-0:1.0 @ /devices/pci0000:00/0000:00:10.3/usb4
bDeviceClass = 9
bDeviceSubClass = 0
bDeviceProtocol = 0
idVendor = 0x1d6b
idProduct = 0x0001
manufacturer = "Linux 2.6.27.59 uhci_hcd"
product = "UHCI Host Controller"
serial = "0000:00:10.3"
bcdDevice = 0206
speed = "12"
usb device: name = usb4
path = /devices/pci0000:00/0000:00:10.3/usb4
usb device: name = 3-0:1.0
path = /devices/pci0000:00/0000:00:10.2/usb3/3-0:1.0
modalias = "usb:v1D6Bp0001d0206dc09dsc00dp00ic09isc00ip00"
bInterfaceNumber = 0
bInterfaceClass = 9
bInterfaceSubClass = 0
bInterfaceProtocol = 0
if: 3-0:1.0 @ /devices/pci0000:00/0000:00:10.2/usb3
bDeviceClass = 9
bDeviceSubClass = 0
bDeviceProtocol = 0
idVendor = 0x1d6b
idProduct = 0x0001
manufacturer = "Linux 2.6.27.59 uhci_hcd"
product = "UHCI Host Controller"
serial = "0000:00:10.2"
bcdDevice = 0206
speed = "12"
usb device: name = usb3
path = /devices/pci0000:00/0000:00:10.2/usb3
usb device: name = 1-8:1.1
path = /devices/pci0000:00/0000:00:10.4/usb1/1-8/1-8:1.1
modalias = "usb:v04F2pB107d0852dcEFdsc02dp01ic0Eisc02ip00"
bInterfaceNumber = 1
bInterfaceClass = 14
bInterfaceSubClass = 2
bInterfaceProtocol = 0
if: 1-8:1.1 @ /devices/pci0000:00/0000:00:10.4/usb1/1-8
bDeviceClass = 239
bDeviceSubClass = 2
bDeviceProtocol = 1
idVendor = 0x04f2
idProduct = 0xb107
manufacturer = "Chicony Electronics Co., Ltd."
product = "CNF7070"
serial = "SN0001"
bcdDevice = 0852
speed = "480"
usb device: name = 1-8:1.0
path = /devices/pci0000:00/0000:00:10.4/usb1/1-8/1-8:1.0
modalias = "usb:v04F2pB107d0852dcEFdsc02dp01ic0Eisc01ip00"
bInterfaceNumber = 0
bInterfaceClass = 14
bInterfaceSubClass = 1
bInterfaceProtocol = 0
if: 1-8:1.0 @ /devices/pci0000:00/0000:00:10.4/usb1/1-8
bDeviceClass = 239
bDeviceSubClass = 2
bDeviceProtocol = 1
idVendor = 0x04f2
idProduct = 0xb107
manufacturer = "Chicony Electronics Co., Ltd."
product = "CNF7070"
serial = "SN0001"
bcdDevice = 0852
speed = "480"
usb device: name = 1-8
path = /devices/pci0000:00/0000:00:10.4/usb1/1-8
usb device: name = 2-0:1.0
path = /devices/pci0000:00/0000:00:10.0/usb2/2-0:1.0
modalias = "usb:v1D6Bp0001d0206dc09dsc00dp00ic09isc00ip00"
bInterfaceNumber = 0
bInterfaceClass = 9
bInterfaceSubClass = 0
bInterfaceProtocol = 0
if: 2-0:1.0 @ /devices/pci0000:00/0000:00:10.0/usb2
bDeviceClass = 9
bDeviceSubClass = 0
bDeviceProtocol = 0
idVendor = 0x1d6b
idProduct = 0x0001
manufacturer = "Linux 2.6.27.59 uhci_hcd"
product = "UHCI Host Controller"
serial = "0000:00:10.0"
bcdDevice = 0206
speed = "12"
usb device: name = usb2
path = /devices/pci0000:00/0000:00:10.0/usb2
usb device: name = 1-0:1.0
path = /devices/pci0000:00/0000:00:10.4/usb1/1-0:1.0
modalias = "usb:v1D6Bp0002d0206dc09dsc00dp00ic09isc00ip00"
bInterfaceNumber = 0
bInterfaceClass = 9
bInterfaceSubClass = 0
bInterfaceProtocol = 0
if: 1-0:1.0 @ /devices/pci0000:00/0000:00:10.4/usb1
bDeviceClass = 9
bDeviceSubClass = 0
bDeviceProtocol = 0
idVendor = 0x1d6b
idProduct = 0x0002
manufacturer = "Linux 2.6.27.59 ehci_hcd"
product = "EHCI Host Controller"
serial = "0000:00:10.4"
bcdDevice = 0206
speed = "480"
usb device: name = usb1
path = /devices/pci0000:00/0000:00:10.4/usb1
removed: /devices/pci0000:00/0000:00:10.4/usb1/1-8/1-8:1.0
>> usb.3.1: joydev mod
>> usb.3.2: evdev mod
>> usb.3.3: input
input: name = event9, path = /class/input/input10/event9
dev = 13:73
input device: bus = usb, bus_id = 2-1:1.0 driver = usbhid
path = /devices/pci0000:00/0000:00:10.0/usb2/2-1/2-1:1.0
input: name = mouse1, path = /class/input/input10/mouse1
dev = 13:33
input device: bus = usb, bus_id = 2-1:1.0 driver = usbhid
path = /devices/pci0000:00/0000:00:10.0/usb2/2-1/2-1:1.0
input: name = event8, path = /class/input/input8/event8
dev = 13:72
input device: bus = usb, bus_id = 1-8:1.0 driver = uvcvideo
path = /devices/pci0000:00/0000:00:10.4/usb1/1-8/1-8:1.0
input: name = event7, path = /class/input/input7/event7
dev = 13:71
input device: bus = platform, bus_id = pcspkr driver = pcspkr
path = /devices/platform/pcspkr
input: name = event6, path = /class/input/input6/event6
dev = 13:70
input device: bus = acpi, bus_id = device:09 driver = video
path = /devices/LNXSYSTM:00/device:00/PNP0A03:00/device:08/device:09
input: name = event5, path = /class/input/input5/event5
dev = 13:69
input device: bus = acpi, bus_id = PNP0C0C:00 driver = button
path = /devices/LNXSYSTM:00/device:00/PNP0C0C:00
input: name = event4, path = /class/input/input4/event4
dev = 13:68
input device: bus = acpi, bus_id = PNP0C0E:00 driver = button
path = /devices/LNXSYSTM:00/device:00/PNP0C0E:00
input: name = event3, path = /class/input/input3/event3
dev = 13:67
input device: bus = acpi, bus_id = PNP0C0D:00 driver = button
path = /devices/LNXSYSTM:00/device:00/PNP0A03:00/PNP0C0D:00
input: name = event2, path = /class/input/input2/event2
dev = 13:66
input device: bus = acpi, bus_id = LNXPWRBN:00 driver = button
path = /devices/LNXSYSTM:00/LNXPWRBN:00
input: name = event1, path = /class/input/input1/event1
dev = 13:65
input device: bus = serio, bus_id = serio0 driver = atkbd
path = /devices/platform/i8042/serio0
input: name = event0, path = /class/input/input0/event0
dev = 13:64
input device: bus = serio, bus_id = serio4 driver = psmouse
path = /devices/platform/i8042/serio4
input: name = mouse0, path = /class/input/input0/mouse0
dev = 13:32
input device: bus = serio, bus_id = serio4 driver = psmouse
path = /devices/platform/i8042/serio4
>> usb.3.4: lp
sysfs: no such class: usb
>> usb.3.5: serial
>> edd.1: edd mod
----- exec: "/sbin/modprobe edd " -----
FATAL: Module edd not found.
----- return code: ? -----
>> edd.2: edd info
>> braille.1.1: alva
>> braille.2.1: alva open
>> braille.3.1: alva init ok
>> braille.4.1: alva read data
alva.100@/dev/ttyS0[-1]:
>> braille.5.1: alva read done
>> braille.1.1: fhp_old
>> braille.2.1: fhp open
>> braille.3.1: fhp init ok
>> braille.4.1: fhp write ok
>> braille.5.1: fhp read done
fhp@/dev/ttyS0[-1]:
no fhp display: 0x00
>> braille.1.1: fhp_el
>> braille.2.1: fhp open
>> braille.3.1: fhp init ok
>> braille.4.1: fhp write ok
>> braille.5.1: fhp read done
fhp@/dev/ttyS0[-1]:
no fhp display: 0x00
>> braille.1.1: ht
>> braille.2.1: ht open
ht@/dev/ttyS0[0]:
no ht display: 0x00
>> braille.1.1: baum
>> braille.2.1: baum open
>> braille.3.1: baum write ok
>> braille.4.1: baum read done
baum@/dev/ttyS0[-1]:
>> modem.1: serial
****** started child process 26600 (15s/120s) ******
>> modem.2: init
>> modem.3.1: at test
>> modem.3.2: at test
>> modem.3.3: at test
>> modem.3.4: at test
>> modem.4: init string
>> modem.5: speed
>> modem.5: pnp id
----- serial modems -----
/dev/ttyS0
not a modem
----- serial modems end -----
****** stopped child process 26600 (121s) ******
----- serial modems -----
/dev/ttyS0
not a modem
----- serial modems end -----
>> mouse.2: serial
****** started child process 26601 (20s/20s) ******
****** stopped child process 26601 (20s) ******
>> input.1: joydev mod
>> input.1.1: evdev mod
>> input.2: input
----- /proc/bus/input/devices -----
I: Bus=0011 Vendor=0002 Product=0007 Version=01b1
N: Name="SynPS/2 Synaptics TouchPad"
P: Phys=isa0060/serio4/input0
S: Sysfs=/class/input/input0
U: Uniq=
H: Handlers=mouse0 event0
B: EV=b
B: KEY=6420 0 70000 0 0 0 0 0 0 0 0
B: ABS=11000003
I: Bus=0011 Vendor=0001 Product=0001 Version=ab41
N: Name="AT Translated Set 2 keyboard"
P: Phys=isa0060/serio0/input0
S: Sysfs=/class/input/input1
U: Uniq=
H: Handlers=kbd event1
B: EV=120013
B: KEY=4 2000000 3803078 f800d001 feffffdf ffefffff ffffffff fffffffe
B: MSC=10
B: LED=7
I: Bus=0019 Vendor=0000 Product=0002 Version=0000
N: Name="Power Button (FF)"
P: Phys=LNXPWRBN/button/input0
S: Sysfs=/class/input/input2
U: Uniq=
H: Handlers=kbd event2
B: EV=3
B: KEY=100000 0 0 0
I: Bus=0019 Vendor=0000 Product=0005 Version=0000
N: Name="Lid Switch"
P: Phys=PNP0C0D/button/input0
S: Sysfs=/class/input/input3
U: Uniq=
H: Handlers=event3
B: EV=21
B: SW=1
I: Bus=0019 Vendor=0000 Product=0003 Version=0000
N: Name="Sleep Button (CM)"
P: Phys=PNP0C0E/button/input0
S: Sysfs=/class/input/input4
U: Uniq=
H: Handlers=kbd event4
B: EV=3
B: KEY=4000 0 0 0 0
I: Bus=0019 Vendor=0000 Product=0001 Version=0000
N: Name="Power Button (CM)"
P: Phys=PNP0C0C/button/input0
S: Sysfs=/class/input/input5
U: Uniq=
H: Handlers=kbd event5
B: EV=3
B: KEY=100000 0 0 0
I: Bus=0019 Vendor=0000 Product=0006 Version=0000
N: Name="Video Bus"
P: Phys=/video/input0
S: Sysfs=/class/input/input6
U: Uniq=
H: Handlers=kbd event6
B: EV=3
B: KEY=3f000b 0 0 0 0 0 0 0
I: Bus=0010 Vendor=001f Product=0001 Version=0100
N: Name="PC Speaker"
P: Phys=isa0061/input0
S: Sysfs=/class/input/input7
U: Uniq=
H: Handlers=kbd event7
B: EV=40001
B: SND=6
I: Bus=0003 Vendor=04f2 Product=b107 Version=0852
N: Name="CNF7070"
P: Phys=usb-0000:00:10.4-8
S: Sysfs=/class/input/input8
U: Uniq=
H: Handlers=event8
B: EV=3
B: KEY=1 0 0 0 0 0 0 0 0
I: Bus=0003 Vendor=15d9 Product=0a4c Version=0111
N: Name=" USB OPTICAL MOUSE"
P: Phys=usb-0000:00:10.0-1/input0
S: Sysfs=/class/input/input10
U: Uniq=
H: Handlers=mouse1 event9
B: EV=17
B: KEY=70000 0 0 0 0 0 0 0 0
B: REL=103
B: MSC=10
----- /proc/bus/input/devices end -----
bus = 17, name = SynPS/2 Synaptics TouchPad
handlers = mouse0 event0
key = 0000642000000000000700000000000000000000000000000000000000000000000000000000000000000000
abs = 11000003
mouse buttons = 3
mouse wheels = 0
bus = 17, name = AT Translated Set 2 keyboard
handlers = kbd event1
key = 000000040200000003803078f800d001feffffdfffeffffffffffffffffffffe
mouse buttons = 0
mouse wheels = 0
bus = 25, name = Power Button (FF)
handlers = kbd event2
key = 00100000000000000000000000000000
mouse buttons = 0
mouse wheels = 0
bus = 25, name = Lid Switch
handlers = event3
mouse buttons = 0
mouse wheels = 0
bus = 25, name = Sleep Button (CM)
handlers = kbd event4
key = 0000400000000000000000000000000000000000
mouse buttons = 0
mouse wheels = 0
bus = 25, name = Power Button (CM)
handlers = kbd event5
key = 00100000000000000000000000000000
mouse buttons = 0
mouse wheels = 0
bus = 25, name = Video Bus
handlers = kbd event6
key = 003f000b00000000000000000000000000000000000000000000000000000000
mouse buttons = 0
mouse wheels = 0
bus = 16, name = PC Speaker
handlers = kbd event7
mouse buttons = 0
mouse wheels = 0
bus = 3, name = CNF7070
handlers = event8
key = 000000010000000000000000000000000000000000000000000000000000000000000000
mouse buttons = 0
mouse wheels = 0
bus = 3, name = USB OPTICAL MOUSE
handlers = mouse1 event9
key = 000700000000000000000000000000000000000000000000000000000000000000000000
rel = 00000103
mouse buttons = 3
mouse wheels = 1
>> kbd.2: uml
>> cpu.1: cpuinfo
----- /proc/cpuinfo -----
processor : 0
vendor_id : CentaurHauls
cpu family : 6
model : 13
model name : VIA C7-M Processor 1600MHz
stepping : 0
cpu MHz : 1595.968
cache size : 128 KB
fdiv_bug : no
hlt_bug : no
f00f_bug : no
coma_bug : no
fpu : yes
fpu_exception : yes
cpuid level : 1
wp : yes
flags : fpu vme de pse tsc msr pae mce cx8 apic sep mtrr pge cmov pat clflush acpi mmx fxsr sse sse2 tm nx pni est tm2 xtpr rng rng_en ace ace_en ace2 ace2_en phe phe_en pmm pmm_en
bogomips : 3191.94
clflush size : 64
power management:
----- /proc/cpuinfo end -----
>> kbd.3: serial console
>> fb.1: read info
fb: size 1280 x 768
fb: timing 98.32 MHz, 60.24 kHz, 76.07 Hz
>> net.1: get network data
net interface: name = eth12, path = /class/net/eth12
type = 1
hw_addr = 00:24:81:59:74:99
net device: path = /devices/pci0000:00/0000:00:13.1/0000:07:03.0
net driver: name = tg3, path = /bus/pci/drivers/tg3
net interface: name = eth13, path = /class/net/eth13
type = 1
hw_addr = 00:21:00:29:34:2a
net device: path = /devices/pci0000:00/0000:00:02.0/0000:02:00.0
net driver: name = wl, path = /bus/pci/drivers/wl
net interface: name = lo, path = /class/net/lo
type = 772
hw_addr = 00:00:00:00:00:00
eth12: ethtool link state: 1
eth13: GLINK ethtool error: Operation not supported
lo: ethtool link state: 1
>> pppoe.1: looking for pppoe
>> pppoe.2: discovery
Attempt number 1
eth12: Sending PADI packet
send failed: Network is down
eth13: Sending PADI packet
recv failed: Network is down
Timeout waiting for PADO packets
Attempt number 2
eth12: Sending PADI packet
send failed: Network is down
eth13: Sending PADI packet
Timeout waiting for PADO packets
>> wlan.1: detecting wlan features
*** device eth13 is wireless ***
>> isdn.1: list
>> dsl.1: list
>> int.2: cdrom
>> int.3: media
>> int.4.1: /dev/hda
read_block0: 512 bytes (5s, 0us)
>> int.4: floppy
>> int.5: bios
bios ctrl 0: 0
>> int.6: mouse
>> int.15: system info
system type: notebook
acpi: 1
>> int.7: hdb
>> int.7.1: modules
----- sysfs driver list (id 0x30fe8c6a71ac9fe4) -----
vesafb: /devices/platform/vesafb.0
serial8250: /devices/platform/serial8250
i8042: /devices/platform/i8042
pcspkr: /devices/platform/pcspkr
pcspkr: module = pcspkr
parport_pc: module = parport_pc
pcieport-driver: /devices/pci0000:00/0000:00:02.0
pcieport-driver: /devices/pci0000:00/0000:00:03.0
agpgart-via: /devices/pci0000:00/0000:00:00.0
agpgart-via: module = via_agp
wl: /devices/pci0000:00/0000:00:02.0/0000:02:00.0
wl: module = wl
ehci_hcd: /devices/pci0000:00/0000:00:10.4
ehci_hcd: module = ehci_hcd
sata_via: module = sata_via
uhci_hcd: /devices/pci0000:00/0000:00:10.0
uhci_hcd: /devices/pci0000:00/0000:00:10.2
uhci_hcd: /devices/pci0000:00/0000:00:10.3
uhci_hcd: module = uhci_hcd
pata_acpi: module = pata_acpi
vt596_smbus: module = i2c_viapro
ata_generic: module = ata_generic
HDA Intel: /devices/pci0000:80/0000:80:01.0
HDA Intel: module = snd_hda_intel
tg3: /devices/pci0000:00/0000:00:13.1/0000:07:03.0
tg3: module = tg3
via-rhine: module = via_rhine
parport_pc: module = parport_pc
ec: /devices/LNXSYSTM:00/device:00/PNP0A03:00/device:21/PNP0C09:00
pci_root: /devices/LNXSYSTM:00/device:00/PNP0A03:00
pci_root: /devices/LNXSYSTM:00/device:00/PNP0A08:00
pci_link: /devices/LNXSYSTM:00/device:00/PNP0C0F:00
pci_link: /devices/LNXSYSTM:00/device:00/PNP0C0F:01
pci_link: /devices/LNXSYSTM:00/device:00/PNP0C0F:02
pci_link: /devices/LNXSYSTM:00/device:00/PNP0C0F:03
pci_link: /devices/LNXSYSTM:00/device:00/PNP0C0F:04
pci_link: /devices/LNXSYSTM:00/device:00/PNP0C0F:05
pci_link: /devices/LNXSYSTM:00/device:00/PNP0C0F:06
pci_link: /devices/LNXSYSTM:00/device:00/PNP0C0F:07
power: /devices/LNXSYSTM:00/device:00/PNP0A08:00/device:2f/LNXPOWER:00
processor: /devices/LNXSYSTM:00/ACPI0007:00
button: /devices/LNXSYSTM:00/LNXPWRBN:00
button: /devices/LNXSYSTM:00/device:00/PNP0A03:00/PNP0C0D:00
button: /devices/LNXSYSTM:00/device:00/PNP0C0E:00
button: /devices/LNXSYSTM:00/device:00/PNP0C0C:00
thermal: /devices/LNXSYSTM:00/LNXTHERM:00/LNXTHERM:01
ac: /devices/LNXSYSTM:00/device:00/PNP0A03:00/ACPI0003:00
battery: /devices/LNXSYSTM:00/device:00/PNP0A03:00/PNP0C0A:00
video: /devices/LNXSYSTM:00/device:00/PNP0A03:00/device:08/device:09
system: /devices/pnp0/00:05
system: /devices/pnp0/00:08
system: /devices/pnp0/00:0a
system: /devices/pnp0/00:0c
i8042 kbd: /devices/pnp0/00:02
i8042 aux: /devices/pnp0/00:09
usbfs: module = usbcore
hub: module = usbcore
hub: /devices/pci0000:00/0000:00:10.4/usb1/1-0:1.0
hub: /devices/pci0000:00/0000:00:10.0/usb2/2-0:1.0
hub: /devices/pci0000:00/0000:00:10.2/usb3/3-0:1.0
hub: /devices/pci0000:00/0000:00:10.3/usb4/4-0:1.0
usb: /devices/pci0000:00/0000:00:10.4/usb1
usb: /devices/pci0000:00/0000:00:10.0/usb2
usb: /devices/pci0000:00/0000:00:10.4/usb1/1-8
usb: /devices/pci0000:00/0000:00:10.2/usb3
usb: /devices/pci0000:00/0000:00:10.3/usb4
usb: /devices/pci0000:00/0000:00:10.0/usb2/2-1
uvcvideo: /devices/pci0000:00/0000:00:10.4/usb1/1-8/1-8:1.0
uvcvideo: /devices/pci0000:00/0000:00:10.4/usb1/1-8/1-8:1.1
uvcvideo: module = uvcvideo
hiddev: module = usbhid
usbhid: /devices/pci0000:00/0000:00:10.0/usb2/2-1/2-1:1.0
usbhid: module = usbhid
atkbd: module = atkbd
atkbd: /devices/platform/i8042/serio0
psmouse: module = psmouse
psmouse: /devices/platform/i8042/serio4
serio_raw: module = serio_raw
ide-disk: /devices/ide0/0.0
dummy: module = i2c_core
----- sysfs driver list end -----
>> int.8: usbscsi
>> int.9: hotplug
>> int.10: modem
>> int.11: wlan
>> int.12: udev
----- udevinfo -----
P: /block/hda
N: hda
S: disk/by-id/ata-ST9120817AS_5RE0G6EJ
S: disk/by-path/ide-0:0
E: ID_TYPE=disk
E: ID_MODEL=ST9120817AS
E: ID_SERIAL=5RE0G6EJ
E: ID_REVISION=3.AHC
E: ID_BUS=ata
E: ID_PATH=ide-0:0
P: /block/hda/hda1
N: hda1
S: disk/by-id/ata-ST9120817AS_5RE0G6EJ-part1
S: disk/by-path/ide-0:0-part1
S: disk/by-uuid/4EF3-1BE3
E: ID_TYPE=disk
E: ID_MODEL=ST9120817AS
E: ID_SERIAL=5RE0G6EJ
E: ID_REVISION=3.AHC
E: ID_BUS=ata
E: ID_PATH=ide-0:0
E: ID_FS_USAGE=filesystem
E: ID_FS_TYPE=vfat
E: ID_FS_VERSION=FAT32
E: ID_FS_UUID=4EF3-1BE3
E: ID_FS_LABEL=
E: ID_FS_LABEL_SAFE=
P: /block/hda/hda2
N: hda2
S: disk/by-id/ata-ST9120817AS_5RE0G6EJ-part2
S: disk/by-path/ide-0:0-part2
E: ID_TYPE=disk
E: ID_MODEL=ST9120817AS
E: ID_SERIAL=5RE0G6EJ
E: ID_REVISION=3.AHC
E: ID_BUS=ata
E: ID_PATH=ide-0:0
E: ID_FS_USAGE=other
E: ID_FS_TYPE=swap
E: ID_FS_VERSION=2
E: ID_FS_UUID=
E: ID_FS_LABEL=
E: ID_FS_LABEL_SAFE=
P: /block/hda/hda3
N: hda3
S: disk/by-id/ata-ST9120817AS_5RE0G6EJ-part3
S: disk/by-path/ide-0:0-part3
S: disk/by-uuid/155f5a5e-88d9-4155-8d67-00f0d46ee195
E: ID_TYPE=disk
E: ID_MODEL=ST9120817AS
E: ID_SERIAL=5RE0G6EJ
E: ID_REVISION=3.AHC
E: ID_BUS=ata
E: ID_PATH=ide-0:0
E: ID_FS_USAGE=filesystem
E: ID_FS_TYPE=ext3
E: ID_FS_VERSION=1.0
E: ID_FS_UUID=155f5a5e-88d9-4155-8d67-00f0d46ee195
E: ID_FS_LABEL=
E: ID_FS_LABEL_SAFE=
P: /block/hda/hda4
N: hda4
S: disk/by-id/ata-ST9120817AS_5RE0G6EJ-part4
S: disk/by-path/ide-0:0-part4
S: disk/by-uuid/3caa1768-37be-4b8a-b45f-451fac500741
E: ID_TYPE=disk
E: ID_MODEL=ST9120817AS
E: ID_SERIAL=5RE0G6EJ
E: ID_REVISION=3.AHC
E: ID_BUS=ata
E: ID_PATH=ide-0:0
E: ID_FS_USAGE=filesystem
E: ID_FS_TYPE=ext3
E: ID_FS_VERSION=1.0
E: ID_FS_UUID=3caa1768-37be-4b8a-b45f-451fac500741
E: ID_FS_LABEL=
E: ID_FS_LABEL_SAFE=
P: /block/ram0
N: ram0
P: /block/ram1
N: ram1
P: /block/ram10
N: ram10
P: /block/ram11
N: ram11
P: /block/ram12
N: ram12
P: /block/ram13
N: ram13
P: /block/ram14
N: ram14
P: /block/ram15
N: ram15
P: /block/ram2
N: ram2
P: /block/ram3
N: ram3
P: /block/ram4
N: ram4
P: /block/ram5
N: ram5
P: /block/ram6
N: ram6
P: /block/ram7
N: ram7
P: /block/ram8
N: ram8
P: /block/ram9
N: ram9
P: /class/graphics/fb0
N: fb0
P: /class/input/input0/event0
N: input/event0
S: input/by-path/platform-i8042-serio-4-event-mouse
E: ID_CLASS=mouse
E: ID_SERIAL=noserial
E: ID_PATH=platform-i8042-serio-4
P: /class/input/input0/mouse0
N: input/mouse0
S: input/by-path/platform-i8042-serio-4-mouse
E: ID_CLASS=mouse
E: ID_SERIAL=noserial
E: ID_PATH=platform-i8042-serio-4
P: /class/input/input1/event1
N: input/event1
S: input/by-path/platform-i8042-serio-0-event-kbd
E: ID_CLASS=kbd
E: ID_SERIAL=noserial
E: ID_PATH=platform-i8042-serio-0
P: /class/input/input10/event9
N: input/event9
S: input/by-id/usb-15d9_USB_OPTICAL_MOUSE-event-mouse
S: input/by-path/pci-0000:00:10.0-usb-0:1:1.0-event-mouse
E: ID_VENDOR=15d9
E: ID_MODEL=USB_OPTICAL_MOUSE
E: ID_REVISION=0100
E: ID_SERIAL=15d9_USB_OPTICAL_MOUSE
E: ID_TYPE=hid
E: ID_BUS=usb
E: ID_CLASS=mouse
E: ID_PATH=pci-0000:00:10.0-usb-0:1:1.0
P: /class/input/input10/mouse1
N: input/mouse1
S: input/by-id/usb-15d9_USB_OPTICAL_MOUSE-mouse
S: input/by-path/pci-0000:00:10.0-usb-0:1:1.0-mouse
E: ID_VENDOR=15d9
E: ID_MODEL=USB_OPTICAL_MOUSE
E: ID_REVISION=0100
E: ID_SERIAL=15d9_USB_OPTICAL_MOUSE
E: ID_TYPE=hid
E: ID_BUS=usb
E: ID_CLASS=mouse
E: ID_PATH=pci-0000:00:10.0-usb-0:1:1.0
P: /class/input/input2/event2
N: input/event2
E: ID_SERIAL=noserial
P: /class/input/input3/event3
N: input/event3
E: ID_SERIAL=noserial
P: /class/input/input4/event4
N: input/event4
E: ID_SERIAL=noserial
P: /class/input/input5/event5
N: input/event5
E: ID_SERIAL=noserial
P: /class/input/input6/event6
N: input/event6
E: ID_SERIAL=noserial
P: /class/input/input7/event7
N: input/event7
S: input/by-path/platform-pcspkr-event-spkr
E: ID_CLASS=spkr
E: ID_SERIAL=noserial
E: ID_PATH=platform-pcspkr
P: /class/input/input8/event8
N: input/event8
S: input/by-path/pci-0000:00:10.4-usb-0:8:1.0-event-
E: ID_VENDOR=Chicony_Electronics_Co.,_Ltd.
E: ID_MODEL=CNF7070
E: ID_REVISION=0852
E: ID_SERIAL=Chicony_Electronics_Co.,_Ltd._CNF7070_SN0001
E: ID_TYPE=generic
E: ID_BUS=usb
E: ID_PATH=pci-0000:00:10.4-usb-0:8:1.0
P: /class/input/mice
N: input/mice
E: ID_SERIAL=noserial
P: /class/mem/full
N: full
P: /class/mem/kmem
N: kmem
P: /class/mem/kmsg
N: kmsg
P: /class/mem/mem
N: mem
P: /class/mem/null
N: null
P: /class/mem/port
N: port
P: /class/mem/random
N: random
P: /class/mem/urandom
N: urandom
P: /class/mem/zero
N: zero
P: /class/misc/agpgart
N: agpgart
P: /class/misc/cpu_dma_latency
N: cpu_dma_latency
P: /class/misc/fuse
N: fuse
P: /class/misc/network_latency
N: network_latency
P: /class/misc/network_throughput
N: network_throughput
P: /class/misc/psaux
N: psaux
P: /class/sound/audio
N: audio
P: /class/sound/controlC0
N: snd/controlC0
P: /class/sound/dsp
N: dsp
P: /class/sound/mixer
N: mixer
P: /class/sound/pcmC0D0c
N: snd/pcmC0D0c
P: /class/sound/pcmC0D0p
N: snd/pcmC0D0p
P: /class/sound/timer
N: snd/timer
P: /class/tty/console
N: console
P: /class/tty/ptmx
N: ptmx
P: /class/tty/ptya0
N: ptya0
P: /class/tty/ptya1
N: ptya1
P: /class/tty/ptya2
N: ptya2
P: /class/tty/ptya3
N: ptya3
P: /class/tty/ptya4
N: ptya4
P: /class/tty/ptya5
N: ptya5
P: /class/tty/ptya6
N: ptya6
P: /class/tty/ptya7
N: ptya7
P: /class/tty/ptya8
N: ptya8
P: /class/tty/ptya9
N: ptya9
P: /class/tty/ptyaa
N: ptyaa
P: /class/tty/ptyab
N: ptyab
P: /class/tty/ptyac
N: ptyac
P: /class/tty/ptyad
N: ptyad
P: /class/tty/ptyae
N: ptyae
P: /class/tty/ptyaf
N: ptyaf
P: /class/tty/ptyb0
N: ptyb0
P: /class/tty/ptyb1
N: ptyb1
P: /class/tty/ptyb2
N: ptyb2
P: /class/tty/ptyb3
N: ptyb3
P: /class/tty/ptyb4
N: ptyb4
P: /class/tty/ptyb5
N: ptyb5
P: /class/tty/ptyb6
N: ptyb6
P: /class/tty/ptyb7
N: ptyb7
P: /class/tty/ptyb8
N: ptyb8
P: /class/tty/ptyb9
N: ptyb9
P: /class/tty/ptyba
N: ptyba
P: /class/tty/ptybb
N: ptybb
P: /class/tty/ptybc
N: ptybc
P: /class/tty/ptybd
N: ptybd
P: /class/tty/ptybe
N: ptybe
P: /class/tty/ptybf
N: ptybf
P: /class/tty/ptyc0
N: ptyc0
P: /class/tty/ptyc1
N: ptyc1
P: /class/tty/ptyc2
N: ptyc2
P: /class/tty/ptyc3
N: ptyc3
P: /class/tty/ptyc4
N: ptyc4
P: /class/tty/ptyc5
N: ptyc5
P: /class/tty/ptyc6
N: ptyc6
P: /class/tty/ptyc7
N: ptyc7
P: /class/tty/ptyc8
N: ptyc8
P: /class/tty/ptyc9
N: ptyc9
P: /class/tty/ptyca
N: ptyca
P: /class/tty/ptycb
N: ptycb
P: /class/tty/ptycc
N: ptycc
P: /class/tty/ptycd
N: ptycd
P: /class/tty/ptyce
N: ptyce
P: /class/tty/ptycf
N: ptycf
P: /class/tty/ptyd0
N: ptyd0
P: /class/tty/ptyd1
N: ptyd1
P: /class/tty/ptyd2
N: ptyd2
P: /class/tty/ptyd3
N: ptyd3
P: /class/tty/ptyd4
N: ptyd4
P: /class/tty/ptyd5
N: ptyd5
P: /class/tty/ptyd6
N: ptyd6
P: /class/tty/ptyd7
N: ptyd7
P: /class/tty/ptyd8
N: ptyd8
P: /class/tty/ptyd9
N: ptyd9
P: /class/tty/ptyda
N: ptyda
P: /class/tty/ptydb
N: ptydb
P: /class/tty/ptydc
N: ptydc
P: /class/tty/ptydd
N: ptydd
P: /class/tty/ptyde
N: ptyde
P: /class/tty/ptydf
N: ptydf
P: /class/tty/ptye0
N: ptye0
P: /class/tty/ptye1
N: ptye1
P: /class/tty/ptye2
N: ptye2
P: /class/tty/ptye3
N: ptye3
P: /class/tty/ptye4
N: ptye4
P: /class/tty/ptye5
N: ptye5
P: /class/tty/ptye6
N: ptye6
P: /class/tty/ptye7
N: ptye7
P: /class/tty/ptye8
N: ptye8
P: /class/tty/ptye9
N: ptye9
P: /class/tty/ptyea
N: ptyea
P: /class/tty/ptyeb
N: ptyeb
P: /class/tty/ptyec
N: ptyec
P: /class/tty/ptyed
N: ptyed
P: /class/tty/ptyee
N: ptyee
P: /class/tty/ptyef
N: ptyef
P: /class/tty/ptyp0
N: ptyp0
P: /class/tty/ptyp1
N: ptyp1
P: /class/tty/ptyp2
N: ptyp2
P: /class/tty/ptyp3
N: ptyp3
P: /class/tty/ptyp4
N: ptyp4
P: /class/tty/ptyp5
N: ptyp5
P: /class/tty/ptyp6
N: ptyp6
P: /class/tty/ptyp7
N: ptyp7
P: /class/tty/ptyp8
N: ptyp8
P: /class/tty/ptyp9
N: ptyp9
P: /class/tty/ptypa
N: ptypa
P: /class/tty/ptypb
N: ptypb
P: /class/tty/ptypc
N: ptypc
P: /class/tty/ptypd
N: ptypd
P: /class/tty/ptype
N: ptype
P: /class/tty/ptypf
N: ptypf
P: /class/tty/ptyq0
N: ptyq0
P: /class/tty/ptyq1
N: ptyq1
P: /class/tty/ptyq2
N: ptyq2
P: /class/tty/ptyq3
N: ptyq3
P: /class/tty/ptyq4
N: ptyq4
P: /class/tty/ptyq5
N: ptyq5
P: /class/tty/ptyq6
N: ptyq6
P: /class/tty/ptyq7
N: ptyq7
P: /class/tty/ptyq8
N: ptyq8
P: /class/tty/ptyq9
N: ptyq9
P: /class/tty/ptyqa
N: ptyqa
P: /class/tty/ptyqb
N: ptyqb
P: /class/tty/ptyqc
N: ptyqc
P: /class/tty/ptyqd
N: ptyqd
P: /class/tty/ptyqe
N: ptyqe
P: /class/tty/ptyqf
N: ptyqf
P: /class/tty/ptyr0
N: ptyr0
P: /class/tty/ptyr1
N: ptyr1
P: /class/tty/ptyr2
N: ptyr2
P: /class/tty/ptyr3
N: ptyr3
P: /class/tty/ptyr4
N: ptyr4
P: /class/tty/ptyr5
N: ptyr5
P: /class/tty/ptyr6
N: ptyr6
P: /class/tty/ptyr7
N: ptyr7
P: /class/tty/ptyr8
N: ptyr8
P: /class/tty/ptyr9
N: ptyr9
P: /class/tty/ptyra
N: ptyra
P: /class/tty/ptyrb
N: ptyrb
P: /class/tty/ptyrc
N: ptyrc
P: /class/tty/ptyrd
N: ptyrd
P: /class/tty/ptyre
N: ptyre
P: /class/tty/ptyrf
N: ptyrf
P: /class/tty/ptys0
N: ptys0
P: /class/tty/ptys1
N: ptys1
P: /class/tty/ptys2
N: ptys2
P: /class/tty/ptys3
N: ptys3
P: /class/tty/ptys4
N: ptys4
P: /class/tty/ptys5
N: ptys5
P: /class/tty/ptys6
N: ptys6
P: /class/tty/ptys7
N: ptys7
P: /class/tty/ptys8
N: ptys8
P: /class/tty/ptys9
N: ptys9
P: /class/tty/ptysa
N: ptysa
P: /class/tty/ptysb
N: ptysb
P: /class/tty/ptysc
N: ptysc
P: /class/tty/ptysd
N: ptysd
P: /class/tty/ptyse
N: ptyse
P: /class/tty/ptysf
N: ptysf
P: /class/tty/ptyt0
N: ptyt0
P: /class/tty/ptyt1
N: ptyt1
P: /class/tty/ptyt2
N: ptyt2
P: /class/tty/ptyt3
N: ptyt3
P: /class/tty/ptyt4
N: ptyt4
P: /class/tty/ptyt5
N: ptyt5
P: /class/tty/ptyt6
N: ptyt6
P: /class/tty/ptyt7
N: ptyt7
P: /class/tty/ptyt8
N: ptyt8
P: /class/tty/ptyt9
N: ptyt9
P: /class/tty/ptyta
N: ptyta
P: /class/tty/ptytb
N: ptytb
P: /class/tty/ptytc
N: ptytc
P: /class/tty/ptytd
N: ptytd
P: /class/tty/ptyte
N: ptyte
P: /class/tty/ptytf
N: ptytf
P: /class/tty/ptyu0
N: ptyu0
P: /class/tty/ptyu1
N: ptyu1
P: /class/tty/ptyu2
N: ptyu2
P: /class/tty/ptyu3
N: ptyu3
P: /class/tty/ptyu4
N: ptyu4
P: /class/tty/ptyu5
N: ptyu5
P: /class/tty/ptyu6
N: ptyu6
P: /class/tty/ptyu7
N: ptyu7
P: /class/tty/ptyu8
N: ptyu8
P: /class/tty/ptyu9
N: ptyu9
P: /class/tty/ptyua
N: ptyua
P: /class/tty/ptyub
N: ptyub
P: /class/tty/ptyuc
N: ptyuc
P: /class/tty/ptyud
N: ptyud
P: /class/tty/ptyue
N: ptyue
P: /class/tty/ptyuf
N: ptyuf
P: /class/tty/ptyv0
N: ptyv0
P: /class/tty/ptyv1
N: ptyv1
P: /class/tty/ptyv2
N: ptyv2
P: /class/tty/ptyv3
N: ptyv3
P: /class/tty/ptyv4
N: ptyv4
P: /class/tty/ptyv5
N: ptyv5
P: /class/tty/ptyv6
N: ptyv6
P: /class/tty/ptyv7
N: ptyv7
P: /class/tty/ptyv8
N: ptyv8
P: /class/tty/ptyv9
N: ptyv9
P: /class/tty/ptyva
N: ptyva
P: /class/tty/ptyvb
N: ptyvb
P: /class/tty/ptyvc
N: ptyvc
P: /class/tty/ptyvd
N: ptyvd
P: /class/tty/ptyve
N: ptyve
P: /class/tty/ptyvf
N: ptyvf
P: /class/tty/ptyw0
N: ptyw0
P: /class/tty/ptyw1
N: ptyw1
P: /class/tty/ptyw2
N: ptyw2
P: /class/tty/ptyw3
N: ptyw3
P: /class/tty/ptyw4
N: ptyw4
P: /class/tty/ptyw5
N: ptyw5
P: /class/tty/ptyw6
N: ptyw6
P: /class/tty/ptyw7
N: ptyw7
P: /class/tty/ptyw8
N: ptyw8
P: /class/tty/ptyw9
N: ptyw9
P: /class/tty/ptywa
N: ptywa
P: /class/tty/ptywb
N: ptywb
P: /class/tty/ptywc
N: ptywc
P: /class/tty/ptywd
N: ptywd
P: /class/tty/ptywe
N: ptywe
P: /class/tty/ptywf
N: ptywf
P: /class/tty/ptyx0
N: ptyx0
P: /class/tty/ptyx1
N: ptyx1
P: /class/tty/ptyx2
N: ptyx2
P: /class/tty/ptyx3
N: ptyx3
P: /class/tty/ptyx4
N: ptyx4
P: /class/tty/ptyx5
N: ptyx5
P: /class/tty/ptyx6
N: ptyx6
P: /class/tty/ptyx7
N: ptyx7
P: /class/tty/ptyx8
N: ptyx8
P: /class/tty/ptyx9
N: ptyx9
P: /class/tty/ptyxa
N: ptyxa
P: /class/tty/ptyxb
N: ptyxb
P: /class/tty/ptyxc
N: ptyxc
P: /class/tty/ptyxd
N: ptyxd
P: /class/tty/ptyxe
N: ptyxe
P: /class/tty/ptyxf
N: ptyxf
P: /class/tty/ptyy0
N: ptyy0
P: /class/tty/ptyy1
N: ptyy1
P: /class/tty/ptyy2
N: ptyy2
P: /class/tty/ptyy3
N: ptyy3
P: /class/tty/ptyy4
N: ptyy4
P: /class/tty/ptyy5
N: ptyy5
P: /class/tty/ptyy6
N: ptyy6
P: /class/tty/ptyy7
N: ptyy7
P: /class/tty/ptyy8
N: ptyy8
P: /class/tty/ptyy9
N: ptyy9
P: /class/tty/ptyya
N: ptyya
P: /class/tty/ptyyb
N: ptyyb
P: /class/tty/ptyyc
N: ptyyc
P: /class/tty/ptyyd
N: ptyyd
P: /class/tty/ptyye
N: ptyye
P: /class/tty/ptyyf
N: ptyyf
P: /class/tty/ptyz0
N: ptyz0
P: /class/tty/ptyz1
N: ptyz1
P: /class/tty/ptyz2
N: ptyz2
P: /class/tty/ptyz3
N: ptyz3
P: /class/tty/ptyz4
N: ptyz4
P: /class/tty/ptyz5
N: ptyz5
P: /class/tty/ptyz6
N: ptyz6
P: /class/tty/ptyz7
N: ptyz7
P: /class/tty/ptyz8
N: ptyz8
P: /class/tty/ptyz9
N: ptyz9
P: /class/tty/ptyza
N: ptyza
P: /class/tty/ptyzb
N: ptyzb
P: /class/tty/ptyzc
N: ptyzc
P: /class/tty/ptyzd
N: ptyzd
P: /class/tty/ptyze
N: ptyze
P: /class/tty/ptyzf
N: ptyzf
P: /class/tty/tty
N: tty
P: /class/tty/tty0
N: tty0
P: /class/tty/tty1
N: tty1
P: /class/tty/tty10
N: tty10
P: /class/tty/tty11
N: tty11
P: /class/tty/tty12
N: tty12
P: /class/tty/tty13
N: tty13
P: /class/tty/tty14
N: tty14
P: /class/tty/tty15
N: tty15
P: /class/tty/tty16
N: tty16
P: /class/tty/tty17
N: tty17
P: /class/tty/tty18
N: tty18
P: /class/tty/tty19
N: tty19
P: /class/tty/tty2
N: tty2
P: /class/tty/tty20
N: tty20
P: /class/tty/tty21
N: tty21
P: /class/tty/tty22
N: tty22
P: /class/tty/tty23
N: tty23
P: /class/tty/tty24
N: tty24
P: /class/tty/tty25
N: tty25
P: /class/tty/tty26
N: tty26
P: /class/tty/tty27
N: tty27
P: /class/tty/tty28
N: tty28
P: /class/tty/tty29
N: tty29
P: /class/tty/tty3
N: tty3
P: /class/tty/tty30
N: tty30
P: /class/tty/tty31
N: tty31
P: /class/tty/tty32
N: tty32
P: /class/tty/tty33
N: tty33
P: /class/tty/tty34
N: tty34
P: /class/tty/tty35
N: tty35
P: /class/tty/tty36
N: tty36
P: /class/tty/tty37
N: tty37
P: /class/tty/tty38
N: tty38
P: /class/tty/tty39
N: tty39
P: /class/tty/tty4
N: tty4
P: /class/tty/tty40
N: tty40
P: /class/tty/tty41
N: tty41
P: /class/tty/tty42
N: tty42
P: /class/tty/tty43
N: tty43
P: /class/tty/tty44
N: tty44
P: /class/tty/tty45
N: tty45
P: /class/tty/tty46
N: tty46
P: /class/tty/tty47
N: tty47
P: /class/tty/tty48
N: tty48
P: /class/tty/tty49
N: tty49
P: /class/tty/tty5
N: tty5
P: /class/tty/tty50
N: tty50
P: /class/tty/tty51
N: tty51
P: /class/tty/tty52
N: tty52
P: /class/tty/tty53
N: tty53
P: /class/tty/tty54
N: tty54
P: /class/tty/tty55
N: tty55
P: /class/tty/tty56
N: tty56
P: /class/tty/tty57
N: tty57
P: /class/tty/tty58
N: tty58
P: /class/tty/tty59
N: tty59
P: /class/tty/tty6
N: tty6
P: /class/tty/tty60
N: tty60
P: /class/tty/tty61
N: tty61
P: /class/tty/tty62
N: tty62
P: /class/tty/tty63
N: tty63
P: /class/tty/tty7
N: tty7
P: /class/tty/tty8
N: tty8
P: /class/tty/tty9
N: tty9
P: /class/tty/ttyS0
N: ttyS0
P: /class/tty/ttyS1
N: ttyS1
P: /class/tty/ttyS2
N: ttyS2
P: /class/tty/ttyS3
N: ttyS3
P: /class/tty/ttya0
N: ttya0
P: /class/tty/ttya1
N: ttya1
P: /class/tty/ttya2
N: ttya2
P: /class/tty/ttya3
N: ttya3
P: /class/tty/ttya4
N: ttya4
P: /class/tty/ttya5
N: ttya5
P: /class/tty/ttya6
N: ttya6
P: /class/tty/ttya7
N: ttya7
P: /class/tty/ttya8
N: ttya8
P: /class/tty/ttya9
N: ttya9
P: /class/tty/ttyaa
N: ttyaa
P: /class/tty/ttyab
N: ttyab
P: /class/tty/ttyac
N: ttyac
P: /class/tty/ttyad
N: ttyad
P: /class/tty/ttyae
N: ttyae
P: /class/tty/ttyaf
N: ttyaf
P: /class/tty/ttyb0
N: ttyb0
P: /class/tty/ttyb1
N: ttyb1
P: /class/tty/ttyb2
N: ttyb2
P: /class/tty/ttyb3
N: ttyb3
P: /class/tty/ttyb4
N: ttyb4
P: /class/tty/ttyb5
N: ttyb5
P: /class/tty/ttyb6
N: ttyb6
P: /class/tty/ttyb7
N: ttyb7
P: /class/tty/ttyb8
N: ttyb8
P: /class/tty/ttyb9
N: ttyb9
P: /class/tty/ttyba
N: ttyba
P: /class/tty/ttybb
N: ttybb
P: /class/tty/ttybc
N: ttybc
P: /class/tty/ttybd
N: ttybd
P: /class/tty/ttybe
N: ttybe
P: /class/tty/ttybf
N: ttybf
P: /class/tty/ttyc0
N: ttyc0
P: /class/tty/ttyc1
N: ttyc1
P: /class/tty/ttyc2
N: ttyc2
P: /class/tty/ttyc3
N: ttyc3
P: /class/tty/ttyc4
N: ttyc4
P: /class/tty/ttyc5
N: ttyc5
P: /class/tty/ttyc6
N: ttyc6
P: /class/tty/ttyc7
N: ttyc7
P: /class/tty/ttyc8
N: ttyc8
P: /class/tty/ttyc9
N: ttyc9
P: /class/tty/ttyca
N: ttyca
P: /class/tty/ttycb
N: ttycb
P: /class/tty/ttycc
N: ttycc
P: /class/tty/ttycd
N: ttycd
P: /class/tty/ttyce
N: ttyce
P: /class/tty/ttycf
N: ttycf
P: /class/tty/ttyd0
N: ttyd0
P: /class/tty/ttyd1
N: ttyd1
P: /class/tty/ttyd2
N: ttyd2
P: /class/tty/ttyd3
N: ttyd3
P: /class/tty/ttyd4
N: ttyd4
P: /class/tty/ttyd5
N: ttyd5
P: /class/tty/ttyd6
N: ttyd6
P: /class/tty/ttyd7
N: ttyd7
P: /class/tty/ttyd8
N: ttyd8
P: /class/tty/ttyd9
N: ttyd9
P: /class/tty/ttyda
N: ttyda
P: /class/tty/ttydb
N: ttydb
P: /class/tty/ttydc
N: ttydc
P: /class/tty/ttydd
N: ttydd
P: /class/tty/ttyde
N: ttyde
P: /class/tty/ttydf
N: ttydf
P: /class/tty/ttye0
N: ttye0
P: /class/tty/ttye1
N: ttye1
P: /class/tty/ttye2
N: ttye2
P: /class/tty/ttye3
N: ttye3
P: /class/tty/ttye4
N: ttye4
P: /class/tty/ttye5
N: ttye5
P: /class/tty/ttye6
N: ttye6
P: /class/tty/ttye7
N: ttye7
P: /class/tty/ttye8
N: ttye8
P: /class/tty/ttye9
N: ttye9
P: /class/tty/ttyea
N: ttyea
P: /class/tty/ttyeb
N: ttyeb
P: /class/tty/ttyec
N: ttyec
P: /class/tty/ttyed
N: ttyed
P: /class/tty/ttyee
N: ttyee
P: /class/tty/ttyef
N: ttyef
P: /class/tty/ttyp0
N: ttyp0
P: /class/tty/ttyp1
N: ttyp1
P: /class/tty/ttyp2
N: ttyp2
P: /class/tty/ttyp3
N: ttyp3
P: /class/tty/ttyp4
N: ttyp4
P: /class/tty/ttyp5
N: ttyp5
P: /class/tty/ttyp6
N: ttyp6
P: /class/tty/ttyp7
N: ttyp7
P: /class/tty/ttyp8
N: ttyp8
P: /class/tty/ttyp9
N: ttyp9
P: /class/tty/ttypa
N: ttypa
P: /class/tty/ttypb
N: ttypb
P: /class/tty/ttypc
N: ttypc
P: /class/tty/ttypd
N: ttypd
P: /class/tty/ttype
N: ttype
P: /class/tty/ttypf
N: ttypf
P: /class/tty/ttyq0
N: ttyq0
P: /class/tty/ttyq1
N: ttyq1
P: /class/tty/ttyq2
N: ttyq2
P: /class/tty/ttyq3
N: ttyq3
P: /class/tty/ttyq4
N: ttyq4
P: /class/tty/ttyq5
N: ttyq5
P: /class/tty/ttyq6
N: ttyq6
P: /class/tty/ttyq7
N: ttyq7
P: /class/tty/ttyq8
N: ttyq8
P: /class/tty/ttyq9
N: ttyq9
P: /class/tty/ttyqa
N: ttyqa
P: /class/tty/ttyqb
N: ttyqb
P: /class/tty/ttyqc
N: ttyqc
P: /class/tty/ttyqd
N: ttyqd
P: /class/tty/ttyqe
N: ttyqe
P: /class/tty/ttyqf
N: ttyqf
P: /class/tty/ttyr0
N: ttyr0
P: /class/tty/ttyr1
N: ttyr1
P: /class/tty/ttyr2
N: ttyr2
P: /class/tty/ttyr3
N: ttyr3
P: /class/tty/ttyr4
N: ttyr4
P: /class/tty/ttyr5
N: ttyr5
P: /class/tty/ttyr6
N: ttyr6
P: /class/tty/ttyr7
N: ttyr7
P: /class/tty/ttyr8
N: ttyr8
P: /class/tty/ttyr9
N: ttyr9
P: /class/tty/ttyra
N: ttyra
P: /class/tty/ttyrb
N: ttyrb
P: /class/tty/ttyrc
N: ttyrc
P: /class/tty/ttyrd
N: ttyrd
P: /class/tty/ttyre
N: ttyre
P: /class/tty/ttyrf
N: ttyrf
P: /class/tty/ttys0
N: ttys0
P: /class/tty/ttys1
N: ttys1
P: /class/tty/ttys2
N: ttys2
P: /class/tty/ttys3
N: ttys3
P: /class/tty/ttys4
N: ttys4
P: /class/tty/ttys5
N: ttys5
P: /class/tty/ttys6
N: ttys6
P: /class/tty/ttys7
N: ttys7
P: /class/tty/ttys8
N: ttys8
P: /class/tty/ttys9
N: ttys9
P: /class/tty/ttysa
N: ttysa
P: /class/tty/ttysb
N: ttysb
P: /class/tty/ttysc
N: ttysc
P: /class/tty/ttysd
N: ttysd
P: /class/tty/ttyse
N: ttyse
P: /class/tty/ttysf
N: ttysf
P: /class/tty/ttyt0
N: ttyt0
P: /class/tty/ttyt1
N: ttyt1
P: /class/tty/ttyt2
N: ttyt2
P: /class/tty/ttyt3
N: ttyt3
P: /class/tty/ttyt4
N: ttyt4
P: /class/tty/ttyt5
N: ttyt5
P: /class/tty/ttyt6
N: ttyt6
P: /class/tty/ttyt7
N: ttyt7
P: /class/tty/ttyt8
N: ttyt8
P: /class/tty/ttyt9
N: ttyt9
P: /class/tty/ttyta
N: ttyta
P: /class/tty/ttytb
N: ttytb
P: /class/tty/ttytc
N: ttytc
P: /class/tty/ttytd
N: ttytd
P: /class/tty/ttyte
N: ttyte
P: /class/tty/ttytf
N: ttytf
P: /class/tty/ttyu0
N: ttyu0
P: /class/tty/ttyu1
N: ttyu1
P: /class/tty/ttyu2
N: ttyu2
P: /class/tty/ttyu3
N: ttyu3
P: /class/tty/ttyu4
N: ttyu4
P: /class/tty/ttyu5
N: ttyu5
P: /class/tty/ttyu6
N: ttyu6
P: /class/tty/ttyu7
N: ttyu7
P: /class/tty/ttyu8
N: ttyu8
P: /class/tty/ttyu9
N: ttyu9
P: /class/tty/ttyua
N: ttyua
P: /class/tty/ttyub
N: ttyub
P: /class/tty/ttyuc
N: ttyuc
P: /class/tty/ttyud
N: ttyud
P: /class/tty/ttyue
N: ttyue
P: /class/tty/ttyuf
N: ttyuf
P: /class/tty/ttyv0
N: ttyv0
P: /class/tty/ttyv1
N: ttyv1
P: /class/tty/ttyv2
N: ttyv2
P: /class/tty/ttyv3
N: ttyv3
P: /class/tty/ttyv4
N: ttyv4
P: /class/tty/ttyv5
N: ttyv5
P: /class/tty/ttyv6
N: ttyv6
P: /class/tty/ttyv7
N: ttyv7
P: /class/tty/ttyv8
N: ttyv8
P: /class/tty/ttyv9
N: ttyv9
P: /class/tty/ttyva
N: ttyva
P: /class/tty/ttyvb
N: ttyvb
P: /class/tty/ttyvc
N: ttyvc
P: /class/tty/ttyvd
N: ttyvd
P: /class/tty/ttyve
N: ttyve
P: /class/tty/ttyvf
N: ttyvf
P: /class/tty/ttyw0
N: ttyw0
P: /class/tty/ttyw1
N: ttyw1
P: /class/tty/ttyw2
N: ttyw2
P: /class/tty/ttyw3
N: ttyw3
P: /class/tty/ttyw4
N: ttyw4
P: /class/tty/ttyw5
N: ttyw5
P: /class/tty/ttyw6
N: ttyw6
P: /class/tty/ttyw7
N: ttyw7
P: /class/tty/ttyw8
N: ttyw8
P: /class/tty/ttyw9
N: ttyw9
P: /class/tty/ttywa
N: ttywa
P: /class/tty/ttywb
N: ttywb
P: /class/tty/ttywc
N: ttywc
P: /class/tty/ttywd
N: ttywd
P: /class/tty/ttywe
N: ttywe
P: /class/tty/ttywf
N: ttywf
P: /class/tty/ttyx0
N: ttyx0
P: /class/tty/ttyx1
N: ttyx1
P: /class/tty/ttyx2
N: ttyx2
P: /class/tty/ttyx3
N: ttyx3
P: /class/tty/ttyx4
N: ttyx4
P: /class/tty/ttyx5
N: ttyx5
P: /class/tty/ttyx6
N: ttyx6
P: /class/tty/ttyx7
N: ttyx7
P: /class/tty/ttyx8
N: ttyx8
P: /class/tty/ttyx9
N: ttyx9
P: /class/tty/ttyxa
N: ttyxa
P: /class/tty/ttyxb
N: ttyxb
P: /class/tty/ttyxc
N: ttyxc
P: /class/tty/ttyxd
N: ttyxd
P: /class/tty/ttyxe
N: ttyxe
P: /class/tty/ttyxf
N: ttyxf
P: /class/tty/ttyy0
N: ttyy0
P: /class/tty/ttyy1
N: ttyy1
P: /class/tty/ttyy2
N: ttyy2
P: /class/tty/ttyy3
N: ttyy3
P: /class/tty/ttyy4
N: ttyy4
P: /class/tty/ttyy5
N: ttyy5
P: /class/tty/ttyy6
N: ttyy6
P: /class/tty/ttyy7
N: ttyy7
P: /class/tty/ttyy8
N: ttyy8
P: /class/tty/ttyy9
N: ttyy9
P: /class/tty/ttyya
N: ttyya
P: /class/tty/ttyyb
N: ttyyb
P: /class/tty/ttyyc
N: ttyyc
P: /class/tty/ttyyd
N: ttyyd
P: /class/tty/ttyye
N: ttyye
P: /class/tty/ttyyf
N: ttyyf
P: /class/tty/ttyz0
N: ttyz0
P: /class/tty/ttyz1
N: ttyz1
P: /class/tty/ttyz2
N: ttyz2
P: /class/tty/ttyz3
N: ttyz3
P: /class/tty/ttyz4
N: ttyz4
P: /class/tty/ttyz5
N: ttyz5
P: /class/tty/ttyz6
N: ttyz6
P: /class/tty/ttyz7
N: ttyz7
P: /class/tty/ttyz8
N: ttyz8
P: /class/tty/ttyz9
N: ttyz9
P: /class/tty/ttyza
N: ttyza
P: /class/tty/ttyzb
N: ttyzb
P: /class/tty/ttyzc
N: ttyzc
P: /class/tty/ttyzd
N: ttyzd
P: /class/tty/ttyze
N: ttyze
P: /class/tty/ttyzf
N: ttyzf
P: /class/usb_device/usbdev1.1
N: bus/usb/001/001
P: /class/usb_device/usbdev1.2
N: bus/usb/001/002
P: /class/usb_device/usbdev2.1
N: bus/usb/002/001
P: /class/usb_device/usbdev2.3
N: bus/usb/002/003
P: /class/usb_device/usbdev3.1
N: bus/usb/003/001
P: /class/usb_device/usbdev4.1
N: bus/usb/004/001
P: /class/usb_endpoint/usbdev1.1_ep00
N: usbdev1.1_ep00
P: /class/usb_endpoint/usbdev1.1_ep81
N: usbdev1.1_ep81
P: /class/usb_endpoint/usbdev1.2_ep00
N: usbdev1.2_ep00
P: /class/usb_endpoint/usbdev1.2_ep83
N: usbdev1.2_ep83
P: /class/usb_endpoint/usbdev2.1_ep00
N: usbdev2.1_ep00
P: /class/usb_endpoint/usbdev2.1_ep81
N: usbdev2.1_ep81
P: /class/usb_endpoint/usbdev2.3_ep00
N: usbdev2.3_ep00
P: /class/usb_endpoint/usbdev2.3_ep81
N: usbdev2.3_ep81
P: /class/usb_endpoint/usbdev3.1_ep00
N: usbdev3.1_ep00
P: /class/usb_endpoint/usbdev3.1_ep81
N: usbdev3.1_ep81
P: /class/usb_endpoint/usbdev4.1_ep00
N: usbdev4.1_ep00
P: /class/usb_endpoint/usbdev4.1_ep81
N: usbdev4.1_ep81
P: /class/vc/vcs
N: vcs
P: /class/vc/vcs1
N: vcs1
P: /class/vc/vcs2
N: vcs2
P: /class/vc/vcs3
N: vcs3
P: /class/vc/vcs4
N: vcs4
P: /class/vc/vcsa
N: vcsa
P: /class/vc/vcsa1
N: vcsa1
P: /class/vc/vcsa2
N: vcsa2
P: /class/vc/vcsa3
N: vcsa3
P: /class/vc/vcsa4
N: vcsa4
P: /class/video4linux/video0
N: video0
P: /devices/pci0000:00/0000:00:10.0/usb2
N: usb2
P: /devices/pci0000:00/0000:00:10.0/usb2/2-1
N: 2-1
P: /devices/pci0000:00/0000:00:10.2/usb3
N: usb3
P: /devices/pci0000:00/0000:00:10.3/usb4
N: usb4
P: /devices/pci0000:00/0000:00:10.4/usb1
N: usb1
P: /devices/pci0000:00/0000:00:10.4/usb1/1-8
N: 1-8
----- udevinfo end -----
/block/hda
name: /dev/hda
links: /dev/disk/by-id/ata-ST9120817AS_5RE0G6EJ, /dev/disk/by-path/ide-0:0
/block/hda/hda1
name: /dev/hda1
links: /dev/disk/by-id/ata-ST9120817AS_5RE0G6EJ-part1, /dev/disk/by-path/ide-0:0-part1, /dev/disk/by-uuid/4EF3-1BE3
/block/hda/hda2
name: /dev/hda2
links: /dev/disk/by-id/ata-ST9120817AS_5RE0G6EJ-part2, /dev/disk/by-path/ide-0:0-part2
/block/hda/hda3
name: /dev/hda3
links: /dev/disk/by-id/ata-ST9120817AS_5RE0G6EJ-part3, /dev/disk/by-path/ide-0:0-part3, /dev/disk/by-uuid/155f5a5e-88d9-4155-8d67-00f0d46ee195
/block/hda/hda4
name: /dev/hda4
links: /dev/disk/by-id/ata-ST9120817AS_5RE0G6EJ-part4, /dev/disk/by-path/ide-0:0-part4, /dev/disk/by-uuid/3caa1768-37be-4b8a-b45f-451fac500741
/block/ram0
name: /dev/ram0
/block/ram1
name: /dev/ram1
/block/ram10
name: /dev/ram10
/block/ram11
name: /dev/ram11
/block/ram12
name: /dev/ram12
/block/ram13
name: /dev/ram13
/block/ram14
name: /dev/ram14
/block/ram15
name: /dev/ram15
/block/ram2
name: /dev/ram2
/block/ram3
name: /dev/ram3
/block/ram4
name: /dev/ram4
/block/ram5
name: /dev/ram5
/block/ram6
name: /dev/ram6
/block/ram7
name: /dev/ram7
/block/ram8
name: /dev/ram8
/block/ram9
name: /dev/ram9
/class/graphics/fb0
name: /dev/fb0
/class/input/input0/event0
name: /dev/input/event0
links: /dev/input/by-path/platform-i8042-serio-4-event-mouse
/class/input/input0/mouse0
name: /dev/input/mouse0
links: /dev/input/by-path/platform-i8042-serio-4-mouse
/class/input/input1/event1
name: /dev/input/event1
links: /dev/input/by-path/platform-i8042-serio-0-event-kbd
/class/input/input10/event9
name: /dev/input/event9
links: /dev/input/by-id/usb-15d9_USB_OPTICAL_MOUSE-event-mouse, /dev/input/by-path/pci-0000:00:10.0-usb-0:1:1.0-event-mouse
/class/input/input10/mouse1
name: /dev/input/mouse1
links: /dev/input/by-id/usb-15d9_USB_OPTICAL_MOUSE-mouse, /dev/input/by-path/pci-0000:00:10.0-usb-0:1:1.0-mouse
/class/input/input2/event2
name: /dev/input/event2
/class/input/input3/event3
name: /dev/input/event3
/class/input/input4/event4
name: /dev/input/event4
/class/input/input5/event5
name: /dev/input/event5
/class/input/input6/event6
name: /dev/input/event6
/class/input/input7/event7
name: /dev/input/event7
links: /dev/input/by-path/platform-pcspkr-event-spkr
/class/input/input8/event8
name: /dev/input/event8
links: /dev/input/by-path/pci-0000:00:10.4-usb-0:8:1.0-event-
/class/input/mice
name: /dev/input/mice
/class/mem/full
name: /dev/full
/class/mem/kmem
name: /dev/kmem
/class/mem/kmsg
name: /dev/kmsg
/class/mem/mem
name: /dev/mem
/class/mem/null
name: /dev/null
/class/mem/port
name: /dev/port
/class/mem/random
name: /dev/random
/class/mem/urandom
name: /dev/urandom
/class/mem/zero
name: /dev/zero
/class/misc/agpgart
name: /dev/agpgart
/class/misc/cpu_dma_latency
name: /dev/cpu_dma_latency
/class/misc/fuse
name: /dev/fuse
/class/misc/network_latency
name: /dev/network_latency
/class/misc/network_throughput
name: /dev/network_throughput
/class/misc/psaux
name: /dev/psaux
/class/sound/audio
name: /dev/audio
/class/sound/controlC0
name: /dev/snd/controlC0
/class/sound/dsp
name: /dev/dsp
/class/sound/mixer
name: /dev/mixer
/class/sound/pcmC0D0c
name: /dev/snd/pcmC0D0c
/class/sound/pcmC0D0p
name: /dev/snd/pcmC0D0p
/class/sound/timer
name: /dev/snd/timer
/class/tty/console
name: /dev/console
/class/tty/ptmx
name: /dev/ptmx
/class/tty/ptya0
name: /dev/ptya0
/class/tty/ptya1
name: /dev/ptya1
/class/tty/ptya2
name: /dev/ptya2
/class/tty/ptya3
name: /dev/ptya3
/class/tty/ptya4
name: /dev/ptya4
/class/tty/ptya5
name: /dev/ptya5
/class/tty/ptya6
name: /dev/ptya6
/class/tty/ptya7
name: /dev/ptya7
/class/tty/ptya8
name: /dev/ptya8
/class/tty/ptya9
name: /dev/ptya9
/class/tty/ptyaa
name: /dev/ptyaa
/class/tty/ptyab
name: /dev/ptyab
/class/tty/ptyac
name: /dev/ptyac
/class/tty/ptyad
name: /dev/ptyad
/class/tty/ptyae
name: /dev/ptyae
/class/tty/ptyaf
name: /dev/ptyaf
/class/tty/ptyb0
name: /dev/ptyb0
/class/tty/ptyb1
name: /dev/ptyb1
/class/tty/ptyb2
name: /dev/ptyb2
/class/tty/ptyb3
name: /dev/ptyb3
/class/tty/ptyb4
name: /dev/ptyb4
/class/tty/ptyb5
name: /dev/ptyb5
/class/tty/ptyb6
name: /dev/ptyb6
/class/tty/ptyb7
name: /dev/ptyb7
/class/tty/ptyb8
name: /dev/ptyb8
/class/tty/ptyb9
name: /dev/ptyb9
/class/tty/ptyba
name: /dev/ptyba
/class/tty/ptybb
name: /dev/ptybb
/class/tty/ptybc
name: /dev/ptybc
/class/tty/ptybd
name: /dev/ptybd
/class/tty/ptybe
name: /dev/ptybe
/class/tty/ptybf
name: /dev/ptybf
/class/tty/ptyc0
name: /dev/ptyc0
/class/tty/ptyc1
name: /dev/ptyc1
/class/tty/ptyc2
name: /dev/ptyc2
/class/tty/ptyc3
name: /dev/ptyc3
/class/tty/ptyc4
name: /dev/ptyc4
/class/tty/ptyc5
name: /dev/ptyc5
/class/tty/ptyc6
name: /dev/ptyc6
/class/tty/ptyc7
name: /dev/ptyc7
/class/tty/ptyc8
name: /dev/ptyc8
/class/tty/ptyc9
name: /dev/ptyc9
/class/tty/ptyca
name: /dev/ptyca
/class/tty/ptycb
name: /dev/ptycb
/class/tty/ptycc
name: /dev/ptycc
/class/tty/ptycd
name: /dev/ptycd
/class/tty/ptyce
name: /dev/ptyce
/class/tty/ptycf
name: /dev/ptycf
/class/tty/ptyd0
name: /dev/ptyd0
/class/tty/ptyd1
name: /dev/ptyd1
/class/tty/ptyd2
name: /dev/ptyd2
/class/tty/ptyd3
name: /dev/ptyd3
/class/tty/ptyd4
name: /dev/ptyd4
/class/tty/ptyd5
name: /dev/ptyd5
/class/tty/ptyd6
name: /dev/ptyd6
/class/tty/ptyd7
name: /dev/ptyd7
/class/tty/ptyd8
name: /dev/ptyd8
/class/tty/ptyd9
name: /dev/ptyd9
/class/tty/ptyda
name: /dev/ptyda
/class/tty/ptydb
name: /dev/ptydb
/class/tty/ptydc
name: /dev/ptydc
/class/tty/ptydd
name: /dev/ptydd
/class/tty/ptyde
name: /dev/ptyde
/class/tty/ptydf
name: /dev/ptydf
/class/tty/ptye0
name: /dev/ptye0
/class/tty/ptye1
name: /dev/ptye1
/class/tty/ptye2
name: /dev/ptye2
/class/tty/ptye3
name: /dev/ptye3
/class/tty/ptye4
name: /dev/ptye4
/class/tty/ptye5
name: /dev/ptye5
/class/tty/ptye6
name: /dev/ptye6
/class/tty/ptye7
name: /dev/ptye7
/class/tty/ptye8
name: /dev/ptye8
/class/tty/ptye9
name: /dev/ptye9
/class/tty/ptyea
name: /dev/ptyea
/class/tty/ptyeb
name: /dev/ptyeb
/class/tty/ptyec
name: /dev/ptyec
/class/tty/ptyed
name: /dev/ptyed
/class/tty/ptyee
name: /dev/ptyee
/class/tty/ptyef
name: /dev/ptyef
/class/tty/ptyp0
name: /dev/ptyp0
/class/tty/ptyp1
name: /dev/ptyp1
/class/tty/ptyp2
name: /dev/ptyp2
/class/tty/ptyp3
name: /dev/ptyp3
/class/tty/ptyp4
name: /dev/ptyp4
/class/tty/ptyp5
name: /dev/ptyp5
/class/tty/ptyp6
name: /dev/ptyp6
/class/tty/ptyp7
name: /dev/ptyp7
/class/tty/ptyp8
name: /dev/ptyp8
/class/tty/ptyp9
name: /dev/ptyp9
/class/tty/ptypa
name: /dev/ptypa
/class/tty/ptypb
name: /dev/ptypb
/class/tty/ptypc
name: /dev/ptypc
/class/tty/ptypd
name: /dev/ptypd
/class/tty/ptype
name: /dev/ptype
/class/tty/ptypf
name: /dev/ptypf
/class/tty/ptyq0
name: /dev/ptyq0
/class/tty/ptyq1
name: /dev/ptyq1
/class/tty/ptyq2
name: /dev/ptyq2
/class/tty/ptyq3
name: /dev/ptyq3
/class/tty/ptyq4
name: /dev/ptyq4
/class/tty/ptyq5
name: /dev/ptyq5
/class/tty/ptyq6
name: /dev/ptyq6
/class/tty/ptyq7
name: /dev/ptyq7
/class/tty/ptyq8
name: /dev/ptyq8
/class/tty/ptyq9
name: /dev/ptyq9
/class/tty/ptyqa
name: /dev/ptyqa
/class/tty/ptyqb
name: /dev/ptyqb
/class/tty/ptyqc
name: /dev/ptyqc
/class/tty/ptyqd
name: /dev/ptyqd
/class/tty/ptyqe
name: /dev/ptyqe
/class/tty/ptyqf
name: /dev/ptyqf
/class/tty/ptyr0
name: /dev/ptyr0
/class/tty/ptyr1
name: /dev/ptyr1
/class/tty/ptyr2
name: /dev/ptyr2
/class/tty/ptyr3
name: /dev/ptyr3
/class/tty/ptyr4
name: /dev/ptyr4
/class/tty/ptyr5
name: /dev/ptyr5
/class/tty/ptyr6
name: /dev/ptyr6
/class/tty/ptyr7
name: /dev/ptyr7
/class/tty/ptyr8
name: /dev/ptyr8
/class/tty/ptyr9
name: /dev/ptyr9
/class/tty/ptyra
name: /dev/ptyra
/class/tty/ptyrb
name: /dev/ptyrb
/class/tty/ptyrc
name: /dev/ptyrc
/class/tty/ptyrd
name: /dev/ptyrd
/class/tty/ptyre
name: /dev/ptyre
/class/tty/ptyrf
name: /dev/ptyrf
/class/tty/ptys0
name: /dev/ptys0
/class/tty/ptys1
name: /dev/ptys1
/class/tty/ptys2
name: /dev/ptys2
/class/tty/ptys3
name: /dev/ptys3
/class/tty/ptys4
name: /dev/ptys4
/class/tty/ptys5
name: /dev/ptys5
/class/tty/ptys6
name: /dev/ptys6
/class/tty/ptys7
name: /dev/ptys7
/class/tty/ptys8
name: /dev/ptys8
/class/tty/ptys9
name: /dev/ptys9
/class/tty/ptysa
name: /dev/ptysa
/class/tty/ptysb
name: /dev/ptysb
/class/tty/ptysc
name: /dev/ptysc
/class/tty/ptysd
name: /dev/ptysd
/class/tty/ptyse
name: /dev/ptyse
/class/tty/ptysf
name: /dev/ptysf
/class/tty/ptyt0
name: /dev/ptyt0
/class/tty/ptyt1
name: /dev/ptyt1
/class/tty/ptyt2
name: /dev/ptyt2
/class/tty/ptyt3
name: /dev/ptyt3
/class/tty/ptyt4
name: /dev/ptyt4
/class/tty/ptyt5
name: /dev/ptyt5
/class/tty/ptyt6
name: /dev/ptyt6
/class/tty/ptyt7
name: /dev/ptyt7
/class/tty/ptyt8
name: /dev/ptyt8
/class/tty/ptyt9
name: /dev/ptyt9
/class/tty/ptyta
name: /dev/ptyta
/class/tty/ptytb
name: /dev/ptytb
/class/tty/ptytc
name: /dev/ptytc
/class/tty/ptytd
name: /dev/ptytd
/class/tty/ptyte
name: /dev/ptyte
/class/tty/ptytf
name: /dev/ptytf
/class/tty/ptyu0
name: /dev/ptyu0
/class/tty/ptyu1
name: /dev/ptyu1
/class/tty/ptyu2
name: /dev/ptyu2
/class/tty/ptyu3
name: /dev/ptyu3
/class/tty/ptyu4
name: /dev/ptyu4
/class/tty/ptyu5
name: /dev/ptyu5
/class/tty/ptyu6
name: /dev/ptyu6
/class/tty/ptyu7
name: /dev/ptyu7
/class/tty/ptyu8
name: /dev/ptyu8
/class/tty/ptyu9
name: /dev/ptyu9
/class/tty/ptyua
name: /dev/ptyua
/class/tty/ptyub
name: /dev/ptyub
/class/tty/ptyuc
name: /dev/ptyuc
/class/tty/ptyud
name: /dev/ptyud
/class/tty/ptyue
name: /dev/ptyue
/class/tty/ptyuf
name: /dev/ptyuf
/class/tty/ptyv0
name: /dev/ptyv0
/class/tty/ptyv1
name: /dev/ptyv1
/class/tty/ptyv2
name: /dev/ptyv2
/class/tty/ptyv3
name: /dev/ptyv3
/class/tty/ptyv4
name: /dev/ptyv4
/class/tty/ptyv5
name: /dev/ptyv5
/class/tty/ptyv6
name: /dev/ptyv6
/class/tty/ptyv7
name: /dev/ptyv7
/class/tty/ptyv8
name: /dev/ptyv8
/class/tty/ptyv9
name: /dev/ptyv9
/class/tty/ptyva
name: /dev/ptyva
/class/tty/ptyvb
name: /dev/ptyvb
/class/tty/ptyvc
name: /dev/ptyvc
/class/tty/ptyvd
name: /dev/ptyvd
/class/tty/ptyve
name: /dev/ptyve
/class/tty/ptyvf
name: /dev/ptyvf
/class/tty/ptyw0
name: /dev/ptyw0
/class/tty/ptyw1
name: /dev/ptyw1
/class/tty/ptyw2
name: /dev/ptyw2
/class/tty/ptyw3
name: /dev/ptyw3
/class/tty/ptyw4
name: /dev/ptyw4
/class/tty/ptyw5
name: /dev/ptyw5
/class/tty/ptyw6
name: /dev/ptyw6
/class/tty/ptyw7
name: /dev/ptyw7
/class/tty/ptyw8
name: /dev/ptyw8
/class/tty/ptyw9
name: /dev/ptyw9
/class/tty/ptywa
name: /dev/ptywa
/class/tty/ptywb
name: /dev/ptywb
/class/tty/ptywc
name: /dev/ptywc
/class/tty/ptywd
name: /dev/ptywd
/class/tty/ptywe
name: /dev/ptywe
/class/tty/ptywf
name: /dev/ptywf
/class/tty/ptyx0
name: /dev/ptyx0
/class/tty/ptyx1
name: /dev/ptyx1
/class/tty/ptyx2
name: /dev/ptyx2
/class/tty/ptyx3
name: /dev/ptyx3
/class/tty/ptyx4
name: /dev/ptyx4
/class/tty/ptyx5
name: /dev/ptyx5
/class/tty/ptyx6
name: /dev/ptyx6
/class/tty/ptyx7
name: /dev/ptyx7
/class/tty/ptyx8
name: /dev/ptyx8
/class/tty/ptyx9
name: /dev/ptyx9
/class/tty/ptyxa
name: /dev/ptyxa
/class/tty/ptyxb
name: /dev/ptyxb
/class/tty/ptyxc
name: /dev/ptyxc
/class/tty/ptyxd
name: /dev/ptyxd
/class/tty/ptyxe
name: /dev/ptyxe
/class/tty/ptyxf
name: /dev/ptyxf
/class/tty/ptyy0
name: /dev/ptyy0
/class/tty/ptyy1
name: /dev/ptyy1
/class/tty/ptyy2
name: /dev/ptyy2
/class/tty/ptyy3
name: /dev/ptyy3
/class/tty/ptyy4
name: /dev/ptyy4
/class/tty/ptyy5
name: /dev/ptyy5
/class/tty/ptyy6
name: /dev/ptyy6
/class/tty/ptyy7
name: /dev/ptyy7
/class/tty/ptyy8
name: /dev/ptyy8
/class/tty/ptyy9
name: /dev/ptyy9
/class/tty/ptyya
name: /dev/ptyya
/class/tty/ptyyb
name: /dev/ptyyb
/class/tty/ptyyc
name: /dev/ptyyc
/class/tty/ptyyd
name: /dev/ptyyd
/class/tty/ptyye
name: /dev/ptyye
/class/tty/ptyyf
name: /dev/ptyyf
/class/tty/ptyz0
name: /dev/ptyz0
/class/tty/ptyz1
name: /dev/ptyz1
/class/tty/ptyz2
name: /dev/ptyz2
/class/tty/ptyz3
name: /dev/ptyz3
/class/tty/ptyz4
name: /dev/ptyz4
/class/tty/ptyz5
name: /dev/ptyz5
/class/tty/ptyz6
name: /dev/ptyz6
/class/tty/ptyz7
name: /dev/ptyz7
/class/tty/ptyz8
name: /dev/ptyz8
/class/tty/ptyz9
name: /dev/ptyz9
/class/tty/ptyza
name: /dev/ptyza
/class/tty/ptyzb
name: /dev/ptyzb
/class/tty/ptyzc
name: /dev/ptyzc
/class/tty/ptyzd
name: /dev/ptyzd
/class/tty/ptyze
name: /dev/ptyze
/class/tty/ptyzf
name: /dev/ptyzf
/class/tty/tty
name: /dev/tty
/class/tty/tty0
name: /dev/tty0
/class/tty/tty1
name: /dev/tty1
/class/tty/tty10
name: /dev/tty10
/class/tty/tty11
name: /dev/tty11
/class/tty/tty12
name: /dev/tty12
/class/tty/tty13
name: /dev/tty13
/class/tty/tty14
name: /dev/tty14
/class/tty/tty15
name: /dev/tty15
/class/tty/tty16
name: /dev/tty16
/class/tty/tty17
name: /dev/tty17
/class/tty/tty18
name: /dev/tty18
/class/tty/tty19
name: /dev/tty19
/class/tty/tty2
name: /dev/tty2
/class/tty/tty20
name: /dev/tty20
/class/tty/tty21
name: /dev/tty21
/class/tty/tty22
name: /dev/tty22
/class/tty/tty23
name: /dev/tty23
/class/tty/tty24
name: /dev/tty24
/class/tty/tty25
name: /dev/tty25
/class/tty/tty26
name: /dev/tty26
/class/tty/tty27
name: /dev/tty27
/class/tty/tty28
name: /dev/tty28
/class/tty/tty29
name: /dev/tty29
/class/tty/tty3
name: /dev/tty3
/class/tty/tty30
name: /dev/tty30
/class/tty/tty31
name: /dev/tty31
/class/tty/tty32
name: /dev/tty32
/class/tty/tty33
name: /dev/tty33
/class/tty/tty34
name: /dev/tty34
/class/tty/tty35
name: /dev/tty35
/class/tty/tty36
name: /dev/tty36
/class/tty/tty37
name: /dev/tty37
/class/tty/tty38
name: /dev/tty38
/class/tty/tty39
name: /dev/tty39
/class/tty/tty4
name: /dev/tty4
/class/tty/tty40
name: /dev/tty40
/class/tty/tty41
name: /dev/tty41
/class/tty/tty42
name: /dev/tty42
/class/tty/tty43
name: /dev/tty43
/class/tty/tty44
name: /dev/tty44
/class/tty/tty45
name: /dev/tty45
/class/tty/tty46
name: /dev/tty46
/class/tty/tty47
name: /dev/tty47
/class/tty/tty48
name: /dev/tty48
/class/tty/tty49
name: /dev/tty49
/class/tty/tty5
name: /dev/tty5
/class/tty/tty50
name: /dev/tty50
/class/tty/tty51
name: /dev/tty51
/class/tty/tty52
name: /dev/tty52
/class/tty/tty53
name: /dev/tty53
/class/tty/tty54
name: /dev/tty54
/class/tty/tty55
name: /dev/tty55
/class/tty/tty56
name: /dev/tty56
/class/tty/tty57
name: /dev/tty57
/class/tty/tty58
name: /dev/tty58
/class/tty/tty59
name: /dev/tty59
/class/tty/tty6
name: /dev/tty6
/class/tty/tty60
name: /dev/tty60
/class/tty/tty61
name: /dev/tty61
/class/tty/tty62
name: /dev/tty62
/class/tty/tty63
name: /dev/tty63
/class/tty/tty7
name: /dev/tty7
/class/tty/tty8
name: /dev/tty8
/class/tty/tty9
name: /dev/tty9
/class/tty/ttyS0
name: /dev/ttyS0
/class/tty/ttyS1
name: /dev/ttyS1
/class/tty/ttyS2
name: /dev/ttyS2
/class/tty/ttyS3
name: /dev/ttyS3
/class/tty/ttya0
name: /dev/ttya0
/class/tty/ttya1
name: /dev/ttya1
/class/tty/ttya2
name: /dev/ttya2
/class/tty/ttya3
name: /dev/ttya3
/class/tty/ttya4
name: /dev/ttya4
/class/tty/ttya5
name: /dev/ttya5
/class/tty/ttya6
name: /dev/ttya6
/class/tty/ttya7
name: /dev/ttya7
/class/tty/ttya8
name: /dev/ttya8
/class/tty/ttya9
name: /dev/ttya9
/class/tty/ttyaa
name: /dev/ttyaa
/class/tty/ttyab
name: /dev/ttyab
/class/tty/ttyac
name: /dev/ttyac
/class/tty/ttyad
name: /dev/ttyad
/class/tty/ttyae
name: /dev/ttyae
/class/tty/ttyaf
name: /dev/ttyaf
/class/tty/ttyb0
name: /dev/ttyb0
/class/tty/ttyb1
name: /dev/ttyb1
/class/tty/ttyb2
name: /dev/ttyb2
/class/tty/ttyb3
name: /dev/ttyb3
/class/tty/ttyb4
name: /dev/ttyb4
/class/tty/ttyb5
name: /dev/ttyb5
/class/tty/ttyb6
name: /dev/ttyb6
/class/tty/ttyb7
name: /dev/ttyb7
/class/tty/ttyb8
name: /dev/ttyb8
/class/tty/ttyb9
name: /dev/ttyb9
/class/tty/ttyba
name: /dev/ttyba
/class/tty/ttybb
name: /dev/ttybb
/class/tty/ttybc
name: /dev/ttybc
/class/tty/ttybd
name: /dev/ttybd
/class/tty/ttybe
name: /dev/ttybe
/class/tty/ttybf
name: /dev/ttybf
/class/tty/ttyc0
name: /dev/ttyc0
/class/tty/ttyc1
name: /dev/ttyc1
/class/tty/ttyc2
name: /dev/ttyc2
/class/tty/ttyc3
name: /dev/ttyc3
/class/tty/ttyc4
name: /dev/ttyc4
/class/tty/ttyc5
name: /dev/ttyc5
/class/tty/ttyc6
name: /dev/ttyc6
/class/tty/ttyc7
name: /dev/ttyc7
/class/tty/ttyc8
name: /dev/ttyc8
/class/tty/ttyc9
name: /dev/ttyc9
/class/tty/ttyca
name: /dev/ttyca
/class/tty/ttycb
name: /dev/ttycb
/class/tty/ttycc
name: /dev/ttycc
/class/tty/ttycd
name: /dev/ttycd
/class/tty/ttyce
name: /dev/ttyce
/class/tty/ttycf
name: /dev/ttycf
/class/tty/ttyd0
name: /dev/ttyd0
/class/tty/ttyd1
name: /dev/ttyd1
/class/tty/ttyd2
name: /dev/ttyd2
/class/tty/ttyd3
name: /dev/ttyd3
/class/tty/ttyd4
name: /dev/ttyd4
/class/tty/ttyd5
name: /dev/ttyd5
/class/tty/ttyd6
name: /dev/ttyd6
/class/tty/ttyd7
name: /dev/ttyd7
/class/tty/ttyd8
name: /dev/ttyd8
/class/tty/ttyd9
name: /dev/ttyd9
/class/tty/ttyda
name: /dev/ttyda
/class/tty/ttydb
name: /dev/ttydb
/class/tty/ttydc
name: /dev/ttydc
/class/tty/ttydd
name: /dev/ttydd
/class/tty/ttyde
name: /dev/ttyde
/class/tty/ttydf
name: /dev/ttydf
/class/tty/ttye0
name: /dev/ttye0
/class/tty/ttye1
name: /dev/ttye1
/class/tty/ttye2
name: /dev/ttye2
/class/tty/ttye3
name: /dev/ttye3
/class/tty/ttye4
name: /dev/ttye4
/class/tty/ttye5
name: /dev/ttye5
/class/tty/ttye6
name: /dev/ttye6
/class/tty/ttye7
name: /dev/ttye7
/class/tty/ttye8
name: /dev/ttye8
/class/tty/ttye9
name: /dev/ttye9
/class/tty/ttyea
name: /dev/ttyea
/class/tty/ttyeb
name: /dev/ttyeb
/class/tty/ttyec
name: /dev/ttyec
/class/tty/ttyed
name: /dev/ttyed
/class/tty/ttyee
name: /dev/ttyee
/class/tty/ttyef
name: /dev/ttyef
/class/tty/ttyp0
name: /dev/ttyp0
/class/tty/ttyp1
name: /dev/ttyp1
/class/tty/ttyp2
name: /dev/ttyp2
/class/tty/ttyp3
name: /dev/ttyp3
/class/tty/ttyp4
name: /dev/ttyp4
/class/tty/ttyp5
name: /dev/ttyp5
/class/tty/ttyp6
name: /dev/ttyp6
/class/tty/ttyp7
name: /dev/ttyp7
/class/tty/ttyp8
name: /dev/ttyp8
/class/tty/ttyp9
name: /dev/ttyp9
/class/tty/ttypa
name: /dev/ttypa
/class/tty/ttypb
name: /dev/ttypb
/class/tty/ttypc
name: /dev/ttypc
/class/tty/ttypd
name: /dev/ttypd
/class/tty/ttype
name: /dev/ttype
/class/tty/ttypf
name: /dev/ttypf
/class/tty/ttyq0
name: /dev/ttyq0
/class/tty/ttyq1
name: /dev/ttyq1
/class/tty/ttyq2
name: /dev/ttyq2
/class/tty/ttyq3
name: /dev/ttyq3
/class/tty/ttyq4
name: /dev/ttyq4
/class/tty/ttyq5
name: /dev/ttyq5
/class/tty/ttyq6
name: /dev/ttyq6
/class/tty/ttyq7
name: /dev/ttyq7
/class/tty/ttyq8
name: /dev/ttyq8
/class/tty/ttyq9
name: /dev/ttyq9
/class/tty/ttyqa
name: /dev/ttyqa
/class/tty/ttyqb
name: /dev/ttyqb
/class/tty/ttyqc
name: /dev/ttyqc
/class/tty/ttyqd
name: /dev/ttyqd
/class/tty/ttyqe
name: /dev/ttyqe
/class/tty/ttyqf
name: /dev/ttyqf
/class/tty/ttyr0
name: /dev/ttyr0
/class/tty/ttyr1
name: /dev/ttyr1
/class/tty/ttyr2
name: /dev/ttyr2
/class/tty/ttyr3
name: /dev/ttyr3
/class/tty/ttyr4
name: /dev/ttyr4
/class/tty/ttyr5
name: /dev/ttyr5
/class/tty/ttyr6
name: /dev/ttyr6
/class/tty/ttyr7
name: /dev/ttyr7
/class/tty/ttyr8
name: /dev/ttyr8
/class/tty/ttyr9
name: /dev/ttyr9
/class/tty/ttyra
name: /dev/ttyra
/class/tty/ttyrb
name: /dev/ttyrb
/class/tty/ttyrc
name: /dev/ttyrc
/class/tty/ttyrd
name: /dev/ttyrd
/class/tty/ttyre
name: /dev/ttyre
/class/tty/ttyrf
name: /dev/ttyrf
/class/tty/ttys0
name: /dev/ttys0
/class/tty/ttys1
name: /dev/ttys1
/class/tty/ttys2
name: /dev/ttys2
/class/tty/ttys3
name: /dev/ttys3
/class/tty/ttys4
name: /dev/ttys4
/class/tty/ttys5
name: /dev/ttys5
/class/tty/ttys6
name: /dev/ttys6
/class/tty/ttys7
name: /dev/ttys7
/class/tty/ttys8
name: /dev/ttys8
/class/tty/ttys9
name: /dev/ttys9
/class/tty/ttysa
name: /dev/ttysa
/class/tty/ttysb
name: /dev/ttysb
/class/tty/ttysc
name: /dev/ttysc
/class/tty/ttysd
name: /dev/ttysd
/class/tty/ttyse
name: /dev/ttyse
/class/tty/ttysf
name: /dev/ttysf
/class/tty/ttyt0
name: /dev/ttyt0
/class/tty/ttyt1
name: /dev/ttyt1
/class/tty/ttyt2
name: /dev/ttyt2
/class/tty/ttyt3
name: /dev/ttyt3
/class/tty/ttyt4
name: /dev/ttyt4
/class/tty/ttyt5
name: /dev/ttyt5
/class/tty/ttyt6
name: /dev/ttyt6
/class/tty/ttyt7
name: /dev/ttyt7
/class/tty/ttyt8
name: /dev/ttyt8
/class/tty/ttyt9
name: /dev/ttyt9
/class/tty/ttyta
name: /dev/ttyta
/class/tty/ttytb
name: /dev/ttytb
/class/tty/ttytc
name: /dev/ttytc
/class/tty/ttytd
name: /dev/ttytd
/class/tty/ttyte
name: /dev/ttyte
/class/tty/ttytf
name: /dev/ttytf
/class/tty/ttyu0
name: /dev/ttyu0
/class/tty/ttyu1
name: /dev/ttyu1
/class/tty/ttyu2
name: /dev/ttyu2
/class/tty/ttyu3
name: /dev/ttyu3
/class/tty/ttyu4
name: /dev/ttyu4
/class/tty/ttyu5
name: /dev/ttyu5
/class/tty/ttyu6
name: /dev/ttyu6
/class/tty/ttyu7
name: /dev/ttyu7
/class/tty/ttyu8
name: /dev/ttyu8
/class/tty/ttyu9
name: /dev/ttyu9
/class/tty/ttyua
name: /dev/ttyua
/class/tty/ttyub
name: /dev/ttyub
/class/tty/ttyuc
name: /dev/ttyuc
/class/tty/ttyud
name: /dev/ttyud
/class/tty/ttyue
name: /dev/ttyue
/class/tty/ttyuf
name: /dev/ttyuf
/class/tty/ttyv0
name: /dev/ttyv0
/class/tty/ttyv1
name: /dev/ttyv1
/class/tty/ttyv2
name: /dev/ttyv2
/class/tty/ttyv3
name: /dev/ttyv3
/class/tty/ttyv4
name: /dev/ttyv4
/class/tty/ttyv5
name: /dev/ttyv5
/class/tty/ttyv6
name: /dev/ttyv6
/class/tty/ttyv7
name: /dev/ttyv7
/class/tty/ttyv8
name: /dev/ttyv8
/class/tty/ttyv9
name: /dev/ttyv9
/class/tty/ttyva
name: /dev/ttyva
/class/tty/ttyvb
name: /dev/ttyvb
/class/tty/ttyvc
name: /dev/ttyvc
/class/tty/ttyvd
name: /dev/ttyvd
/class/tty/ttyve
name: /dev/ttyve
/class/tty/ttyvf
name: /dev/ttyvf
/class/tty/ttyw0
name: /dev/ttyw0
/class/tty/ttyw1
name: /dev/ttyw1
/class/tty/ttyw2
name: /dev/ttyw2
/class/tty/ttyw3
name: /dev/ttyw3
/class/tty/ttyw4
name: /dev/ttyw4
/class/tty/ttyw5
name: /dev/ttyw5
/class/tty/ttyw6
name: /dev/ttyw6
/class/tty/ttyw7
name: /dev/ttyw7
/class/tty/ttyw8
name: /dev/ttyw8
/class/tty/ttyw9
name: /dev/ttyw9
/class/tty/ttywa
name: /dev/ttywa
/class/tty/ttywb
name: /dev/ttywb
/class/tty/ttywc
name: /dev/ttywc
/class/tty/ttywd
name: /dev/ttywd
/class/tty/ttywe
name: /dev/ttywe
/class/tty/ttywf
name: /dev/ttywf
/class/tty/ttyx0
name: /dev/ttyx0
/class/tty/ttyx1
name: /dev/ttyx1
/class/tty/ttyx2
name: /dev/ttyx2
/class/tty/ttyx3
name: /dev/ttyx3
/class/tty/ttyx4
name: /dev/ttyx4
/class/tty/ttyx5
name: /dev/ttyx5
/class/tty/ttyx6
name: /dev/ttyx6
/class/tty/ttyx7
name: /dev/ttyx7
/class/tty/ttyx8
name: /dev/ttyx8
/class/tty/ttyx9
name: /dev/ttyx9
/class/tty/ttyxa
name: /dev/ttyxa
/class/tty/ttyxb
name: /dev/ttyxb
/class/tty/ttyxc
name: /dev/ttyxc
/class/tty/ttyxd
name: /dev/ttyxd
/class/tty/ttyxe
name: /dev/ttyxe
/class/tty/ttyxf
name: /dev/ttyxf
/class/tty/ttyy0
name: /dev/ttyy0
/class/tty/ttyy1
name: /dev/ttyy1
/class/tty/ttyy2
name: /dev/ttyy2
/class/tty/ttyy3
name: /dev/ttyy3
/class/tty/ttyy4
name: /dev/ttyy4
/class/tty/ttyy5
name: /dev/ttyy5
/class/tty/ttyy6
name: /dev/ttyy6
/class/tty/ttyy7
name: /dev/ttyy7
/class/tty/ttyy8
name: /dev/ttyy8
/class/tty/ttyy9
name: /dev/ttyy9
/class/tty/ttyya
name: /dev/ttyya
/class/tty/ttyyb
name: /dev/ttyyb
/class/tty/ttyyc
name: /dev/ttyyc
/class/tty/ttyyd
name: /dev/ttyyd
/class/tty/ttyye
name: /dev/ttyye
/class/tty/ttyyf
name: /dev/ttyyf
/class/tty/ttyz0
name: /dev/ttyz0
/class/tty/ttyz1
name: /dev/ttyz1
/class/tty/ttyz2
name: /dev/ttyz2
/class/tty/ttyz3
name: /dev/ttyz3
/class/tty/ttyz4
name: /dev/ttyz4
/class/tty/ttyz5
name: /dev/ttyz5
/class/tty/ttyz6
name: /dev/ttyz6
/class/tty/ttyz7
name: /dev/ttyz7
/class/tty/ttyz8
name: /dev/ttyz8
/class/tty/ttyz9
name: /dev/ttyz9
/class/tty/ttyza
name: /dev/ttyza
/class/tty/ttyzb
name: /dev/ttyzb
/class/tty/ttyzc
name: /dev/ttyzc
/class/tty/ttyzd
name: /dev/ttyzd
/class/tty/ttyze
name: /dev/ttyze
/class/tty/ttyzf
name: /dev/ttyzf
/class/usb_device/usbdev1.1
name: /dev/bus/usb/001/001
/class/usb_device/usbdev1.2
name: /dev/bus/usb/001/002
/class/usb_device/usbdev2.1
name: /dev/bus/usb/002/001
/class/usb_device/usbdev2.3
name: /dev/bus/usb/002/003
/class/usb_device/usbdev3.1
name: /dev/bus/usb/003/001
/class/usb_device/usbdev4.1
name: /dev/bus/usb/004/001
/class/usb_endpoint/usbdev1.1_ep00
name: /dev/usbdev1.1_ep00
/class/usb_endpoint/usbdev1.1_ep81
name: /dev/usbdev1.1_ep81
/class/usb_endpoint/usbdev1.2_ep00
name: /dev/usbdev1.2_ep00
/class/usb_endpoint/usbdev1.2_ep83
name: /dev/usbdev1.2_ep83
/class/usb_endpoint/usbdev2.1_ep00
name: /dev/usbdev2.1_ep00
/class/usb_endpoint/usbdev2.1_ep81
name: /dev/usbdev2.1_ep81
/class/usb_endpoint/usbdev2.3_ep00
name: /dev/usbdev2.3_ep00
/class/usb_endpoint/usbdev2.3_ep81
name: /dev/usbdev2.3_ep81
/class/usb_endpoint/usbdev3.1_ep00
name: /dev/usbdev3.1_ep00
/class/usb_endpoint/usbdev3.1_ep81
name: /dev/usbdev3.1_ep81
/class/usb_endpoint/usbdev4.1_ep00
name: /dev/usbdev4.1_ep00
/class/usb_endpoint/usbdev4.1_ep81
name: /dev/usbdev4.1_ep81
/class/vc/vcs
name: /dev/vcs
/class/vc/vcs1
name: /dev/vcs1
/class/vc/vcs2
name: /dev/vcs2
/class/vc/vcs3
name: /dev/vcs3
/class/vc/vcs4
name: /dev/vcs4
/class/vc/vcsa
name: /dev/vcsa
/class/vc/vcsa1
name: /dev/vcsa1
/class/vc/vcsa2
name: /dev/vcsa2
/class/vc/vcsa3
name: /dev/vcsa3
/class/vc/vcsa4
name: /dev/vcsa4
/class/video4linux/video0
name: /dev/video0
/devices/pci0000:00/0000:00:10.0/usb2
name: /dev/usb2
/devices/pci0000:00/0000:00:10.0/usb2/2-1
name: /dev/2-1
/devices/pci0000:00/0000:00:10.2/usb3
name: /dev/usb3
/devices/pci0000:00/0000:00:10.3/usb4
name: /dev/usb4
/devices/pci0000:00/0000:00:10.4/usb1
name: /dev/usb1
/devices/pci0000:00/0000:00:10.4/usb1/1-8
name: /dev/1-8
>> int.13: device names
>> int.14: soft raid
----- soft raid devices -----
----- soft raid devices end -----
>> int.15: geo
>> int.16: parent
prop read: rdCR.lZF+r4EgHp4 (failed)
old prop read: rdCR.lZF+r4EgHp4 (failed)
prop read: rdCR.n_7QNeEnh23 (failed)
old prop read: rdCR.n_7QNeEnh23 (failed)
prop read: rdCR.EMpH5pjcahD (failed)
old prop read: rdCR.EMpH5pjcahD (failed)
prop read: rdCR.f5u1ucRm+H9 (failed)
old prop read: rdCR.f5u1ucRm+H9 (failed)
prop read: rdCR.8uRK7LxiIA2 (failed)
old prop read: rdCR.8uRK7LxiIA2 (failed)
prop read: rdCR.AJKleuxpiP0 (failed)
old prop read: rdCR.AJKleuxpiP0 (failed)
prop read: rdCR.9N+EecqykME (failed)
old prop read: rdCR.9N+EecqykME (failed)
prop read: rdCR.DziBbWO85o5 (failed)
old prop read: rdCR.DziBbWO85o5 (failed)
prop read: rdCR.CxwsZFjVASF (failed)
old prop read: rdCR.CxwsZFjVASF (failed)
prop read: FVI2.GlJxKj9C3MF (failed)
old prop read: FVI2.GlJxKj9C3MF (failed)
prop read: xJBP.FnR_gbvdRi0 (failed)
old prop read: xJBP.FnR_gbvdRi0 (failed)
prop read: OVRT.ZugsYBr16xD (failed)
old prop read: OVRT.ZugsYBr16xD (failed)
prop read: VCu0.lAhfe5B+RC0 (failed)
old prop read: VCu0.lAhfe5B+RC0 (failed)
prop read: 9n5e.HHSMJjh6gC5 (failed)
old prop read: 9n5e.HHSMJjh6gC5 (failed)
prop read: HSco.jfGiUiN+dB5 (failed)
old prop read: HSco.jfGiUiN+dB5 (failed)
prop read: BWxi.NhM1uBZ0XP5 (failed)
old prop read: BWxi.NhM1uBZ0XP5 (failed)
prop read: 7EWs.JRMntr2WuE8 (failed)
old prop read: 7EWs.JRMntr2WuE8 (failed)
prop read: WQQk.Bbr16aUOXm1 (failed)
old prop read: WQQk.Bbr16aUOXm1 (failed)
prop read: f5xu.M+iEzzTSsLF (failed)
old prop read: f5xu.M+iEzzTSsLF (failed)
prop read: nmR3.M+iEzzTSsLF (failed)
old prop read: nmR3.M+iEzzTSsLF (failed)
prop read: 37TO.M+iEzzTSsLF (failed)
old prop read: 37TO.M+iEzzTSsLF (failed)
prop read: _+Pw.uEnt96FgSd9 (failed)
old prop read: _+Pw.uEnt96FgSd9 (failed)
prop read: 3hqH.ASKGEfPHzS4 (failed)
old prop read: 3hqH.ASKGEfPHzS4 (failed)
prop read: _Znp.g78+51qvkd0 (failed)
old prop read: _Znp.g78+51qvkd0 (failed)
prop read: vSkL.S16qDHSKEeD (failed)
old prop read: vSkL.S16qDHSKEeD (failed)
prop read: ud6k.smx+hvUIzS5 (failed)
old prop read: ud6k.smx+hvUIzS5 (failed)
prop read: 0Jdu.KvU_alV38+A (failed)
old prop read: 0Jdu.KvU_alV38+A (failed)
prop read: 9_73.cjbsqqlCSpC (failed)
old prop read: 9_73.cjbsqqlCSpC (failed)
prop read: HfeD.qaIjS7whv97 (failed)
old prop read: HfeD.qaIjS7whv97 (failed)
prop read: QK9O.s7ZTRfJZWoD (failed)
old prop read: QK9O.s7ZTRfJZWoD (failed)
prop read: Z+fY.KG6SKVKKhK3 (failed)
old prop read: Z+fY.KG6SKVKKhK3 (failed)
prop read: hgAj.46WJGzIDbw7 (failed)
old prop read: hgAj.46WJGzIDbw7 (failed)
prop read: qLht.qxvACtkySVF (failed)
old prop read: qLht.qxvACtkySVF (failed)
prop read: 30p6.+GmdJItMGB9 (failed)
old prop read: 30p6.+GmdJItMGB9 (failed)
prop read: cqY2.gNN83gfynbD (failed)
old prop read: cqY2.gNN83gfynbD (failed)
prop read: 9fI_.B95vU_X3dpD (failed)
old prop read: 9fI_.B95vU_X3dpD (failed)
prop read: iT2w.B+yZ9Ve8gC1 (failed)
old prop read: iT2w.B+yZ9Ve8gC1 (failed)
prop read: H20r.+t_YHFi_6u4 (failed)
old prop read: H20r.+t_YHFi_6u4 (failed)
prop read: qslm.B+yZ9Ve8gC1 (failed)
old prop read: qslm.B+yZ9Ve8gC1 (failed)
prop read: NhVi.WYwRElrJa93 (failed)
old prop read: NhVi.WYwRElrJa93 (failed)
prop read: hEKD.fG36JLVNse9 (failed)
old prop read: hEKD.fG36JLVNse9 (failed)
prop read: E349.B+yZ9Ve8gC1 (failed)
old prop read: E349.B+yZ9Ve8gC1 (failed)
prop read: ntp4.DE8RM9cWQQ8 (failed)
old prop read: ntp4.DE8RM9cWQQ8 (failed)
prop read: KiZ0.bvKf3UMzZfE (failed)
old prop read: KiZ0.bvKf3UMzZfE (failed)
prop read: tWJy.xhndlW9HXJ7 (failed)
old prop read: tWJy.xhndlW9HXJ7 (failed)
prop read: QL3u.ld94kxNGZf5 (failed)
old prop read: QL3u.ld94kxNGZf5 (failed)
prop read: z9pp.QBqTp8zQt87 (failed)
old prop read: z9pp.QBqTp8zQt87 (failed)
prop read: S_Uw.3fyvFV+mbWD (failed)
old prop read: S_Uw.3fyvFV+mbWD (failed)
prop read: rdCR.g9fwCXkwNOD (failed)
old prop read: rdCR.g9fwCXkwNOD (failed)
prop read: Fffu.MiLwIsFrYDD (failed)
old prop read: Fffu.MiLwIsFrYDD (failed)
prop read: 0fbI.SE1wIdpsiiC (failed)
old prop read: 0fbI.SE1wIdpsiiC (failed)
prop read: TqrM.SE1wIdpsiiC (failed)
old prop read: TqrM.SE1wIdpsiiC (failed)
prop read: x+5R.SE1wIdpsiiC (failed)
old prop read: x+5R.SE1wIdpsiiC (failed)
prop read: OBMV.SE1wIdpsiiC (failed)
old prop read: OBMV.SE1wIdpsiiC (failed)
prop read: FKGF.m7C82g3gZbB (failed)
old prop read: FKGF.m7C82g3gZbB (failed)
prop read: zPk0.Oz8tSgc5mXF (failed)
old prop read: zPk0.Oz8tSgc5mXF (failed)
prop read: uIhY.dE4I5wpNpF8 (failed)
old prop read: uIhY.dE4I5wpNpF8 (failed)
prop read: QR8P.6SrbWBBevvA (failed)
old prop read: QR8P.6SrbWBBevvA (failed)
prop read: pBe4.5nw7MPEyvh9 (failed)
old prop read: pBe4.5nw7MPEyvh9 (failed)
prop read: k4bc.22MfGOBVe10 (failed)
old prop read: k4bc.22MfGOBVe10 (failed)
prop read: AH6Q.845qvaQafo3 (failed)
old prop read: AH6Q.845qvaQafo3 (failed)
prop read: EXC1.TBWTwSuMeW2 (failed)
old prop read: EXC1.TBWTwSuMeW2 (failed)
prop read: rdCR.j8NaKXDZtZ6 (failed)
old prop read: rdCR.j8NaKXDZtZ6 (failed)
prop read: rdCR.EY_qmtb9YY0 (failed)
old prop read: rdCR.EY_qmtb9YY0 (failed)
prop read: 9iZU.ndpeucax6V1 (failed)
old prop read: 9iZU.ndpeucax6V1 (failed)
prop read: ctpY.ndpeucax6V1 (failed)
old prop read: ctpY.ndpeucax6V1 (failed)
prop read: ZsBS.GQNx7L4uPNA (failed)
old prop read: ZsBS.GQNx7L4uPNA (failed)
----- /proc/modules -----
michael_mic 2440 2 - Live 0xf8bed000
arc4 1928 2 - Live 0xf8b3e000
ecb 2824 2 - Live 0xf8860000
sg 28740 0 - Live 0xf8c7b000
st 37180 0 - Live 0xf8c70000
lp 10152 0 - Live 0xf8c2d000
parport_pc 25960 0 - Live 0xf8c38000
parport 35100 2 lp,parport_pc, Live 0xf8c59000
e_powersaver 4364 0 - Live 0xf8b85000
usbhid 30116 0 - Live 0xf8c50000
hid 53924 1 usbhid, Live 0xf8c41000
fan 4748 0 - Live 0xf8ac7000
rsrc_nonstatic 11540 0 - Live 0xf8bf3000
pcmcia_core 37456 1 rsrc_nonstatic, Live 0xf8c22000
af_packet 13320 2 - Live 0xf8b51000
freq_table 4492 1 e_powersaver, Live 0xf8b33000
via_rhine 21664 0 - Live 0xf8c1b000
via 40652 0 - Live 0xf8bfa000
drm 77824 1 via, Live 0xf8c07000
uvcvideo 56624 0 - Live 0xf8b76000
compat_ioctl32 1416 1 uvcvideo, Live 0xf8864000
videodev 36776 1 uvcvideo, Live 0xf8be3000
v4l1_compat 13584 2 uvcvideo,videodev, Live 0xf8b39000
serio_raw 5644 0 - Live 0xf8abd000
tg3 121616 0 - Live 0xf8b57000
libphy 19216 1 tg3, Live 0xf8aea000
snd_hda_intel 367512 0 - Live 0xf8b88000
snd_pcm_oss 41824 0 - Live 0xf8b05000
snd_mixer_oss 15496 1 snd_pcm_oss, Live 0xf8aab000
snd_pcm 76332 2 snd_hda_intel,snd_pcm_oss, Live 0xf8af1000
snd_timer 22548 1 snd_pcm, Live 0xf8ac0000
snd 54668 5 snd_hda_intel,snd_pcm_oss,snd_mixer_oss,snd_pcm,snd_timer, Live 0xf8aca000
soundcore 7396 1 snd, Live 0xf8ab4000
snd_page_alloc 8340 2 snd_hda_intel,snd_pcm, Live 0xf8ab0000
pcspkr 2568 0 - Live 0xf883a000
video 18076 0 - Live 0xf8a90000
output 3080 1 video, Live 0xf882a000
battery 10768 0 - Live 0xf8aa7000
i2c_viapro 7972 0 - Live 0xf8aa4000
ata_generic 5136 0 - Live 0xf8837000
ac 4364 0 - Live 0xf8a8d000
i2c_core 23960 1 i2c_viapro, Live 0xf8a9d000
pata_acpi 4232 0 - Live 0xf884d000
uhci_hcd 23196 0 - Live 0xf8a96000
ieee80211_crypt_tkip 9224 0 - Live 0xf8859000
thermal 16444 0 - Live 0xf887a000
button 6424 0 - Live 0xf885d000
sata_via 7820 0 - Live 0xf8834000
ehci_hcd 35876 0 - Live 0xf8870000
processor 33368 2 thermal, Live 0xf8866000
thermal_sys 10408 4 fan,video,thermal,processor, Live 0xf8855000
wl 2438284 0 - Live 0xf8d11000 (P)
ieee80211_crypt 5640 2 ieee80211_crypt_tkip,wl, Live 0xf884a000
libata 173976 3 ata_generic,pata_acpi,sata_via, Live 0xf8a61000
dock 8984 1 libata, Live 0xf8846000
via_agp 8200 1 - Live 0xf8830000
agpgart 34244 2 drm,via_agp, Live 0xf883c000
joydev 10212 0 - Live 0xf882c000
evdev 10532 1 - Live 0xf8826000
----- /proc/modules end -----
used irqs: 0,1,4,9,11,12,14,15,16,17,20,21,23,24,27,31
=========== end debug info ============
01: None 00.0: 10105 BIOS
[Created at bios.173]
Unique ID: rdCR.lZF+r4EgHp4
Hardware Class: bios
BIOS Keyboard LED Status:
Scroll Lock: off
Num Lock: off
Caps Lock: off
Base Memory: 639 kB
PnP BIOS: DA\3000
MP spec rev 1.4 info:
OEM id: "TEMPLATE"
Product id: "ETEMPLATE"
1 CPUs (0 disabled)
BIOS32 Service Directory Entry: 0xf0010
SMBIOS Version: 2.5
BIOS Info: #0
Vendor: "Hewlett-Packard"
Version: "68VGU Ver. F.06"
Date: "11/11/2008"
Start Address: 0xf0000
ROM Size: 1024 kB
Features: 0x0793000000013d0b9e80
PCI supported
PnP supported
APM supported
BIOS flashable
BIOS shadowing allowed
CD boot supported
Selectable boot supported
BIOS ROM socketed
EDD spec supported
720kB Floppy supported
Print Screen supported
8042 Keyboard Services supported
Serial Services supported
Printer Services supported
ACPI supported
USB Legacy supported
LS-120 boot supported
Smart Battery supported
BIOS Boot Spec supported
F12 Network boot supported
System Info: #1
Manufacturer: "Hewlett-Packard"
Version: "F.06"
UUID: undefined, but settable
Wake-up: 0x06 (Power Switch)
Board Info: #2
Manufacturer: "Hewlett-Packard"
Product: "3030"
Version: "KBC Version 07.17"
Type: 0x0a (Motherboard)
Features: 0x09
Hosting Board
Replaceable
Chassis: #3
Chassis Info: #3
Manufacturer: "Hewlett-Packard"
Type: 0x0a (Notebook)
Bootup State: 0x03 (Safe)
Power Supply State: 0x03 (Safe)
Thermal State: 0x03 (Safe)
Security Status: 0x05 (External interface enabled)
Processor Info: #4
Socket: "CPU 1"
Socket Type: 0x0f (Socket 478)
Socket Status: Populated
Type: 0x03 (CPU)
Family: 0xd2 (Other)
Manufacturer: "VIA"
Version: "VIA C7-M Processor 1600MHz"
Serial: "To Be Filled By O.E.M."
Asset Tag: "To Be Filled By O.E.M."
Part Number: "To Be Filled By O.E.M."
Processor ID: 0xa7c9bbff000006d0
Status: 0x01 (Enabled)
Voltage: 1.0 V
External Clock: 200 MHz
Max. Speed: 1600 MHz
Current Speed: 1600 MHz
L1 Cache: #5
L2 Cache: #6
Cache Info: #5
Designation: "L1-Cache"
Level: L1
State: Enabled
Mode: 0x01 (Write Back)
Location: 0x00 (Internal, Not Socketed)
ECC: 0x04 (Parity)
Type: 0x04 (Data)
Associativity: 0x05 (4-way Set-Associative)
Max. Size: 128 kB
Current Size: 128 kB
Supported SRAM Types: 0x0001 (Other)
Current SRAM Type: 0x0001 (Other)
Cache Info: #6
Designation: "L2-Cache"
Level: L2
State: Enabled
Mode: 0x01 (Write Back)
Location: 0x00 (Internal, Not Socketed)
ECC: 0x05 (Single-bit)
Type: 0x05 (Unified)
Associativity: 0x01 (Other)
Max. Size: 128 kB
Current Size: 128 kB
Supported SRAM Types: 0x0001 (Other)
Current SRAM Type: 0x0001 (Other)
System Slot: #7
Designation: "AGP"
Type: 0x11 (AGP 4X)
Bus Width: 0x05 (32 bit)
Status: 0x04 (In Use)
Length: 0x03 (Short)
Slot ID: 0
Characteristics: 0x010c (3.3 V, Shared, PME#)
System Slot: #8
Designation: "PCI1"
Type: 0x06 (PCI)
Bus Width: 0x05 (32 bit)
Status: 0x03 (Available)
Length: 0x03 (Short)
Slot ID: 1
Characteristics: 0x010c (3.3 V, Shared, PME#)
On Board Devices: #9
Video: "To Be Filled By O.E.M."
OEM Strings: #10
www.hp.com
LOC#ZZZ
ABS 70/71 79 7A 7B 7C
Language Info: #11
Languages: en|US|iso8859-1
Current: en|US|iso8859-1
Type 15 Record: #12
Data 00: 0f 23 0c 00 04 00 00 00 02 00 02 00 00 00 00 00
Data 10: 6a 04 6c 04 00 06 02 ff ff ff ff ff ff ff ff ff
Data 20: ff ff ff
Physical Memory Array: #13
Use: 0x03 (System memory)
Location: 0x03 (Motherboard)
Slots: 1
Max. Size: 4 GB
ECC: 0x03 (None)
Memory Array Mapping: #14
Memory Array: #13
Partition Width: 1
Start Address: 0x00000000
End Address: 0x80000000
Memory Device: #15
Location: "DIMM0"
Bank: "BANK0"
Manufacturer: "Manufacturer00"
Serial: "SerNum00"
Asset Tag: "AssetTagNum0"
Part Number: "ModulePartNumber00"
Memory Array: #13
Form Factor: 0x09 (DIMM)
Type: 0x13 (Other)
Type Detail: 0x0080 (Synchronous)
Data Width: 64 bits
Size: 2 GB
Memory Device Mapping: #16
Memory Device: #15
Array Mapping: #14
Row: 1
Interleave Pos: 0
Interleaved Depth: 1
Start Address: 0x00000000
End Address: 0x80000000
Type 32 Record: #17
Data 00: 20 14 11 00 00 00 00 00 00 00 00 00 00 00 00 00
Data 10: 00 00 00 00
Config Status: cfg=new, avail=yes, need=no, active=unknown
02: None 00.0: 10107 System
[Created at sys.59]
Unique ID: rdCR.n_7QNeEnh23
Hardware Class: system
Model: "System"
Driver Info #0:
Driver Status: thermal,fan are active
Driver Activation Cmd: "modprobe thermal; modprobe fan"
Config Status: cfg=new, avail=yes, need=no, active=unknown
03: None 00.0: 10104 FPU
[Created at misc.192]
Unique ID: rdCR.EMpH5pjcahD
Hardware Class: unknown
Model: "FPU"
I/O Ports: 0xf0-0xff (rw)
Config Status: cfg=new, avail=yes, need=no, active=unknown
04: None 00.0: 0801 DMA controller (8237)
[Created at misc.206]
Unique ID: rdCR.f5u1ucRm+H9
Hardware Class: unknown
Model: "DMA controller"
I/O Ports: 0x00-0x1f (rw)
I/O Ports: 0xc0-0xdf (rw)
I/O Ports: 0x80-0x8f (rw)
DMA: 4
Config Status: cfg=new, avail=yes, need=no, active=unknown
05: None 00.0: 0800 PIC (8259)
[Created at misc.219]
Unique ID: rdCR.8uRK7LxiIA2
Hardware Class: unknown
Model: "PIC"
I/O Ports: 0x20-0x21 (rw)
I/O Ports: 0xa0-0xa1 (rw)
Config Status: cfg=new, avail=yes, need=no, active=unknown
06: None 00.0: 0802 Timer (8254)
[Created at misc.230]
Unique ID: rdCR.AJKleuxpiP0
Hardware Class: unknown
Model: "Timer"
IRQ: 0 (105229650 events)
Config Status: cfg=new, avail=yes, need=no, active=unknown
07: None 00.0: 0900 Keyboard controller
[Created at misc.251]
Unique ID: rdCR.9N+EecqykME
Hardware Class: unknown
Model: "Keyboard controller"
I/O Port: 0x60 (rw)
I/O Port: 0x64 (rw)
Config Status: cfg=new, avail=yes, need=no, active=unknown
08: None 00.0: 10400 PS/2 Controller
[Created at misc.304]
Unique ID: rdCR.DziBbWO85o5
Hardware Class: unknown
Model: "PS/2 Controller"
Config Status: cfg=new, avail=yes, need=no, active=unknown
10: None 00.0: 10102 Main Memory
[Created at memory.61]
Unique ID: rdCR.CxwsZFjVASF
Hardware Class: memory
Model: "Main Memory"
Memory Range: 0x00000000-0x6ebb6fff (rw)
Memory Size: 1 GB + 768 MB
Config Status: cfg=new, avail=yes, need=no, active=unknown
11: PCI 8001.0: 0403 Audio device
[Created at pci.281]
Unique ID: FVI2.GlJxKj9C3MF
SysFS ID: /devices/pci0000:80/0000:80:01.0
SysFS BusID: 0000:80:01.0
Hardware Class: sound
Model: "Hewlett-Packard Company VIA High Definition Audio Controller"
Vendor: pci 0x1106 "VIA Technologies, Inc."
Device: pci 0x3288 "VIA High Definition Audio Controller"
SubVendor: pci 0x103c "Hewlett-Packard Company"
SubDevice: pci 0x3030
Revision: 0x10
Driver: "HDA Intel"
Driver Modules: "snd_hda_intel"
Memory Range: 0xfebfc000-0xfebfffff (rw,non-prefetchable)
IRQ: 17 (666358 events)
Module Alias: "pci:v00001106d00003288sv0000103Csd00003030bc04sc03i00"
Driver Info #0:
Driver Status: snd_hda_intel is active
Driver Activation Cmd: "modprobe snd_hda_intel"
Config Status: cfg=new, avail=yes, need=no, active=unknown
12: PCI 703.0: 0200 Ethernet controller
[Created at pci.281]
Unique ID: xJBP.FnR_gbvdRi0
Parent ID: 9n5e.HHSMJjh6gC5
SysFS ID: /devices/pci0000:00/0000:00:13.1/0000:07:03.0
SysFS BusID: 0000:07:03.0
Hardware Class: network
Model: "Hewlett-Packard Company NetXtreme BCM5788 Gigabit Ethernet"
Vendor: pci 0x14e4 "Broadcom"
Device: pci 0x169c "NetXtreme BCM5788 Gigabit Ethernet"
SubVendor: pci 0x103c "Hewlett-Packard Company"
SubDevice: pci 0x3030
Revision: 0x03
Driver: "tg3"
Driver Modules: "tg3"
Device File: eth12
Memory Range: 0xfeaf0000-0xfeafffff (rw,non-prefetchable)
IRQ: 16 (no events)
HW Address: 00:24:81:59:74:99
Link detected: yes
Module Alias: "pci:v000014E4d0000169Csv0000103Csd00003030bc02sc00i00"
Driver Info #0:
Driver Status: tg3 is active
Driver Activation Cmd: "modprobe tg3"
Config Status: cfg=new, avail=yes, need=no, active=unknown
Attached to: #15 (PCI bridge)
13: PCI 200.0: 0200 Ethernet controller
[Created at pci.281]
Unique ID: OVRT.ZugsYBr16xD
Parent ID: _Znp.g78+51qvkd0
SysFS ID: /devices/pci0000:00/0000:00:02.0/0000:02:00.0
SysFS BusID: 0000:02:00.0
Hardware Class: network
Model: "Hewlett-Packard Company BCM4310 USB Controller"
Vendor: pci 0x14e4 "Broadcom"
Device: pci 0x4315 "BCM4310 USB Controller"
SubVendor: pci 0x103c "Hewlett-Packard Company"
SubDevice: pci 0x137d
Revision: 0x01
Driver: "wl"
Driver Modules: "wl"
Device File: eth13
Features: WLAN
Memory Range: 0xfdffc000-0xfdffffff (rw,non-prefetchable)
IRQ: 24 (12862567 events)
HW Address: 00:21:00:29:34:2a
WLAN channels: 1 2 3 4 5 6 7 8 9 10 11
WLAN frequencies: 2.412 2.417 2.422 2.427 2.432 2.437 2.442 2.447 2.452 2.457 2.462
WLAN bitrates: 1 2 5.5 6 9 11 12 18 24 36 48 54
WLAN encryption modes: WEP40 WEP104 WEP256 WEP128 TKIP CCMP
WLAN authentication modes: open sharedkey wpa-psk wpa-eap wpa-leap
Module Alias: "pci:v000014E4d00004315sv0000103Csd0000137Dbc02sc80i00"
Driver Info #0:
Driver Status: wl is active
Driver Activation Cmd: "modprobe wl"
Config Status: cfg=new, avail=yes, need=no, active=unknown
Attached to: #25 (PCI bridge)
14: PCI(AGP) 100.0: 0300 VGA compatible controller (VGA)
[Created at pci.281]
Unique ID: VCu0.lAhfe5B+RC0
Parent ID: vSkL.S16qDHSKEeD
SysFS ID: /devices/pci0000:00/0000:00:01.0/0000:01:00.0
SysFS BusID: 0000:01:00.0
Hardware Class: graphics card
Model: "Hewlett-Packard Company VGA compatible controller"
Vendor: pci 0x1106 "VIA Technologies, Inc."
Device: pci 0x3371
SubVendor: pci 0x103c "Hewlett-Packard Company"
SubDevice: pci 0x3030
Revision: 0x01
Memory Range: 0xc0000000-0xcfffffff (rw,prefetchable)
Memory Range: 0xfc000000-0xfcffffff (rw,non-prefetchable)
Memory Range: 0xfbff0000-0xfbffffff (ro,prefetchable,disabled)
IRQ: 11 (no events)
I/O Ports: 0x3c0-0x3df (rw)
Module Alias: "pci:v00001106d00003371sv0000103Csd00003030bc03sc00i00"
Config Status: cfg=new, avail=yes, need=no, active=unknown
Attached to: #26 (PCI bridge)
15: PCI 13.1: 0604 PCI bridge (Subtractive decode)
[Created at pci.281]
Unique ID: 9n5e.HHSMJjh6gC5
SysFS ID: /devices/pci0000:00/0000:00:13.1
SysFS BusID: 0000:00:13.1
Hardware Class: bridge
Model: "VIA VT8237A PCI to PCI Bridge"
Vendor: pci 0x1106 "VIA Technologies, Inc."
Device: pci 0x337a "VT8237A PCI to PCI Bridge"
Module Alias: "pci:v00001106d0000337Asv00000000sd00000000bc06sc04i01"
Config Status: cfg=new, avail=yes, need=no, active=unknown
16: PCI 13.0: 0600 Host bridge
[Created at pci.281]
Unique ID: HSco.jfGiUiN+dB5
SysFS ID: /devices/pci0000:00/0000:00:13.0
SysFS BusID: 0000:00:13.0
Hardware Class: bridge
Model: "VIA VT8237A PCI to PCIE Bridge"
Vendor: pci 0x1106 "VIA Technologies, Inc."
Device: pci 0x337b "VT8237A PCI to PCIE Bridge"
Module Alias: "pci:v00001106d0000337Bsv00000000sd00000000bc06sc00i00"
Config Status: cfg=new, avail=yes, need=no, active=unknown
17: PCI 11.7: 0600 Host bridge
[Created at pci.281]
Unique ID: BWxi.NhM1uBZ0XP5
SysFS ID: /devices/pci0000:00/0000:00:11.7
SysFS BusID: 0000:00:11.7
Hardware Class: bridge
Model: "VIA VT8251 Ultra VLINK Controller"
Vendor: pci 0x1106 "VIA Technologies, Inc."
Device: pci 0x287e "VT8251 Ultra VLINK Controller"
SubVendor: pci 0x1106 "VIA Technologies, Inc."
SubDevice: pci 0x337e
Module Alias: "pci:v00001106d0000287Esv00001106sd0000337Ebc06sc00i00"
Config Status: cfg=new, avail=yes, need=no, active=unknown
18: PCI 11.0: 0601 ISA bridge
[Created at pci.281]
Unique ID: 7EWs.JRMntr2WuE8
SysFS ID: /devices/pci0000:00/0000:00:11.0
SysFS BusID: 0000:00:11.0
Hardware Class: bridge
Model: "Hewlett-Packard Company ISA bridge"
Vendor: pci 0x1106 "VIA Technologies, Inc."
Device: pci 0x3372
SubVendor: pci 0x103c "Hewlett-Packard Company"
SubDevice: pci 0x3030
Module Alias: "pci:v00001106d00003372sv0000103Csd00003030bc06sc01i00"
Driver Info #0:
Driver Status: i2c_viapro is active
Driver Activation Cmd: "modprobe i2c_viapro"
Config Status: cfg=new, avail=yes, need=no, active=unknown
19: PCI 10.4: 0c03 USB Controller (EHCI)
[Created at pci.281]
Unique ID: WQQk.Bbr16aUOXm1
SysFS ID: /devices/pci0000:00/0000:00:10.4
SysFS BusID: 0000:00:10.4
Hardware Class: usb controller
Model: "Hewlett-Packard Company USB 2.0"
Vendor: pci 0x1106 "VIA Technologies, Inc."
Device: pci 0x3104 "USB 2.0"
SubVendor: pci 0x103c "Hewlett-Packard Company"
SubDevice: pci 0x3030
Revision: 0x90
Driver: "ehci_hcd"
Driver Modules: "ehci_hcd"
Memory Range: 0xfbeffc00-0xfbeffcff (rw,non-prefetchable)
IRQ: 21 (99 events)
Module Alias: "pci:v00001106d00003104sv0000103Csd00003030bc0Csc03i20"
Driver Info #0:
Driver Status: ehci-hcd is active
Driver Activation Cmd: "modprobe ehci-hcd"
Config Status: cfg=new, avail=yes, need=no, active=unknown
20: PCI 10.3: 0c03 USB Controller (UHCI)
[Created at pci.281]
Unique ID: f5xu.M+iEzzTSsLF
SysFS ID: /devices/pci0000:00/0000:00:10.3
SysFS BusID: 0000:00:10.3
Hardware Class: usb controller
Model: "Hewlett-Packard Company VT82xxxxx UHCI USB 1.1 Controller"
Vendor: pci 0x1106 "VIA Technologies, Inc."
Device: pci 0x3038 "VT82xxxxx UHCI USB 1.1 Controller"
SubVendor: pci 0x103c "Hewlett-Packard Company"
SubDevice: pci 0x3030
Revision: 0xb0
Driver: "uhci_hcd"
Driver Modules: "uhci_hcd"
I/O Ports: 0xcc00-0xcc1f (rw)
IRQ: 23 (no events)
Module Alias: "pci:v00001106d00003038sv0000103Csd00003030bc0Csc03i00"
Driver Info #0:
Driver Status: uhci-hcd is active
Driver Activation Cmd: "modprobe uhci-hcd"
Config Status: cfg=new, avail=yes, need=no, active=unknown
21: PCI 10.2: 0c03 USB Controller (UHCI)
[Created at pci.281]
Unique ID: nmR3.M+iEzzTSsLF
SysFS ID: /devices/pci0000:00/0000:00:10.2
SysFS BusID: 0000:00:10.2
Hardware Class: usb controller
Model: "Hewlett-Packard Company VT82xxxxx UHCI USB 1.1 Controller"
Vendor: pci 0x1106 "VIA Technologies, Inc."
Device: pci 0x3038 "VT82xxxxx UHCI USB 1.1 Controller"
SubVendor: pci 0x103c "Hewlett-Packard Company"
SubDevice: pci 0x3030
Revision: 0xb0
Driver: "uhci_hcd"
Driver Modules: "uhci_hcd"
I/O Ports: 0xc880-0xc89f (rw)
IRQ: 21 (99 events)
Module Alias: "pci:v00001106d00003038sv0000103Csd00003030bc0Csc03i00"
Driver Info #0:
Driver Status: uhci-hcd is active
Driver Activation Cmd: "modprobe uhci-hcd"
Config Status: cfg=new, avail=yes, need=no, active=unknown
22: PCI 10.0: 0c03 USB Controller (UHCI)
[Created at pci.281]
Unique ID: 37TO.M+iEzzTSsLF
SysFS ID: /devices/pci0000:00/0000:00:10.0
SysFS BusID: 0000:00:10.0
Hardware Class: usb controller
Model: "Hewlett-Packard Company VT82xxxxx UHCI USB 1.1 Controller"
Vendor: pci 0x1106 "VIA Technologies, Inc."
Device: pci 0x3038 "VT82xxxxx UHCI USB 1.1 Controller"
SubVendor: pci 0x103c "Hewlett-Packard Company"
SubDevice: pci 0x3030
Revision: 0xb0
Driver: "uhci_hcd"
Driver Modules: "uhci_hcd"
I/O Ports: 0xc800-0xc81f (rw)
IRQ: 20 (142495 events)
Module Alias: "pci:v00001106d00003038sv0000103Csd00003030bc0Csc03i00"
Driver Info #0:
Driver Status: uhci-hcd is active
Driver Activation Cmd: "modprobe uhci-hcd"
Config Status: cfg=new, avail=yes, need=no, active=unknown
23: PCI 0f.0: 0101 IDE interface
[Created at pci.281]
Unique ID: _+Pw.uEnt96FgSd9
SysFS ID: /devices/pci0000:00/0000:00:0f.0
SysFS BusID: 0000:00:0f.0
Hardware Class: storage
Model: "Hewlett-Packard Company IDE interface"
Vendor: pci 0x1106 "VIA Technologies, Inc."
Device: pci 0x5372
SubVendor: pci 0x103c "Hewlett-Packard Company"
SubDevice: pci 0x3030
I/O Ports: 0x1f0-0x1f7 (rw)
I/O Port: 0x3f6 (rw)
I/O Ports: 0x170-0x177 (rw)
I/O Port: 0x376 (rw)
I/O Ports: 0xfc00-0xfc0f (rw)
I/O Ports: 0xf800-0xf8ff (rw)
Module Alias: "pci:v00001106d00005372sv0000103Csd00003030bc01sc01i8a"
Driver Info #0:
Driver Status: sata_via is active
Driver Activation Cmd: "modprobe sata_via"
Driver Info #1:
Driver Status: ata_generic is active
Driver Activation Cmd: "modprobe ata_generic"
Driver Info #2:
Driver Status: pata_acpi is active
Driver Activation Cmd: "modprobe pata_acpi"
Config Status: cfg=new, avail=yes, need=no, active=unknown
24: PCI 03.0: 0604 PCI bridge (Normal decode)
[Created at pci.281]
Unique ID: 3hqH.ASKGEfPHzS4
SysFS ID: /devices/pci0000:00/0000:00:03.0
SysFS BusID: 0000:00:03.0
Hardware Class: bridge
Model: "VIA PCI bridge"
Vendor: pci 0x1106 "VIA Technologies, Inc."
Device: pci 0xc364
Revision: 0x80
Driver: "pcieport-driver"
IRQ: 31 (no events)
Module Alias: "pci:v00001106d0000C364sv00000000sd00000000bc06sc04i00"
Config Status: cfg=new, avail=yes, need=no, active=unknown
25: PCI 02.0: 0604 PCI bridge (Normal decode)
[Created at pci.281]
Unique ID: _Znp.g78+51qvkd0
SysFS ID: /devices/pci0000:00/0000:00:02.0
SysFS BusID: 0000:00:02.0
Hardware Class: bridge
Model: "VIA PCI bridge"
Vendor: pci 0x1106 "VIA Technologies, Inc."
Device: pci 0xa364
Revision: 0x80
Driver: "pcieport-driver"
IRQ: 27 (no events)
Module Alias: "pci:v00001106d0000A364sv00000000sd00000000bc06sc04i00"
Config Status: cfg=new, avail=yes, need=no, active=unknown
26: PCI 01.0: 0604 PCI bridge (Normal decode)
[Created at pci.281]
Unique ID: vSkL.S16qDHSKEeD
SysFS ID: /devices/pci0000:00/0000:00:01.0
SysFS BusID: 0000:00:01.0
Hardware Class: bridge
Model: "VIA VT8237 PCI Bridge"
Vendor: pci 0x1106 "VIA Technologies, Inc."
Device: pci 0xb198 "VT8237 PCI Bridge"
Module Alias: "pci:v00001106d0000B198sv00000000sd00000000bc06sc04i00"
Config Status: cfg=new, avail=yes, need=no, active=unknown
27: PCI 00.7: 0600 Host bridge
[Created at pci.281]
Unique ID: ud6k.smx+hvUIzS5
SysFS ID: /devices/pci0000:00/0000:00:00.7
SysFS BusID: 0000:00:00.7
Hardware Class: bridge
Model: "VIA Host bridge"
Vendor: pci 0x1106 "VIA Technologies, Inc."
Device: pci 0x7364
Module Alias: "pci:v00001106d00007364sv00000000sd00000000bc06sc00i00"
Config Status: cfg=new, avail=yes, need=no, active=unknown
28: PCI 00.6: 0600 Host bridge
[Created at pci.281]
Unique ID: 0Jdu.KvU_alV38+A
SysFS ID: /devices/pci0000:00/0000:00:00.6
SysFS BusID: 0000:00:00.6
Hardware Class: bridge
Model: "Hewlett-Packard Company Host bridge"
Vendor: pci 0x1106 "VIA Technologies, Inc."
Device: pci 0x6364
SubVendor: pci 0x103c "Hewlett-Packard Company"
SubDevice: pci 0x3030
Module Alias: "pci:v00001106d00006364sv0000103Csd00003030bc06sc00i00"
Config Status: cfg=new, avail=yes, need=no, active=unknown
29: PCI 00.5: 0800 PIC (IO(X)-APIC)
[Created at pci.281]
Unique ID: 9_73.cjbsqqlCSpC
SysFS ID: /devices/pci0000:00/0000:00:00.5
SysFS BusID: 0000:00:00.5
Hardware Class: unknown
Model: "Hewlett-Packard Company PIC"
Vendor: pci 0x1106 "VIA Technologies, Inc."
Device: pci 0x5364
SubVendor: pci 0x103c "Hewlett-Packard Company"
SubDevice: pci 0x3030
Module Alias: "pci:v00001106d00005364sv0000103Csd00003030bc08sc00i20"
Config Status: cfg=new, avail=yes, need=no, active=unknown
30: PCI 00.4: 0600 Host bridge
[Created at pci.281]
Unique ID: HfeD.qaIjS7whv97
SysFS ID: /devices/pci0000:00/0000:00:00.4
SysFS BusID: 0000:00:00.4
Hardware Class: bridge
Model: "Hewlett-Packard Company Host bridge"
Vendor: pci 0x1106 "VIA Technologies, Inc."
Device: pci 0x4364
SubVendor: pci 0x103c "Hewlett-Packard Company"
SubDevice: pci 0x3030
Module Alias: "pci:v00001106d00004364sv0000103Csd00003030bc06sc00i00"
Config Status: cfg=new, avail=yes, need=no, active=unknown
31: PCI 00.3: 0600 Host bridge
[Created at pci.281]
Unique ID: QK9O.s7ZTRfJZWoD
SysFS ID: /devices/pci0000:00/0000:00:00.3
SysFS BusID: 0000:00:00.3
Hardware Class: bridge
Model: "VIA Host bridge"
Vendor: pci 0x1106 "VIA Technologies, Inc."
Device: pci 0x3364
Module Alias: "pci:v00001106d00003364sv00000000sd00000000bc06sc00i00"
Config Status: cfg=new, avail=yes, need=no, active=unknown
32: PCI 00.2: 0600 Host bridge
[Created at pci.281]
Unique ID: Z+fY.KG6SKVKKhK3
SysFS ID: /devices/pci0000:00/0000:00:00.2
SysFS BusID: 0000:00:00.2
Hardware Class: bridge
Model: "Hewlett-Packard Company Host bridge"
Vendor: pci 0x1106 "VIA Technologies, Inc."
Device: pci 0x2364
SubVendor: pci 0x103c "Hewlett-Packard Company"
SubDevice: pci 0x3030
Module Alias: "pci:v00001106d00002364sv0000103Csd00003030bc06sc00i00"
Config Status: cfg=new, avail=yes, need=no, active=unknown
33: PCI 00.1: 0600 Host bridge
[Created at pci.281]
Unique ID: hgAj.46WJGzIDbw7
SysFS ID: /devices/pci0000:00/0000:00:00.1
SysFS BusID: 0000:00:00.1
Hardware Class: bridge
Model: "Hewlett-Packard Company Host bridge"
Vendor: pci 0x1106 "VIA Technologies, Inc."
Device: pci 0x1364
SubVendor: pci 0x103c "Hewlett-Packard Company"
SubDevice: pci 0x3030
Module Alias: "pci:v00001106d00001364sv0000103Csd00003030bc06sc00i00"
Config Status: cfg=new, avail=yes, need=no, active=unknown
34: PCI(AGP) 00.0: 0600 Host bridge
[Created at pci.281]
Unique ID: qLht.qxvACtkySVF
SysFS ID: /devices/pci0000:00/0000:00:00.0
SysFS BusID: 0000:00:00.0
Hardware Class: bridge
Model: "Hewlett-Packard Company Host bridge"
Vendor: pci 0x1106 "VIA Technologies, Inc."
Device: pci 0x0364
SubVendor: pci 0x103c "Hewlett-Packard Company"
SubDevice: pci 0x3030
Driver: "agpgart-via"
Driver Modules: "via_agp"
Memory Range: 0xf0000000-0xf7ffffff (rw,prefetchable)
Module Alias: "pci:v00001106d00000364sv0000103Csd00003030bc06sc00i00"
Driver Info #0:
Driver Status: via_agp is active
Driver Activation Cmd: "modprobe via_agp"
Config Status: cfg=new, avail=yes, need=no, active=unknown
35: ISA(PnP) 00.0: 0000 Unclassified device
[Created at isapnp.142]
Unique ID: 30p6.+GmdJItMGB9
SysFS ID: /devices/pnp0/00:0d
SysFS BusID: 00:0d
Hardware Class: unknown
Model: "PnP Unclassified device"
SubVendor: PNP "PnP"
SubDevice: eisa 0x0a08
Config Status: cfg=new, avail=yes, need=no, active=unknown
36: ISA(PnP) 00.0: 0000 Unclassified device
[Created at isapnp.142]
Unique ID: cqY2.gNN83gfynbD
SysFS ID: /devices/pnp0/00:0c
SysFS BusID: 00:0c
Hardware Class: unknown
Model: "PnP Unclassified device"
SubVendor: PNP "PnP"
SubDevice: eisa 0x0c01
Config Status: cfg=new, avail=yes, need=no, active=unknown
37: ISA(PnP) 00.0: 0000 Unclassified device
[Created at isapnp.142]
Unique ID: 9fI_.B95vU_X3dpD
SysFS ID: /devices/pnp0/00:0b
SysFS BusID: 00:0b
Hardware Class: unknown
Model: "Unclassified device"
SubVendor: HPQ
SubDevice: eisa 0x0004
Config Status: cfg=new, avail=yes, need=no, active=unknown
38: ISA(PnP) 00.0: 0000 Unclassified device
[Created at isapnp.142]
Unique ID: iT2w.B+yZ9Ve8gC1
SysFS ID: /devices/pnp0/00:0a
SysFS BusID: 00:0a
Hardware Class: unknown
Model: "PnP Unclassified device"
SubVendor: PNP "PnP"
SubDevice: eisa 0x0c02
Config Status: cfg=new, avail=yes, need=no, active=unknown
39: ISA(PnP) 00.0: 0000 Unclassified device
[Created at isapnp.142]
Unique ID: H20r.+t_YHFi_6u4
SysFS ID: /devices/pnp0/00:09
SysFS BusID: 00:09
Hardware Class: unknown
Model: "Unclassified device"
SubVendor: SYN
SubDevice: eisa 0x013d
Config Status: cfg=new, avail=yes, need=no, active=unknown
40: ISA(PnP) 00.0: 0000 Unclassified device
[Created at isapnp.142]
Unique ID: qslm.B+yZ9Ve8gC1
SysFS ID: /devices/pnp0/00:08
SysFS BusID: 00:08
Hardware Class: unknown
Model: "PnP Unclassified device"
SubVendor: PNP "PnP"
SubDevice: eisa 0x0c02
Config Status: cfg=new, avail=yes, need=no, active=unknown
41: ISA(PnP) 00.0: 0000 Unclassified device
[Created at isapnp.142]
Unique ID: NhVi.WYwRElrJa93
SysFS ID: /devices/pnp0/00:07
SysFS BusID: 00:07
Hardware Class: unknown
Model: "PnP Unclassified device"
SubVendor: PNP "PnP"
SubDevice: eisa 0x0b00
Config Status: cfg=new, avail=yes, need=no, active=unknown
42: ISA(PnP) 00.0: 0000 Unclassified device
[Created at isapnp.142]
Unique ID: hEKD.fG36JLVNse9
SysFS ID: /devices/pnp0/00:06
SysFS BusID: 00:06
Hardware Class: unknown
Model: "PnP Unclassified device"
SubVendor: PNP "PnP"
SubDevice: eisa 0x0103
Config Status: cfg=new, avail=yes, need=no, active=unknown
43: ISA(PnP) 00.0: 0000 Unclassified device
[Created at isapnp.142]
Unique ID: E349.B+yZ9Ve8gC1
SysFS ID: /devices/pnp0/00:05
SysFS BusID: 00:05
Hardware Class: unknown
Model: "PnP Unclassified device"
SubVendor: PNP "PnP"
SubDevice: eisa 0x0c02
Config Status: cfg=new, avail=yes, need=no, active=unknown
44: ISA(PnP) 00.0: 0000 Unclassified device
[Created at isapnp.142]
Unique ID: ntp4.DE8RM9cWQQ8
SysFS ID: /devices/pnp0/00:04
SysFS BusID: 00:04
Hardware Class: unknown
Model: "PnP Unclassified device"
SubVendor: PNP "PnP"
SubDevice: eisa 0x0c04
Config Status: cfg=new, avail=yes, need=no, active=unknown
45: ISA(PnP) 00.0: 0000 Unclassified device
[Created at isapnp.142]
Unique ID: KiZ0.bvKf3UMzZfE
SysFS ID: /devices/pnp0/00:03
SysFS BusID: 00:03
Hardware Class: unknown
Model: "PnP Unclassified device"
SubVendor: PNP "PnP"
SubDevice: eisa 0x0800
Config Status: cfg=new, avail=yes, need=no, active=unknown
46: ISA(PnP) 00.0: 0000 Unclassified device
[Created at isapnp.142]
Unique ID: tWJy.xhndlW9HXJ7
SysFS ID: /devices/pnp0/00:02
SysFS BusID: 00:02
Hardware Class: unknown
Model: "PnP Unclassified device"
SubVendor: PNP "PnP"
SubDevice: eisa 0x0303
Config Status: cfg=new, avail=yes, need=no, active=unknown
47: ISA(PnP) 00.0: 0000 Unclassified device
[Created at isapnp.142]
Unique ID: QL3u.ld94kxNGZf5
SysFS ID: /devices/pnp0/00:01
SysFS BusID: 00:01
Hardware Class: unknown
Model: "PnP Unclassified device"
SubVendor: PNP "PnP"
SubDevice: eisa 0x0200
Config Status: cfg=new, avail=yes, need=no, active=unknown
48: ISA(PnP) 00.0: 0000 Unclassified device
[Created at isapnp.142]
Unique ID: z9pp.QBqTp8zQt87
SysFS ID: /devices/pnp0/00:00
SysFS BusID: 00:00
Hardware Class: unknown
Model: "PnP Unclassified device"
SubVendor: PNP "PnP"
SubDevice: eisa 0x0a03
Config Status: cfg=new, avail=yes, need=no, active=unknown
49: None 00.0: 0700 Serial controller (16550)
[Created at serial.74]
Unique ID: S_Uw.3fyvFV+mbWD
Hardware Class: unknown
Model: "16550A"
Device: "16550A"
Device File: /dev/ttyS0
I/O Ports: 0x3f8-0x3ff (rw)
IRQ: 4 (no events)
Config Status: cfg=new, avail=yes, need=no, active=unknown
50: None 00.0: 0101 IDE interface
[Created at misc.347]
Unique ID: rdCR.g9fwCXkwNOD
Hardware Class: storage
Model: "IDE interface"
Compatible to: int 0x3000 0x1000
IRQ: 14 (314374 events)
IRQ: 15 (no events)
Driver Info #0:
Driver Status: ide-generic is not active
Driver Activation Cmd: "modprobe ide-generic"
Config Status: cfg=new, avail=yes, need=no, active=unknown
51: IDE 00.0: 10600 Disk
[Created at block.218]
Unique ID: Fffu.MiLwIsFrYDD
SysFS ID: /block/hda
SysFS BusID: 0.0
SysFS Device Link: /devices/ide0/0.0
Hardware Class: disk
Model: "ST9120817AS"
Device: "ST9120817AS"
Revision: "3.AHC"
Serial ID: "5RE0G6EJ"
Driver: "ide-disk"
Device File: /dev/hda
Device Files: /dev/hda, /dev/disk/by-id/ata-ST9120817AS_5RE0G6EJ, /dev/disk/by-path/ide-0:0
Device Number: block 3:0-3:63
BIOS id: 0x80
Size: 234441648 sectors a 512 bytes
Geometry (Physical): CHS 232581/16/63
Geometry (Logical): CHS 14593/255/63
Cache: 8192 kb
Config Status: cfg=new, avail=yes, need=no, active=unknown
52: None 00.0: 11300 Partition
[Created at block.387]
Unique ID: 0fbI.SE1wIdpsiiC
Parent ID: Fffu.MiLwIsFrYDD
SysFS ID: /block/hda/hda1
Hardware Class: partition
Model: "Partition"
Device File: /dev/hda1
Device Files: /dev/hda1, /dev/disk/by-id/ata-ST9120817AS_5RE0G6EJ-part1, /dev/disk/by-path/ide-0:0-part1, /dev/disk/by-uuid/4EF3-1BE3
Config Status: cfg=new, avail=yes, need=no, active=unknown
Attached to: #51 (Disk)
53: None 00.0: 11300 Partition
[Created at block.387]
Unique ID: TqrM.SE1wIdpsiiC
Parent ID: Fffu.MiLwIsFrYDD
SysFS ID: /block/hda/hda2
Hardware Class: partition
Model: "Partition"
Device File: /dev/hda2
Device Files: /dev/hda2, /dev/disk/by-id/ata-ST9120817AS_5RE0G6EJ-part2, /dev/disk/by-path/ide-0:0-part2
Config Status: cfg=new, avail=yes, need=no, active=unknown
Attached to: #51 (Disk)
54: None 00.0: 11300 Partition
[Created at block.387]
Unique ID: x+5R.SE1wIdpsiiC
Parent ID: Fffu.MiLwIsFrYDD
SysFS ID: /block/hda/hda3
Hardware Class: partition
Model: "Partition"
Device File: /dev/hda3
Device Files: /dev/hda3, /dev/disk/by-id/ata-ST9120817AS_5RE0G6EJ-part3, /dev/disk/by-path/ide-0:0-part3, /dev/disk/by-uuid/155f5a5e-88d9-4155-8d67-00f0d46ee195
Config Status: cfg=new, avail=yes, need=no, active=unknown
Attached to: #51 (Disk)
55: None 00.0: 11300 Partition
[Created at block.387]
Unique ID: OBMV.SE1wIdpsiiC
Parent ID: Fffu.MiLwIsFrYDD
SysFS ID: /block/hda/hda4
Hardware Class: partition
Model: "Partition"
Device File: /dev/hda4
Device Files: /dev/hda4, /dev/disk/by-id/ata-ST9120817AS_5RE0G6EJ-part4, /dev/disk/by-path/ide-0:0-part4, /dev/disk/by-uuid/3caa1768-37be-4b8a-b45f-451fac500741
Config Status: cfg=new, avail=yes, need=no, active=unknown
Attached to: #51 (Disk)
56: USB 00.0: 10503 USB Mouse
[Created at usb.122]
Unique ID: FKGF.m7C82g3gZbB
Parent ID: pBe4.5nw7MPEyvh9
SysFS ID: /devices/pci0000:00/0000:00:10.0/usb2/2-1/2-1:1.0
SysFS BusID: 2-1:1.0
Hardware Class: mouse
Model: "USB OPTICAL MOUSE"
Hotplug: USB
Vendor: usb 0x15d9
Device: usb 0x0a4c "USB OPTICAL MOUSE"
Revision: "1.00"
Compatible to: int 0x0210 0x0013
Driver: "usbhid"
Driver Modules: "usbhid"
Device File: /dev/input/mice (/dev/input/mouse1)
Device Files: /dev/input/mice, /dev/input/mouse1, /dev/input/event9, /dev/input/by-id/usb-15d9_USB_OPTICAL_MOUSE-event-mouse, /dev/input/by-path/pci-0000:00:10.0-usb-0:1:1.0-event-mouse, /dev/input/by-id/usb-15d9_USB_OPTICAL_MOUSE-mouse, /dev/input/by-path/pci-0000:00:10.0-usb-0:1:1.0-mouse
Device Number: char 13:63 (char 13:33)
Speed: 1.5 Mbps
Module Alias: "usb:v15D9p0A4Cd0100dc00dsc00dp00ic03isc01ip02"
Driver Info #0:
Buttons: 3
Wheels: 1
XFree86 Protocol: explorerps/2
GPM Protocol: exps2
Config Status: cfg=new, avail=yes, need=no, active=unknown
Attached to: #61 (Hub)
57: USB 00.0: 10a00 Hub
[Created at usb.122]
Unique ID: zPk0.Oz8tSgc5mXF
Parent ID: f5xu.M+iEzzTSsLF
SysFS ID: /devices/pci0000:00/0000:00:10.3/usb4/4-0:1.0
SysFS BusID: 4-0:1.0
Hardware Class: hub
Model: "Linux 2.6.27.59 uhci_hcd UHCI Host Controller"
Hotplug: USB
Vendor: usb 0x1d6b "Linux 2.6.27.59 uhci_hcd"
Device: usb 0x0001 "UHCI Host Controller"
Revision: "2.06"
Serial ID: "0000:00:10.3"
Driver: "hub"
Driver Modules: "usbcore"
Speed: 12 Mbps
Module Alias: "usb:v1D6Bp0001d0206dc09dsc00dp00ic09isc00ip00"
Config Status: cfg=new, avail=yes, need=no, active=unknown
Attached to: #20 (USB Controller)
58: USB 00.0: 10a00 Hub
[Created at usb.122]
Unique ID: uIhY.dE4I5wpNpF8
Parent ID: nmR3.M+iEzzTSsLF
SysFS ID: /devices/pci0000:00/0000:00:10.2/usb3/3-0:1.0
SysFS BusID: 3-0:1.0
Hardware Class: hub
Model: "Linux 2.6.27.59 uhci_hcd UHCI Host Controller"
Hotplug: USB
Vendor: usb 0x1d6b "Linux 2.6.27.59 uhci_hcd"
Device: usb 0x0001 "UHCI Host Controller"
Revision: "2.06"
Serial ID: "0000:00:10.2"
Driver: "hub"
Driver Modules: "usbcore"
Speed: 12 Mbps
Module Alias: "usb:v1D6Bp0001d0206dc09dsc00dp00ic09isc00ip00"
Config Status: cfg=new, avail=yes, need=no, active=unknown
Attached to: #21 (USB Controller)
59: USB 00.1: 0000 Unclassified device
[Created at usb.122]
Unique ID: QR8P.6SrbWBBevvA
Parent ID: k4bc.22MfGOBVe10
SysFS ID: /devices/pci0000:00/0000:00:10.4/usb1/1-8/1-8:1.1
SysFS BusID: 1-8:1.1
Hardware Class: unknown
Model: "Chicony Electronics CNF7070"
Hotplug: USB
Vendor: usb 0x04f2 "Chicony Electronics Co., Ltd."
Device: usb 0xb107 "CNF7070"
Revision: "8.52"
Serial ID: "SN0001"
Driver: "uvcvideo"
Driver Modules: "uvcvideo"
Speed: 480 Mbps
Module Alias: "usb:v04F2pB107d0852dcEFdsc02dp01ic0Eisc02ip00"
Config Status: cfg=new, avail=yes, need=no, active=unknown
Attached to: #62 (Hub)
61: USB 00.0: 10a00 Hub
[Created at usb.122]
Unique ID: pBe4.5nw7MPEyvh9
Parent ID: 37TO.M+iEzzTSsLF
SysFS ID: /devices/pci0000:00/0000:00:10.0/usb2/2-0:1.0
SysFS BusID: 2-0:1.0
Hardware Class: hub
Model: "Linux 2.6.27.59 uhci_hcd UHCI Host Controller"
Hotplug: USB
Vendor: usb 0x1d6b "Linux 2.6.27.59 uhci_hcd"
Device: usb 0x0001 "UHCI Host Controller"
Revision: "2.06"
Serial ID: "0000:00:10.0"
Driver: "hub"
Driver Modules: "usbcore"
Speed: 12 Mbps
Module Alias: "usb:v1D6Bp0001d0206dc09dsc00dp00ic09isc00ip00"
Config Status: cfg=new, avail=yes, need=no, active=unknown
Attached to: #22 (USB Controller)
62: USB 00.0: 10a00 Hub
[Created at usb.122]
Unique ID: k4bc.22MfGOBVe10
Parent ID: WQQk.Bbr16aUOXm1
SysFS ID: /devices/pci0000:00/0000:00:10.4/usb1/1-0:1.0
SysFS BusID: 1-0:1.0
Hardware Class: hub
Model: "Linux 2.6.27.59 ehci_hcd EHCI Host Controller"
Hotplug: USB
Vendor: usb 0x1d6b "Linux 2.6.27.59 ehci_hcd"
Device: usb 0x0002 "EHCI Host Controller"
Revision: "2.06"
Serial ID: "0000:00:10.4"
Driver: "hub"
Driver Modules: "usbcore"
Speed: 480 Mbps
Module Alias: "usb:v1D6Bp0002d0206dc09dsc00dp00ic09isc00ip00"
Config Status: cfg=new, avail=yes, need=no, active=unknown
Attached to: #19 (USB Controller)
63: PS/2 00.0: 10500 PS/2 Mouse
[Created at input.159]
Unique ID: AH6Q.845qvaQafo3
Hardware Class: mouse
Model: "SynPS/2 Synaptics TouchPad"
Vendor: int 0x0212
Device: int 0x0001 "SynPS/2 Synaptics TouchPad"
Compatible to: int 0x0210 0x0003
Device File: /dev/input/mice (/dev/input/mouse0)
Device Files: /dev/input/mice, /dev/input/mouse0, /dev/input/event0, /dev/input/by-path/platform-i8042-serio-4-event-mouse, /dev/input/by-path/platform-i8042-serio-4-mouse
Device Number: char 13:63 (char 13:32)
Driver Info #0:
Buttons: 3
Wheels: 0
XFree86 Protocol: explorerps/2
GPM Protocol: exps2
Config Status: cfg=new, avail=yes, need=no, active=unknown
64: PS/2 00.0: 10800 Keyboard
[Created at input.139]
Unique ID: EXC1.TBWTwSuMeW2
Hardware Class: keyboard
Model: "AT Translated Set 2 keyboard"
Vendor: int 0x0211
Device: int 0x0001 "AT Translated Set 2 keyboard"
Device File: /dev/input/event1
Device Files: /dev/input/event1, /dev/input/by-path/platform-i8042-serio-0-event-kbd
Device Number: char 13:65
Driver Info #0:
XkbRules: xfree86
XkbModel: pc104
Config Status: cfg=new, avail=yes, need=no, active=unknown
65: None 00.0: 10103 CPU
[Created at cpu.305]
Unique ID: rdCR.j8NaKXDZtZ6
Hardware Class: cpu
Arch: Intel
Vendor: "CentaurHauls"
Model: 6.13.0 "VIA C7-M Processor 1600MHz"
Features: fpu,vme,de,pse,tsc,msr,pae,mce,cx8,apic,sep,mtrr,pge,cmov,pat,clflush,acpi,mmx,fxsr,sse,sse2,tm,nx,pni,est,tm2,xtpr,rng,rng_en,ace,ace_en,ace2,ace2_en,phe,phe_en,pmm,pmm_en
Clock: 1595 MHz
BogoMips: 3191.94
Cache: 128 kb
Config Status: cfg=new, avail=yes, need=no, active=unknown
66: None 00.0: 10000 Monitor
[Created at fb.71]
Unique ID: rdCR.EY_qmtb9YY0
Hardware Class: monitor
Model: "Generic Monitor"
Vendor: "Generic"
Device: "Monitor"
Resolution: 1280x768@76Hz
Driver Info #0:
Max. Resolution: 1280x768
Vert. Sync Range: 50-90 Hz
Hor. Sync Range: 31-62 kHz
Config Status: cfg=new, avail=yes, need=no, active=unknown
67: None 0c.0: 10701 Ethernet
[Created at net.119]
Unique ID: 9iZU.ndpeucax6V1
Parent ID: xJBP.FnR_gbvdRi0
SysFS ID: /class/net/eth12
SysFS Device Link: /devices/pci0000:00/0000:00:13.1/0000:07:03.0
Hardware Class: network interface
Model: "Ethernet network interface"
Driver: "tg3"
Driver Modules: "tg3"
Device File: eth12
HW Address: 00:24:81:59:74:99
Link detected: yes
Config Status: cfg=new, avail=yes, need=no, active=unknown
Attached to: #12 (Ethernet controller)
68: None 0d.0: 10701 Ethernet
[Created at net.119]
Unique ID: ctpY.ndpeucax6V1
Parent ID: OVRT.ZugsYBr16xD
SysFS ID: /class/net/eth13
SysFS Device Link: /devices/pci0000:00/0000:00:02.0/0000:02:00.0
Hardware Class: network interface
Model: "Ethernet network interface"
Driver: "wl"
Driver Modules: "wl"
Device File: eth13
HW Address: 00:21:00:29:34:2a
Config Status: cfg=new, avail=yes, need=no, active=unknown
Attached to: #13 (Ethernet controller)
69: None 00.0: 10700 Loopback
[Created at net.119]
Unique ID: ZsBS.GQNx7L4uPNA
SysFS ID: /class/net/lo
Hardware Class: network interface
Model: "Loopback network interface"
Device File: lo
Link detected: yes
Config Status: cfg=new, avail=yes, need=no, active=unknown
[1] Boot up problem: "Cannot open root device 306 or hda6" | KernelTrap
http://kerneltrap.org/node/970
[2] Cannot open root device ""error | KernelTrap
http://kerneltrap.org/node/4746
[3] Broadcom Linux hybrid wireless driver Version 5.100.82.1XX
http://www.broadcom.com/docs/linux_sta/hybrid-portsrc_x86_32-v5_100_82_112.tar.gz
[4] HP 2133 Mini-Note PC and HP 2140 Mini-Note PC Maintenance and Service Guide
http://bizsupport1.austin.hp.com/bc/docs/support/SupportManual/c01658655/c01658655.pdf
[5] Debian HCL - HP / Mini (HP2133)
http://kmuto.jp/debian/hcl/HP/Mini+(HP2133)
